Star Trac Spinning User manual

Spinning®Computer
User Manual
Installation, Service and Instructor Education

01
02
03
05
06
07
08
10
11
12
15
18
19
20
21
22
23
25
FCC Regulatory Statements
Parts List
Marketing Statement Regarding Heart Rate
Specifications
How it Works
Computer Window and Buttons
Installing or Replacing Batteries
Do I need to Re-sync?
Testing for RPM
Syncing Mode
Setup Mode
Installation of Cadence Sensor and Magnet – All Spinners®
Mounting Computer On Handlebars - Spinner®V
Mounting Computer On Handlebars - Spinner® Sport / Fit / Velo
Mounting Computer On Handlebars - Pro 7070 / Elite 7080 / NXT 7090
Maintenance Checklist
FAQs and Troubleshooting
Spinning®Instructor Education
Table of Contents

FCC Regulatory Statements
1. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) this device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.
2. Changes or modifications not expressly approved by Star Trac could void the user’s authority to
operate the equipment.
1

Parts List
Part Number for
re-order
Quantity Description
727-0100 Spinning®
Computer Kit
1 Spinning®Computer
727-0093-KT Mounting
Bracket Kit
1 Mounting Bracket
1 Spinner®V Mounting Bracket Insert
1 Mounting Insert for open handlebars
727-0101-KT 1 Cadence Sensor
727-0094 1 Cadence Magnet
N/A 1 AA Panasonic Batteries
N/A 1 Spinning®Computer Manual
N/A 1 5 mm Allen Assembly Tool
N/A 1 2 mm Allen Assembly Tool
N/A 1 M6x30 Computer Clamp Screw for Rhino Horn
Before installing the Spinning®Computer, verify that all the parts needed for mounting onto bikes are
included. If any of the items are missing, call Star Trac at 800-503-1221 or 714-669-1660 to order a
replacement kit.
2

Marketing Statement Regarding Heart Rate
Marketing Statement Regarding Heart Rate Acquisition on the Star Trac Spinning®Computer:
Star Trac takes the acquisition and accuracy of heart rate very seriously and has developed a system to perform
to the best ability that technology will allow. Star Trac has engineered a product that has taken every precaution
possible to acquire an accurate heart rate signal as well as eliminate “crosstalk” interference that may be
caused by other monitors being placed too close together.
To achieve the best possible results from your Spinning®Computer, please abide by the following important
parameters:
1) Users must wear either a CodedTransmitter (such as Polar© T61, Polar© T31C or Polar© WearLink®)
or an Ant+ compatible transmitter when operating the Spinner®bike with the Spinning®Computer. Only
the listed transmitters allow a “one to one” relationship with the Spinning®Computer and will minimize
potential “crosstalk” interference. If users wear non-coded straps, there is significantly increased potential for
“crosstalk” which will cause erratic heart rate display, loss of heart rate display and significantly reduce the
consistency of accurate heart rate reporting.
2) Bikes should be spaced so that the side-to-side distance from the Spinning®Computer on one bike and the
Spinning®Computer on bikes to the left or right is at least 36 inches (91.4 cm). In addition, the distance from
the bottom of the Spinning®Computer on one bike to the seat of the bike in front of it (where another rider
and his her transmitter would be seated) should be at least 24 inches (61 cm) in order to significantly reduce
chances for interference. See the diagram on page 5 regarding bike layout.
3

3) In order for the computer to display the user’s heart rate,
the rider must lean into the display within 10” (25 cm) during
the first 30 seconds of the ride and wait for the HR to display.
During this time the Heart Rate icon is rapidly blinking (2 x
per second), showing that the computer is actively searching
for a wireless heart rate. Once a heart rate has been found
the heart rate value is displayed and the HR icon changes to
a slow blink (1 x per second) If no heart rate is found after
30 seconds the console stops searching and no HR will be
displayed.
4) Calorie calculations are displayed as a summary only.
5) Cell phones, televisions, speakers and other electronic
devices can cause interference with the operation if they
are in close proximity to the Spinning®Computer and/or
transmitter.
If there are any questions regarding operation or usage of
the Spinning®Computer, please contact Star Trac Customer
Support at 800-503-1221 or 714-669-1660.
4

Specifications
Computer:
Heart Rate Range:
Battery:
Battery life expectancy:
Cadence Sensor:
Battery:
Battery life expectancy:
Distance to magnet:
Approximately 25”- 30” (63 cm - 76 cm) from computer to users HR chest strap
Qty. 4 AA Alkaline
1 year (depending on use and backlight usage)
Lithium CR2032
Approximately 1 year in a commercial environment (depending on use)
Approximately 5mm
5
At least 36
inches (91.4 cm)
At least 24
inches (61 cm)

How it Works
How does the Spinning®computer work?
The Spinning®computer displays heart rate, RPM (speed), total distance and elapsed time.
• The heart rate (HR) information is received from an Ant+ or Polar®compatible heart rate strap worn by
the person riding the Spinning®Bike. The HR strap sends a radio signal to the computer and the computer
displays the person’s heart rate. If any other strap is used it will not display the heart rate. The computer and
heart rate strap must be within range of each other and no other heart rate strap can be within this imaginary
circle. The range is approximately 25”- 30” (63 cm - 76 cm) from the computer.
•The RPM signal is transmitted by the cadence sensor sending the RPM to the computer. Each time the
magnet on the flywheel passes the cadence sensor it records one revolution and sends this number to
the computer.
6
RPM Heart Rate

Computer Window and Buttons
Start pedaling then press any button to turn on the Spinning®Computer; the following data
will be displayed:
HR- Displays the Heart Rate of the user when wearing a compatible HR telemetry strap in beats
per minute.
RPM- Shows the pedaling speed of the user in revolutions per minute.
Total Distance- Distance measured in miles or kilometers depending on the setup selection.
Elapsed Time – The length of time in minutes from the time the computer has been activated or reset.
Buttons:
Toggle (right) button - Toggles between: Total Distance
and Elapsed Time.
Light (left) button - Turns on the backlight to enable
viewing in low light settings.
7

Installing or Replacing Console Batteries
Time required:
• 5 Minutes
Parts required:
• 4 new AA alkaline batteries
Tools required:
• Slotted or Phillips screwdriver
NOTE:The batteries in the computer will last approximately
1 year depending on usage.The cadence sensor battery will
last approximately 1 year.
1. Remove the computer from the handlebar or computer mounting bracket.
2. Loosen the captive screw on the back of the battery cover (screw will not
completely come off, it will remain captive.) To remove the cover, pull on the
captive screw and lift.
3. Install 4 new batteries.
NOTE: Replace all 4 batteries at the same time.
Low Battery
Indicator
8

Installing or Replacing Batteries – continued
4. Note the directions each battery is to be installed. There is a plus (+) and minus (-) symbol inside the
battery compartment. The + sign indicates the positive (+) side on the battery and the - indicates the
negative (-) side on the battery.
5. Insert each of the 4 batteries into the battery compartment of the computer.
6. Attach the battery cover and tighten the screw.
7. Attach the computer onto the handlebar or computer mounting bracket and test.
9

Do I need to Re-sync?
NOTE: Syncing will not improve heart rate and is not a calibration; it should only be used to Sync (Pair up) the
cadence sensor and the computer so that RPM can be transmitted.
Perform the Syncing process after checking all of the following:
• Is the battery secure in the cadence sensor and the cover tight?
oA loose battery will prevent the cadence sensor from transmitting
the RPM signal to the computer.
• Is the magnet aligned with the cadence sensor?
oA missing magnet or one that is not lined up properly will prevent the
cadence sensor from transmiting the RPM signal to the computer.
oThe cadense sensor LED will blink for the first few revolutions at start up. If
the LED does not blink, check the magnet alignment before changing the batteries.
• Does the computer turn on when you press a button?
oIf the computer does not turn on, replace the batteries in the computer.
• The computer turns on but as you pedal it does not show the RPM.
oIf you have performed all of the above steps, you may now sync the computer and cadence sensor.
This will make them a paired set and will be able to transmit and receive the RPM signal.
10

Time required:
• Less than 5 Minutes
Parts required:
• N/A
Tools required:
• N/A
TEST Procedure:
1. Once the batteries are installed, press any button and the display window will turn on in the
Workout Mode.
2. Test by waving a magnet across the cadence sensor. If you see RPM
values, then the cadence sensor and computer are synced successfully,
there is no need to perform the sync process.
3. If you do not get any RPM reading and the computer turns off, you WILL
need to perform the Syncing process.
NOTE: If the cadence sensor and computer are no longer a pair (i.e. when users swap handlebars with the
computer attached.), the cadence sensor and computer will have to be SYNCED again. Do not swap handlebars.
CAUTION:TEST ONE BIKE AT A TIME;the range for the cadence sensor is approximately 30 feet and
if you are testing the bike and someone else on the same room is pedaling another bike, you may be picking up
the wrong RPM signal.
Testing for RPM
11

Syncing Process:
Time required:
• 30 seconds
Steps to Syncing:
1. Turn on computer and boot up to Workout Mode.
Workout Mode window
CAUTION: SYNC ONE BIKE AT A TIME; the range for the cadence sensor is approximately 30 feet
and if you are testing the bike and someone else on the same room is pedaling another bike, you may be
picking up the wrong RPM signal.
Syncing Mode
12

Syncing Process - continued
13
2. Activate Sync Mode on the computer by holding down the Light and Toggle
buttons for 6 seconds until the window displays “Conn“.
3. Press the button on top of the cadence sensor. Make sure the button
is depressed completely. The red LED will flash indicating the cadence
sensor has entered pairing mode.
NOTE: If the red LED does not flash after you press the button, you may
need to replace the cadence battery.

4. The syncing process is complete when the window on the computer displays a
random ID number (e.g. ID123).
5. The computer will then automatically reboot.
Wait for 5 seconds.
You must wait for 5 seconds to allow the computer to reset the ID properly.
6. Test for response by turning the computer on then waving a magnet across the cadence sensor. By doing
this you are simulating the same motion as when the flywheel rotates and the magnet passes by the
cadence sensor. If you see RPM displayed, then the cadence sensor and computer were synced
successfully. Proceed with the installation and mounting to the bike.
NOTE: Remember to keep the computer and cadence sensor as a set at all times.
Syncing Process - continued
14

Your Spinning®Computer is pre-set with a gear ratio of 3.25:1 and a setting display distance in miles. It is also
pre-set with recommended default settings for the length of time the backlight will stay on when activated
and the length of time summary information will be displayed. You can make changes to these settings by
following the steps below. Any time you want to change settings or view information, follow these Setup Mode
steps again.
To activate Setup Mode:
1. Press any button to activate computer.
2. Wave a magnet along the right side of the Spinning®Computer
until the display window switches to the Gear and Software version.
3. Press the Toggle (right) button to scroll through available setup options.
4. Press the Light (left) button to change settings on the current display option.
Setup Mode options:
• GEAR and Software Version
o Gear Ratio, Select 1 (2.875) for V-Bikes, V2
and Spinner® V
o Select 2 (3.250) for all other models.
o Software Version displayed (-XX)
NOTE: User will not get the correct RPM values if the Gear
Ratio setting is not correct.
Setup Mode
15
(Default Setting)

• Units - MILES or KM
NOTE: User will not get the correct distance values if
the Gear Ratio setting is not correct.
• BLON – (Default Back Light On*) The amount of time the backlight
will stay on when the left button is pressed. Select between 1
second to 60 seconds using the Light (left) button and press the
Toggle (right) button to save and advance to the next setting.
*NOTE: Increasing the BLON (Back Light On) time will reduce
overall battery life. A shorter BLON time will result in longer
battery life (recommended).
• BLU – (Back Light Usage) Total time in minutes that the back light has
been on since the last data clearing. Press the Light (left) button to
clear data, if desired, then press the Toggle (right) button to accept and
advance to the next setting.
Setup Mode - continued
16
(Default Setting)

• UH – (Usage Hours) Total operation time in hours of display since the last
data clearing. Press the Light (left) button to clear data, if desired, then
press the Toggle (right) button to accept and advance to the next setting.
o Usage hours should be reset during battery replacement.
• ODO – Total Miles / KM
Total traveled distance in miles or KM since the last data clearing.
Press the Light (left) button to clear data, if desired then press the
Toggle (right) button to accept and advance to the next setting.
• SON – (Summary ON Time) Number of seconds the summary will be
displayed at the end of the workout.
o Options: 30, 60, 90, or 120 seconds
Select by using the Light (left) button and press the Toggle
(right) button to accept and exit Setup Mode.
5. To exit Setup Mode, press the Toggle (right) button several times until the computer returns
to Workout Mode.
6. Once out of Setup Mode and in the Workout Mode, the computer is ready for use.
Setup - continued Installation of Cadence Sensor and Magnet – All Spinners®
17
