Ego Power+ LM2020SP User manual

OPERATOR'S MANUAL
56-VOLT LITHIUM-ION
CORDLESS MOWER
MODEL NUMBER LM2020SP/LM2020SP-FC
LM2020/LM2020-FC
WARNING: To reduce the risk of injury, the user must read and understand the
Operator’s Manual before using this product. Save these instructions for future reference.
17-0623_EGO_LM2020SP & LM2020_56V Lithium-ion cordless mower_manual_NA_140mm x 216mm_NA
Español p. 109
Français p. 53

56-VOLT LITHIUM-ION CORDLESS MOWER — LM2020SP/LM2020SP-FC/LM2020/LM2020-FC2
TABLE OF CONTENTS
Safety Symbols ..........................................4
Safety Instructions......................................5-6
Safety Rules for Cordless Lawn Mower.....................7-12
Specications .......................................13-14
Description .........................................15-17
Assembly ...........................................18-24
Operation ...........................................24-33
Maintenance ........................................34-45
Troubleshooting ......................................46-48
Warranty ...........................................49-50

56-VOLT LITHIUM-ION CORDLESS MOWER — LM2020SP/LM2020SP-FC/LM2020/LM2020-FC 3
READ ALL INSTRUCTIONS!
WARNING: Some dust created by power cutting contains chemicals known to
the state of California to cause cancer, birth defects or other reproductive harm. Some
examples of these chemicals are:
◾Lead from lead-based paints
◾Crystalline silica from bricks and cement and other masonry products, and
◾Arsenic and chromium from chemically-treated lumber.
Your risk from these exposures varies, depending on how often you do this type of
work. To reduce your exposure to these chemicals: work in a well ventilated area, and
work with approved safety equipment, such as those dust masks that are specially
designed to lter out microscopic particles.

56-VOLT LITHIUM-ION CORDLESS MOWER — LM2020SP/LM2020SP-FC/LM2020/LM2020-FC4
SAFETY SYMBOLS
The purpose of safety symbols is to attract your attention to possible dangers. The
safety symbols and the explanations with them deserve your careful attention and
understanding. The symbol warnings do not, by themselves, eliminate any danger. The
instructions and warnings they give are no substitutes for proper accident prevention
measures.
WARNING: Be sure to read and understand all safety instructions in this
Operator’s Manual, including all safety alert symbols such as “DANGER,” “WARNING,”
and “CAUTION” before using this tool. Failure to follow all instructions listed below may
result in electric shock, re, and/or serious personal injury.
SYMBOL MEANING
SAFETY ALERT SYMBOL: Indicates DANGER, WARNING, or CAUTION. May be
used in conjunction with other symbols or pictographs.
WARNING: The operation of any power tools can result in foreign
objects being thrown into your eyes, which can result in severe eye
damage. Before beginning power tool operation, always wear safety
goggles or safety glasses with side shields and a full face shield when
needed. We recommend a Wide Vision Safety Mask for use over
eyeglasses or standard safety glasses with side shields. Always use eye
protection which is marked to comply with ANSI Z87.1.

56-VOLT LITHIUM-ION CORDLESS MOWER — LM2020SP/LM2020SP-FC/LM2020/LM2020-FC 5
SAFETY INSTRUCTIONS
This page depicts and describes safety symbols that may appear on this product. Read,
understand, and follow all instructions on the machine before attempting to assemble
and operate.
Safety Alert Indicates a potential personal injury
hazard.
Eye Protection
Always wear safety goggles or safety
glasses with side shields and a full face
shield when operating this product.
Read & understand
Operator's Manual
To reduce the risk of injury, user must
read and understand operator’s manual
before using this product.
Maintain Safety
Devices
Do not open or remove safety shields
while the tool is running.
Look Behind While
Backing
Look down and behind rst to avoid
tripping when pulling back.
DANGER — Keep
Hands and Feet
Away
To reduce the risk of injury, keep hands
and feet away from rotating parts. Do
not operate unless discharge cover
or grass bag is in its proper place. If
damaged, replace immediately.
DANGER — Keep
Bystanders Away
Do not mow when children or others
are nearby.
DANGER — Thrown
Debris
Remove objects that can be thrown by
the blade in any direction. Wear safety
glasses.

56-VOLT LITHIUM-ION CORDLESS MOWER — LM2020SP/LM2020SP-FC/LM2020/LM2020-FC6
DANGER — Steep
Slope Hazard
Use extra caution on slopes. Do not
mow slopes greater than
15 degrees.
Recycle Symbols
This product uses lithium-ion (Li-ion)
batteries. Local, state, or federal laws
may prohibit disposal of batteries in
ordinary trash. Consult your local waste
authority for information regarding
available recycling and/or disposal
options.
IPX4 Ingress Protection
Degree Protection from splashing water
V Volt Voltage
A Amperes Current
Hz Hertz Frequency (cycles per second)
WWatt Power
min Minutes Time
Alternating Current Type of current
Direct Current Type or a characteristic of current
n0No Load Speed Rotational speed, at no load
... /min Per Minute Revolutions per minute
WARNING: To ensure safety and reliability, all repairs should be performed by a
qualied service technician.

56-VOLT LITHIUM-ION CORDLESS MOWER — LM2020SP/LM2020SP-FC/LM2020/LM2020-FC 7
SAFETY RULES FOR CORDLESS LAWN MOWER
DANGER: This machine was built to be operated according to the rules for safe
operation included in this manual. As with any type of power equipment, carelessness
or error on the part of the operator can result in serious injury. This machine is capable
of amputating hands and feet and throwing objects. Failure to observe all safety
instructions could result in serious injury or death.
WARNING: When using electric lawn mowers, basic safety precautions should
always be followed to reduce the risk of re, electric shock, and personal injury. These
basic precautions include the following:
CHILDREN
Tragic accidents can occur if the operator is not alert to the presence of children.
Children are often attracted to the mower and mowing activity. They do not understand
the dangers. Never assume that children will remain where you last saw them.
◾Keep children out of the mowing area and under the watchful care of a
responsible adult other than the operator.
◾Be alert and turn the mower off if a child enters the area.
◾Use extreme care when approaching blind corners, doorways, shrubs, trees, or
other objects that may obscure your vision of a child who may run into the mower.
◾Never allow children under 14 years old to operate a power mower. Children 14
years old and over should read and understand the operation instructions and
safety rules in this manual and should be trained and supervised by a parent.
Only responsible individuals who are familiar with these rules of safe operation
should be allowed to use this machine.
OPERATION
GENERAL OPERATION:
◾Read this operator’s manual carefully in its entirety before attempting to assemble
this machine. Read, understand, and follow all instructions on the machine and in
the manuals before operation. Be completely familiar with the controls and proper
use of this machine before operating it. Keep this manual in a safe place for
future and regular reference and for ordering replacement parts.

56-VOLT LITHIUM-ION CORDLESS MOWER — LM2020SP/LM2020SP-FC/LM2020/LM2020-FC8
◾Use the right appliance – Do not use the lawn mower for any job except that for
which it is intended. Your lawn mower has been designed to perform only one job:
to mow grass.
◾Don’t overreach – Keep proper footing and balance at all times.
◾Objects struck by the lawn mower blade can cause severe injuries to persons.
The lawn should always be carefully examined and cleared of all objects prior to
each mowing.
◾Keep the area of operation clear of all persons, particularly small children, and
pets.
◾Before and while moving backwards with the mower, look behind and down for
small children and other people.
◾Keep clear of the discharge opening at all times.
◾This machine is a precise piece of power equipment, not a plaything. Therefore,
exercise extreme caution at all times. Your unit has been designed to perform one
job: to mow grass. Do not use it for any other purpose.
◾Don’t force the lawn mower – it will do the job better and more safely at the rate
for which it was designed.
◾Thoroughly inspect the area where the equipment is to be used. Remove all
stones, sticks, wire, toys and other foreign objects that could be tripped over or
picked up and thrown by the blade. Thrown objects can cause serious personal
injury.
◾Plan your mowing pattern to avoid discharge of material toward roads, sidewalks,
bystanders and the like. Also, avoid discharging material against walls or
obstructions, which may cause discharged material to ricochet back toward the
operator.
◾To help avoid blade contact or an injury from thrown objects, stay in the operator
zone behind the handles and keep children, bystanders, helpers and pets at
least 100 feet (30m) from the mower while it is in operation. Stop the machine if
anyone enters the area.
◾Always wear safety glasses or safety goggles during operation and while
performing an adjustment or repair to protect your eyes. Thrown objects that
ricochet can cause serious injury to the eyes. Always use a face or dust mask if
the operation is dusty.

56-VOLT LITHIUM-ION CORDLESS MOWER — LM2020SP/LM2020SP-FC/LM2020/LM2020-FC 9
◾Dress properly – Do not wear loose clothing or jewelry. They can be caught in
moving parts. Use of rubber gloves and footwear is recommended when working
outdoors. Wear sturdy, rough-soled work shoes and close-tting slacks and
shirts. Shirts and pants that cover the arms and legs and steel-toed shoes are
recommended. Never operate this machine in bare feet, sandals, slippery or
lightweight (e.g., canvas) shoes.
◾Do not put hands or feet near rotating parts or under the cutting deck. Contact
with the blade can amputate hands and feet.
◾A missing or damaged discharge cover can cause blade contact or injuries from
thrown objects.
◾Many injuries occur as a result of the mower being pulled over the foot during a
fall caused by slipping or tripping. Do not hold onto the mower if you are falling;
immediately release the handle.
◾Never pull the mower back toward you while you are walking. If you must back
the mower away from a wall or obstruction, rst look down and behind you to
avoid tripping, and then follow these steps:
◾Step back from mower to fully extend your arms.
◾Be sure you are well balanced with sure footing.
◾Pull the mower back slowly, no more than half way toward you.
◾Repeat these steps as needed.
◾Do not operate the mower while under the inuence of alcohol or drugs.
◾Stay alert – watch what you are doing. Use common sense. Do not operate the
lawn mower when you are tired.
◾The motor/blade control handle is a safety device. Never attempt to bypass its
operation. Doing so makes the safety device inoperative and may result in personal
injury through contact with the rotating blade. The motor/blade control handle
must operate easily in both directions and automatically return to the disengaged
position when released.
◾Avoid dangerous environments – Don’t use lawn mowers in damp or wet
locations so as to avoid slipping and falling during operation.
◾Always be sure of your footing. A slip and fall can cause serious personal injury.
If you feel you are losing your footing, release the motor/blade control handle
immediately and the blade will stop rotating within three seconds.
◾Mow only in daylight or good articial light. Walk, never run while operating.

56-VOLT LITHIUM-ION CORDLESS MOWER — LM2020SP/LM2020SP-FC/LM2020/LM2020-FC10
◾Stop the blade when crossing gravel drives, walks or roads.
◾If the equipment should start to vibrate abnormally, immediately stop the motor,
remove the battery and check for the cause. Vibration is generally a warning of
trouble.
◾Before cleaning the machine, unclogging the chute or removing or replacing the
grass bag, mulching insert, or side discharge chute, turn the motor off and wait
until the blade comes to a complete stop, then remove the battery pack. The
cutting blade continues to rotate for a few seconds after the motor is shut off.
Never place any part of the body in the blade area until you are sure the blade
has stopped rotating.
◾Never operate the mower without the proper trailing shield, discharge cover,
grass bag, mulching insert, side discharge chute, motor/blade control handle or
other safety protective devices in place and working. Never operate the mower
with damaged safety devices. Failure to do so can result in personal injury.
◾If situations occur that are not covered in this manual, use care and good
judgment. Contact EGO Customer Service for assistance.
◾Use only with the battery packs and chargers listed below:
BATTERY PACK CHARGER
BA1120, BA1120-FC, BA1400, BA1400-FC,
BA2240, BA2240-FC, BA2800, BA2800-FC,
BA4200, BA4200-FC, BA1400T, BA1400T-FC,
BA2800T, BA2800T-FC, BA4200T, BA4200T-FC,
BA5600T, BA5600T-FC
CH2100, CH2100-FC,
CH5500, CH5500-FC
OPERATION ON A SLOPE:
Slopes are a major factor related to slip-and-fall accidents, which can result in severe
injury. Operation on slopes requires extra caution. If you feel uneasy on a slope, do
not mow it. For your safety, use the slope gauge on page 22 to measure slopes before
operating this unit on a sloped or hilly area. If the slope is greater than 15 degrees, do
not mow it.
Do:
◾Mow across the face of slopes; never mow up and down. Exercise extreme
caution when changing direction on slopes.

56-VOLT LITHIUM-ION CORDLESS MOWER — LM2020SP/LM2020SP-FC/LM2020/LM2020-FC 11
◾Watch for holes, ruts, rocks, hidden objects, or bumps which can cause you to slip
or trip. Tall grass can hide obstacles.
Do not:
◾Do not mow near drop-offs, ditches or embankments; you could lose your footing
or balance.
◾Do not mow slopes greater than 15 degrees, as shown on the slope gauge.
◾Do not mow on wet grass. Unstable footing could cause slipping.
SERVICE
WARNING: Grass bag components, the discharge cover, side discharge chute,
mulching insert and trailing shield are subject to wear and damage, which could
expose moving parts or allow objects to be thrown and could increase the risk of
injury. For safety protection, frequently check all components and replace damaged
components immediately with identical replacement parts, listed in this manual.
◾If the mower’s built-in overload protection switch frequently trips, contact EGO
Customer Service or your closest EGO service center.
◾Do not wash the mower with a hose; avoid getting water in the motor and
electrical connections.
◾Remove the battery and store the idle lawn mower in a covered area when not in
use. Allow the motor to cool before storing it in any enclosure. The lawn mower
should be stored in a dry, high, or locked-up enclosure, out of reach of children.
◾When servicing, use only identical replacement parts listed in this manual. Use of
parts that do not meet the original equipment specications may lead to improper
performance and compromised safety.
◾Remove or disconnect the battery pack before servicing, cleaning, or removing
material from the lawn mower.
◾Follow instructions for lubricating and changing accessories.
◾Keep handles dry, clean and free from oil and grease.
◾To reduce a re hazard, keep the motor cover free of grass, leaves and debris build-up.
◾Check the blade and motor mounting bolts at frequent intervals for proper tightness.
Also, visually inspect the blade for damage (e.g., bending, cracking and wear.).
Replace the blade only with the identical replacement blade, as listed in this manual.

56-VOLT LITHIUM-ION CORDLESS MOWER — LM2020SP/LM2020SP-FC/LM2020/LM2020-FC12
◾Maintain your mower with care – keep the mower blade sharp and clean for the
best and safest performance. Mower blades are sharp and can cut. Wrap the
blade or wear gloves and use extra caution when servicing it.
◾Keep all nuts, bolts, and screws tight to be sure the equipment is in safe working
condition.
◾Never remove or tamper with safety devices. Regularly check their proper
operation. Never do anything to interfere with the intended function of a safety
device or to reduce the protection provided by a safety device.
◾Always stop the motor before making adjustments to a wheel or a cutting-height
adjustment.
◾After striking a foreign object, stop the motor, remove the battery pack, allow the
blade to stop rotating, and thoroughly inspect the mower for any damage. Repair
the damage before operating the mower.
◾Maintain or replace safety and instruction labels, as necessary.
◾Do not incinerate the appliance even if it is severely damaged. The batteries can
explode in a re.
◾Do not expose a battery pack or tool to re or excessive temperature. Exposure to
re or temperature above 212 °F (100°C) may cause explosion.
◾SAVE THESE INSTRUCTIONS. Refer to them frequently and use them to
instruct others who may use this tool. If you lend this tool to someone else, also lend
these instructions to them to prevent misuse of the product and possibly injury.
INTRODUCTION
Congratulations on your selection of a new generation of 56V Lithium-ion powered
lawn mower. It has been designed, engineered and manufactured to give you the best
possible dependability and performance.
Should you experience any problem you cannot easily remedy, please contact EGO
customer service center 1-855-EGO-5656.
This manual contains important information on the safe assembly, operation and
maintenance of your mower. Read it carefully before using the mower. Keep this
manual handy so you can refer to it at any time.

56-VOLT LITHIUM-ION CORDLESS MOWER — LM2020SP/LM2020SP-FC/LM2020/LM2020-FC 13
SERIAL NUMBER _____________________ DATE OF PURCHASE _________________
THE MODEL AND SERIAL NUMBERS WILL BE FOUND ON A LABEL ATTACHED ON THE
REAR DISCHARGE DOOR.
YOU SHOULD RECORD BOTH SERIAL NUMBER AND DATE OF PURCHASE AND KEEP IN A SAFE
PLACE FOR FUTURE REFERENCE
SPECIFICATIONS
Model Number LM2020/LM2020-FC LM2020SP/LM2020SP-FC
Self Propel System No Yes
Voltage 56 V 56 V
No-Load Speed 3000 rpm 3000 rpm
Approximate Cutting
Height Settings
1 1-3/16'' (30 mm) 1-3/16'' (30 mm)
2 1-9/16'' (40 mm) 1-9/16'' (40 mm)
3 2-1/8'' (55 mm) 2-1/8'' (55 mm)
4 2-3/4'' (70 mm) 2-3/4'' (70 mm)
5 3-3/8' (85 mm) 3-3/8' (85 mm)
6 4" (100 mm) 4" (100 mm)
Deck Size 20'' 20''
Grass Bag Volume 1.7 Bushel (60 L) 1.7 Bushel (60 L)
Mower Weight (Without battery
pack; with mulching insert) 55.18 lb. (25.08 Kg) 55.40 lb. (25.13 kg)
Recommended Operating
Temperature 32°F-104°F(0°C-40°C)
Recommended Storage
Temperature -4°F-158°F(-20°C-70°C)

56-VOLT LITHIUM-ION CORDLESS MOWER — LM2020SP/LM2020SP-FC/LM2020/LM2020-FC14
APPROXIMATE RUNNING TIME
Battery
Model
With BA2800/BA2800-FC 56V
Battery 5.0Ah
With BA4200/BA4200-FC 56V
Battery 7.5Ah
LM2020/
LM2020-FC 55 min 85 min
LM2020SP/
LM2020SP-FC 45 min 70 min
NOTICE: The actual running time will vary with grass condition: species,
density, moisture, etc.
ACCESSORIES
WARNING: The following part is subjected to be worn out from normal use. Use
only identical replacement parts listed below. Use of parts that do not meet the original
equipment specications may lead to improper performance and compromised safety.
PART NAME MODEL NUMBER
Blade AB2000
PACKING LIST
PART NAME QUANTITY
Lawn mower 1
Grass bag 1
Grass bag frame 1
Mulching insert (pre-installed in mower) 1
Side discharge chute 1
Operator’s manual 1

56-VOLT LITHIUM-ION CORDLESS MOWER — LM2020SP/LM2020SP-FC/LM2020/LM2020-FC 15
DESCRIPTION
1Self-Propel Trigger
Safety Button
Handle-Locking Clamp
Grass Bag
Cutting-Height Adjustment
Lever
Rear Wheel
Side-Discharge Door Deck Cover
Power
Indicator
Rear
Discharge
Door
Trailing
Shield
Battery-Release
Button
Mulching Insert
Side Discharge
Chute
Switch Button for
LED Headlights
Front Wheel
Mower Deck
LED Headlights
Battery-Pack Cover
Rear Handle
Quick-Adjust Lever
Rear-Discharge Door
Side Rail
Self-Propel Speed-Control
Lever
Bail switch (Switch Lever)
Handle

56-VOLT LITHIUM-ION CORDLESS MOWER — LM2020SP/LM2020SP-FC/LM2020/LM2020-FC16
WARNING: The safe use of this product requires an understanding of the
information on the tool and in this operator’s manual, as well as knowledge of the
project you are attempting. Before use of this product, familiarize yourself with all
operating features and safety rules.
Safety Button
The safety button must be pressed down before the motor can be started.
Bail Switch
The bail switch is located on the upper handle of the mower. The switch engages and
disengages the motor/ blade.
Self-Propel Trigger (model LM2020SP/LM2020SP-FC only)
Turns the self-propel function ON and OFF.
Self-Propel Speed Control Lever (model LM2020SP/LM2020SP-FC
only)
Increases or decreases the self-propel speed by moving the control lever.
WARNING: The bail switch and the safety button are safety devices. Never
attempt to bypass their operations.
Electric Brake
Quickly stops blade rotation when the bail switch is released.
Handle-Locking Clamp
Locks/unlocks the side rails in the extended or the recessed position.
Side Rails
Can be extended and locked for operation or recessed for storage.

56-VOLT LITHIUM-ION CORDLESS MOWER — LM2020SP/LM2020SP-FC/LM2020/LM2020-FC 17
Quick-Adjust Lever
Locks/unlocks the handle position when adjusting the angle of the mower handle:
1. Locked Storage Position
2. Grass Bag Attachment/Removal Position
3. Upper Operating Position
4. Middle Operating Position
5. Lower Operating Position
Trailing Shield & Rear Discharge Door
The trailing shield is designed to minimize stones or other objects being thrown
backward by the mower blade. The shield and the rear discharge door minimize the
possibility of accidental foot contact with the blade. DO NOT operate the mower without
the trailing shield and rear discharge door in place.
Led Headlights
The LED headlights are located in the front of the mower. This feature provides extra
light for increased visibility.
Spring-Loaded Cutting-Height Adjustment Lever
One-handed cutting-height adjustment.

56-VOLT LITHIUM-ION CORDLESS MOWER — LM2020SP/LM2020SP-FC/LM2020/LM2020-FC18
ASSEMBLY
WARNING: To prevent accidental starting that could cause serious personal
injury, always remove the battery pack from the tool when assembling parts.
WARNING: Do not attempt to modify this tool or create accessories not
recommended for use with this mower. Any such alteration or modication is misuse
and could result in a hazardous condition leading to serious injury.
UNPACKING
◾First remove all the accessories from the carton, then grasp both the front part of
the deck cover and the rear handle at the same time to carefully lift the mower up
and out of the carton. Make sure that all items listed in the parts list are included.
◾Inspect the product carefully to make sure that no breakage or damage occurred
during shipping.
◾Do not discard the packing material until you have carefully inspected and
satisfactorily operated the mower.
◾If any parts are damaged or missing, please return the mower to the place of
purchase.

56-VOLT LITHIUM-ION CORDLESS MOWER — LM2020SP/LM2020SP-FC/LM2020/LM2020-FC 19
ASSEMBLING THE GRASS BAG
1. Check the grass bag before
assembling, to make sure that there
is no damage.
2. Slide the grass bag onto the frame,
as shown in Fig. 2.
3. Assemble the top clips to the frame,
as shown in Fig. 3, then assemble
the two side clips. Assemble the
bottom clip last.
4. The completely assembled grass
bag is shown in Fig. 4.
2
3
4
Attaches

56-VOLT LITHIUM-ION CORDLESS MOWER — LM2020SP/LM2020SP-FC/LM2020/LM2020-FC20
ADJUSTING THE FOLDABLE HANDLE
WARNING: Do not attempt to start the mower until the handle has been locked
at one of the three preset operating positions.
1. LOCKED STORAGE POSITION: Your
mower is shipped with the handle in
the compact, locked position (Fig. 5).
2. GRASS BAG ATTACHMENT/REMOVAL
POSITION: Press and hold the
quick-adjust lever with one hand to
release the handle from the locked
storage position. Begin to lift the
handle from its folded position with
your other hand, and then release
the lever (Fig. 5). Gently pivot the
handle upward until you hear and
feel the lock pin engage in the rst
position (Fig. 6). This position allows
easy access to install and remove
the grass bag.
5
Press the Quick
Adjust Lever
1
2
6
Grass Bag
Attachment/Removal
Position
Upper Operating
Position
Lower
Operating
Position
Locked Storage
Position
Middle
Operating
Position
