Electrohome DVRC802E User manual

TV/CABLE MODE SELECTION
When shipped from the factory, the TV/CABLE menu option is set to the “CABLE” (Cable Television)
mode.If not using Cable TV, set this menu option to the “TV”position.
ATTENTION
If you purchase a universal remote control from your local retailer, please contact the remote
manufacturer for the required programming code.
DVD-RW RECORDER & VCR
USER MANUAL
ENGLISH
DVRC802E
Before operating the unit, please read this manual thoroughly.
2H6P001A[E] Cover 6/28/05, 5:33 PM1
DRAFT

2
Contents
Setting the screen ...................................................29
TV SCREEN ........................................................29
STILL MODE .......................................................29
LINE1 INPUT .......................................................29
LINE2 INPUT .......................................................29
Setting the image quality.........................................30
BRIGHTNESS .....................................................30
Setting the audio .....................................................30
DRC .....................................................................30
EXTERNAL AUDIO INPUT..................................30
SAP (Second Audio Program) .............................30
Setting the recording ...............................................31
INITIAL REC TO ..................................................31
INITIAL REC MODE ............................................31
AUTO CHAPTER.................................................31
INDEX PICTURE .................................................31
Setting the channel .................................................32
TV/CABLE SELECT ............................................32
AUTO CH MEMORY............................................32
ADD/DELETE (channels) ....................................32
Setting other items ..................................................32
JPEG INTERVAL .................................................32
Disc playback
Playback procedure ................................................33
Playback by selecting a title ....................................34
Checking media information....................................35
Special playback .....................................................36
Fast forward playback ..........................................36
Review playback ..................................................36
Still playback ........................................................36
Frame advance ....................................................36
Slow motion playback ..........................................36
Locating a chapter or track ..................................36
Commercial skip......................................................37
Locating a specific scene ........................................37
Repeat playback .....................................................38
One touch repeat .................................................38
A-B repeat playback ............................................38
Title, Chapter repeat playback .............................38
Title selection ..........................................................39
DVD menu...............................................................39
Changing angles .....................................................40
Zooming ..................................................................40
Karaoke playback....................................................40
Changing soundtrack language ..............................41
Subtitles ..................................................................41
Turning the subtitles On and Off ..........................41
Various operations on CD .......................................42
MP3/WMA/JPEG playback .....................................44
Progressive scan.....................................................47
Before using your unit
CAUTION ..................................................................4
IMPORTANT SAFEGUARDS....................................5
Features ....................................................................8
Disc ...........................................................................9
Handling discs .......................................................9
Discs which can be played back ............................9
Discs on which video can be recorded ................10
Recording format .................................................10
Disc playback in other players .............................11
Parts and functions .................................................12
Front ....................................................................12
Rear .....................................................................12
Display window ....................................................13
Remote control ....................................................14
Power Source ......................................................15
Antenna connections ..............................................16
Cable TV connections .............................................18
Connections with the TV or audio component ........20
Auto clock setting ....................................................22
Setting the video channel........................................22
Various settings
SETUP MENU.........................................................23
Using the SETUP MENU .....................................23
Setting the language ...............................................24
OSD LANGUAGE ................................................24
DVD MENU..........................................................24
AUDIO .................................................................24
SUBTITLE............................................................24
Setting the parental control .....................................25
Selecting parental control ....................................25
Temporarily cancelling parental control ...............25
Setting the clock......................................................26
CLOCK (manually)...............................................26
AUTO CLOCK......................................................26
STANDARD TIME (Time zone) ............................26
DAYLIGHT SAVING TIME ...................................26
Setting the disc .......................................................27
REFORMAT .........................................................27
NEW DISC FORMAT ...........................................27
FINALIZE .............................................................27
PROTECT DISC ..................................................28
UNDO FINALIZE .................................................28
Other (SYSTEM SETUP) ........................................28
DIMMER (Brightness of the display window).......28
DISPLAY/CALL (Turning the screen display
“ON” or “OFF”) ....................................................28
2H6P001A[E] P02-11 6/28/05, 5:33 PM2

3
Contents
: DVD-Video : DVD-R
: DVD-RW inVR mode : Audio CD and CD-R/CD-RW
: DVD-RW inVideo mode :Video tape
Media mark
Each applicable media are indicated using the symbol shown below.
Dubbing
Dubbing a tape onto a disc .....................................76
Dubbing a disc onto a tape .....................................77
Dubbing using other equipment ..............................78
Additional information
Glossary..................................................................79
Language code list ..................................................81
Error/Warning message list.....................................82
Problems and troubleshooting ................................83
Video head cleaning ...............................................84
Specifications ..........................................................85
WARRANTY............................................................86
Tape playback
Loading and unloading a cassette tape ............. 48
Cassette tape playback ...................................... 49
Special playback ................................................ 50
Picture search................................................. 50
Still picture ...................................................... 50
Slow motion .................................................... 50
Frame by frame picture................................... 50
Adjusting tracking condition ............................ 50
Repeat playback ............................................. 50
Commercial skip ............................................. 50
To displayVCR operation status..................... 50
ZERO RETURN function.................................... 51
Video index search system ................................ 51
Recording
Read this before recording on disc .................... 52
Types of disc ................................................... 52
Recording modes ........................................... 52
Disc remaining time ........................................ 53
Images that cannot be recorded ..................... 53
Recording a TV program .................................... 54
One-touch Timer Recording (OTR) .................... 56
Timer recording .................................................. 57
Stereo recording and playback .......................... 60
Editing the disc
Editing the disc................................................... 61
Editing a playlist ................................................. 62
Creating a playlist ........................................... 62
Changing a title name..................................... 63
Erasing a scene (Edit title).............................. 64
Combining the title .......................................... 66
Erasing a playlist............................................. 67
Editing an original title ........................................ 68
Adding a chapter mark ................................... 68
Combining chapters........................................ 69
Changing an original title name ...................... 70
Erasing a scene (Edit title).............................. 71
Erasing an original title ................................... 72
Changing a disc name ....................................... 73
Changing a disc name .................................... 73
Using the keyboard screen ............................. 74
Disc playback
Before using your unit Additional
information
Editing the discVarious settings Tape playback Recording Dubbing
2H6P001A[E] P02-11 6/28/05, 5:33 PM3

4
WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLI-
ANCE TO RAIN OR MOISTURE.
CAUTION: TO PREVENT ELECTRIC SHOCK DO NOT USE THIS POLARIZED PLUG WITH AN EXTEN-
SION CORD, RECEPTACLE OR OTHER OUTLET UNLESS THE BLADES CAN BE FULLY
INSERTEDTO PREVENT BLADE EXPOSURE.
CAUTION:
THIS DIGITAL VIDEO PLAYER EMPLOYS A LASER SYSTEM.
TO ENSURE PROPER USE OF THIS PRODUCT, PLEASE READ THIS USER’S GUIDE CAREFULLY AND
RETAIN FOR FUTURE REFERENCE. SHOULD THE UNIT REQUIRE MAINTENANCE, CONTACT AN AU-
THORIZED SERVICE LOCATION-SEE SERVICE PROCEDURE.
USEOF CONTROLS,ADJUSTMENTSORTHEPERFORMANCE OF PROCEDURESOTHERTHANTHOSE
SPECIFIED HEREIN MAY RESULT IN HAZARDOUS RADIATION EXPOSURE.
TO PREVENT DIRECT EXPOSURE TO LASER BEAM, DO NOT TRY TO OPEN THE ENCLOSURE. VIS-
IBLE LASER RADIATION MAY BE PRESENT WHEN THE ENCLOSURE IS OPENED. DO NOT STARE
INTO BEAM.
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION
The lightning flash with arrowhead sym-
bol, within an equilateral triangle is in-
tended to alert the user to the presence
of uninsulated dangerous voltage within
the product’s enclosure that may be of
sufficient magnitude to constitute a risk
of electric shock to persons.
The exclamation point within an equilat-
eral triangle is intended to alert the user
to the presence of important operating
andmaintenance (servicing)instructions
intheliterature accompanyingtheappli-
ance.
CAUTION: TO REDUCE THE RISK OF ELECTRIC
SHOCK, DO NOT REMOVE COVER (OR
BACK).NO USER-SERVICEABLE PARTS
INSIDE. REFER SERVICING TO QUALI-
FIED SERVICE PERSONNEL.
WARNING: This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation.If this equip-
ment does cause harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is con-
nected.
- Consult the dealer or an experienced radio/TV technician for help.
CAUTION: Changes or modifications not expressly approved by the partly responsible for compliance with the
FCC Rules could void the user’s authority to operate this equipment.
CAUTION
CERTIFICATION: COMPLIES WITH FDA RADIATION PERFORMANCE
STANDARD, 21 CFR SUBCHAPTER J.
Location of the required Marking
The rating sheet and the safety caution are on the rear of the unit.
2H6P001A[E] P02-11 6/28/05, 5:33 PM4

5
1. READ INSTRUCTIONS
All the safety and operating instructions should be read before the unit is operated.
2. RETAIN INSTRUCTIONS
The safety and operating instructions should be retained for future reference.
3. HEEDWARNINGS
All warnings on the unit and in the operating instructions should be adhered to.
4. FOLLOW INSTRUCTIONS
All operating and use instructions should be followed.
5. CLEANING
Unplug this unit from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners.
Use a damp cloth for cleaning the exterior cabinet only.
6. ATTACHMENTS
The manufacturer of this unit does not make any recommendations for attachments, as they may cause
hazards.
7. WATER AND MOISTURE
Do not use this unit near water. For example, near a bathtub, washbowl, kitchen sink, laundry tub, in a wet
basement, or near a swimming pool.
8. ACCESSORIES
Do not place this unit on an unstable cart, stand, tripod, bracket, or table.
The unit may fall, causing serious injury, and serious damage to the unit.
8A. An appliance and cart combination should be moved with care. Quick
stops, excessive force, and uneven surfaces may cause the appliance
and cart combination to overturn.
9. VENTILATION
Slots and openings in the cabinet back or bottom are provided for ventila-
tion, to ensure reliable operation of the unit, and to protect it from over-
heating.
These openings must not be blocked or covered. The openings should
never be blocked by placing the unit on a bed, sofa, rug, or other similar
surface.This unit should never be placed near or over a radiator or heat source.This unit should not be placed
inabuilt-ininstallationsuchasa bookcase or rackunless proper ventilationis providedand/orthemanufacturer’s
instructions have been adhered to.
10. POWER SOURCES
This unit should be operated only from the type of power source indicated on the rating plate. If you are not
sureof the type of powersupplyto yourhome,consult your appliance dealer or local powercompany.Forunits
intended to operate from battery power, or other sources, refer to the operating instructions.
11. GROUNDING OR POLARIZATION
This unit is equipped with a polarized alternating-current line plug (a plug having one blade wider than the
other).This plug will fit into the power outlet only one way.This is a safety feature.If you are unable to insert the
plug fully into the outlet, try reversing the plug. If the plug should still fail to fit, contact your electrician to
replace your obsolete outlet. Do not defeat the safety purpose of the polarized plug, if your unit is equipped
with a 3-wire grounding-type plug, a plug having a third (grounding) pin.This plug will only fit into a grounding-
type power outlet.This too, is a safety feature.If you are unable to insert the plug into the outlet, contact your
electrician to replace your obsolete outlet. Do not defeat the safety purpose of the grounding-type plug.
12. POWER-CORD PROTECTION
Power-supply cords should be routed so that they are not likely to be walked on or pinched by items placed
upon or against them, paying particular attention to cords at plugs, convenience receptacles, and the point
where they exit from the appliance.
13. LIGHTNING
To protect your unit from a lightning storm, or when it is left unattended and unused for long periods of time,
unplug it from the wall outlet and disconnect the antenna or cable system.This will prevent damage to the unit
due to lightning and power line surges.
S3125A
PORTABLE CART WARNING
(symbol provided by RETAC)
IMPORTANT SAFEGUARDS
Before using your unit
2H6P001A[E] P02-11 6/28/05, 5:33 PM5

6
IMPORTANT SAFEGUARDS
14. POWER LINES
An outside antenna system should not be located in the vicinity of overhead power lines or other electric light
or power circuits, or where it can fall into such power lines or circuits. When installing an outside antenna
system, extreme care should be taken to keep from touching such power lines or circuits, as contact with them
might be fatal.
15. OVERLOADING
Do not overload wall outlets and extension cords, as this can result in a risk of fire or electric shock.
16. OBJECT AND LIQUID ENTRY
Do not push objects through any openings in this unit, as they may touch dangerous voltage points or short
out parts that could result in fire or electric shock.Never spill or spray any type of liquid into the unit.
17. OUTDOOR ANTENNA GROUNDING
Ifan outside antenna or cablesystemis connected tothe unit,be sure the antenna orcablesystem is grounded
to provide some protection against voltage surges and built-up static charges, Section 810 of the National
Electrical Code, ANSI/NFPA 70, provides information with respect to proper grounding of the mast and sup-
porting structure, grounding of the lead-in wire to an antenna discharge unit, size of grounding conductors,
location of antenna discharge unit, connection to grounding electrodes, and requirements for the grounding
electrode.
18. SERVICING
Do not attempt to service this unit yourself as opening or removing covers may expose you to dangerous
voltage or other hazards. Refer all servicing to qualified service personnel.
19. DAMAGE REQUIRING SERVICE
Unplug this unit from the wall outlet and refer servicing to qualified service personnel under the following
conditions:
a. When the power-supply cord or plug is damaged.
b. If liquid has been spilled, or objects have fallen into the unit.
c. If the unit has been exposed to rain or water.
d. If the unit does not operate normally by following the operating instructions.Adjust only those controls
that are covered by the operating instructions, as an improper adjustment of other controls may result in
damage and will often require extensive work by a qualified technician to restore the unit to its normal
operation.
e. If the unit has been dropped or the cabinet has been damaged.
f. When the unit exhibits a distinct change in performance, this indicates a need for service.
20. REPLACEMENT PARTS
When replacement parts are required, be sure the service technician uses replacement parts specified by the
manufacturer or those that have the same characteristics as the original part.
Unauthorized substitutions may result in fire, electric shock or other hazards.
21. SAFETY CHECK
Upon completion of any service or repairs to this unit, ask the service technician to perform safety checks to
determine that the unit is in proper operating condition.
22. HEAT
The product should be situated away from heat sources such as radiators, heat registers, stoves, or other
products (including amplifiers) that produce heat.
23. DISCTRAY
Keep your fingers well clear of the disc tray as it is closing. It may cause serious personal injury.
24. CONNECTING
When you connect the product to other equipment, turn off the power and unplug all of the equipment from
the wall outlet. Failure to do so may cause an electric shock and serious personal injury. Read the owner’s
manual of the other equipment carefully and follow the instructions when making any connections.
25. LASER BEAM
Do not look into the opening of the disc tray or ventilation opening of the product to see the source of the laser
beam. It may cause sight damage.
2H6P001A[E] P02-11 6/28/05, 5:33 PM6

7
EXAMPLE OF ANTENNA GROUNDING AS PERTHE
NATIONAL ELECTRICAL CODE
26. DISC
Do not use a cracked, deformed, or repaired disc. These discs are easily broken and may cause serious
personal injury and product malfunction.
27. NOTETO CABLETV SYSTEM INSTALLER
This reminder is provided to call the cable TV system installer’s attention to Article 820-40 of the NEC that
provides guidelines for proper grounding and, in particular, specifies that the cable ground shall be connected
to the grounding system of the building, as close to the point of cable entry as practical.
ANTENNA
DISCHARGE UNIT
(NEC SECTION 810-20)
ANTENNA LEAD IN WIRE
GROUNDING CONDUCTORS
(NEC SECTION 810-21)
GROUND CLAMPS
POWER SERVICE GROUNDING
ELECTRODE SYSTEM
(NEC ART 250, PART H)
GROUND CLAMP
ELECTRIC
SERVICE
EQUIPMENT
S2898A
IMPORTANT SAFEGUARDS
*This product incorporates copyright protection technology that is protected by U.S.patents and other intel-
lectual property rights.Use of this copyright protection technology must be authorized by Macrovision, and
is intended for home and other limited viewing uses only unless otherwise authorized by Macrovision. Re-
verse engineering or disassembly is prohibited.
*Consumers should note that not all high definition television sets are fully compatible with this product and
may cause artifacts to be displayed in the picture. In case of 525 progressive scan picture problems, it is
recommended that the user switch the connection to the “STANDARD DEFINITION” output. If there are
questions regarding ourTV set compatibility with this model 525p DVD player, please contact our customer
service center.
*Manufactured under license from Dolby Laboratories.“Dolby” and the double-D symbol are trademarks of
Dolby Laboratories.
*“DTS” and “DTS Digital Out” are trademarks of Digital Theater Systems, Inc.
* Unauthorized recording of copyrighted television programs, films, video cassettes and other materials may
infringe the rights of copyright owners and be contrary to copyright laws.
Before using your unit
MOISTURE CONDENSATION
DO NOT OPERATE THIS DVD/VCR FOR AT LEAST TWO OR THREE HOURS WHEN MOISTURE IN THE AIR
CONDENSES ONTHE DVD/VCR.
WHAT IS MOISTURE CONDENSATION?
When cold liquid is poured into a glass, for example, water vapour in the air will condense on the surface of the glass.
This is called moisture condensation.
MOISTUREWILL CONDENSE ONTHE UNIT INTHE FOLLOWING CASES;
• When you move this DVD/VCR from a cold to a warm place.
• After heating a cold room or under extremely humid conditions.
WHENYOU EXPERIENCETHE ABOVE CONDITIONS;
Plug the power cord into an AC outlet, set the power switch to ON and leave the unit at room temperature until
moisture condensation disappears.Depending on the surrounding conditions, this may take from two or three hours.
NEC-NATIONAL ELECTRICAL CODE
2H6P001A[E] P02-11 6/28/05, 5:33 PM7

8
Features
Playback function
Title menu
Recording function
Timer recording
The timer recording system allows you to select the
date,timeandchannelandrecordthedesiredprograms.
Up to 12 timer programs within a month can be stored
in this unit.
One-touch Timer Recording (OTR)
The One-touch Timer Recording feature provides a
simple and convenient way to make a timed recording.
Edit function
Editing recorded material without changing
the original titles
You can create a playlist based on the original titles.
The playlist won’t affect the original titles. If you erase
theplaylist, the originaltitles remain.It is recommended
to create and edit the playlist to prevent important titles
from being erased accidentally.
Chapter mark
You can add (or delete) a chapter mark to (from) the
original title.This function is useful when searching for
thescene you wish to watch that you have marked with
the Chapter mark function.
Erasing scenes
You can erase an unnecessary scene from the created
playlist or the original titles.
Combining titles
You can combine several original titles or playlists to a
separate playlist.
Dubbing function
Dubbing a tape onto a disc or a disc onto a
tape
MP3/WMA/JPEG playback
MP3 and WMA files can be played back. Also, you can
display JPEG files on theTV screen and enjoy them as
a slide show.
Progressive scan
This unit supports the progressive scanning system. If
your TV is equipped with component video input jacks
which support the progressive video input, you can
enjoy high quality picture.
Thumbnailimage willnot appearafter finalizing DVD-
RW (recorded in theVideo mode) and DVD-R.
•
•Dubbing cannot be carried out when attempting to
copy a “copy guarded” video tape or disc.
Not only can you playback and record video tapes, but
you can also playback DVD discs or make recordings
using DVD-RW, DVD-R discs with this unit.In addition,
you can enjoy editing the programs you record.
A realistic, powerful, Movie Theater sound
When connected to Dolby Digital and DTS compliant
devices, you can enjoy realistic, powerful surround
sound.
Playback the scene you want to see immediately
As DVD’s do not require rewinding like video tapes, you
can get to the scene you wish to watch immediately. A
variety of search functions allow you to find the scene
you wish to watch.
As thumbnail images are displayed in the title menu,
you can find the title you want to play back quickly.
With just this one unit, you can dub however you like,
from video tape to disc, or from disc to video tape.
2H6P001A[E] P02-11 6/28/05, 5:33 PM8

9
Disc
Region management information
This unit is designed and manufactured to support the
region management information that is recorded on a
DVD disc.If the region number written on the DVD disc
does not correspond to the region number of this unit,
this unit cannot play that disc.
• The region number of this unit is “1”.
• The unit will play DVD-Video discs marked with la-
bels containing “1” or “ALL”.
Example:
1
Operating DVD-Video
• Some operations of DVD-Video may be prohibited
by the manufacturer, or some operation methods or
functions of the DVD-Video may be different from the
description in this manual.
• If you attempt an operation that is prohibited by ei-
therthe disc or the unit, a“ ”mark will appearon the
TVmonitor.Foroperationsprohibitedbythe disc,see
the information that came with the disc.
• When the menu screen or the operation guide ap-
pears during disc playback, follow the displayed in-
formation.
Discs which cannot be played back
The discs listed below cannot be played back in gen-
eral. Even if one of these can be played back, it may
not be played back correctly.If a disc is played back by
mistake, extensively loud sounds may blow the speak-
ers or may damage the hearing of those in hearing
range.Do not playback the discs listed below.
CDG, Photo-CD, CD-ROM, CD-TEXT, CD-EXTRA,
VCD,SVCD,SACD, PD,CDV,DVD-ROM,DVD-RAM,
DVD+R/RW, DVD audio, etc.
The below DVD-Video may not be played back.
• DVD-Video that do not have the region number“1”or
“ALL”.
• PAL or SECAM DVD-Video.
• Prohibited or business-use DVD-Video.
Use only CD-R discs and CD-RW discs - all other CD
discs will not work in this unit.
CD-R/CD-RWs cannot be played back for the follow-
ing reasons.
• Compatibility of the disc and this unit.
• Compatibility of the disc and the recorder used.
• Unfinalized discs.
Do not playback the following discs. Playback of
these discs may cause a failure.
• Discs on which paper, labels or stickers are affixed.
• Discs that have sticky areas left by adhesive tape.
• Special-shaped discs.
* This unit is designed to playback music Compact Discs (CD) that
conform to the CD standard.CDs that contain (copy-restriction) sig-
nals to protect copyrights cannot be played back.
Media type Logo mark
DVD-Video
DVD-RW Ver.1.0 Ver.1.1Ver.1.2
Ver.1.1 CPRM support
DVD-R Ver.2.0 (Ver.2.0/4x/8x)
Audio CD*
CD-R/CD-RW
l
Before using your unit
Handling discs
Removing the Disc from its case
Be sure to hold the disc by its edges. Do not touch the
surface of the disc.
Take the disc carefully from its case.
• Do not scratch the disc.
• Do not get dirt on the surface of the disc.
• Do not stick labels or adhesive tapes on the disc.
• Do not drop or bend the disc.
Storing discs
• Store the disc in the case to avoid any risk of
scratches, dirt or damage.
• Do not leave the disc exposed to direct sunlight or in
hot or humid places.
Cleaning discs
Wipe the disc with a clean, dry cloth from the center
outward toward the edges.
• Do not wipe the disc in a circular motion around the
center.
• Do not use liquid or aerosol cleaners.
Discs which can be played back
In this unit, use only discs that meet the standard, such
as those bearing the below logo marks on the disc label
surface.If you use a non-standard disc, we cannot guar-
antee playback.Even if such a disc can be played back,
we cannot guarantee the image or sound quality.
The DVD logo is a registered trademark.
2H6P001A[E] P02-11 6/28/05, 5:34 PM9

10
Recording format
This unit has two modes for formatting discs for record-
ing:VR mode and Video mode.
When a blank, new disc is loaded into this unit, the au-
tomatic format function starts to format the disc. (For
the disc format setting in this step, see page 27.)
VR mode
• This mode can be used for DVD-RW.
• In this mode, the discs can be recorded and edited
repeatedly.
• The disc recorded in this mode can be played back
with other DVD-RW-compatible players.
• When a Ver.1.1 CPRM or Ver.1.2 disc is used, you
can record a “Copy Once” program (see page 53).
Video mode
• This mode can be used for DVD-R and DVD-RW
(Ver.1.1/1.2).
• When you finalize the disc after recording, the disc
recorded with this unit can be played back with other
DVD players.
• Recording, editing or playback of an unfinalized disc
can be done only with this unit. However, there are
some limitation to editing operations.
• In this mode, you cannot record a “Copy Once” pro-
gram (see page 53).
• When you record a TV program of a bilingual broad-
cast, only one of the audio modes can be recorded.
You have to select it.
Format modes that can be used each disc
Theusableformat dependsonthe media type asshown
in the below table.
Disc
Discs on which video can be re-
corded
To record video with this unit, use the discs below:
DVD-RW
• The disc can be erased and used again about 1,000
times.
• Only theVR mode can be used for Ver.1.0 discs.
• With Ver.1.1/1.2 discs, you can record by selecting
the VR mode or Video mode.
• When you record in the VR mode, you can repeat-
edlyrecord and erase.By erasingunnecessarytitles,
you effectively increase remaining time.
• When you record in the Video mode, you can record
until the disc becomes full.
• Whenyouuse theVideo mode,youcannewlyrecord
on the disc by formatting the disc. However, if the
disc is formatted, all the recorded contents will be
erased.
DVD-R
• You can record on the disc only in the Video mode.
• You can record until the disc becomes full.
• Finalizing the discs allows playback on other DVD
players. However, the finalized discs can no longer
be recorded.
• Discs can be recorded to repeatedly until they are
finalized.
NOTES:
• There are some players that cannot playback discs
that were recorded with this unit.We cannot guaran-
tee the playback with other units.
• Thisunitcannot record onDVD-R and DVD-RWdiscs
that are 8 cm in diameter.
• This unit cannot record on CD-R or CD-RW.
Media type Format
DVD-RW
(Ver.1.0)
DVD-RW
(Ver.1.1 and
1.2)
DVD-R
(Ver.2.0/4x/8x)
Available functions
VR mode
VR mode
Video mode
Video mode
Playback,recording and
editing(Original/playlist)
Playback, recording and
editing(Original/playlist)
Playback and recording
Editing (with limitation)
Playback and recording
Editing (with limitation)
Media type Logo mark
DVD-RW Ver.1.0 Ver.1.1 Ver.1.2
Ver.1.1 CPRM support
DVD-R Ver.2.0 (Ver.2.0/4x/8x)
2H6P001A[E] P02-11 6/28/05, 5:34 PM10

11
Disc
CHAPTER 1
TITLE 1 TITLE 2
DVD DISC
CHAPTER 2 CHAPTER 2 CHAPTER 3CHAPTER 1
Title/Chapter/Track
A DVD-Video has large partitions called “Titles”, and
smaller partitions within them called “Chapters”.
Amusic CD has other partitions called“Tracks”.A num-
ber is allotted to each partition and these numbers are
called“titlenumbers”,“chapter numbers”or“tracknum-
bers”.
When recording in theVR mode
One-time recording is set to 1 title (1 chapter). How-
ever, if you stop recording temporarily or erase scenes
byediting, the chapter will automatically bepartitioned.
The interval between chapters can be specified. (See
page 31.)
When recording in theVideo mode
One-time recording is set to 1 title.In recording, chap-
ters are set automatically. The interval between chap-
ters can be specified. (See page 31.)
NOTES:
• The title, chapter and track are numbered, but some
discs may not record the numbers.
• Recordingon DVD-R/RWin theVideo mode is a new
standard approved at the 2000 DVD forum. Confor-
mity to this standard varies with each DVD player
manufacturer. Some models of DVD player or DVD-
ROM drive, therefore, will not playback recorded vid-
eos.
Disc playback in other players
A disc recorded in this unit can be finalized. The disc
can be played back in other players that can playback
DVD-RW and DVD-R.
For more information on finalization, see“FINALIZE”in
“Setting the disc” (page 27).
When recording in theVR mode
Even if a disc recorded in theVR mode is finalized, you
can record or edit by cancelling the finalization. (See
“UNDO FINALIZE” on page 28.)
When you playback the disc with another player, make
sure that the DVD player supports DVD-RW and bears
the following mark.
When recording in theVideo mode
When a disc recorded in theVideo mode is finalized, it
cannot be recorded onto any more.Therefore, before
finalization, be sure to perform all desired recording.
Afterfinalization, a title list that can be used bytheDVD
player is automatically created.
NOTES:
• The finalization process may require from a few min-
utes up to 1 hour depending on the disc type and the
amount of free space on the disc.
• A DVD-RW Ver.1.1/1.2 recorded in the Video mode
cannot be recorded or edited after finalization, but if
you format the disc by erasing all the content, you
can again record on this disc.
• A finalized disc may not play because of the condi-
tion of the DVD or the compatibility with the player
used for playback.
• Some players may not playback the discs recorded
with this unit.We cannot guarantee the playback us-
ing other players.
TRACK 1 TRACK 2 TRACK 3 TRACK 4 TRACK 5
Audio-CD
Before using your unit
2H6P001A[E] P02-11 6/28/05, 5:34 PM11

12
Parts and functions
Rear
Front
AC power cord DVD COAXIAL DIGITAL
AUDIO OUT jack
DVD/VCR common
AUDIO (L/R)/VIDEO OUT jacks
DVD AUDIO (L/R)
OUT jacks
DVD/VCR common
AUDIO (L/R)/VIDEO
IN (LINE 1) jacks
S-VIDEO
IN (LINE 1) jack
DVD/VCR common
S-VIDEO OUT jack
DVD COMPONENT
OUT jacks
DVD OPTICAL DIGITAL
AUDIO OUT jack
RF IN jack
RF OUT jack
POWER button
AUDIO (L/R)/VIDEO
IN (LINE 2) jacks EJECT button
DVD S-VIDEO IN (LINE 2) jack
VCR/DVD button
OPEN/CLOSE button
PLAY button
STOP button
FF (Fast Forward) button
REW (Rewind) button
REC/OTR button
CHANNEL /buttons
Disc tray
Cassette Loading Slot
VCR indicator
DVD indicator
Display window
2H6P001A[E] P12-21 6/28/05, 5:34 PM12

13
No. Display Description
Lights during video tape playback.
1
Parts and functions
NOTE:
Some discs may not playback correctly, or chapter number, playback time, etc may not be displayed.
Display window
Video tape is temporarily stopped.
Lights during video tape recording.
Progressive scanning mode.
Timer recording display.
P
P
2
1 3
4
2
4
Appears when a CD is inserted.
Appears when a CD-R is inserted.
Appears when a DVD-Video is inserted.
Appears when a DVD-R is inserted.
Appears when a DVD-RW is inserted.
Appears when a DVD-RW inVR mode is inserted.When the disc is set to video mode,VR does not appear.
Video tape is in the unit.
Clock display (Colon [ : ] flashes).
Counter display in hour/minute/second for VCR/DVD, minute/second for CD.
Cable TV channel display.
TV channel display.
Track number display for CD.
Display for afternoon (out in the morning).
The external input channel (L1 or L2) display.
Error display.
Lights during playback of DVD and CD. Flashes in auto resume.
DVD or CD is temporarily stopped.
Lights during DVD recording.
CD
CD-R
DVD
DVD-R
DVD-RW
VR
10:00
01H00M00S
C 36CH
2CH
TRK 002
PM
L1/L2
Err
3
4 DVD recording modes.XP, SP, LP or SLP can be selected in turn by pressing the REC MODE/SPEED repeatedly.
2VCR recording modes.SP or SLP can be selected in turn by pressing the REC MODE/SPEED repeatedly.
SP/SLP
XP/SP/LP/SLP
Before using your unit
Appears when a CD-RW is inserted.
CD-RW
Appears when the tuner built into this unit is not selected.When you pressTV/VIDEO disappears.
TV
2H6P001A[E] P12-21 6/28/05, 5:34 PM13

14
Remote control Page
Parts and functions
POWER Turns power on/off 22
EJECT Ejects the cassette tapes 48
OPEN/CLOSE Opens or Closes the tray. 33
DVD/VCR
Switches to operation between VCR and DVD 33, 49, 76, 77
0-9 Direct channel selection of TV 54
Setting input 37, 74
Entering a password 25
TIMER REC Sets the unit to start recording at a preset time 59
INPUT SELECT Switches between the external inputs 78
DISPLAY DisplaysVCR or DVD operation status 35, 51
RETURN Close the menu window 23, 45
CANCEL Deletes the Timer recording program 59
Cancels input data in the setting mode 25
TITLE MENU/TOP MENU Selects titles of a DVD disc 34, 39, 42, 62
CH / Channel selection for the connectedTV or VCR 54
/ Cursor buttons 23, 33, 37, 57
TRK +/– Manual tracking in the playback mode for VCR 50
/ Cursor buttons 33, 37
ENTER Option selection in the menu 23, 33, 37, 57
DVD MENU Displays the menu of the DVD disc 39
SETUP Displays the setup menu 23, 57
STOP Stop 33, 49, 55
PLAY Playback 33, 49
PAUSE/STILL Still picture/Recording pause on/off 36, 50
SKIP / Skips chapters in the forward or reverse direction 36
INDEX – /+ Searches for the INDEX mark of a tape 51
REW/SEARCH –Rewind/Review playback 36, 49, 50
F.FWD/SEARCH +Fast Forward/Forward search playback 36, 49, 50
ONE TOUCH REPEAT Repeats playback between the section played
10 seconds before and present section 38
CM SKIP Skips commercial breaks 37, 50
SLOW Slow motion playback 36, 50
REC/OTR Recording 54, 56, 78
REC MODE/SPEED Selects the recording mode 54, 56
DUBBING Copies VCR to DVD or DVD to VCR 76,77
AUDIO/AUDIO SELECT Switches sound between mono and stereo 60
Changes the language of the DVD 41
ZOOM Zoom 40
REPEAT A-B Repeats playback between A and B 38
ZERO RETURN Stops the tape when the counter reaches 00
H
00
M
00
S
51
ANGLE Changes playback angle 40
COUNTER RESET Resets the counter to 00H00M00S51
SUBTITLE Selects subtitles of the DVD disc 41
ATR Digital AUTO TRACKING 50
PLAY MODE Selects the playback mode 37
REPEAT Repeats playback 38, 50
CLOCK/COUNTER Changes the front panel display mode 51
TV/VIDEO Switches input between the TV and VCR 22, 55
PROGRESSIVE Activates the progressive scanning mode 47
2H6P001A[E] P12-21 6/28/05, 5:34 PM14

15
Inserting Batteries into the Remote Control:
Parts and functions
3Replacethecompartmentcover.
2Install two “AAA” batteries (not
supplied),payingattention tothe
polarity diagram in the battery
compartment.
1Open the battery compartment
cover in the direction of the ar-
row.
Battery precautions
The precautions below should be followed when using batteries in this device:
1.Use only the size and type of batteries specified.
2.Be sure to follow the correct polarity when installing the batteries as indicated in the battery compartment.
Reversed batteries may cause damage to the device. To avoid a potential short circuit, insert the “–”end first.
3.Do not mix different types of batteries together (e.g. Alkaline and Carbon-zinc) or old batteries with fresh ones.
4.If the device is not to be used for a long period of time, remove the batteries to prevent damage or injury from
possible battery leakage.
5.Do not try to recharge batteries not intended to be recharged; they can overheat and rupture. (Follow battery
manufacturer’s directions.)
Remote control basics
•Press POWER to turn the DVD/VCR on or off.
•Press CH or CH to move through the channels one channel at a time.
•The / / / are also used to navigate on-screen menu system.
•You can directly access specific channels using numeric keys.
• Each press of DVD/VCR, switches the screen between the DVD screen (DVD mode) and theVCR screen (VCR
mode).
Operation
• Aim the remote control at the remote sensor and press control buttons to op-
erate.
• Operate the remote control within 30°angle on either side of the remote sen-
sor, up to a distance of approximately 5 meters (15 feet).
Polarized AC Cord Plug
(One blade is wider than the other.)
AC Outlet
Wider Hole
and Blade
Power Source
TO USE AC POWER SOURCE
Use the AC polarized line cord provided for operation on AC. Insert the AC
cord plug into a standard 120V 60Hz polarized AC outlet.
NOTES:
• Never connect the AC line cord plug to other than the specified voltage
(120V 60Hz). Use the attached power cord only.
• If the polarized AC cord does not fit into a non-polarized AC outlet, do not
attempt to file or cut the blade. It is the user’s responsibility to have an
electrician replace the obsolete outlet.
• If you cause a static discharge when touching the unit and the unit fails to
function,simply unplug the unit from the ACoutlet andplug it backin.The
unit should return to normal operation.
Before using your unit
30°30°Approx.5 meters (15 feet)
2H6P001A[E] P12-21 6/28/05, 5:34 PM15

16
NOTES: • A clear picture will not be obtained by the DVD/VCR unless the antenna signal is good. Connect the
antenna to the DVD/VCR properly.
•For better quality recording, an indoor antenna or a telescopic antenna is not recommended.The use
of an outdoor type antenna is required.
•If you are not sure about the connection, please refer to qualified service personnel.
If you are using an antenna system,follow these instructions. If you are a cableTV subscriber, skip ahead
to page 18 for the proper connections.
ANTENNATO DVD/VCR CONNECTION
The DVD/VCR must be connected “between” the antenna and the TV. First, disconnect the antenna from the TV
and connect it to the DVD/VCR.Then connect the DVD/VCR to the TV.Below are 3 common methods of connect-
ing an antenna system to a DVD/VCR. Find the type of antenna system you are using and follow the connection
diagram.
If both UHF and VHF antennas have 300 ohms twin lead (flat) wires,
use a combiner having two 300 ohms inputs and one 75 ohms output.
NOTE:
Antenna connections
Combination UHF/VHF antenna with 75 ohms coaxial cable
Combination UHF/VHF antenna with 300 ohms twin lead (flat) wire
Separate UHF and VHF antennas
1
2
3
DVD/VCR
300 ohms twin lead (flat) wire
75
(su
Matching transformer
300 ohms input
75 ohms output
(not supplied)
DVD/VCR
300 ohms twin lead (flat) wire
75 ohms coaxial cable
UHFVHF
75
(su
Combiner
75/300 ohms input
75 ohms output
(not supplied)
DVD/VCR
75 ohms coaxial cable 75
2H6P001A[E] P12-21 6/28/05, 5:34 PM16

17
NOTE: If a UHF or VHF antenna is used,
set the TV/CABLE menu option
to the “TV” mode.
TV with single 75 ohms UHF/VHF an-
tenna input
NOTE: If aUHForVHF antenna is used,
set the TV/CABLE menu option
to the “TV” mode.
TV with 300 ohms UHF and 75 ohms
VHF antenna inputs
NOTE: If a UHF or VHF antenna is used,
settheTV/CABLE menuoptionto
the “TV” mode.
TV with 300 ohms UHF and 300 ohms
VHF antenna inputs
DVD/VCRTOTV CONNECTION
After you have connected the antenna to the DVD/VCR, you must connect the DVD/VCR to theTV.
Below are 3 common methods of connecting your DVD/VCR to a TV.Find the type of TV you are using and follow
the connection diagram.
This DVD/VCR has a single 75 ohms output for connection to aTV. If yourTV has separate UHF andVHF antenna
inputs (numbers 2 and 3 below), use a splitter to connect the DVD/VCR to theTV for UHF andVHF reception.
Antenna connections
Before using your unit
UHF
VHF
TV
75 ohms coaxial cable
(supplied)
Splitter
75 ohms input
75/300 ohms outputs
(not supplied)
UHF
VHF
TV
75 ohms coaxial cable
(supplied)
Splitter
75 ohms input
300 ohms outputs
(not supplied)
UHF/VHF IN
TV
75 ohms coaxial cable (supplied)
2H6P001A[E] P12-21 6/28/05, 5:34 PM17

18
UHF/VHF
IN (ANT)
TV
DVD/VCR
Incoming cable
Converter/
descrambler
UHF/VHF
IN (ANT)
TV
DVD/VCR
Incoming
cable
Converter/
descrambler
Many cable TV companies offer services permitting reception of extra channels including pay or subscription
channels.This DVD/VCR has an extended tuning range and can be tuned to most cable channels without using a
cable TV company supplied converter box, except for those channels which are intentionally scrambled. If you
subscribe to a special channel which is scrambled, you must have a descrambler box for proper reception.
CableTV connections
NOTE: Whenevera converter/descramblerboxis placed beforetheDVD/VCR, you must tune the DVD/VCR to the
output of the converter/descrambler box, usually channel 3 or 4.
ALLOWS: • Recording of nonscrambled channels.
•Use of the programmable timer.
•Recording of one channel while watching another.
ALLOWS: • Recording of channels through the converter box
(scrambled and unscrambled).
•Using the programmable timer to record only the
channel selected at the converter box.
PREVENTS: • Recording one channel while watching another.
•Using the DVD/VCR tuner to select channels.
1
2
3
ALLOWS: • Recording of nonscrambled channels.
•Use of the programmable timer.
•Recording an unscrambled channel while watch-
ing any channel selected at the converter box.
PREVENT: Recording scrambled channels.
NOTE:
If you are playing a tape or using the
tuner built into the DVD/VCR, the con-
verter must be set to the video channel
output of the DVD/VCR (either 3 or 4).
NOTE:
To record from converter/descrambler,
DVD/VCR tuner must be tuned to the
converter outputchannel, usually chan-
nel 3 or 4.
UHF/VHF
IN (ANT)
TV
DVD/VCR
Incoming cable
2H6P001A[E] P12-21 6/28/05, 5:34 PM18

19
UHF/VHF
IN (ANT)
TV
DVD/VCR
Incoming
cable
Splitter
Converter/descrambler
A/B switch
UHF/VHF
IN (ANT)
TV
DVD/VCR
Incoming
cable
Splitter
Converter/
descrambler
A/B switch
IMPORTANT: Make sure the TV/CABLE menu option is set to the“CABLE” mode.
ThisDVD/VCR cannot receivescrambledprogramssinceit does not contain a descrambler.In order toreceivescrambled
programs, your existing descrambler must be used. Descrambler boxes are available from cable companies.Consult your
local cable company for more information concerning connection to their descrambler equipment.There are many ways
to connect your DVD/VCR to a cable system. Below are six common methods of connection.
4
5
6
ALLOWS: • Recording of one channel while watching another.
•Using the programmable timer to record only the channel selected at the converter box.
•Recording of all channels through the converter box.
PREVENTS: • Watching scrambled channels while recording another channel.
•Using the DVD/VCR tuner to select channels.
ALLOWS: •Recording of nonscrambled channels.
•Recording of one channel while watching another.
•Watching premium channels through the converter while recording nonscrambled channels.
•Using the programmable timer.
PREVENT: Recording scrambled channels.
ALLOWS: • Recording of all channels through the converter box.
•Recording a scrambled or unscrambled channel while watching another (scrambled or
unscrambled) channel.
•Using the programmable timer to record only the channel selected at the converter box.
PREVENT: Using the DVD/VCR tuner to select channels.
CableTV connections
UHF/VHF
IN (ANT)
TV
DVD/VCR
Incoming
cable
Splitter
Converter/descrambler
A/B switch
Converter/
descrambler
Before using your unit
2H6P001A[E] P12-21 6/28/05, 5:34 PM19

20
Connections with theTV or audio component
The exact arrangement you use to interconnect various video and audio components to the DVD/VCR is depen-
dent on the model and features of each component.Check the Owner’s Manual provided with each component for
the location of video and audio inputs and outputs.
Connect to aTV with Audio/Video output
You can enjoy playback by connecting the unit to aTV.
Connect the unit to aTV equipped with audio input (L/R) and video input jacks using the supplied audio/video cable.
Connect to aTV with S-Video output
IfyourTV has an S-Video input,youcan gethigher quality by connectingit with the S-Video output of the unit using
the S-Video cable instead of connecting the video input of the TV to the video output jack of the unit.
Connect to aTV with Component video output (for DVD/CD playback)
You can enjoy the highest quality picture by connecting the unit’s component video out jacks to the component
video input jacks of your TV, with component video cables (not supplied).
NOTES:
• When connecting to a TV using the video or S-Video jack, make sure that the progressive indicator on the
display window is not lit.If it is lit, the video and S-Video outputs do not feed the correct signals and you cannot
see any picture.To turn off the progressive indicator, make the progressive scanning mode inactive (see page
47).
• If the component video input jacks on aTV are the BNC type, use an adapter to convert the RCA jacks from the
component video cables to BNC (not supplied).
To Audio (R) input
Audio/video cable (supplied)
Audio (R) output
To Audio (L) input
Audio (L) output
To Video input
Video output TV
DVD/VCR
To Audio (R) input
Audio cable (not supplied)
DVD audio (R) output
DVD audio (L) output
S-Video output
To S-Video
input
S-Video cable (not supplied)
To Audio (L) input
TV
DVD/VCR
To Audio (R) input
Audio cable (not supplied)
DVD audio (R) output
To Audio (L) input
DVD audio (L) output
TV
DVD/VCR
Component video cable (not supplied)
Component video output
To Component
video input
2H6P001A[E] P12-21 6/28/05, 5:34 PM20
