EKHO WM-25 User manual

Ekho –WM-25
Heart Rate Monitor
1. Functions
Heart Rate Functions:
Current Heart Rate
Average Heart Rate
Target Zone (TZ) Programming
Audible and Visual Alarm for High/Low
TZ
Out-of-Zone Visual Display
Audible Alarm OFF Mode
ECG Accurate
Watch Functions:
Time/Date
Stopwatch
Calorie Functions:
Calculates Calories Burned
Other:
Large Dual Display
Water Resistant
Comfortable Ultra-Slim Ergonomic Chest
Belt Transmitter w/ user Changeable
Batteries
Interfaces with Heart Rate Interactive
Exercise
Equipment at home and in the gym
2. Putting on your Ekho Heart
Rate Monitor
Receiver:
Mount the Receiver on either
your left or right wrist.
The watch receives and
translates the electrical signals
generated by your heart via the
transmitter.
Transmitter Belt:
Attach the transmitter to the
elastic strap.
Wrap the transmitter around your
chest and adjust the length of the
strap so it fits snug.
The strap should be comfortable
and secure.
(If the strap is not secure, the
electrodes may lose contact or
the transmitter may slide down
during exercise.)
The transmitter should be
positioned just below the
breasts/pectoral muscles, with
the transmitter centered on the
chest.
Wet the electrodes (rubber pads),
the
electrodes must be wet for
accurate heart rate.
The transmitter will automatically
turn on when the above actions
are done.
The optimal distance from the receiver
(watch) to the transmitter is 1 meter (3.28
feet).
Note: All telemetry pulse watches are
subject to interference from strong
electromagnetic fields generated from
motors, TV sets, computers, high voltage
power cables which can disrupt the
reception and cause incorrect hear rate
measurements.
3. Setting Time
Press “Mode” and hold for 3 seconds.
12/24 hour will flash.
When 12/24 hour begins to flash, press
“Start/Stop” to select mode.
When finished, press “Mode” the hour will
begin to flash, press “Start/Stop” to select
hour.
Repeat with Minutes and seconds.
Once complete press “Mode” for three
seconds and your ready to go.
4. Setting Date
Press “Mode” until the date is shown.
Press “Mode” and hold for 3 seconds.
Day will flash, adjust day by pressing
“Start/Stop”.

Press “Mode”, adjust Month by pressing
“Start/Stop”.
Press “Mode”, adjust Date by pressing
“Start/Stop”.
Press “Mode” for three seconds and your
ready to go.
5. Using your Stopwatch
Press “Mode” until 00:00o is displayed.
To start the stopwatch press “Start/Stop”
To stop the stopwatch press “Start/Stop”
To clear stopwatch, press and hold
“Start/Stop” for three seconds.
The maximum time displayed is 99:59:59.
(hr:mn:ss)
6. Setting your Target Zones
Press “Mode” until 00:00o is displayed.
Press “Set”, two sets of number will appear
with a flashing arrow.
Press “Mode” to select the direction of the
arrow.
Press “Start/Stop” to adjust the flashing
number. Note each time you adjust number
the non-flashing number changes to always
be in increments of ten.
Once you have set your Target Zone you
desire press “set” and you will back to
00:00o.
7. Now It’s Time to Begin
Press “Select”, a zero will appear in the
lower portion of the Display. Once a signal
from the transmitter is detected, the heart
symbol will begin to flash in conjunction
with your heartbeat. Your heart rate will
display in a few seconds.
If the heart symbol does not flash, the
signal is not being received. Check the
position of the transmitter. Verify the
electrodes are moistened.
8. Your done exercising.
Wash Transmitter belt with soapy water
then rinse.
Dry Transmitter with soft cloth.
Store Transmitter a place that is clean and
dry. Dirt and moisture may cause
transmitter to continue reading, reducing
the life of the battery.
9. Haven’t exercised in a while?
Ekho Heart Rate Monitors is to be used to
display heart rate during exercise only and
cannot predict the intensity level that is safe
for you. It is not intended for medical
diagnostic purposes or for prevention of
heart related health problems. Before you
begin any exercise program, please consult
your physician:
a. If you have been inactive for a
period of time
b. Have a history of cardiac illness
c. Smoke
d. Have high blood pressure
e. Are over-weight.
If you use a pacemaker, do not use a heart
monitor until you consult your doctor.
9. Ekho Specifications
Receiver:
Heart Rate Range 30 to 240
BPM
Heart Rate Accuracy +/-1 BPM
Operating Temperature 0 C-50 C (32
F –xx F)
Storage Temperature -20 C –80 C
(xxF-xxF)
Battery 3 volt Lithium
2032 cell
Weight 30.6 grams
Transmitter & Belt:
Emitted Frequency 5KHz +/-10%
Battery 3 volt lithium
2032 cell
Weight 4 oz.
12. Disclaimer
The material in this manual is for
informational purposes only. The products
it describes are subject to change without
prior notice, due to the manufacturer’s
continuous development program.
Ekho makes no representations or
warranties with respect to this manual or
with respect to the products described
herein. Ekho shall not be liable for any
damages, direct or incidental,
consequential or special, arising out of, or
related to the use of this material or the
products described herein.

Distributed in the USA by:
Ekho
4330 Upton Ave S Unit B
Minneapolis, Minnesota 55410
001-612-922-3766
001-612-922-3767
www.ekho.us
Ekho is a division of Leeward
LLC.
13. Limited Warranty
Warranty, Terms and Conditions
If the product becomes defective during the
5-year Limited Warranty period Ekho will
repair or
replace any defective component part at no
charge to the original owner, subject to the
limitations
and requirements listed.
THE FOLLOWING IS REQUIRED BY
EKHO when requesting warranty services:
Check your resellers return policy. All
purchased products must be returned to
original place of
purchase within their return policy time
period.
The product must be packed in the original
shipping carton or in a suitable packing
offering
similar degree of protection. To avoid
scratches or other damages to the product
during shipping
separate items, such as HRM, transmitter
belt, transmitter, should be individually
wrapped and
placed in the same package. This will
reduce any extra cost of return
freight/postage. Please
include a copy of Proof of Purchase and/or
copy of registration form.
Limitations: The limited warranty provided
by Ekho does not cover: A: Batteries. B:
Damages
due to misuse. C: Abuse or accidents. D:
Cracked or broken cases. E: Negligence
of Precautions. F: Improper maintenance
or commercial use. D: Repairs made by a
non-
Authorized technician. The warranties
contained herein are expressly in lieu of
any other warranties including implied
warranty of merchantability and/or fitness
for purpose. In no event
Shall Ekho be liable for arising out of or
related to the use of this manual or the
products
Described herein.
