Electrolux EHD90230P User manual

user manual
Ceramic glass induction hob
EHD90230P

Electrolux. Thinking of you.
Share more of our thinking at www.electrolux.com
Contents
Safety instructions 2
Description of the appliance 3
Operating the appliance 4
Tips on cooking and frying 9
Cleaning and care 11
What to do if… 11
Disposal 13
Installation Instructions 13
Assembly 14
Service 16
Warranty 16
Subject to change without notice
Safety instructions
Warning! Please comply with these
instructions. If you do not, any damage
resulting is not covered by the warranty.
Correct use
• This appliance is not intended for use by
persons (including children) with reduced
physical, sensory or mental capabilities, or
lack of experience and knowledge, unless
they have been given supervision or in-
struction concerning use of the appliance
by a person responsible for their safety.
• Do not leave the appliance unattended
during operation.
• This appliance should be used only for
normal domestic cooking and frying of
food.
• The appliance must not be used as a work
surface or as a storage surface.
• Additions or modifications to the appliance
are not permitted.
• Do not place or store flammable liquids,
highly inflammable materials or fusible ob-
jects (e.g. plastic film, plastic, aluminium)
on or near the appliance.
Children's safety
• Children should be supervised to ensure
that they do not play with the appliance.
• To avoid small children and pets uninten-
tionally switching the appliance on, we rec-
ommend activation of the child safety de-
vice.
Warning! Accessible parts will become
hot during use. To avoid burns young
children should be kept away
General Safety
• The appliance may only be installed and
connected by a qualified electrician.
• Built-in appliances may only be used after
they have been built into suitable built-in
units and work surfaces that meet stand-
ards.
• In the event of faults with the appliance or
damage to the glass ceramic (cracks,
scratches or splits), the appliance must be
switched off and disconnected from the
electrical supply, to prevent the possibility
of an electric shock.
• Repairs to the appliance must only be car-
ried out by trained registered service engi-
neers.
• This appliance is not intended to be oper-
ated by means of an external timer or sep-
arate remote control system.
Safety during use
• Remove stickers and film from the glass
ceramic.
• There is the risk of burns from the appli-
ance if used carelessly.
• Cables from electrical appliances must not
touch the hot surface of the appliance or
hot cookware.
• Overheated fats and oils can ignite very
quickly. Warning! Fire hazard!
• Switch the cooking zones off after each
use, do not rely on the pan detector.
• Users with implanted pacemakers should
keep their upper body at least 30 cm from
induction cooking zones that are switched
on.
2 electrolux

Induction cooking zone 2200 W, with
Induction cooking zone 2200 W, with
Induction cooking zone 2200 W, with
• Risk of burns! Do not place objects made
of metal, such as knives, forks, spoons
and saucepan lids on the cooking surface,
as they can get hot
Safety when cleaning
• For cleaning, the appliance must be
switched off and cooled down.
• For safety reasons, the cleaning of the ap-
pliance with steam jet or high pressure
cleaning equipment is not permitted.
How to avoid damage to the appliance
• The glass ceramic can be damaged by
objects falling onto it.
• The edge of the glass ceramic can be
damaged by being knocked by the cook-
ware.
• Cookware made of cast iron, cast alumi-
nium or with damaged bottoms can
scratch the glass ceramic if pushed across
the surface.
• Spillage from cookware can burn onto the
glass ceramic and should be removed
straight away.
• Do not use the cooking zones with empty
cookware or without cookware.
• To avoid damaging cookware and glass
ceramics, do not allow saucepans or frying
pans to boil dry.
• The Ventilation gap of 5 mm between the
worktop and front of the unit underneath it
must not be covered.
Description of the appliance
Cooking surface layout
1 2 3
4
1
power function 3200 W
2
power function 3200 W
3
power function 3200 W
4Control panel
The cooking surface is divided into three
cooking zones. In each cooking zone under
the glass ceramic is an induction heating el-
ement, the middle of each one being marked
with a cross on the glass ceramic surface.
Cookware can be placed on any of the cook-
ing zones. But the cross must be completely
covered by the cookware. The bottom of the
cookware must be from 125 - 210 mm in di-
ameter.
Control panel layout
1 2 3 4 5
89
10
11
6 7
1Child Lock with pilot light 2STOP+GO with pilot light
electrolux 3

3Cooking zone indicators Timer function
4Timer display
5Timer
6Heat setting indicator
7Pan recognition and automatic switch-
off indicator
8Residual heat indicator
9Heat setting selection
10 Power function
11 On/Off with indicator
Touch Control sensor fields
The appliance is operated using Touch Con-
trol sensor fields. Functions are controlled by
touching sensor fields and confirmed by dis-
plays and acoustic signals. Touch the sensor
fields from above, without covering other
sensor fields.
Sensor field Function
On / Off Switches appliance on and off
Lock Locking/unlocking the control panel
STOP+GO To switch the Keep Warm setting on/ off
Cooking zone Off To switch off the cooking zone
/ Heat settings To set heat settings
Power Switching the power function on and off
Timer Timer selection
Increase settings To increase Timer time
Reduce settings To reduce Timer time
Displays
Display Description
Residual heat Cooking zone is still hot
+ number Fault Malfunction has occurred
Pan detection Cookware is unsuitable or too small or no cookware
has been placed on the cooking zone
Automatic switch off Switch off is active.
Residual heat indicator
Warning! Risk of burns from residual
heat. After being switched off, the
cooking zones need some time to cool
down. Look at the residual heat indicator
.
Residual heat can be used for melting
and keeping food warm.
The induction cooking zones create the
heat required for cooking directly in the base
of the cookware. The glass ceramic is merely
heated by the residual heat of the cookware.
Operating the appliance
Use the induction cooking zones with suitable cookware.
4 electrolux

Switching the appliance on and off
Control panel Display
To switch
on Touch for 1 second Indicator lights up. The operational readiness indicators of the individual cooking zones also light up.
To switch
off Touch for 1 second Indicator goes out. The operational readiness indicators of the individual cooking zones also go out.
After switching on, within approx. 10
seconds a heat setting or a function
must be set, otherwise the appliance au-
tomatically switches itself off.
Setting the heat setting
The control bar is touched where the desired
heat setting is positioned. The heat setting is
shown in the display. Correct to the left or the
right, if necessary. Do not release before the
desired heat setting is reached.
Locking/unlocking the control panel
The control panel, with the exception of the
“On/Off” sensor field, can be locked at any
time in order to prevent the settings being
changed e.g. by wiping over the panel with a
cloth.
Control panel Display
To switch on Touch Indicator lights up
To switch off Touch Indicator goes out
When you switch the appliance off, the locking function is automatically switched off.
Switching the STOP+GO function on and
off
The STOP+GO function simultaneously
switches all cooking zones that are switched
on to the keep warm setting and then back
to the heat setting that was previously set.
Control panel Display
To switch on Touch
To switch off Touch Heat setting that was previously set (not automatic warm up
function)
STOP+GO does not stop the Timer
function.
STOP+GO locks the whole control panel
except the sensor field .
Using the automatic warm-up function
All cooking zones are equipped with an au-
tomatic warm-up function. When setting a
heat setting using the automatic warm-up
function, the cooking zone switches to full
power for a certain amount of time and then
automatically switches back to the heat set-
ting set.
electrolux 5

Step Control panel Display
1. Select warm-up setting display flashes
2. Select the desired heat setting be-
tween 1 and 8 The desired heat setting is displayed. display
lights up.
As long as the display is lit, the appliance is
working at full power.
After the automatic warm-up is completed, the
display goes out.
The length of time that the automatic warm
up function operates depends on the heat
setting selected.
Heat setting Length of the automatic warm up [min:sec]
10:12
20:12
33:07
45:51
510:12
62:01
72:28
82:52
9---
Using the child safety device
The child safety device prevents unintention-
al use of the appliance.
Switching on the child safety device
Step Control panel Pilot light
1. Switch on appliance. Do not set a heat setting. lights up. The operational readiness
indicators of the individual cooking
zones light up.
2. Touch for 4 seconds above lights up
The child safety device is switched on.
Overriding the child safety device
The child safety device can be switched off
in this way for a single cooking session; it re-
mains activated afterwards.
Step Control panel Pilot light
1. Switch appliance on above lights up
2. Touch for 4 seconds above goes out
Until the appliance is next switched off, it can used as normal.
After overriding the child safety device, a heat setting or a function must be set within
approx. 10 seconds, otherwise the appliance automatically switches itself off.
6 electrolux

Switching off the child safety device
Step Control panel Pilot light
1. Switch on appliance. Do not set a heat setting. above lights up
2. Touch for 4 seconds above goes out
3. Switch appliance off.
The child safety device is switched off.
Switching the power function on and off
The power function makes more power
available to the induction cooking zones, e.g.
to bring a large quantity of water to the boil
quickly. The power function is activated for
10 minutes at most. After that the induction
cooking zone automatically switches back to
heat setting 9.
Control panel Display
To switch on Touch The light elements in the control bar light up. The
display flashes
To switch off Select the heat setting
1-9
The heat setting selected is shown in the display. The
display above will go out.
Power Management
The cooking zones of the cooking surface
have a maximum power.
The maximum power is reached when the
heat setting 9 has been set for all cooking
zones.
Two cooking zones generate a pair (see fig-
ure) and therefore, the power management
shares the maximum available power be-
tween these cooking zones.
When the power function is selected for one
cooking zone, the power management
makes the additional power for this cooking
zone available by reducing the power of the
corresponding other cooking zone.
Example: the heat setting 9 is selected on
one cooking zone. The power function is
switched on for the corresponding cooking
zone. The power function is carried out but
the heat setting 9 of one of the cooking zones
and the power function for the other cooking
zone of the pair exceed the maximum power
for both at the same time. For this purpose,
the power management reduces the power
of the cooking zone that switched on first
from 9 to example 5 and the display of this
cooking zone changes between 9 and 5 and
then stays at the current possible maximum
5. (If the display changes between 9 and 5 or
9 and 3 or another value depends on the type
of appliance and the size of the cooking
zone.).
Using the timer
Function Condition Outcome after the time has elapsed
Automatic cut-out a heat setting is set acoustic signal
00
flashes
Cooking zone switches off
Countdown timer cooking zones not in use acoustic signal
00
flashes
If a heat setting is set on this cooking
zone in addition to a countdown timer,
the cooking zone is switched off after the
time set has elapsed.
electrolux 7

If a cooking zone is switched off, the tim-
er function set is also switched off.
Selecting a cooking zone
Step Control panel Display
1Touch once Pilot light of the first cooking zone flashes
2Touch once Pilot light of the second cooking zone flashes
3Touch once Pilot light of the third cooking zone flashes
If other timer functions are set, after a few seconds the shortest remaining time of all the
timer functions is displayed and the corresponding pilot light flashes.
Setting the time
Step Control panel Indicator
1Select cooking zone Pilot light for the cooking zone selected
flashes
2Touch or
00
to
99
minutes
After a few seconds the pilot light flashes more slowly.
The time is set.
The time counts down.
Switching off the timer function
Step Control panel Indicator
1Select cooking zone Pilot light of cooking zone selected flashes
faster
Time remaining is displayed
2Touch The time remaining counts backwards to
00
.
The pilot light goes out.
The Timer function for the selected cooking zone is switched off.
Changing the time
Step Control panel Display
1Select cooking zone Pilot light of the selected cooking zone flash-
es faster
Remaining time is displayed
2Touch or
0
1
to
99
minutes
After a few seconds the pilot light flashes more slowly.
The time is set.
The time counts down.
Displaying the time remaining for a cooking zone
Step Control panel field Display
1Select cooking zone Pilot light of the cooking zone selected flash-
es faster
The time remaining is displayed
After a few seconds the pilot light flashes more slowly.
8 electrolux

Switching off the acoustic signal
Step Control panel field Acoustic signal
1Touch Acoustic signal to acknowledge.
Acoustic signal stops.
Automatic switch off
Cooking surface
• If after switching on the cooking surface, a
heat setting is not set for a cooking zone
within approx. 10 seconds, the cooking
surface automatically switches itself off.
• If one or more sensor fields are covered by
objects (a pan, etc.) for longer than approx.
10 seconds, a signal sounds and the
cooking surface switches off automatical-
ly.
• If all cooking zones are switched off, the
cooking surface automatically switches it-
self off after approx. 10 seconds.
Control panel
• When the appliance is switched off, if one
or more of the sensor fields on the control
panel are covered for more than 10 sec-
onds, an acoustic signal sounds. The
acoustic signal switches itself off automat-
ically when the sensor fields are no longer
covered.
Induction cooking zones
• In the case of overheating (e.g. when a
saucepan boils dry) the cooking zone au-
tomatically switches itself off. is dis-
played. Before being used again the cook-
ing zone must be set to 0 and allowed to
cool.
• If cookware that is not suitable is used,
lights up in the display and after 2 mi-
nutes the indicator for the cooking zone
switches itself off.
• If one of the cooking zones is not switched
off after a certain time, or if the heat setting
is not modified, the relevant cooking zone
switches off automatically. is displayed.
Before being used again, the cooking zone
must be set to .
Heat setting Switches off after
1 - 2 6 hours
3 - 4 5 hours
54 hours
6 - 9 1.5 hours
Tips on cooking and frying
Information about acrylamides
According to the latest scientific re-
search, intensive browning of food, es-
pecially in products containing starch,
may present a health risk due to acryla-
mide. Therefore we recommend cook-
ing at low temperatures and not brown-
ing foods too much.
Cookware for induction cooking zones
Cookware material Suitable
Steel, enamelled steel +
Cast iron +
Stainless steel +*
Cookware bottom of multilayer +*
Aluminium, copper, brass -
Glass, ceramic, porcelain -
electrolux 9

* Cookware for induction cooking zones is
labelled as suitable by the manufacturer.
Suitability test
Cookware is suitable for induction cooking, if
…
• ... a little water on an induction cooking
zone set to the highest heat setting is heat-
ed within a short time.
• ... a magnet sticks to the bottom of the
cookware.
Certain cookware can make noises
when being used on induction cooking
zones. These noises are not a fault in the
appliance and do not affect operation in
any way.
Bottom of the cookware
The bottom of the cookware should be as
thick and level as possible.
Pan size
Induction cooking zones adapt automatically
to the size of the bottom of the cookware up
to a certain point. However the magnetic part
of the bottom of the cookware must have a
minimum diameter depending on the size of
the cooking zone. Cookware with a bottom
with a diameter of less than 12cm is not suit-
able.
Tips on energy saving
Place cookware on the cooking zone
before it is switched on.
If possible, always place a lid on the
cookware.
Examples of cooking applications
The information given in the following table is
for guidance only.
Heat
setting
Cooking proc-
ess
suitable for Cook time Tips/Hints
0 Off position
1Keeping food
warm
Keeping cooked foods
warm
as required Cover
1-2 Melting Hollandaise sauce, melt-
ing butter, chocolate,
gelatine
5-25 mins. Stir occasionally
1 - 2 Solidifying Fluffy omelettes, baked
eggs
10-40 mins. Cook with lid on
2-3 Simmering on low
heat
Simmering rice and milk-
based dishes
Heating up ready-
cooked meals
25-50 mins. Add at least twice as
much liquid as rice, stir
milk dishes part way
through cooking
3-4 Steaming
Braising
Steaming vegetables,
fish
Braising meat
20-45 mins. With vegetables add
only a little liquid (a few
tablespoons)
4-5 Boiling Steaming potatoes 20-60 mins. Use only a little liquid, e.
g.: max. ¼ l water for
750 g of potatoes
4-5 Boiling Cooking larger quanti-
ties of food, stews and
soups
60-150 mins. Up to 3 l liquid plus in-
gredients
6-7 Gentle frying Frying escalope, veal
cordon bleu, cutlets, ris-
soles, sausages, liver,
roux, eggs, pancakes,
doughnuts
Steady frying Turn halfway through
cooking
7-8 Heavy frying Hash browns, loin
steaks, steaks, Flädle
(pancakes for garnishing
soup)
5-15 mins. per
pan
Turn halfway through
cooking
10 electrolux

Heat
setting
Cooking proc-
ess
suitable for Cook time Tips/Hints
9Boiling Searing
Deep frying
Boiling large quantities of water, cooking pasta, searing meat (gou-
lash, pot roast), deep frying chips
The power function is suitable for heating
large quantities of liquid.
Cleaning and care
Warning! Sharp objects and abrasive
cleaning agents can damage the
appliance by scratching the glass
surface, which may result in shattering of
glass. Clean the appliance and remove
the residues with water and washing up
liquid after each use. Remove also
remnants of cleaning agents!
Scratches or dark stains on the glass
ceramic that cannot be removed do not
affect the functioning of the appliance.
Cleaning the appliance after each use
1. Food containing sugar, plastics, tin foil
residues should be removed at once us-
ing a scraper. Place a scraper on the
glass ceramic surface at an angle and re-
move residues by sliding the blade over
the surface. Wipe the appliance with a
damp cloth and a little washing up liquid.
Finally, rub the appliance dry using a
clean cloth .
2. Limescale rings, water rings, fat
splashes, shiny metallic discolorations
should be removed after the appliance
has cooled down using cleaner for glass
ceramic or stainless steel.
Warning! Do not use a steam cleaner to
clean this appliance.
What to do if…
Problem Possible cause Remedy
The cooking zones cannot be
switched on or are not operating
More than 10 seconds have
passed since the appliance was
switched on
Switch the appliance on again
The lock is switched on Switch off the lock (See the sec-
tion “Locking/unlocking the
control panel”)
The child safety device is
switched on
Deactivate child safety device
(See the section “Child safety
device”)
Several sensor fields were
touched at the same time
Only touch one sensor field
Automatic switch-off has been
triggered
Remove any objects (pans, etc.)
that are lying on the control pan-
el. Switch appliance on again
is active Switch off
Acoustic signal sounds when ap-
pliance is switched off
The control panel is wholly or
partly covered by objects.
Remove objects.
The residual heat indicator is not
displaying anything
The cooking zone was only on
for a short time and is therefore
not hot
If the cooking zone is supposed
to be hot, call your local Service
Force Centre.
electrolux 11

Problem Possible cause Remedy
Repeated acoustic signal (6x),
appliance switches off
One or more sensor fields have
been covered for longer than 10
seconds
Uncover sensor field
Acoustic signal sounds and ap-
pliance switches itself on and
then off again; after 5 seconds
another acoustic signal sounds
The On/Off sensor field has
been covered up, e.g. by a cloth
Do not place any objects on the
control panel
Display is switching between two
heat settings
Power management is reducing
the power of this cooking zone
See the section “Switching the
power function on and off”
lights up Unsuitable cookware Use suitable cookware
No cookware on the cooking
zone
Put cookware on zone
Diameter of the base of the
cookware is too small for the
cooking zone
Move to smaller cooking zone
Use suitable cookware
Overheating protection for the
cooking zone has been trig-
gered
Switch off the cooking zone.
Switch the cooking zone on
again
Automatic switch-off has been
triggered
Switch appliance off. Switch ap-
pliance on again
and number are displayed Electronics fault Disconnect the appliance from
the electrical supply for a few
minutes (Take the fuse out of the
house’s wiring system) If after
switching on again, is dis-
played again, call the customer
service department
If you are unable to remedy the problem
by following the above suggestions,
please contact your dealer or the Cus-
tomer Care Department.
Warning! Repairs to the appliance are only to be carried out by qualified service
engineers. Considerable danger to the user may result from improper repairs.
If the appliance has been operated incorrectly, the engineer's visit will be chargeable,
even during the warranty period.
Operating noises
Depending on the material and the process-
ing of the base, the following noises may oc-
cur when using induction cooking zones.
•Cracking noise
1
when using cookware made of different
materials (Sandwich construction)
1
3
2
12 electrolux

•Whistling
1
when using an individual cooking zone or
several cooking zones with high powers
when the cookware is made of different
materials (Sandwich construction)
•Humming
2
can occur at high power levels
•Clicking
2
during electric switching processes
•Hissing, buzzing
3
The device is fitted with a fan for cooling
the electrics. A whiring noise can be heard
when operating the fan which may deviate
depending on the performance and may
continue for a while after the appliance is
switched off.
The noises described are normal and do
not refer to any defects.
Disposal
The symbol on the product or on its
packaging indicates that this product may
not be treated as household waste. Instead
it should be taken to the appropriate
collection point for the recycling of electrical
and electronic equipment. By ensuring this
product is disposed of correctly, you will help
prevent potential negative consequences for
the environment and human health, which
could otherwise be caused by inappropriate
waste handling of this product. For more
detailed information about recycling of this
product, please contact your local council,
your household waste disposal service or the
shop where you purchased the product.
Packaging material
The packaging materials are environ-
mentally friendly and can be recycled.
The plastic components are identified by
markings, e.g. >PE<, >PS<, etc. Please
dispose of the packaging materials in the
appropriate container at your local
waste disposal facilities.
Installation Instructions
Warning! Safety instructions
Warning! This must be read! The laws,
ordinances, directives and standards in
force in the country of use are to be
followed (safety regulations, proper
recycling in accordance with the
regulations, etc.)
Important! Installation may only be carried
out by a qualified electrician.
The minimum distances to other appliances
and units are to be observed.
Anti-shock protection must be provided by
the installation, for example drawers may on-
ly be installed with a protective floor directly
underneath the appliance.
The cut surfaces of the worktop are to be
protected against moisture using a suitable
sealant. The sealant seals the appliance to
the work top with no gap. Do not use silicon
sealant between the appliance and the work
top.
Avoid installing the appliance next to doors
and under windows. Otherwise hot cook-
ware may be knocked off the rings when
doors and windows are opened.
Caution! Warning! Risk of injury
from electrical current.
• The electrical mains terminal is live.
• Make electrical mains terminal free of volt-
age.
• Follow connection schematic.
• Observe electrical safety rules.
• Ensure anti-shock protection by installing
correctly.
• The appliance must be connected to the
electrical supply by a qualified electrician.
• Loose and inappropriate plug and socket
connections can make the terminal over-
heat.
• Have the clamping connections correctly
installed by a qualified electrician.
• Use strain relief clamp on cable.
• A ventilation gap of 5 mm underneath the
cooktop must be left.
electrolux 13

Caution! The surface temperature
exceeds 95°C. To avoid a hazard,
underbench access must be restric-
ted
Electrical Connection
Before connecting, check that the nominal
voltage of the appliance, that is the voltage
stated on the rating plate, corresponds to the
available supply voltage. Also check the
power rating of the appliance and ensure that
the wire is suitably sized in accordance with
local wiring rules to suit the appliance power
rating. The rating plate is located on the lower
casing of the hob. The heating element volt-
age is AC230V~. The appliance also works
perfectly on networks with AC220V~ or
AC240V~. Means for disconnection must be
incorporated in the fixed wiring in accord-
ance with local wiring rules.The hob is to be
connected to the mains using a device that
allows the appliance to be disconnected
from the mains at all poles with a contact
opening width of at least 3 mm, eg. auto-
matic line protecting cut-out, earth leakage
trips or fuse. If this appliance’s mains cable
is damaged, it must be replaced by a special
cable (type H05BB-F Tmax 90°C; or higher).
The latter is available from the Customer
Care Department. The connection must be
carried out as shown in the diagram. The
connecting links should be fitted according
to the connection diagram sticker on the
back of the appliance. Note for single phase
connection the link supplied in the terminal
box needs to be fitted between terminals 1
and 2. The earth lead is connected to termi-
nal . The earth lead must be longer than
leads carrying electric current. The cable
connections must be made in accord-
ance with regulations and the terminal
screws tightened securely. Finally, the
connecting cable is to be secured with the
mains cable cleat and the covering closed by
pressing firmly (lock into place). Before
switching on for the first time, any protective
foil or stickers must be removed from the
glass ceramic surface.
Warning! Once connected to the
mains supply check that all cooking
zones are ready for use by briefly
switching each on in turn at the
maximum setting.
• A duplicate rating label is supplied
with this unit. For easy identification of
this unit after installation, stick it to a
readily available surface adjacent to
the cooktop.
Sticking on the seal
• Clean the worktop around the cutout area.
• Stick the single-sided adhesive sealing
tape provided on the underside of the hob
around the outside edge ensuring that it is
not stretched. The two ends of the tape
should join in the middle of one side. After
trimming the tape (allow it to overlap by 2-3
mm), press the two ends together.
Assembly
14 electrolux

min. 5min. 5
min. 20
min.
38mm
min. 5mm
min.
25mm
min. 5mm
min. 20mm
Warning! Surface temperatures of
base exceed 95°C, under bench
access must be restricted by use of
non-combustible barrier on
installation
Rating plate
Modell EHD90230P
Electrolux
Prod. Nr. 949 593 170
Typ 55 GDD E2 AG 230 V, 50 Hz
6,9 kW
electrolux 15

Service
In the event of technical faults, please first
check whether you can remedy the problem
yourself with the help of the operating in-
structions (section “What to do if…”).
If you were not able to remedy the problem
yourself, please contact the Customer Care
Department or one of our service partners.
In order to be able to assist you quickly, we
require the following information:
– Three-digit-letter combination
for glass ceramic
– Model description
– Product number (PNC)
– Serial number
(S No. - see rating plate)
–Typeoffault
– Any error messages displayed by
the appliance
Warranty
FOR SALES IN AUSTRALIA AND NEW ZEA-
LAND
This document sets out the terms and
conditions of product warranties for
Electrolux branded appliances. It is an
important document. Please keep it with
your proof of purchase documents in a
safe place for future reference should
you require service for your Electrolux
appliance. General Terms and Condi-
tions
1. In this warranty
– Electrolux' means Electrolux Home
Products Pty Ltd ABN 51 004 762 341
in respect of Appliances purchased in
Australia and Electrolux (NZ) Limited in
respect of Appliances purchased in
New Zealand;
– 'Appliance' means any Electrolux
product purchased by you accompa-
nied by this document;
– 'Warranty Period' means
i) where you use the Appliance for per-
sonal, domestic or household purpo-
ses in Australia the period of 24
months and in New Zealand the peri-
od of 24 months;
ii) where you use the Appliance for
commercial purposes, in Australia the
period of 3 months and in New Zea-
land the period of 3 months, (if the pe-
riod stated is 0 months you are not
covered by this product warranty) fol-
lowing the date of original purchase of
the Appliance;
– 'you' means the purchaser of the Ap-
pliance not having purchased the ap-
pliance for re-sale, and 'your' has a
corresponding meaning.
2. This warranty only applies to Appliances
purchased and used in Australia or New
Zealand and is in addition to (and does
not exclude, restrict, or modify in any
way) any non-excludable statutory war-
ranties in Australia or New Zealand.
3. Electrolux warrants that, when dispatch-
ed from an Electrolux warehouse, the
Appliance is free from defects in materi-
als and workmanship for the Warranty
Period.
4. During the Warranty Period Electrolux or
its Authorised Service Centre will, at no
extra charge if your appliance is readily
accessible without special equipment,
and subject to these terms and condi-
tions, repair or replace any parts which it
considers to be defective. You agree that
any replaced Appliances or parts be-
come the property of Electrolux. This
warranty does not apply to light globes,
batteries, filters or similar perishable
parts.
5. Parts and Appliances not supplied by
Electrolux are not covered by this war-
ranty.
16 electrolux

6. Where you are within an Electrolux serv-
ice area, this warranty covers the cost of
transport of the Appliance to and from
Authorised Service Centres of Electrolux
and travelling costs for representatives of
the Authorised Service Centre to and
from your home or business. If you are
outside an Electrolux service area, you
will bear these costs. For information
about whether you are within an Electro-
lux service area, please phone 13 13 49
in Australia, or 0800 10 66 10 in New
Zealand.
7. Proof of purchase is required before you
can make a claim under this warranty.
8. You may not make a claim under this
warranty unless the defect claimed is
due to faulty or defective parts or work-
manship. Electrolux is not liable in the
following situations (which are not ex-
haustive):
– The Appliance is damaged by
i) accident
ii) misuse or abuse, including failure to
properly maintain or service
iii) normal wear and tear
iv) power surges, electrical storm
damage or incorrect power supply
v) incomplete or improper installation
vi) incorrect, improper or inappropriate
operation
vii) insect or vermin infestation.
– The Appliance is modified without au-
thority from Electrolux in writing.
– The Appliance's serial number or war-
ranty seal has been removed or de-
faced.
– The Appliance was serviced or re-
paired by anyone other than Electrolux
or its Authorised Service Centres.
9. This warranty, the contract to which it
relates and the relationship between you
and Electrolux are governed by the law
applicable in the Australian State where
the Appliance was purchased or the law
applicable in New Zealand if the Appli-
ance was purchased in New Zealand.
Where the Appliance was purchased in
New Zealand for business purposes the
Consumer Guarantee Act does not ap-
ply.
Limitation of Liability
10. To the extent permitted by law:
– Electrolux excludes all warranties oth-
er than as contained in this document;
– Electrolux shall not be liable for any
loss or damage whether direct or in-
direct or consequential arising from
your purchase, use or non-use of the
Appliance.
11. Provisions of the Trade Practices Act
and State consumer legislation in Aus-
tralia, and the Consumer Guarantees
Act, the Sale of Goods Act and the Fair
Trading Act in New Zealand, imply war-
ranties or conditions, or impose obliga-
tions, upon Electrolux which cannot be
excluded, restricted or modified. To the
extent permitted by law, the liability of
Electrolux (if any) arising out of or in re-
lation to the Appliance or any services
supplied by Electrolux shall be limited
(where it is fair and reasonable to do so),:
– in the case of Appliances, at its option,
to the replacement or repair of the Ap-
pliances or the supply of equivalent
products or the payment of the cost of
replacing the Appliances or having the
Appliances repaired or of acquiring
equivalent Appliances. Upon being re-
placed, parts and Appliances become
the property of Electrolux; or
– in the case of services, at its option, to
the supply of the services again or the
payment of the cost of having the
services re-supplied;
and in the case of Appliances or services
supplied in New Zealand, loss or dam-
age whether direct or indirect or conse-
quential that is reasonably foreseeable.
Privacy
You acknowledge that in the event that you
make a warranty claim it will be necessary for
Electrolux and its Authorised Service Centres
to exchange information in relation to you to
enable Electrolux to meet its obligations un-
der this warranty.
Important Notice
Before Calling a Service Technician please
check carefully the operating instructions,
service booklet and the warranty terms and
conditions.
electrolux 17

FOR SERVICE
OR TO FIND THE ADDRESS OF
YOUR NEAREST STATE SERV-
ICE CENTRE IN AUSTRALIA
Please call 13 13 4 9
For the cost of a local call (Australia only)
SERVICE AUSTRALIA
ELECTROLUX HOME PROD-
UCTS
www.electrolux.com.au
FOR SPARE PARTS
OR TO FIND THE ADDRESS OF
YOUR NEAREST STATE
SPARE PARTS CENTRE IN
AUSTRALIA
Please call 13 13 50
For the cost of a local call (Australia only)
FOR SERVICE
OR TO FIND THE ADDRESS OF
YOUR NEAREST AUTHORISED
SERVICE CENTRE IN NEW
ZEALAND
Free call 0800 10 66 10
(New Zealand only)
SERVICE NEW ZEALAND
ELECTROLUX HOME PROD-
UCTS
www.electrolux.co.nz
FOR SPARE PARTS
OR TO FIND THE ADDRESS OF
YOUR NEAREST SPARE
PARTS CENTRE IN NEW ZEA-
LAND
Free call 0800 10 66 20
(New Zealand only)
18 electrolux

electrolux 19

892930416-C-032009
www.electrolux.com
www.electrolux.com.au
www.electrolux.co.nz
