Electrolux ESL 424 User manual

Dishwasher
Instruction book
Model ESL 424
UK
4 02/02

2
Important safety information 3
Hints and tips 3
Description of the appliance 4
The control panel 4
Before use 5
Setting the water softener 5
Filling with salt 5
Rinse aid 6
Use of detergent 6
Using your appliance 7
Loading your appliance 7
The lower asket 7
The cutlery asket 7
The upper asket 7
Adjusting the height of the upper asket 7
Washing programmes 8
Operating sequence 9
Maintenance and cleaning 10
Internal cleaning 10
Cleaning the central filters 10
Cleaning the large filter 10
External cleaning 10
Prolonged periods of non-operation 10
Frost precautions 10
Moving the machine 10
Something not wor ing 11
Service and Spare Parts 11
Customer Care Department 11
Guarantee conditions 11
Installation instructions 13
Water supply connections 13
Water outlet hose connection 13
Electrical connection 14
Hints for test centres 15
Contents
Dimensions Width 44.6 cm
Height with worktop 81.8 - 87.8 cm
Max depth 55.5 cm
Max depth with open door 111.4 cm
Electrical connection Voltage 220/240 V - 50 Hz
Motor rating during wash 200 W
Power of heating element 2570 W
Overall power 2770 W
Water supply pressure Minimum 50 kPa (0.5 ar)
Maximum 800 kPa (8 ar)
Capacity 8 place settings
Technical specifications

3
Installation
●This appliance is heavy. Care should e taken when moving
it.
●It is dangerous to alter the specifications or attempt to modify
this product in any way.
●Care must e taken to ensure that the appliance does not
stand on the electrical supply ca le.
●Any electrical work required to install this appliance should
e carried out y a qualified electrician or competent person.
●Any plum ing work required to install this appliance should
e carried out y a qualified plum er or competent person.
Child Safety
●This appliance is designed to e operated y adults.
Children should not e allowed to tamper with the controls or
play with the product.
●Keep all packaging well away from children.
●Keep all detergents in a safe place out of children's reach.
During Use
●Items that are contaminated y petrol, paint, steel or iron
de ris, corrosive, acidic or alkaline chemicals must not e
washed in this dishwasher.
●Under no circumstances should you open the door whilst the
appliance is in operation. Always turn off the appliance
efore opening the door.
●Only use detergent specifically designed for use in
dishwashers.
●Long laded knives stored in an upright position are a
potential hazard.
●Long and/or sharp items of cutlery such as carving knives
must e positioned horizontally in the upper asket.
●When finishing loading or unloading close the door, as an
open door can e a hazard.
●Do not sit or stand on the open door.
●Isolate the appliance from the power supply and turn off the
water supply after use.
●Care should e taken when cleaning the ottom door seal
and hinge area as any exposed metal edges may cut if care
is not taken.
●This product should e serviced y an authorised Service
engineer, and only genuine spare parts should e used.
●Under no circumstances should you attempt to repair the
machine yourself. Repairs carried out y inexperienced
persons may cause injury or serious malfunctioning. Contact
your local Service Force Centre. Always insist on genuine
spare parts.
Conservation
In the interest of the environment:
●Materials marked with the sym ol are recycla le.
●Check with your local Council or Environmental Health Office
to see if there are facilities in your area for re-cycling this
appliance.
●When the appliance is to e scrapped, cut off the power
supply ca le and make the door closing device unusa le to
prevent young children from eing trapped inside.
●Help to keep your country tidy - use authorised disposal sites
for your old appliance.
Important safety information
It is most important that this instruction boo should be retained with the appliance for future reference. Should the
appliance be sold or transferred to another owner, or should you move house and leave the appliance, always ensure that
the boo is left with the appliance in order that the new owner can get to now the functioning of the appliance and the
relevant safety information.
This information has been provided in the interest of your safety. You MUST read it carefully before installing or using the
appliance.
To save energy
Place dishes in the machine immediately after every meal and
wait until the dishwasher is full efore washing.
If necessary run the Rinse and Hold programme (see
"Washing Programmes" chart) so that any food scraps do not
ecome caked on the dishes while you are waiting to run the
complete wash programme.
Do not prewash dishes under running water.
For best washing and drying results
Before loading, remove all scraps of food and soak very
heavily soiled pots and pans.
Arrange saucepans, cups and glasses etc. upside-down.
Tilt items with convex or concave surfaces so that the water
drains off easily.
Avoid contact etween the dishes as far as possi le.
Items not suitable for dishwashers
The following items should not be washed in the
dishwasher (unless they are sold as dishwasher proof):
- Cutlery with wooden or horn handles or glued parts
- ronze cutlery
- saucepans with wooden handles
- aluminium ware
- crystal ware
- leaded glass
- plastic items
- antique or fine decorated china
Certain types of decoration can discolour when washed in a
dishwasher.
Crystal-ware and plastic o jects, if not guaranteed dishwasher
proof should e washed y hand.
Certain types of glass can also ecome opaque after eing
washed several times in a dishwasher.
A chemical reaction can occur etween silver cutlery and
stainless steel cutlery. As a precaution, do not wash together.
Iron and cast iron o jects can rust and stain other items.
Aluminium tends to go lack, copper, pewter and rass tend to
stain.
If in doubt chec with manufacturer of the item.
When buying new dishes, ensure that they are dishwasher
proof.
Hints and tips

1. Water hardness adjustment
2. Upper asket stop
3. Lower spray arm
4. Salt container
5. Detergent dispenser
6. Rinse aid dispenser
7. Control panel
8. Filters
9. Upper spray arm
10.Upper asket
11. Levelling spacers
Description of the appliance
IN99
4
1. On/Off push button
2. Programme guide
3. Programme mar er
4. Programme selector dial
The control panel

5
Before using your dishwasher for the
first time:
1. Ensure that the electrical and water connections comply
with the installation instructions.
2. Remove all packaging from inside the appliance.
3. Set the water softener.
4. Pour a litre of water inside the salt container and then fill
with salt.
5. Fill the rinse aid dispenser.
Setting the water softener
The dishwasher is equipped with a water softener designed to
remove minerals and salts from the water supply, which would
have a detrimental or adverse effect on the operation of the
appliance.
The higher the content of these salts, the harder your water is.
Water hardness is measured in equivalent scales, Clarke,
French degrees and PPM (parts per Million).
The softener should e adjusted according to the hardness of
the water in your area. Your local Water Authority can advise
you on the hardness of the water in your area.
The dishwasher is factory set at level 2.
If this level is not suita le for your area the softener should e
adjusted.
To adjust the water softener
Level 1
If your water is "level 1" it is already soft and therefore there is
no need to use salt.
Levels 3 and 5
(water softener adjustment)
If your water is level 3 or 5, proceed as follows:
- slide out the lower asket and unscrew the cap of the salt
container;
- turn the two-position
selector anticlockwise from
position -to position +with
the aid of a lunt knife or
screwdriver.
Levels 4 and 5
(adjustment on the machine)
If your water is level 4 or 5,
open the door and drill
mem rane (A) on the upper
left-hand corner of the
machine.
With a water hardness of level 5 both adjustments must be
made.
Filling with salt
Only use salt specifically designed for use in
dishwashers.
All other types of salt not specifically designed for use in
a dishwasher, especially table salt, will damage the water
softener.
Only fill with salt just before starting one of the complete
washing programmes (not the Rinse and Hold
programme). This will prevent any grains of salt or salty
water, which may have been spilled, remaining on the
bottom of the machine for any period of time, which may
cause corrosion.
To fill:
1. To fill with salt, unscrew the cap of the salt container.
2. Pour a litre of water inside the container (this is
necessary only before filling with salt for the first time).
3. Using the funnel provided,
pour in the salt until the
container is full.
Do not worry if water over
flows from the unit when
filling with salt, this is quite
normal.
4. Replace the cap making
sure that there is no trace
of salt on the screw thread
or on the gasket.
5. Screw on the cap tightly.
The salt container will require topping up periodically.
The salt cap has a refill
indicator window in the
centre.
Agreen float is clearly
visi le when there is salt
inside the container, and
almost disappears when the
salt has finished reminding
you to add salt.
Before use
Level
Water
softener
adjustment
Adjustment
on the
machine
French
degrees
(°TH)
PPM
(Parts per
Million)
Clar e
degrees
1
2
3
4
5
NO
NO
YES
NO
YES
NO
NO
NO
YES
YES
0 - 10
11 - 27
28 - 35
36 - 49
50 - 63
0 - 14
15 - 39
40 - 50
51 - 70
71 - 90
0 - 140
141 - 390
400 - 500
501 - 700
701 - 900
Water hardness
A
AA04
AA01
SALE
SALT
SALZ
SEL
SR02
SR11

6
Rinse aid
Rinse aid is automatically added during the last rinse, ensuring
thorough rinsing, and spot and streak free drying. The
dispenser, which is positioned inside the door, holds a out 110
ml of rinse aid, which is sufficient for 16 - 40 dishwashing
programmes, depending upon the dosage setting.
Filling with rinse aid
1. Open the container y turning the lid (A) anticlockwise.
2. Add the rinse aid until the container is completely full. The
indicator (B) will e completely dark.
3. Top up the rinse aid when the indicator (B) ecomes clear.
Ensure that the lid is closed after every refill.
Do not put liquid detergent in the rinse aid compartment. Clean
up any rinse aid spilt during filling with an a sor ent cloth to
avoid excess foaming during the next wash.
Adjusting the dose
According to the finish and drying results o tained, adjust the
dose of rinse aid y means of the 6 position selector (C)
(position 1 minimum dosage, position 6 maximum dosage).
Increase the dose if there are drops of water or lime spots on
the dishes after washing. Reduce it if there are sticky whitish
streaks on the dishes.
Use of detergent
Only use detergents specifically designed for use in
dishwashers.
We recommend the use of Finish detergents which are
availa le in the following options:
Finish Double Action Tablets. Each ta let has the exact
amount of detergent required, simply place in the dispenser.
Finish Powder recommended for every day use.
Finish Liquid Gel ideal for every day use. As the gel is extra
gentle it is recommended for fine one china.
If using powder detergents proceed as follows:
1. Open the dispenser lid y pulling the catch (D).
2. Add the detergent according to the recommended quantity
given in the "Washing programmes" chart.
As all detergents are not the same, you should also consult
the instructions on the packet.
3. Always close the lid.
4. If the programme has a prewash add a little amount of
detergent over the lid of the dispenser. Follow the
recommended quantity of detergent given in the "Washing
programmes" chart.
If using detergent in tablets proceed as follows:
1. For all programmes; place 1 ta let inside the detergent
dispenser.
2. Always close the lid.
3. For all programmes with prewash; place a portion of a
further ta let on the lid of the detergent dispenser.
Insufficient quantities of detergent will produce poor
washing results, whereas an excessive amount of
detergent will not improve washing results and is also
wasteful.
Using no more than the correct amount also contributes
to reducing pollution.
Compact detergents with enzymes
In these low-alkaline compact powders the environmentally
unfriendly components have een replaced y natural
enzymes and other more iodegrada le su stances.
These new compact powders are generally phosphate-free.
BR01 BR03
BR02
BRILLIANT
FOR A
SHINE
RINSE
CONCENTRATED DISHWASHER DETERGENT
ACTION
NEW
DOUBLE
LIQUID GEL
POWDER
EASY
POURING
PACK
DE15
DE17
DE02

7
Loading your appliance
Before placing dishes in the machine, remove any scraps of
food, to avoid clogging the filters and consequently reducing
the performance.
Do not load very small items which can fall through the
bas ets.
Open the door and slide out the askets to load the dishes.
The lower bas et
The lower asket is designed to take saucepans, lids, plates,
salad owls, cutlery etc.
Serving dishes and large lids should e arranged around the
edge of the asket, ensuring that the upper spray arm can turn
freely.
The cutlery bas et
Long bladed nives stored in an upright position are a
potential hazard.
Long and/or sharp items of cutlery such as carving nives
must be positioned horizontally in the upper bas et.
Ta e care when loading or unloading sharp items such as
nives.
Cutlery should e placed in the remova le cutlery asket with
the handles facing downwards.
If the handles protrude from the ottom of the asket,
o structing the lower spray arm, load the cutlery with the
handles facing upwards.
Mix spoons with other cutlery
to prevent them from sticking
together.
Silver cutlery tends to go
lack if mixed with steel
cutlery. Place it in the cutlery
asket separate from the
others.
The upper bas et
The upper asket is designed for plates (dessert plates,
saucers, dinner plates of up to 24 cm in diameter), salad
owls, cups and glasses.
Arrange items on and
underneath the cup rack so
that water can reach all
surfaces.
Glasses with long stems can
e placed upside down in the
cup rack.
Light items (plastic owls
etc.) should e loaded in the
upper asket and arranged
so they do not move.
Before closing the door, ensure that the spray arms can
rotate freely.
Adjusting the height of the upper bas et
If washing very large plates (over 27 cm and up to 31 cm in
diameter) you can load them in the lower asket after moving
the upper asket to the higher position.
To move to the higher position proceed as follows:
1. Move the front runner stops (A) of the upper asket
outward and slide the asket out.
2. Refit the asket in the higher position and replace the stops
(A) in their original position.
When the top bas et is in the higher position it will only
ta e plates up to 20 cm in diameter and you will not be
able to use the cup rac .
After loading your machine always close the door, as an
open door can be a hazard.
Using your appliance
UI57
UI12
UI45
US63
RC01

8
Washing programmes
Programme Degree of soil
and
type of load
Required
push button Recommended
quantity of detergent
wash prewash
Starting position
of the programme
selector
Heavy soil.
Crockery, cutlery, pots
and pans
Normal soil.
Crockery and cutlery
Light soil.
Crockery and party
crockery
Any.
Partial load (to e
completed later in the
day).
Cycle
description
*
POWER WASH 65°
NORMAL WASH
65°
**
ECO WASH
RINSE & HOLD
Cold prewash
Main wash up to 65°C
1 cold rinse
1 hot rinse
Drying
Main wash up to 65°C
1 cold rinse
1 hot rinse
Main wash up to 65°C
1 cold rinse
1 hot rinse
Drying
1 cold rinse (to avoid
food scraps from
sticking together).
*Testing programme for EN 50242 (see "Hints for Test Centres").
** This is a special programme for quick washing a full load of lightly soiled dishes, glasses and crockery (except pots) so that you
may re-use them promptly.
On/Off
On/Off
On/Off
On/Off
A
B
C
D
20 g 5 g
25 g /
25 g /
//

9
1. Chec the filters
Ensure they are clean and properly positioned (see
"Maintenance and cleaning").
2. Chec that there is rinse aid and salt
3. Load the dishes
Remove any scraps of food.
Pull the lower asket out and arrange the saucepans,
plates and cutlery in it.
Pull the upper asket out and arrange the plates, saucers,
glasses and cups etc. in it.
Slide the askets ack into the machine.
4. Ensure that the spray arms can
rotate freely.
5. Measure out detergent
Add the required amount of detergent into the dispenser
according to the dosage quantity given in the "Washing
programmes" chart.
Close the detergent dispenser lid.
6. Set the programme
The selection of a programme occurs with the door
partially opened.
Turn the programme selector dial clockwise until the letter
of the programme you wish to select corresponds with the
programme marker on the control panel.
9. Start the programme
Depress the On/Off push utton and close the door, the
machine will start.
If you wish to interrupt the washing programme at any
time open the door and press this utton again.
10.At the end of the washing
programme
At the end of the programme the dishwasher will
automatically stop.
11. Switch off the dishwasher
Switch off the dishwasher y opening the
door and pressing the On/Off push utton.
Wait a few minutes efore removing the dishes; in this
way they will e cooler and the drying will e improved.
Empty the lower asket first and then the upper one; this
will avoid water dripping from the upper asket onto the
dishes in the lower one.
When the washing programme has finished, it is
recommended that the dishwasher is unplugged and the
water tap turned off.
In general it is not advisable to open the door while the
machine is wor ing; if the door is opened however, a
safety device ensures that the machine stops.
Important!
Care must be ta en if the door is opened during the hot
phase or immediately after a programme has finished, as
steam may escape.
Operating sequence

10
Internal cleaning
Ensure that the seals around the door, the detergent and rinse
aid dispensers are cleaned regularly with a damp cloth.
We recommend the use of Finish Dishwasher Cleaner every
3 months or run a 65°C wash without dishes using detergent.
Regular use of Finish Dishwasher Cleaner cleans inaccessi le
parts, eliminates unpleasant food odours and helps prevent the
uild-up of limescale.
Cleaning the central filters
(After each wash)
Inspect the central filters (B) and (C) and remove any scraps of
food with a rush, under running water.
Filters (B) and (C) are oth removed y lifting up the outer one
(B) (pulling the central funnel upwards); the smaller filter (C)
can e removed y pressing the two tongues (D).
Once cleaned, refit the filters y pressing them down until they
click into place.
Cleaning the large filter
(every week)
Clean the large filter (A) on oth sides under running water,
using a rush.
To take it out, remove the spray arm y pressing the two
tongues (E), turn the ring (F) anticlockwise and then slide the
whole part out. Refit the filter following the a ove instructions
in reverse order.
The dishwasher must not be used without filters.
Incorrect repositioning and fitting of the filters will
produce poor washing results.
Cleaning the filters is vital to ensure correct operation of
the machine.
External cleaning
Clean the external surfaces of the machine and control panel
with a damp soft cloth. If necessary use only neutral
detergents. Never use a rasive products, scouring pads or
solvent (acetone, trichloroethylene etc....).
Prolonged periods of non-operation
If you are not using the machine for any period of time you
are advised to:
1. Unplug the appliance and then turn off the water.
2. Fill the rinse aid dispenser.
3. Leave the door ajar to prevent the formation of any
unpleasant smells.
4. Leave the inside of the machine clean.
Frost precautions
Avoid placing the machine in a location where the temperature
is elow 0°C. If this is unavoida le, empty the machine, close
the appliance door, disconnect the water inlet pipe and empty
it.
Moving the machine
If you have to move the machine (moving house etc....):
1. Unplug it.
2. Turn the water tap off.
3. Remove the water inlet and discharge hoses.
4. Pull the machine out together with the hoses.
Avoid over tilting the machine during transportation.
Maintenance and cleaning
MA02
B
DC
MA03
F
A
E
MA08

11
Certain pro lems are due to lack of simple maintenance or oversights, which can e solved easily without calling out an engineer.
Before contacting your local Service Force Centre, please carry out the checks listed elow.
Important: If you call out an engineer to a fault listed elow or to repair a fault caused y incorrect use or installation a charge will
e made even if the appliance is in guarantee.
Something not wor ing
Symptom Solution
The machine will not start ●The door has not een properly closed.
●The plug is not properly inserted in the power socket.
●There is a power failure.
The machine does not fill ●Ensure the water tap is open.
with water ●Ensure the mains water supply has not een cut off.
●The inlet hose may e squashed or ent. Reposition the hose.
●The inlet hose may e locked. Switch off the water supply and clean the
filter.
The filters are bloc ed ●Clean the filters (refer to "Maintenance and cleaning").
The spray arms are not rotating ●Ensure the crockery is loaded correctly.
The dishwasher will not drain ●The drain hose may e squashed or ent. Reposition the hose.
●The sink may e locked. Clear any lockages.
●The drain hose extension is not correct. Follow the instructions for connecting
to the waste.
●There is no vent in the end of the drain hose.
The machine is noisy ●Dishes are rattling against each other, refer to “Loading your machine”.
●The spray arms are knocking against the dishes. Refer to "Loading your
machine".
The door is difficult to close ●The dishwasher is not level, or not properly uilt-in.
Visible lime deposits or white ●Check that there is salt and that the salt cap is tight.
film on the dishes ●Check that the right level of the water softener is set.
The dishes are not quite dry ●The rinse aid has run out or too little is eing used.
The dishes are not clean ●The askets are too full.
(poor wash) ●The dishes have not een arranged properly.
●The spray arms do not rotate
●The spray arms are clogged.
●The filters are clogged.
●The filters are not in the correct position.
●Not enough detergent has een used or it is unsuita le.
●The detergent is old or has gone hard.
●The salt container cap is not properly closed.
●The washing programme selected is too gentle.
If after all these checks, the pro lem persists, contact your
local Service Force Centre, quoting the model and serial
num er. This information can e found on the rating plate
located on the right hand side of the dishwasher door (see
picture).
This product should be serviced by an authorised Service
engineer, and only genuine spare parts should be used.
Under no circumstances should you attempt to repair the
machine yourself.
Repairs carried out by inexperienced persons may cause
injury or serious malfunctioning.
Contact your local Service Force Centre.
Always insist on genuine spare parts.
Prod.No. ........ Ser. No. .........
Mod. ........
RA01

12
In the event of your appliance requiring service, or if you wish to
purchase spare parts please contact your local Service Force
Centre y telephoning:
08705 929929
Your telephone call will e automatically routed to the Service
Force centre covering your post code area.
For the address of your local Service Force Centre and further
information a out Service Force, please visit the we site at
www.serviceforce.co.u
Before calling out an engineer, please ensure you read the details
under the heading Something not working.
When you contact the Service Force Centre you will need to give
the following details:
1. Your name, address and post code
2. Your telephone num er
3. Clear and concise details of the fault
4. The model and serial num er (found on the rating plate)
5. The purchase date
Please note that a valid purchase receipt or guarantee
documentation is required for in-guarantee service calls.
Customer Care
Department
For general enquiries concerning your Electrolux appliance or for
further information on Electrolux products please contact our
Customer Care Department y letter or telephone at the address
elow or visit our we site at www.electrolux.co.u
Customer Care Department
Electrolux
55-77 High Street
Slough
Berkshire
SL1 1DZ
Tel: [phone] (*)
*calls to this number may be recorded for training purposes
Guarantee Conditions
Standard guarantee conditions
We, Electrolux, undertake that if within 12 months of the date of
purchase this Electrolux appliance or any part thereof is proved to
e defective y reason only of faulty workmanship or materials, we
will, at our option repair or replace the same FREE OF CHARGE
for la our, materials or carriage on condition that:
●The appliance has een correctly installed and used only on the
electricity supply stated on the rating plate.
●The appliance has een used for normal domestic purposes
only, and in accordance with the manufacturer’s instructions.
●The appliance has not een serviced, maintained repaired,
taken apart or tampered with y any person not authorised y
us.
●All service work under this guarantee must e undertaken y a
Electrolux Service Force Centre.
●Any appliance or defective part replaced shall ecome the
Company’s property.
●This guarantee is in addition to your statutory and other legal
rights.
Home visits are made etween 8.30am and 5.30pm Monday to
Friday. Visits may e availa le outside these hours in which case a
premium will e charged.
Exclusions
This guarantee does not cover:
●Damage or calls resulting from transportation, improper use or
neglect, the replacement of any light ul s or remova le parts
of glass or plastic.
●Costs incurred for calls to put right an appliance which is
improperly installed or calls to appliances outside the United
Kingdom.
●Appliances found to e in use within a commercial environment,
plus those which are su ject to rental agreements.
●Products of Electrolux manufacture which are not marketed y
Electrolux.
European Guarantee
If you should move to another country within Europe then your
guarantee moves with you to your new home su ject to the
following qualifications:
●The guarantee starts from the date you first purchased your
product.
●The guarantee is for the same period and to the same extent
for la our and parts as exists in the new country of use for this
rand or range of products.
●This guarantee relates to you and cannot e transferred to
another user.
●Your new home is within the European Community (EC) or
European free Trade Area.
●The product is installed and used in accordance with our
instructions and is only used domestically, i.e. a normal
household.
●The product is installed taking into account regulations in your
new country.
Before you move please contact your nearest Customer Care
centre, listed elow, to give them details of your new home. They
will then ensure that the local service Organisation is aware of
your move and a le to look after you and your appliances.
France Senlis [phone]
Sweden Stockholm [phone]
Germany Nurn erg [phone]
UK Slough [phone]
Italy Pordenone [phone]
Ireland Du lin [phone]
Service and Spare Parts

13
Any electrical wor required to install this appliance
should be carried out by a qualified electrician or
competent person.
Any plumbing wor required to install this appliance
should be carried out by a qualified plumber or competent
person.
Remove all pac aging before positioning the machine.
If possi le, position the machine next to a water tap and a
drain.
Attention!
Carefully follow the instructions on the enclosed template
for uilding in the dishwasher and fitting the furniture panel.
Water supply connections
This dishwasher must e plum ed into a cold water supply.
The water pressure must e within the limits given in the
technical specifications.
Your local Water Authority will advise you on the average
mains pressure in your area.
The dishwasher features fill and drain hoses which can e
turned either to the left or the right to suit the installation. The
loc nut must be correctly fitted to avoid water lea s.
Avoid ends or kinks in the hose which could prevent or slow
down the water supply.
If the machine is connected to new pipes or pipes which have
not een used for a long time, you should run the water for a
few minutes efore connecting the inlet hose. This will prevent
deposits of sand or rust clogging the inlet hose filter.
Do not use, for the connection, old hoses which have
been used in another appliance.
Water outlet hose connection
The end of the drain hose can e connected in the following
ways:
1. To the sink outlet spigot, securing it if necessary with a clip.
2. To a stand pipe provided with vent-hole, minimum internal
diameter 4 cm.
The waste connection must e at a height of etween 30 cm
(minimum) and 100 cm (maximum) from the ottom of the
dishwasher.
The drain hose can face either to the right or left of the
dishwasher
Ensure the hose is not ent or squashed as this could prevent
or slow down the discharge of water.
If you use a drain hose extension it must e no longer than 2
metres and its internal diameter must e no smaller than the
diameter of the hose provided.
Likewise the internal diameter of the couplings used for
connections to the waste outlet must e no smaller than the
diameter of the hose provided.
The sin plug must not be in place when the machine is
draining as this could cause the water to siphon bac into
the machine.
Attention!
Our appliances are supplied with a security device to
protect against the return of dirty water bac into the
machine.
If the spigot of your sin has a "no return valve"
incorporated this can prevent the correct draining of your
dishwasher.
We advise you therefore to remove it.
Installation instructions
CS13
min 30 cm max 100 cm
min 4 cm
Ø 21
Ø 18
1 2
CS14
min 30 cm max 100 cm
+ 2 m max
Ø 18 Ø 21

14
Electrical connection
This appliance must be earthed.
The manufacturer declines any responsibility should this
safety measure not be observed.
If the plug that is fitted to your appliance is not suita le for the
socket, it must e cut off and the appropriate plug fitted.
Important
The wires on the mains lead are coloured in accordance with
the following code:
Green and Yellow -Earth
Blue -Neutral
Brown -Live
If you fit your own plug, the colours of the wires in the mains
lead of your appliance may not correspond with the markings
identifying the terminals in your plug.
Proceed as follows:
1. Connect the Green and Yellow (earth) wire to the terminal in
the plug which is marked with the letter "E" or the earth
sym ol or coloured green and yellow.
2. Connect the Blue (neutral) wire to the terminal in the plug
which is marked with the letter "N" or coloured lack.
3. Connect the Brown (live) wire to the terminal in the plug
which is marked with the letter "L" or coloured red.
The plug moulded onto the lead incorporates a 13amp BSI362
fuse. Only ASTA or BSI fuses should e used.
The plug must not e used if the fuse cover/carrier is lost. The
cover/carrier is indicated y the coloured insert at the ase of
the plug.
A replacement cover/carrier must e o tained from your local
Service Force Centre.
This appliance complies with the following E.E.C.
Directives:
- 73/23 or 19.2.73 (Low Voltage Directive) and subsequent
modifications;
- 89/336 or 3.5.89 (Electromagnetic Compatibility Directive)
and subsequent modifications.
13A
CE04
E
NL

15
Hints for test centres
Before starting any test it is necessary to fill completely with salt the salt container and with rinse aid the rinse aid dispenser.
Test standard EN 50242
Reference programme: Power Wash 65°C
Load: 8 standard place settings
Rinse aid selector: position 4
Detergent dosage : 20 g in the dispenser
5 g on the dispenser lid
Arrangement upper asket
Arrangement
cutlery asket
Arrangement lower asket

The Electrolux Group. The world’s No.1 choice.
The Electrolux Group is the world’s largest producer of powered appliances for kitchen,
cleaning and outdoor use. More than 55 million Electrolux Group products (such as
refrigerators, cookers, vacuum cleaners, chain saws and lawn mowers) are sold each year
to a value of approx. 14 billion USD in more than 150 countries around the world.
152983 62/4 Subject to change without notice ©Electrolux Household Appliances Limited 2002
