DSPPA DSP364 User manual

DSP364 ABS Horn Speaker(10W-20W) With Transformer
Built in 70v/100v transformer
IP66 waterproof level
Rated power 10W-20W
Wide Freq.Resp.:140-20,000Hz
Max SPL:96±2dB
High sensitivity:106±2dB
Waterproof type loudspeaker
ABS enclosure and metal bracket
Features
The DSP364 is a horn speaker built-in 70v/100v transformer.The 70v/100v transmission is realized in a
high-voltage, low-current mode, which makes longer distance transmission and allows easy parallel
connection of multiple loudspeakers.
The built-in speaker driver is designed of wide frequency response 140-12,000Hz, the multiple power taps
of 10W & 20W are helpful for different applications varies from outdoor area size and ambient noise
surroundings.
The ABS enclosure and metal bracket are of white color. Easy and secure wall mount installation through
the supplied mounting bracket; long-term durability; high sensitivity, clear and sonorous sound.
It is ideal choice for industrial and commercial applications in the outdoor area of parking, park, garden,
corridor and playground where paging is needed..
Description
Specification
Model
DSP364
Rated Power
10W
Max Power
20W
Line Voltage
70/100V
Sensitivity(1M,1W)
96±2dB
Max SPL(1M)
106±2dB
Freq. Resp
140Hz-20kHz
Dimension(H×W×L)
267×152×303mm
Weight
3 kg

POSITIONING DIMENSIONS & DIAGRAM
50mm 50mm
3- 8mm
152mm
303mm
267mm
FREQ. RESPONSE DISTORTION
(dB SPL、1W、1m) (THD< 3% 1W、1m、400Hz~10kHz)
Installation
1. Fit three Ø8 mm screws in the position where needed to be install a speaker;
2. Set the system in those three screws;
2. Connect audio broadcasting wire to the terminals according to the table below;
70V
100V
Red---Black
5W
10W
Red---White
10W
20W(Notice)
Notice: While broadcasting wire is quite long and with high impedance only.
3. Finally, adjust the direction of the system and examine whether it is steady.
Line
Voltage
Terminals
Power
