EINHELL HOME TH-VC 1820 S User manual

Art.-Nr.: 23.421.69 I.-Nr.: 11013
Original operating instructions
Wet and Dry Vacuum Cleaner
TH-VC 1820 S
Anleitung_TH_VC_1820_S_SPK7__ 13.06.12 10:06 Seite 1

2
1
2
8
11
12
2
6
10
10
18
1
13
17
15 14
16
12 11
13
3
7
Anleitung_TH_VC_1820_S_SPK7__ 13.06.12 10:06 Seite 2

3
6
3
5
4
9
5
7
4
8
3
6
7
13
15
18 1
3
Anleitung_TH_VC_1820_S_SPK7__ 13.06.12 10:06 Seite 3

4
11b
9
11a
10
11c
14
7
10
8
11 17 16 11 17
10 11
12
12
19
3
Anleitung_TH_VC_1820_S_SPK7__ 13.06.12 10:06 Seite 4

5
GB
Important!
When using the equipment, a few safety precautions
must be observed to avoid injuries and damage.
Please read the complete operating manual with due
care. Keep this manual in a safe place so that the
information is available at all times. If you give the
equipment to any other person, give them these
operating instructions as well.
We cannot accept any liability for damage or
accidents which arise due to a failure to follow these
instructions and the safety information.
1. Safety information
Important: read the operating instructions before
assembling and using the appliance for the first
time.
Check that the mains voltage is the same as the
mains voltage specified on the rating plate.
Pull out the power plug in the following
circumstances: whenever the appliance is not in
use, before opening the appliance and before all
cleaning and maintenance work.
Never clean the appliance with solvents.
Never pull the plug out of the socket by pulling
the cable.
Never leave the appliance unattended when
operational.
Keep away from children.
Take care to ensure that the power cable does
not get damaged by being run over, crushed,
pulled or suchlike.
Do not use the machine if the power cable is in a
less than perfect condition.
If the power cable has to be replaced, the
replacement must comply with the design
specifications of the manufacturer.
Power cable: H 05 VV - F 2 x 0.75 mm2
Never vacuum the following: burning matches,
smoldering ash and cigarette butts, combustible,
caustic, inflammable or explosive substances,
vapor or liquids.
This appliance is not suitable for vacuuming dust
which can be harmful to health.
Store the appliance in a dry indoor location.
Never use the appliance if it is damaged.
Only allow the appliance to be serviced by an
authorized after sales service outlet.
Only use the appliance to carry out work for
which has been designed.
Take extra care when cleaning steps.
Use only genuine accessories and spare parts.
2. Layout and items supplied
1 Handle
2 On/Off switch
3 Appliance head
4 Filter basket
5 Safety float valve
6 Locking hook
7 Container
8 Suction hose connector
9 Blow connector
10. Flexible hose
11 3-part suction tube
12 Combination nozzle
13 Wheels
14 Dirt bag
15 Foamed plastic filter
16 Crevice nozzle
17 Adapter
18 Additional filter
19 Hook for cable store
3. Intended use
The wet and dry vacuum cleaner is designed for wet
and dry vacuuming using the appropriate filter. The
appliance is not suitable for the vacuuming of
combustible, explosive or harmful substances.
The equipment is to be used only for its prescribed
purpose. Any other use is deemed to be a case of
misuse. The user / operator and not the
manufacturer will be liable for any damage or injuries
of any kind caused as a result of this.
Anleitung_TH_VC_1820_S_SPK7__ 13.06.12 10:06 Seite 9
This appliance is not intended for use by persons
(including children) with reduced physical, sensory or
mental capabilities, or lack of experience and
knowledge, unless they have been given supervision
or instruction concerning use of the appliance by a
person responsible for their safety.
Children should be supervised to ensure that they do
not play with the appliance.

Please note that our equipment has not been
designed for use in commercial, trade or industrial
applications. Our warranty will be voided if the
equipment is used in commercial, trade or industrial
businesses or for equivalent purposes.
4. Technical data
zH05~V0 - 24022:egatlovsniaM
W052.1:tupnirewoP
l02:emulovreniatnoC
gk0.5:thgieW
/II:ssalcnoitcetorP
5. Before starting the equipment
Important!
Before you connect the equipment to the mains
supply make sure that the data on the rating
plate are identical to the mains data.
The appliance may only be connected to a
shock-proof socket!
5.1 Appliance assembly
Fitting the appliance head (Fig. 4)
The appliance head (3) is fastened to the container
(7) by the locking hook (6). To remove the appliance
head (3), open the locking hook (6) and remove the
appliance head (3). When fitting the appliance head
(3), make sure that the locking hook (6) locks into
place correctly.
Assembling the wheels (Fig. 5)
Fit the wheels (13) in accordance with fig. 5.
Fitting the handle (Fig. 8)
Use a screwdriver to fit the handle (8).
Mounting the hook for the cable store (Fig. 12)
Press the hook for the cable store (19) into the mount.
After use, the power cable can be wound up onto the
hook (19) and the head (3).
5.2 Fitting the filter
Important!
Never use the wet and dry vacuum cleaner without a
filter!
Always ensure that the filters are perfectly secure!
Fitting the foam filter (Fig. 6)
For wet-vacuuming, slip the supplied foamed plastic
filter (15) over the filter basket (Figs. 2/4).
Fitting the additional filter (Fig. 7)
For dry vacuum cleaning always use the supplied
additional filter (18). Mount the additional filter, so
that no air is sucked through the filter cage (4)
without being filtered.
Assembling the dirt bag (Fig. 9)
For vacuuming fine, dry dirt it is recommended that
you fit the dirt bag (14). Slip the dirt bag (14) over the
vacuuming hole. The dirt bag (14) is suitable for dry-
vacuuming only. The dirt bag makes it easier to
dispose of the sucked-in dust.
5.3 Fitting the suction hose (Fig. 3, 10, 11)
Connect the suction hose (10) to the corresponding
connector on the wet and dry vacuum cleaner,
depending on the application required.
Vacuuming
Connect the suction hose (10) to the suction hose
connector (8)
Blowing
Connect the suction hose (10) to the blow connector
(9)
One or more of the elements which make up the 3-
part suction tube (11) can be attached to the suction
hose (10) to extend it. The adapter (17) must be
inserted between the suction tube (10) and the
combination nozzle (12) or crevice nozzle (16).
5.4 Suction nozzles
Combination nozzle (12)
The combination nozzle (12) with attachments is for
vacuuming solids and liquids over medium to large
areas. The crevice nozzle (16) is specially designed
for cleaning cervices and edges.
6
GB
Anleitung_TH_VC_1820_S_SPK7__ 13.06.12 10:06 Seite 10

7
GB
6. Operation
Important!
Switch off the equipment if liquid or foam is emitted
with the exhaust air when wet vacuum cleaning.
6.1 On/Off switch (Fig. 1)
Switch position 0: Off
Switch position I: On
6.2 Dry vacuuming
Use the dirt bag (14) and the additional filter (18) for
dry vacuuming (see point 5.2).
Always ensure that the filters are perfectly secure.
6.3 Wet vacuuming
For wet-vacuuming, use the foam filter (15) (see
point 5.2).
Check that the filter is securely fitted at all times.
Important.
When wet vacuuming, the floating safety switch (5)
turns off the wet and dry vacuum cleaner
automatically when the maximum level is reached.
Important!
The wet and dry vacuum cleaner is not suitable for
the vacuuming of combustible liquids.
For wet vacuuming, use only the supplied foam filter.
6.4 Blowing
Connect the suction hose (10) to the blow connector
(9) on the wet and dry vacuum cleaner.
7. Cleaning, maintenance and ordering
of spare parts
Important!
Always pull out the mains power plug before starting
any cleaning work.
7.1 Cleaning
Keep all safety devices, air vents and the motor
housing free of dirt and dust as far as possible.
We recommend that you clean the equipment
immediately after you use it.
7.2 Cleaning the appliance head (3)
Clean the appliance regularly with a damp cloth and
some soft soap. Do not use cleaning agents or
solvents; these may be aggressive to the plastic
parts in the appliance.
7.3 Cleaning the container (7)
The container can be cleaned with a damp cloth and
some soft soap or under running water, depending
on the amount of dirt.
7.4 Cleaning the foam filter (15)
Clean the foam filter (15) with a little soft soap under
running water and allow it to air-dry.
7.5 Servicing
At regular intervals and before each use, check that
the filters in the wet and dry vacuum cleaner are
securely fitted.
7.6. Ordering spare parts
Please provide the following information on all orders
for spare parts:
Model/type of the equipment
Article number of the equipment
ID number of the equipment
Part number of the required spare part
For our latest prices and information please go to
www.einhell.com.au
8. Replacing the power cable
If the power cable for this equipment is damaged, it
must be replaced by the manufacturer or its after-
sales service or similarly trained personnel to avoid
danger.
9. Disposal and recycling
The equipment is supplied in packaging to prevent it
from being damaged in transit. The raw materials in
this packaging can be reused or recycled. The
equipment and its accessories are made of various
types of material, such as metal and plastic.
Defective components must be disposed of as
special waste. Ask your dealer or your local council.
Anleitung_TH_VC_1820_S_SPK7__ 13.06.12 10:06 Seite 11
EH 02/2013 (01)

Anleitung_TH_VC_1815_SPK7__ 13.06.12 11:04 Seite 10
The guarantee provided in this Guarantee Certificate is given by Einhell Australia Pty Limited
ACN 134 632 858 of 6/166 Wellington Street, Collingwood, Victoria (Telephone number 1300 922 271)
GUARANTEE CERTIFICATE
EINHELL AUSTRALIA PTY LTD
6/166 Wellington Street
Collingwood VIC 3066
Australia
Phone: [phone]
Dear Customer,
All of our products undergo strict quality checks. In the unlikely event that your device develops a fault, please
contact our service department at the address shown on this guarantee certificate. Of course, if you would
prefer to call us then we are also happy to offer our assistance under the service number printed below.
Please note the following terms under which claims under the Einhell Express Guarantee can be made:
1. The benefits conferred by the Einhell Express Guarantee are in addition to all rights and remedies which
you may be entitled to under the Australian Consumer Law, and anyother statutory rights you may have
under other applicable laws. This Einhell Express Guarantee does not exclude, restrict or modify any
We do not charge you for the Einhell Express Guarantee.
2. Our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are
entitled to a replacement or refund for amajor failure and for compensation for any other reasonably
foreseeableloss or damage. You are also entitled to have the goods repaired or replaced if the goods
fail to be of acceptable quality and the failure does not amount to a major failure.
3. The Einhell Express Guarantee only covers problems caused by material or manufacturing defects, and
our liabilityunder the Einhell Express Guarantee is limited, at our discretion, to the rectification of these
defects or replacement of the product. Please note that the product has not been designed for use in
commercial, trade or industrial applications. Consequently, the Einhell Express Guarantee will not apply
if the product is used in commercial, trade or industrial applications or for other equivalent activities.
4. The following are also excluded from the Einhell Express Guarantee: compensation for transport
damage, damage caused by failure to comply with the installation/assemblyinstructions or damage
caused by unprofessional installation, failure to comply with the operating instructions (e.g. connection to
the wrong mains voltage or current type), misuse or inappropriate use (such as overloading of the
product or use of non-approved tools or accessories), failure to comply with the maintenance and safety
regulations, ingress of foreign bodies into the product (e.g. sand, stones or dust), effects of force or
external influences (e.g. damage caused by the product being dropped) and normal wear resulting from
proper operation of the product. The Einhell Express Guarantee will also not applyif any attempt is made
5. The Einhell Express Guarantee is valid for a period of 2 years starting from the purchase date of the
product. Claims made under the Einhell Express Guarantee should be submitted before the end of this
guarantee period and within two weeks of the defect being noticed. No claims under the Einhell Express
Guarantee will be accepted if submitted after the end of this guarantee period. The original guarantee
period remains applicable to the device even if repairs are carried out or parts are replaced. In such
cases, the work performed or parts fitted will not result in an extension of the guarantee period for the
Einhell Express Guarantee, and the Einhell Express Guarantee will notapply for the work performed or
6. To make a claim under the Einhell Express Guarantee, please send the relevant product postage-free to
the address shown below and enclose either the original or a copy of your sales receipt or another dated
proof of purchase. It would help us if you could describe the nature of the problem in as much detail as
possible. If the defect is covered by the Einhell Express Guarantee, yourproduct will be repaired
immediatelyand returned to you,or we will send you a newdevice (at our election).
Any costs incurred by you in making a claim under this Einhell Express Guarantee, unless specified
otherwise in this guarantee certificate, must be borne by you.
Of course, we are also happyto offer a chargeable repair service for any defects which are not covered by the
scope of the Einhell Express Guarantee or for products which are no longer covered by the Einhell Express
Guarantee. To take advantage of this service, please send the product to our service address.
such rights or remedies.
to tamper with the product.
parts fitted. This also applies when an on-site service is used.
(Einhell Express Guarantee).
