Operating Instructions - Dishwasher Electrolux ESL4115
The Control Panel
Indicator lights
End of cycle
Illuminates when the washing programme has ended.
Salt
Refilling indicator light.
Illuminates when the salt has run out.
Programme selection/cancel button
To select a washing programme press the button until the indicator light corresponding to the desired washing
programme illuminates.
The end of cycle indicator light flashes.
Once the washing programme has been set, close the dishwasher’s door, the programme will start automatically.
Audible signals
The audible signals indicate which operations the dishwasher is performing.
•end of washing programme
•the setting of the water softener

•malfunction of the machine
Loading cutlery and dishes
Before loading the dishes remove large left-overs and soften remnants of burnt food in pans.
When loading the dishes and cutlery, please note:
•Dishes and cutlery must not impede the rotation of the spray arms.
•Load hollow items such as cups, glasses, pans etc. with the opening downwards so that water cannot collect
in the container or a deep base.
•Dishes and items of cutlery must not lie inside one another or cover each other.
•To avoid damage to glasses, they must not touch.
•Lay small objects in the cutlery basket.
The lower basket
The lower basket is designed to take saucepans, lids, plates,
salad bowls, cutlery etc.
Serving dishes and large lids should be arranged around the
edge of the basket ensuring that the spray arms can turn
freely.
The cutlery basket
Long and/or sharp items of cutlery such as carving knives must be positioned
horizontally in the upper basket.
Forks and spoons should be placed in the removable cutlery basket with the handles
facing downwards and the knives with their handles facing upwards.
Mix spoons with other cutlery to prevent them from sticking together.
The upper basket
The upper basket is designed for plates, salad bowls, cups and glasses. Arrange items on and underneath the cup
racks so that water can reach all surfaces. Glasses with long stems can be placed upside down in the cup racks. For

taller items, the cup racks can be folded upwards. Light items (plastic bowls etc.) must be loaded in the upper basket
and arranged so they do not move.
Fill with detergent
1. If the lid is closed: press release button (1). The lid
springs open. Fill the detergent dispenser (2) with
detergent. The marking indicates the dosing levels.
2. All programmes with prewash need an additional
detergent dose (5/10g) that must be placed in the
prewash detergent chamber (3). This detergent will take effect during the prewash phase.
3. Close the lid and press until it locks in place.
Washing programmes
Starting a washing programme
1. Check that the baskets have been loaded correctly and the spray arms can rotate freely.
2. Set the washing programme by pressing the programme selection/cancel button until the indicator light
corresponding to the desired washing programme illuminates. The end of cycle indicator light flashes.
3. Once the washing programme has been set, close the dishwasher’s door, the programme will start automatically.

To interrupt a washing programme in progress
1. Open the dishwasher’s door; the programme will stop.
2. Close the door; the programme will start from the point at which it was interrupted.
To cancel a washing programme in progress
1. Open the dishwasher’s door.
2. Press the programme selection/cancel button for about 3 seconds, until the indicator light of the running
programme turns off and the end of cycle indicator light flashes. The machine has returned to setting mode and
it is possible to select another washing programme.
Only interrupt or cancel a washing programme in progress if it is absolutely necessary. Hot steam may escape
when the door is opened.
End of the washing programme
1. The dishwasher will automatically stop.
2. An audible signal informs you of the end of the washing programme.
3. Open the dishwasher’s door, leave it ajar and wait a few minutes before removing the dishes.
4. The end of cycle indicator light is on. The indicator light of the programme just ended is on.
5. Switch off the dishwasher by pressing the On/Off button.
Unloading the dishwasher
1. Allow the dishes to cool down before removing from the appliance.
2. Empty the lower basket first and then the upper one; this will avoid water dripping from the upper basket onto
the dishes in the lower one.
3. Water may appear on the sides and door of the dishwasher as the stainless steel will eventually become cooler
than the dishes.
