Edwards Genesis WG4 Assembly instructions

© 2011 UTC Fire & Security. All rights reserved. 1 / 4 P/N 3101852 • REV 2.0 • ISS 21MAR11
Genesis WG4 Speaker Installation Sheet
Description
The Genesis WG4 Speaker is a fire alarm and mass
notification and emergency communication (MNEC) appliance
designed for indoor or outdoor wet location use on ceilings or
walls. See Table 1 for a list of models and Table 2 for a list of
accessories.
Table 1: Models
Number Description
WG4WA-S Outdoor-rated wall/ceiling speaker (25/70 V), multi-
tap, white with ALERT marking
WG4WN-S Outdoor-rated wall/ceiling speaker (25/70 V), multi-
tap, white
WG4RN-S Outdoor-rated wall/ceiling speaker (25/70 V), multi-
tap, red
WG4WF-S Outdoor-rated wall/ceiling speaker (25/70 V), multi-
tap, white with FIRE marking
WG4RF-S Outdoor-rated wall/ceiling speaker (25/70 V), multi-
tap, red with FIRE marking
Table 2: Accessories
Number Description
WG4WTS [1] Outdoor-rated surface skirt, white - for Genesis WG4
speaker or speaker/strobe
WG4RTS [1] Outdoor-rated surface skirt, red - for Genesis WG4
speaker or speaker/strobe
WGRGSKT Appliance replacement gasket
[1] The trim skirt is outdoor-rated when used with the 449 weatherproof
box.
Installation
Install this device in accordance with the latest edition of NFPA
72 and the local authority having jurisdiction.
WARNING: Electrocution hazard. To avoid personal injury or
death from electrocution, remove all sources of power and
allow stored energy to discharge before installing or removing
equipment
Caution: Electrical supervision requires the wire run to be
broken at each terminal. Do not loop the signaling circuit field
wires around the terminals.
Note: The Genesis WG4 Speaker may be ceiling-mounted or
wall-mounted and may be placed in one of four positions. See
Figure 4. Place the electrical box accordingly.
To install the speaker:
1. Remove the cover from the speaker by first removing the
six cover screws. See Figure 1.
2. If desired, place the optional trim skirt over the electrical
box. See “Specifications” for a list of compatible boxes.
3. Remove the gasket that comes with the 449 weatherproof
box and replace it with the gasket that comes with the
WG4 speaker.
4. Place the gasket over the backplate, and then feed the
field wiring through the wire slots on the gasket and the
backplate. See Figure 2, item 2.
5. Secure the backplate to the electrical box with four
screws.
6. Connect the wiring to the terminal strip.
7. Connect the speaker to the audio NAC. Observe polarity.
See Figure 2.
8. Set the speaker voltage.
The default speaker voltage is 70 V. For 25 V, reposition
the speaker voltage selection switch S3. See Figure 2,
item 3.
9. Set the wattage.
The wattage default setting is Z corresponding to 1/4 watt.
To select a different wattage, align the S1 indicator to the
desired wattage setting. See Table 3 and Figure 2, item 1.
10. Position the cover over the backplate, and then secure it
with the six cover screws.
11. Test the unit for proper operation.
firealarmresources.com

2 / 4 P/N 3101852 • REV 2.0 • ISS 21MAR11
Figure 1: Exploded view of assembly
2
3
5
6
4
1
1. Cover screws (6X)
2. Front cover
3. Backplate
4. Optional skirt
5. Gasket
6. Electrical box
Figure 3: Assembled
1
2
3
4
1. Optional skirt
2. Backplate
3. Front cover
4. Cover screws (6X)
Figure 2: Wiring and switch locations
2
1
3
DETAILA
SPKR + SPKR +
S
PKR -
S
PKR -
1. S1 wattage-setting switch (see Table 3.)
2. Wire slot
Note: Polarity shown in alarm condition.
3. S3 speaker voltage-setting switch. UP position is 70 V (default);
DOWN position is 25 V.
firealarmresources.com

P/N 3101852 • REV 2.0 • ISS 21MAR11 3 / 4
Figure 4: Mounting positions
AZ
DO NOT PAINT
A
Z
DO NOT P
A
INT
AZ
DO NOT PAINT
AZ
DO NOT PAINT
Maintenance
This unit is not serviceable or repairable. Should the unit fail to
operate, contact the supplier for replacement.
Perform a visual inspection and an operational test twice a
year or as directed by the local authority having jurisdiction.
Caution: Do not change the factory-applied finish.
Specifications
Operating voltage
Speaker
Default
25 VRMS or 70 VRMS, switch selectable
70 VRMS
Supervisory voltage 30 V max.
Sound level output See Table 3
Speaker response 400 to 4,000 Hz
Wire size 12 to 18 AWG (0.75 to 2.50 mm²)
Compatible electrical
box
Wet
Dry
Model 449
4 in. square by 1-1/2 in. deep box
Operating environment
Temperature
Relative humidity
Wet
−40 to 151°F (−40 to 66°C)
0 to 95% noncondensing
Table 3: Sound level output (dBA)
Wattage Setting 25 V 70 V
2 W T 90 89.7
1 W X 87.1 86.9
1/2 W Y 84.0 83.9
1/4 W Z 80.8 80.8
dBA = Decibels, A-weighted.
UL 1480: Sound level output at 10 ft. (3.05 m) measured in a
reverberant room using 400 to 4,000 Hz band-limited pink noise.
Regulatory information
Manufacturer Edwards, A Division of UTC Fire & Security
Americas Corporation, Inc.
8985 Town Center Parkway, Bradenton, FL
34202, USA
Year of manufacture The first two digits of the DATE MFG
number (located on the product identification
label) are the year of manufacture.
North American
standards
Meets: UL 1480
Follow: NFPA 72
FCC compliance This device complies with part 15 of the
FCC Rules. Operation is subject to the
following two conditions: (1) This device may
not cause harmful interference, and (2) this
device must accept any interference
received, including interference that may
cause undesired operation.
Industry Canada
compliance
This Class A digital apparatus complies with
Canadian ICES-003
Contact information
For contact information, see www.utcfireandsecurity.com.
