6. Operation
6.1 Charging the Li battery pack (Fig. 2-3)
The battery is protected from exhaustive dischar-
ge. An integrated protective circuit automatically
switches offthe equipment when the battery is
flat. In this case the bit chuck will cease to turn.
Warning! Do not press the ON/OFF switch any
more if the protective circuit has actuated. This
may damage the battery.
1. Remove the battery pack (5) from the handle,
pressing the pushlock buttons (8) on the left
and right sides to do so.
2. Check that your mains voltage is the same as
that marked on the rating plate of the battery
charger. Insert the power plug of the charger
(6) into the mains socket outlet.The green
LED will then begin to flash.
3. Insert the battery pack (5) into the battery
charger (6).
4. In section 10 „Charger indicator“ you will find
a table with an explanation of the LED indica-
tor on the charger.
If the battery pack fails to charge, check for the
following:
• voltage at the power socket
• whether there is good contact at the charging
contacts of the charging unit.
If the battery pack still fails to charge, send
• the charger and charging adapter
• and the battery pack
to our customer service center.
6.2 Changeover switch (Fig. 4/Item 3)
The slide switch above the On/Offswitch is for
setting the direction of rotation of the cordless
screwdriver and for preventing the cordless
screwdriver from being switched on inadvertently.
You can select between clockwise and counter-
clockwise rotation.To avoid causing damage to
the gearing, the direction of rotation must only be
changed when the equipment is at a standstill.
When the slide switch is in the middle position,
the On/Offswitch is blocked.
6.3 On/Offswitch (Fig. 4 / Item 4)
Infinitely variable speed control is possible with
the On/Offswitch.The further you push the
switch, the higher the speed of the cordless
screwdriver.
To switch on:
Press the On/Offswitch (4).
To switch off:
Release the ON/OFF switch (4)
6.4 Battery capacity indicator (Fig. 4 – Item 2)
Push the On/Offswitch (4).The battery capacity
indicator (2) shows the charge status of the batte-
ry using 3 LEDs.
All 3 LEDs are lit:
The battery is fully charged.
2 LEDs are lit:
The battery has an adequate remaining charge.
1 LED:
The battery is empty, recharge the battery.
6.5 LED lamp (Fig. 5/Item 7)
The LED lamp (7) can be used in poor lighting
conditions to illuminate the area where you want
to screw.The LED light (7) will come on automati-
cally as soon as you press the On/Offswitch (4).
6.6 Changing the bit (Fig. 6)
Important! Set the changeover switch (3) to its
center position whenever you carry out any work
(for example changing the tool, maintenance
work, etc.) on the cordless screwdriver.
Inserting the bit:
• Insert the bit into the bit mount (1) as far as
the stop while simultaneously pulling the slee-
ve on the bit mount (1) toward the bit.
• Release the sleeve again.
• Check that the bit is securely seated.
Removing the bit:
• Pull the sleeve on the bit mount (1) toward the
bit, hold it tight and remove the bit.
6.7 Screws
It is advisable to use self-centering screws (e.g.
Torx, cross recessed head) as these will enable
you to work safely and reliably. Always make sure
that the bit used is of the same size and shape as
the screw.
