Electrolux ESF2300DW User manual

ESF2300DW
EN Dishwasher User Manual

CONTENTS
1. SAFETY INFORMATION....................................................................................2
2. SAFETY INSTRUCTIONS..................................................................................4
3. PRODUCT DESCRIPTION................................................................................ 6
4. CONTROL PANEL............................................................................................. 6
5. PROGRAMMES................................................................................................. 7
6. DAILY USE......................................................................................................... 9
7. HINTS AND TIPS............................................................................................. 12
8. CARE AND CLEANING....................................................................................13
9. TROUBLESHOOTING......................................................................................14
10. INSTALLATION.............................................................................................. 16
11. TECHNICAL DATA.........................................................................................17
12. ENVIRONMENTAL CONCERNS................................................................... 18
WE’RE THINKING OF YOU
Thank you for purchasing an Electrolux appliance. You’ve chosen a product that
brings with it decades of professional experience and innovation. Ingenious and
stylish, it has been designed with you in mind. So whenever you use it, you can
be safe in the knowledge that you’ll get great results every time.
Welcome to Electrolux.
Visit our website to:
Get usage advice, brochures, trouble shooter, service and repair information:
www.electrolux.com/support
Register your product for better service:
www.registerelectrolux.com
Buy Accessories, Consumables and Original spare parts for your appliance:
www.electrolux.com/shop
CUSTOMER CARE AND SERVICE
Always use original spare parts.
When contacting our Authorised Service Centre, ensure that you have the
following data available: Model, PNC, Serial Number.
The information can be found on the rating plate.
Warning / Caution-Safety information
General information and tips
Environmental information
Subject to change without notice.
1. SAFETY INFORMATION
Before the installation and use of the appliance, carefully
read the supplied instructions. The manufacturer is not
responsible for any injuries or damage that are the result
www.electrolux.com2

of incorrect installation or usage. Always keep the
instructions in a safe and accessible location for future
reference.
1.1 Children and vulnerable people safety
•This appliance is not intended for use by persons
(including children) with reduced physical, sensory or
mental capabilities, or lack of experience and
knowledge, unless they have been given supervision
or instruction concerning use of the appliance by a
person responsible for their safety.
•Children should be supervised to ensure that they do
not play with the appliance.
•Keep detergents away from children.
•Keep children and pets away from the appliance when
the door is open.
•Children shall not carry out cleaning and user
maintenance of the appliance without supervision.
1.2 General Safety
•This appliance is for cleaning household-type dishes
and tableware only.
•This appliance is designed for single household
domestic use in an indoor environment.
•This appliance may be used in, offices, hotel guest
rooms, bed & breakfast guest rooms, farm guest
houses and other similar accommodation where such
use does not exceed (average) domestic usage levels.
•Do not change the specification of this appliance.
•The operating water pressure (minimum and
maximum) must be between 0.3 (0.03) / 10 (1) bar
(MPa)
•Follow the maximum number of 6 place settings.
•If the supply cord is damaged, it must be replaced by
the manufacturer, its Authorised Service Centre or
similarly qualified persons in order to avoid a hazard.
ENGLISH 3

•WARNING: Knives and other utensils with sharp
points must be loaded in the basket with their points
down or placed in a horizontal position.
•Do not leave the appliance with the open door
unattended to avoid stepping accidentally onto it.
•Before any maintenance operation, deactivate the
appliance and disconnect the mains plug from the
socket.
•Do not use high pressure water sprays and/or steam
to clean the appliance.
•If the appliance has ventilation openings in the base,
they must not be covered e.g. by a carpet.
•The appliance is to be connected to the water mains
using the new supplied hose-sets. Old hose sets must
not be reused.
2. SAFETY INSTRUCTIONS
2.1 Installation
WARNING!
Only a qualified person must
install this appliance.
• Remove all the packaging.
• Do not install or use a damaged
appliance.
• Follow the installation instructions
supplied with the appliance.
• Always take care when moving the
appliance as it is heavy. Always use
safety gloves and enclosed footwear.
• Do not install or use the appliance
where the temperature is less than
0 °C.
• Install the appliance in a safe and
suitable place that meets installation
requirements.
2.2 Electrical connection
WARNING!
Risk of fire and electric
shock.
• Warning: this appliance is designed to
be installed / connected to a
grounding connection in the building.
• Make sure that the parameters on the
rating plate are compatible with the
electrical ratings of the mains power
supply.
• Always use a correctly installed
shockproof socket.
• Do not use multi-plug adapters and
extension cables.
• Make sure not to cause damage to
the mains plug and to the mains
cable. Should the mains cable need to
be replaced, this must be carried out
by our Authorised Service Centre.
• Connect the mains plug to the mains
socket only at the end of the
installation. Make sure that there is
access to the mains plug after the
installation.
• Do not pull the mains cable to
disconnect the appliance. Always pull
the mains plug.
• This appliance is fitted with a 13 A
mains plug. If it is necessary to
change the mains plug fuse, use only
a 13 A ASTA (BS 1362) fuse (UK and
Ireland only).
2.3 Water connection
• Do not cause damage to the water
hoses.
www.electrolux.com4

• Before connection to new pipes, pipes
not used for a long time, where repair
work has been carried out or new
devices fitted (water meters, etc.), let
the water flow until it is clean and
clear.
• Ensure that there are no visible water
leaks during and after the first use of
the appliance.
• If the water inlet hose is damaged,
immediately close the water tap and
disconnect the mains plug from the
mains socket. Contact the Authorised
Service Centre to replace the water
inlet hose.
2.4 Use
• Do not put flammable products or
items that are wet with flammable
products in, near or on the appliance.
• Dishwasher detergents are
dangerous. Follow the safety
instructions on the detergent
packaging.
• Do not drink and play with the water in
the appliance.
• Do not remove the dishes from the
appliance until the programme is
complete. Some detergent may
remain on the dishes.
• Do not store items or apply pressure
on the open door of the appliance.
• The appliance can release hot steam
if you open the door while a
programme operates.
2.5 Service
• To repair the appliance contact the
Authorised Service Centre. Use
original spare parts only.
• Please note that self-repair or non-
professional repair can have safety
consequences and might void the
guarantee.
• Concerning the lamp(s) inside this
product and spare part lamps sold
separately: These lamps are intended
to withstand extreme physical
conditions in household appliances,
such as temperature, vibration,
humidity, or are intended to signal
information about the operational
status of the appliance. They are not
intended to be used in other
applications and are not suitable for
household room illumination.
2.6 Disposal
WARNING!
Risk of injury or suffocation.
• Disconnect the appliance from the
mains supply.
• Cut off the mains cable and discard it.
• Remove the door catch to prevent
children and pets to get closed in the
appliance.
ENGLISH 5

3. PRODUCT DESCRIPTION
3.1 General overview
9
1 2 5 63 7 84
10
11
12
13
1Salt container
2Detergent dispenser
3Rinse aid dispenser
4Spray arm
5Filters
6Rating plate
7Drain hose
8Inlet hose connection
9Mains cable
10 Basket
11 Cutlery basket
12 Inlet hose
13 Funnel
4. CONTROL PANEL
4.1 Control Panel
1 2 3 4
56
1On / Off 2Salt indicator
www.electrolux.com6

3Rinse aid indicator
4Programme indicators
5Programme
6Start / Reset
4.2 Indicators
Indicator Description
It is on when the rinse aid dispenser needs refilling. It is always off
while the programme operates.
It is on when the salt container needs refilling. It is always off while
the programme operates.
5. PROGRAMMES
5.1 Programme overview
Programme Degree of soil
Type of load
Phases in the cy‐
cle
Detergent pre-
wash / main wash
(g)
Rinse
aid
Heavy , dried-on
soiling, pans, pots,
casserole dishes
• Pre-wash
50 °C
• Dishwash
70 °C
• Rinse 70 °C
• Drying
3 / 15
Normal soiling,
pots, plates,
glasses, pans
• Pre-wash
• Dishwash
60 °C
• Rinse 70 °C
• Drying
3 / 15
1)
Normal soiling,
crockery, cutlery
• Pre-wash
• Dishwash
45 °C
• Rinse 65°C
• Drying
- / 14
Light soiling, all
types of dish load
• Dishwash
65 °C
• Rinse 70°C
• Drying
- / 18
Light soiling, all
types of dish load
• Dishwash
65 °C
• Rinse 50°C
• Drying
- / 18
ENGLISH 7

Programme Degree of soil
Type of load
Phases in the cy‐
cle
Detergent pre-
wash / main wash
(g)
Rinse
aid
Light soiling, all
types of dish load
• Dishwash
40 °C
• Rinse
- / 15
1) This programme offers the most efficient use of water and energy consumption for crock‐
ery and cutlery with normal soil. This is the standard programme for test institutes.
5.2 Consumption values
Programme 1) 2) Duration (min) Energy (kWh) Water (l)
140 1.20 9.6
120 1.05 7.7
230 0.609 6.5
90 1.10 6.6
60 0.82 5.8
30 0.50 5.8
1) The pressure and the temperature of the water, the variations of the mains supply, the
options, the quantity of dishes and the degree of soil can change the values.
2) The values for programmes other than ECO are indicative only.
5.3 Information for test
institutes
To receive the necessary information for
conducting performance tests (e.g.
according to: EN60436 ), send an email
to:
[email protected]
In your request, include the product
number code (PNC) from the rating plate.
For any other questions regarding your
dishwasher, refer to the service book
provided with your appliance.
5.4 Before starting a
programme
Before you start the selected
programme, make sure that:
• The filters are clean and correctly
installed.
• The cap of the salt container is tight.
• The spray arms are not clogged.
• There is enough salt and rinse aid
(unless you use multi-tablets).
• The arrangement of the items in the
baskets is correct.
• The programme is suitable to the type
of load and the degree of soil.
• The correct quantity of detergent is
used.
5.5 Using a programme
1. Close the appliance door.
2. Open the water tap.
3. Press the On / Off button to activate
the appliance.
4. Press Programme button until the
indicator of the selected programme
comes on.
5. Press Start / Reset button to start the
programme.
When a programme is completed, an
intermittent acoustic signal sounds for a
few seconds.
www.electrolux.com8

6. Press On / Off button to deactivate
the appliance.
The appliance turns off automatically
in 15 minutes after the programme
ends.
7. Close the water tap.
Wait until the dishes are cold before you
remove them from the appliance.
There can be water on the
sides and the door of the
appliance.
5.6 Cancelling a programme
1. Press the Start / Reset button.
2. Press and hold Start / Reset button
for 3 seconds.
The appliance comes back to its initial
settings.
Make sure that there is
detergent in the detergent
dispenser before you start a
new programme.
5.7 Interrupting a programme
1. Open the appliance door.
The appliance stops.
2. Close the appliance door.
The programme continues from the point
of interruption.
6. DAILY USE
6.1 Use of the appliance
1. Fill the salt container with salt for
dishwashers.
2. Fill the rinse aid dispenser with rinse
aid.
3. Load the basket.
4. Open the water tap.
5. Set the correct programme for the
type of load and the degree of soil.
6. Add the detergent.
7. Start the programme.
6.2 Filling the salt container
CAUTION!
Use only salt designed for
dishwashers.
1. Turn the cap of the salt container
counterclockwise and remove it.
2. Put 1 litre of water in the salt
container (Only for the first time).
3. Use the funnel to fill the salt
container with dishwasher salt.
4. Remove the salt around the opening
of the salt container.
5. Turn the cap of the salt container
clockwise to close the salt container.
Water and salt can come out
from the salt container when
you fill it, which causes
corrosion. To prevent it, start
a programme immediately
after filling the salt container.
6.3 The water softener
The water softener removes minerals
from the water supply, which would have
a detrimental effect on the washing
results and on the appliance.
The higher the content of these minerals,
the harder your water is. Water hardness
is measured in equivalent scales.
ENGLISH 9

The water softener should be adjusted
according to the hardness of the water in
your area. Your local water authority can
advise you on the hardness of the water
in your area. Set the right level of the
water softener to assure good washing
results.
Softening hard water
increases the consumption
of water and energy as well
as the programme duration.
The higher the level of water
softener, the higher the
consumption and the longer
the duration.
Water hardness
German
degrees
(°dH)
French de‐
grees (°fH)
mmol/l Clarke de‐
grees
Setting on
the water
softener
Setting indi‐
cation
0 - 5 0 - 9 0.0 - 0.9 0 - 7 1
6 - 11 10 - 19 1.0 - 2.0 8 - 14 2
12 - 17 20 - 30 2.1 - 3.0 15 - 21 3
18 - 22 31 - 39 3.1 - 4.0 22 - 27 4 1)
23 - 34 40 - 60 4.1 - 6.1 28 - 42 5
35 - 45 61 - 80 6.2 - 8.0 43 - 56 6
1) Factory setting.
Regardless of the type of detergent
used, set the proper water hardness
level to keep the salt refill indicator
active.
Multi-tabs containing salt are
not effective enough to
soften hard water.
6.4 Changing water softening
setting
1. Close the appliance door.
2. Press On / Off button.
3. Press and hold Start / Reset button
immediately for 6 seconds.
The programme indicators show the
current water softener level.
4. Press Start / Reset button to select
the water softening level.
The level is set after 6 seconds.
6.5 Filling the detergent
dispenser
CAUTION!
Use only detergents for
dishwashers.
1. Press the release button to open the
lid of the detergent dispenser.
A B
2. Put the detergent (approximately 15
g) in the compartment (C). Put
detergent tablets in part (E) of the
compartment.
www.electrolux.com10
