Electrolux EHTAIMLAU User manual

Electrolux Dishwashing
Medical Line Hood Type
The Electrolux Dishwashing range is produced for customers with the highest conceivable demands for good
efficiency, economy and ergonomics for dishwashing operation. The product range comprises glasswashers,
undercounter dishwashers, hood type dishwashers, rack type dishwashers, flight type dishwashers and pot
and pan washers. The hood type dishwasher range consists of units with different voltages and has a capacity
of 17 baskets per hour. The model has an insulated hood and automatic hood lifting.
504236
SANITIZATION AND
PERFORMANCE
• The atmospheric boiler
combined with the rinse booster
pump for perfect rinsing
performances in terms of quality,
high water temperature and
pressure, always constant at 84°C
during rinsing phase, independent
from the water pressure of the
network (with a minimum of 0.5
bar).
• 4 second (variable) pause after
washing and before rinsing
ensures that no drops of unclean
water will fall on the clean items at
the end of the rinsing cycle.
• 4 different dishwashing cycles:
glass and lightly soiled items (1st
cycle of 210 seconds), standard
soiled items (2nd cycle of 270
seconds), heavy soiled items (3rd
cycle of 390 seconds) and the
continuous program.
• Simple control panel with digital
thermometers, indicationg both
wash & rinse temperatures, rinse
aid dispenser.
• Electronic board with digital
display incorporating fault
diagnosis system, number of
cycles counter and number of
drain cycles counter.
• Thermal disinjection thanks to
the special rinsing condition of 30
seconds at 85°C, measured on the
items in the basket (not in the
boiler) in order to meet strict
hospital requirements.
• Double skinned insulated hood
ensures a low noise level and a
reduction in heat loss from the
machine.
• Fault auto-diagnosis system.
HYGIENE AND RELIABILITY
• Large deep drawn wash tank
and internal wash area with round
corners and no pipes to avoid dirt
built-up.
• Easily removable washing and
rinsing arms, filters and rack
support.
• All the machines have smooth
surfaces and a wash tank with
rounded corners to facilitate
cleaning.
• Safety devices prevent the hood
from suddenly closing in case of
spring breakage, thus avoiding
operator injury.

Electrolux Dishwashing
Medical Line Hood Type
Internet: http://www.electrolux.com/foodservice
IDC0102010-05-28Subject to change without notice
Convertible to 230 V / 3 / 50 Hz
Supply voltage 400 V, 3N, 50
Net weight - kg. 130
Noise level - dBA <63
total power 12.1
Rinse pump 0.35
Power - kW
water consumption lt./h 8.3
Rinsing
Boiler elements - kW 10.5
Boiler capacity - lt. 12
water consumption - lt./cycle 8.3
temperature during rinse - °C 90
duration - sec. 35
Hot rinse cycle
electrical elements - kW 3
power pump - kW 1.5
tank capacity - lt. 42
temperature -°C 65
Washing cycle
height 409
depth 560
width 590
Cell dimensions - mm
height 1560
depth 756
width 735
External dimensions - mm
Door/hood thickness Double
Basket capacity/h 17
Dishes capacity/h 308
Duration cycles - sec. 210/270/390/inf
N° of cycles 4
Rinse aid dispenser ●
Automatic lifting ●
Rinse Booster Pump ●
hardness - °f 7-14
temperature - °C 50
Water supply
TECHNICAL DATA
EHTAIMLAU
504236
• The fully automatic self-cleaning
cycle avoids the risk of bacteria
proliferation.
• The self-draining wash pump
and the boiler facilitates the
evacuation of stagnant water after
long periods of inactivity to ensure
a higher level of hygiene.
• Load bearing frame height
adjustable feet, hood, tank,
washing and rinsing arms, jets and
screws in 304 AISI stainless steel
to ensure long term reliability.
• High efficiency air gap (class A)
in water inlet circuit to avoid water
being siphoned back into the
network as a result of a sudden
drop in main pressures.
• 304L stainless steel boiler with
higher welding protection
improves the resistance against
corrosion by chlorinated water.
• PVC water supply hose with
metal connections resistant to
high water pressure.
• The IPX5 water protection.
• Pre-arranged for on-site HACCP
implementation and Energy
Management device.
FLEXIBILITY AND ERGONOMICS
• The incorporated Soft Start
feature offers additional protection
to delicate items such as
glassware and crockery and
increases wash pump reliability.
• Suitable to be connected to
specific pre-wash tabling, service
entry and exit tabling and roller
conveyor tabling – included in
Electrolux Professional Handling
System range.
• More ergonomic operation
thanks to the Automatic hood
lifting, with a button on the control
panel to close the hood which will
automatically open when the cycle
finishes.
• Open hood on the back side to
prevent steam blasts to the
operator.
• All machines are pre-arranged to
accept external dispensers.
EASY ON THE ENVIRONMENT
• 97% recyclable by weight.
• CFC free packaging.
• Low noise level.
• Developed and produced in ISO
9001 and ISO 14001 certified
factory.
• In compliance with H
requirements.
* Duration cycles: declared actual
cycle duration times can extend
when water supply temperature is
lower than indicated.

Electrolux Dishwashing
Medical Line Hood Type
Internet: http://www.electrolux.com/foodservice
IDC0102010-05-28Subject to change without notice
YELLOW CUTLERY CONTAINER 864242
STAINLESS STEEL INLET HOSE KIT 864016
RINSE AID LEVEL PROBE KIT FOR UC+HT DW 864005
KIT TO MEASURE TOTAL/PART.WATER HARDNESS 864050
KIT HACCP EKIS 922166
KIT 8 PLASTIC BOXES FOR CUTLERY-YELLOW 780068
KIT 4 PLASTIC BOXES FOR CUTLERY-YELLOW 865574
INTEGRATED HACCP KIT FOR UC, HT AND POTW 864001
HACCP PRINTER KIT FOR UC, HT AND POTW 864002
FILTER FOR TOTAL DEMINERALIZATION 864015
FILTER FOR PARTIAL DEMINERALIZATION 864017
EXT.REVERSE OSMOSIS FILT-ATMOSPH. BOILER 864026
DRAIN PUMP KIT FOR 50HZ DISHWASHERS 864199
DETERGENT PUMP KIT 864218
DETERGENT LEVEL PROBE KIT FOR UC+HT DW 864004
COVER GRID FOR SMALL/LIGHT ITEMS IN RACK 867016
BRASS INLET VALVE KIT FOR UC AND HT 864000
BASKET SEMI-PROFESSIONAL 500X500X190MM 867024
BASKET FOR BULK CUTLERY-BROWN 867009
BASKET FOR 6 TRAYS 530X370MM-RED 866743
BASKET FOR 48 SMALL CUPS/24 CUPS-BLUE 867007
BASKET FOR 18 DINNER PLATES 240MM-YELLOW 867002
BASKET FOR 12 SOUP BOWLS 240MM-GREEN 867000
BASKET F.16 VERTIC.GLASSES (H70MM)-BLUE 867023
8 L EXTERNAL AUTOMATIC WATER SOFTENER 860413
304 AISI BACK PANEL FOR HT AUTO.TOP LEV. 864308
20 L EXTERNAL MANUAL WATER SOFTENER 860430
12 L EXTERNAL MANUAL WATER SOFTENER 860412
ACCESSORIES
YELLOW CUTLERY CONTAINER 2
BASKET FOR 48 SMALL CUPS/24 CUPS-BLUE 1
BASKET FOR 18 DINNER PLATES 240MM-YELLOW 1
INCLUDED ACCESSORIES
EHTAIMLAU
504236

Electrolux Dishwashing
Medical Line Hood Type
Internet: http://www.electrolux.com/foodservice
IDC0102010-05-28Subject to change without notice
XR - Connection for detergent dispenser ●
HWI - Hot water inlet G 3/4"
EQ - Equipotential Screw ●
EI - Electrical connection 400 V, 3N, 50
D - Water drain 40mm
LEGEND
EHTAIMLAU
504236
504236
