Electrolux EB4GL90KCN User manual

EB4GL90KCN
EB4GL90KSP
EN User Manual | Microwave combi-oven 2
DE Benutzerinformation | Backofen mit Mikrowelle 37

Welcome to Electrolux! Thank you for choosing our appliance.
Get usage advice, brochures, trouble shooter, service and repair information:
www.electrolux.com/support
Subject to change without notice.
CONTENTS
1. SAFETY INFORMATION................................................................................ 2
2. SAFETY INSTRUCTIONS.............................................................................. 5
3. PRODUCT DESCRIPTION............................................................................. 8
4. CONTROL PANEL.......................................................................................... 9
5. BEFORE FIRST USE....................................................................................10
6. DAILY USE....................................................................................................11
7. CLOCK FUNCTIONS.................................................................................... 14
8. AUTOMATIC PROGRAMMES......................................................................15
9. USING THE ACCESSORIES........................................................................15
10. ADDITIONAL FUNCTIONS.........................................................................16
11. HINTS AND TIPS........................................................................................ 17
12. CARE AND CLEANING.............................................................................. 32
13. TROUBLESHOOTING................................................................................ 33
14. ENERGY EFFICIENCY...............................................................................35
15. GUARANTEE ............................................................................................. 35
16. ENVIRONMENTAL CONCERNS................................................................36
1. SAFETY INFORMATION
Before the installation and use of the appliance, carefully read
the supplied instructions. The manufacturer is not responsible
for any injuries or damage that are the result of incorrect
installation or usage. Always keep the instructions in a safe
and accessible location for future reference.
1.1 Children and vulnerable people safety
• This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concerning
the use of the appliance in a safe way and understand the
hazards involved. Children of less than 8 years of age and
persons with very extensive and complex disabilities shall
2 ENGLISH

be kept away from the appliance unless continuously
supervised.
• Children should be supervised to ensure that they do not
play with the appliance.
• Keep all packaging away from children and dispose of it
appropriately.
• WARNING: The appliance and its accessible parts become
hot during use. Keep children and pets away from the
appliance when in use and when cooling down.
• If the appliance has a child safety device, it should be
activated.
• Children shall not carry out cleaning and user maintenance
of the appliance without supervision.
1.2 General Safety
• This appliance is for cooking purposes only.
• This appliance is designed for single household domestic
use in an indoor environment.
• This appliance may be used in, offices, hotel guest rooms,
bed & breakfast guest rooms, farm guest houses and other
similar accommodation where such use does not exceed
(average) domestic usage levels.
• Only a qualified person must install this appliance and
replace the cable.
• Do not use the appliance before installing it in the built-in
structure.
• Disconnect the appliance from the power supply before
carrying out any maintenance.
• If the supply cord is damaged, it must be replaced by the
manufacturer, its Authorised Service Centre or similarly
qualified persons to avoid an electrical hazard.
• WARNING: Ensure that the appliance is switched off before
replacing the lamp to avoid the possibility of electric shock.
• WARNING: The appliance and its accessible parts become
hot during use. Care should be taken to avoid touching
heating elements or the surface of the appliance cavity.
ENGLISH 3

• Always use oven gloves to remove or insert accessories or
ovenware.
• Do not activate the microwave function when the appliance
is empty. Metal parts inside the cavity can create electric
arcing.
• Metallic containers for food and beverages are not allowed
during microwave cooking. This requirement is not
applicable if the manufacturer specifies size and shape of
metallic containers suitable for microwave cooking.
• WARNING: If the door or door seals are damaged, the
appliance must not be operated until it has been repaired by
a qualified person.
• WARNING: Only a qualified person can carry out any
service or repair operation that involves the removal of a
cover which gives protection against exposure to
microwave energy.
• WARNING: Do not heat liquids and other foods in sealed
containers. They are liable to explode.
• Use only utensils that are suitable for use in microwave
ovens.
• When heating food in plastic or paper containers, observe
the appliance due to the possibility of ignition.
• The appliance is intended for heating food and beverages.
Drying of food or clothing and heating of warming pads,
slippers, sponges, damp cloth and similar may lead to risk
of injury, ignition or fire.
• If smoke is emitted, switch off or unplug the appliance and
keep the door closed in order to stifle any flames.
• Microwave heating of beverages can result in delayed
eruptive boiling. Care must be taken when handling the
container.
• The contents of feeding bottles and baby food jars shall be
stirred or shaken and the temperature checked before
consumption, in order to avoid burns.
4 ENGLISH

• Eggs in their shell and whole hard-boiled eggs should not
be heated in the appliance since they may explode, even
after microwave heating has ended.
• To remove the shelf supports first pull the front of the shelf
support and then the rear end away from the side walls.
Install the shelf supports in the opposite sequence.
• The appliance should be cleaned regularly and any food
deposits removed.
• Do not use a steam cleaner to clean the appliance.
• Do not use harsh abrasive cleaners or sharp metal scrapers
to clean the glass door since they can scratch the surface,
which may result in shattering of the glass.
• Failure to maintain the appliance in a clean condition could
lead to deterioration of the surface that could adversely
affect the life of the appliance and possibly result in a
hazardous situation.
2. SAFETY INSTRUCTIONS
2.1 Installation
WARNING!
Only a qualified person must install this
appliance.
• Remove all the packaging.
• Do not install or use a damaged
appliance.
• Follow the installation instructions supplied
with the appliance.
• Always take care when moving the
appliance as it is heavy. Always use safety
gloves and enclosed footwear.
• Do not pull the appliance by the handle.
• Install the appliance in a safe and suitable
place that meets installation requirements.
• Keep the minimum distance from other
appliances and units.
• Before mounting the appliance, check if
the appliance door opens without restraint.
• The appliance is equipped with an electric
cooling system. It must be operated with
the electric power supply.
• The built-in unit must meet the stability
requirements of DIN 68930.
Cabinet minimum height
(Cabinet under the worktop
minimum height)
450 (460) mm
Cabinet width 560 mm
Cabinet depth 550 (550) mm
Height of the front of the
appliance
455 mm
Height of the back of the
appliance
440 mm
Width of the front of the ap‐
pliance
596 mm
Width of the back of the ap‐
pliance
560 mm
Depth of the appliance 567 mm
Built in depth of the appli‐
ance
546 mm
Depth with open door 882 mm
Ventilation opening mini‐
mum size. Opening placed
on the bottom rear side
560x20 mm
ENGLISH 5

Mains supply cable length.
Cable is placed in the right
corner of the back side
2500 mm
Mounting screws 3.5x25 mm
2.2 Electrical connection
WARNING!
Risk of fire and electric shock.
• All electrical connections should be made
by a qualified electrician.
• The appliance must be earthed.
• Make sure that the parameters on the
rating plate are compatible with the
electrical ratings of the mains power
supply.
• Always use a correctly installed
shockproof socket.
• Do not use multi-plug adapters and
extension cables.
• Make sure not to cause damage to the
mains plug and to the mains cable. Should
the mains cable need to be replaced, this
must be carried out by our Authorised
Service Centre.
• Do not let mains cables touch or come
near the appliance door or the niche below
the appliance, especially when it operates
or the door is hot.
• The shock protection of live and insulated
parts must be fastened in such a way that
it cannot be removed without tools.
• Connect the mains plug to the mains
socket only at the end of the installation.
Make sure that there is access to the
mains plug after the installation.
• If the mains socket is loose, do not
connect the mains plug.
• Do not pull the mains cable to disconnect
the appliance. Always pull the mains plug.
• Use only correct isolation devices: line
protecting cut-outs, fuses (screw type
fuses removed from the holder), earth
leakage trips and contactors.
• The electrical installation must have an
isolation device which lets you disconnect
the appliance from the mains at all poles.
The isolation device must have a contact
opening width of minimum 3 mm.
• This appliance is supplied with a main
plug and a main cable.
2.3 Use
WARNING!
Risk of injury, burns and electric shock or
explosion.
• Do not change the specification of this
appliance.
• Make sure that the ventilation openings
are not blocked.
• Do not let the appliance stay unattended
during operation.
• Deactivate the appliance after each use.
• Be careful when you open the appliance
door while the appliance is in operation.
Hot air can release.
• Do not operate the appliance with wet
hands or when it has contact with water.
• Do not apply pressure on the open door.
• Do not use the appliance as a work
surface or as a storage surface.
• Open the appliance door carefully. The
use of ingredients with alcohol can cause
a mixture of alcohol and air.
• Do not let sparks or open flames to come
in contact with the appliance when you
open the door.
• Do not put flammable products or items
that are wet with flammable products in,
near or on the appliance.
• Do not use microwave function to preheat
the appliance.
WARNING!
Risk of damage to the appliance.
• To prevent damage or discoloration to the
enamel:
– do not put aluminium foil directly on
the bottom of cavity of the appliance.
– do not put water directly into the hot
appliance.
– do not keep moist dishes and food in
the appliance after you finish the
cooking.
– be careful when you remove or install
the accessories.
• Discoloration of the enamel or stainless
steel has no effect on the performance of
the appliance.
• Use a deep pan for moist cakes. Fruit
juices cause stains that can be
permanent.
6 ENGLISH

• Always cook with the appliance door
closed.
• If the appliance is installed behind a
furniture panel (e.g. a door) make sure the
door is never closed when the appliance
operates. Heat and moisture can build up
behind a closed furniture panel and cause
subsequent damage to the appliance, the
housing unit or the floor. Do not close the
furniture panel until the appliance has
cooled down completely after use.
2.4 Care and cleaning
WARNING!
Risk of injury, fire, or damage to the
appliance.
• Before maintenance, deactivate the
appliance and disconnect the mains plug
from the mains socket.
• Make sure the appliance is cold. There is
the risk that the glass panels can break.
• Replace immediately the door glass
panels when they are damaged. Contact
the Authorised Service Centre.
• Be careful when you remove the door from
the appliance. The door is heavy!
• Make sure the cavity and the door are
wiped dry after each use. Steam produced
during the operation of the appliance
condensates on cavity walls and can
cause corrosion.
• Clean regularly the appliance to prevent
the deterioration of the surface material.
• Fat and food remaining in the appliance
can cause fire and electric arcing when
the microwave function operates.
• Clean the appliance with a moist soft
cloth. Use only neutral detergents. Do not
use abrasive products, abrasive cleaning
pads, solvents or metal objects.
• If you use an oven spray, follow the safety
instructions on its packaging.
2.5 Glassware use
Handling your glassware without an
appropriate degree of care could result in
breakage, chipping, cracking or severe
scratching:
• Do not spill cold water or other liquids on
the glassware because a sudden
temperature drop may cause immediate
breakage of the glass. Broken glass
pieces may be extremely sharp and
difficult to locate.
• Do not place hot glassware on a wet or
cool surface, directly on countertop or
metal surface, or in sink; or handle hot
glassware with wet cloth.
• Do not use or repair any glassware that is
chipped, cracked or severely scratched.
• Do not drop or hit glassware against a
hard object or strike utensils against it.
• Do not heat empty or nearly empty
glassware in microwave, or overheat oil or
butter in microwave (use minimum amount
of cooking time).
Allow hot glassware to cool on a cooling rack,
a potholder or a dry cloth. Make sure that the
glassware is cool enough before washing,
refrigerating or freezing.
Avoid handling hot glassware (including ware
with silicone gripping surfaces) without dry
potholders.
Avoid microwave misuse (i.e. running the
oven without any load or small load).
2.6 Internal lighting
WARNING!
Risk of electric shock.
• Concerning the lamp(s) inside this product
and spare part lamps sold separately:
These lamps are intended to withstand
extreme physical conditions in household
appliances, such as temperature,
vibration, humidity, or are intended to
signal information about the operational
status of the appliance. They are not
intended to be used in other applications
and are not suitable for household room
illumination.
• This product contains a light source of
energy efficiency class G.
• Use only lamps with the same
specifications.
2.7 Service
• To repair the appliance contact the
Authorised Service Centre.
• Use original spare parts only.
ENGLISH 7

2.8 Disposal
WARNING!
Risk of injury or suffocation.
• Contact your municipal authority for
information on how to dispose of the
appliance.
• Disconnect the appliance from the mains
supply.
• Cut off the mains electrical cable close to
the appliance and dispose of it.
• Remove the door catch to prevent children
or pets from becoming trapped in the
appliance.
3. PRODUCT DESCRIPTION
3.1 General overview
1 2
8
4
3
1
2
3
6
4
5
7
1Control panel
2Electronic programmer
3Heating element
4Microwave generator
5Lamp
6Fan
7Shelf support, removable
8Shelf positions
3.2 Accessories
Wire shelf
For cookware, cake tins, roasts.
Baking tray
For cakes and biscuits.
Microwave bottom glass plate
To prepare food in microwave mode.
8 ENGLISH

4. CONTROL PANEL
4.1 Electronic programmer
21 3 4 5 8 9 10 1176
Use the sensor fields to operate the appliance.
Sensor field Function Comment
1-Display Shows the current settings of the appliance.
2ON / OFF To turn on and off the oven.
3
Heating Functions
or Recipes
Press the sensor field once to choose a heating function or the
menu: Recipes. Press the sensor field again to switch between
the menus: Heating Functions, Recipes. To turn on or turn off
the light, touch the field for 3 seconds.
4
Microwave function To activate the Microwave function. You can use it when the ap‐
pliance is deactivated. When you use the Microwave function
with the function: Duration for more than 7 minutes and in Com‐
bi mode, the Microwave power cannot be more than 600 W.
5Temperature selec‐
tion
To set the temperature or show the current temperature in the
oven.
6Down To move down in the menu.
7Up To move up in the menu.
8OK / Microwave
Quick Start
To confirm the selection or settings. To activate the Microwave
function. You can use it when the appliance is deactivated.
9Back To go back one level in the menu. To show the main menu,
touch the field for 3 seconds.
10 Time and additional
functions
To set different functions. When a heating function operates,
touch the sensor field to set the timer or the functions: Function
Lock, Favourites, Heat + Hold, Set + Go.
11 Minute Minder To set the function: Minute Minder.
ENGLISH 9

4.2 Display
A
DE
B C
A. Heating function or Microwave function
B. Time of day
C. Heat-up indicator
D. Temperature or power of the microwave
E. Duration time or end time of a function
Other indicators of the display:
Symbol Function
Minute Minder The function works.
Time of day The display shows the current time.
Duration The display shows the necessary time for cook‐
ing.
End Time The display shows when the cooking time is
complete.
Temperature The display shows the temperature.
Time Indication The display shows how long the heating function
works. Press and at the same time to
reset the time.
Heat-up Indicator The display shows the temperature in the oven.
Weight Automatic The display shows that the automatic weight
system is on or that weight can be changed.
Heat + Hold The function is on.
5. BEFORE FIRST USE
WARNING!
Refer to Safety chapters.
5.1 Initial Cleaning
Step 1 Step 2 Step 3
Remove all accessories and remov‐
able shelf supports from the oven.
Clean the oven and the accessories
with a soft cloth, warm water and a
mild detergent.
Place the accessories and the re‐
movable shelf supports in the oven.
10 ENGLISH
