Electrolux 253.60722005 Manual

P08F0077.eps P08D0542.eps P08C1117.eps P08S0470.eps
REPAIR
PARTS
LIST
253.60722005
For Parts or Service:
Call
1-800-4-MY-HOME®
(1-800-469-4663)
Or Visit
www.sears.com
REFRIGERATOR
In all orders or correspondence, avoid delays and misunderstandings
by always giving the complete model number shown on the left side of
the access panel.
All repair parts listed are available for immediate purchase or special
order when you visit your nearest Sears Parts & Repair Center, or the
Service Department at most Sears stores. To order parts by phone, call
the toll-free number listed to the left or visit sears.com.
When requesting service or ordering parts, always provide the following
information:
• Product Type • Part Number
• Model Number • Part Description
Sears, Roebuck and Co., Hoffman Estates, IL 60179 U.S.A
Publication number 5995535738

253.60722005
03/09 2
DOOR
CAUTION: Use the Kenmore part number to order part, not the illustration number.

253.60722005
# Functional Parts 3 03/09
* Non-Illustrated Parts
DOOR
CAUTION: Use the Kenmore part number to order part, not the illustration number.
POS. NO PART NO. DESCRIPTION
1 216522309 Gasket-door, white
9 216527813 Panel-inner door
11 297245214 Panel-outer door, white
12A 216885200 Nameplate
13 297257000 Door Stop, chrome, RH/LH
18 218803901 Handle-door, white
21A 297197500 Screw, door stop mtg, FH38-16X.750, P Twin
22 216970800 Bearing, hinge w/o'ring, top
22A 297006800 Bearing-hinge, btm, w/o'ring
26 216524201 Gasket, secondary
27 F5304472186Clip, panel mtg
27* 5304406520 Clip, panel mtg kit, (40)
28 216951600 Rack-door, (5)
32 5309950074 Valve, breather
37 218771201 Trim-handle, 1.34", white
58 218252201 Screw, #8 truss hd, 10-32CA x 0.500
64 216403700 Plug-button, hole filler, door base
72 218397000 Button-handle mtg, dovetail
73 218396700 Block-handle mtg, dovetail
74 240521303 Screw, #10-16 x 1/2
93 5304460605 Screw, ph truss head, 8-18AB x 0.500

253.60722005
03/09 4
CABINET
CAUTION: Use the Kenmore part number to order part, not the illustration number.
6
9
34
132
47
63
25
19
18
71A 21
20
93B
80
24
22
42
42
42
42A
22A
9
6
3
32
9
14
16
15
P08C1117
38
41
40
93
72
31
10A
10
35
29
49
93
93
37
37
93A
93A
169
50
13
5
26
41 28

253.60722005
# Functional Parts 5 03/09
* Non-Illustrated Parts
CABINET
CAUTION: Use the Kenmore part number to order part, not the illustration number.
POS. NO PART NO. DESCRIPTION
3 216503100 Screen-drain
5 # 216325600 Fan Blade
6 297200600 Breaker Kit w/corners, no lock slot
9 297200100 Breaker Kit w/corners, 32", top and bottom
10 # 297175600 Heater-Drain Pan
10A 297177400 Bracket, (2), drain pan
13 # 297250000 Motor, fan, 115 V
14 216998000 Switch, light/lamp, ramp
15 216846400 Light Bulb/Lamp
16 297139500 Socket, light/lamp
18 216707200 Knob, temp control
19 216204900 Gasket, evap cover
20 216230300 Cover, temp control
21 # 216807800 Control-temperature
22 216823500 Clamp, cap tube, cold control
22A 5303916855 Tube, sensor sleeve, plastic, clear
24 5304460604 Screw, type A, 10-24 x 3/8
25 297098850 Cover-evaporator
26 216503300 Ramp, door closer
28 297283900 Hinge-bottom, stepped pin
29 216313501 Hose-drain
31 297165800 Pan-drain
32 5308005500 Drain
34 216816200 Shield-light
35 216273000 Clip, drain hose
37 241611301 Trim-cabinet corner, white, (2)
38 297283800 Hinge-upper
40 297164400 Cover-hinge
41 240578902 Screw, hex head, 1/4-20 x 5/8
42 297119600 Shelf, 14.50x27.88, (3)
42A 297119500 Shelf, 12.50x27.88, white
* 216502400 Grommet-shelf mtg
47 216661601 Baffle-plate
49 216937700 Trivet
50 216394050 Bracket, fan motor mount
63 216396900 Screw, leveling foot, plastic, adjustable
63* 297164600 Bracket, LH leg levelor
63* 297164601 Bracket, RH leg levelor
71A 297146800 Screw, 8-18AB x 0.470
72 297036900 Grille/Kickplate, 32", white
80 06594601 Bracket, control
93 5304460605 Screw, ph truss head, 8-18AB x 0.500
93A 216629601 Screw, hex washer head, 10-16 x 0.500, tapping
93B 216036601 Screw, RWHD, 8-32A x 0.500, GX-CA
132 5304460601 Screw, 6-20AB x 3/8
169 216912401 Screw, hex washer head, 8-32 x 0.500, bracket fan mtr, (2)
* 216946200 Service Data Sheet
* 297088200 Owners Guide
* 216697901 Energy Guide
* 5995535738 Repair Parts List
* 297001704 Insulation, 24", drain tube

253.60722005
03/09 6
SYSTEM
CAUTION: Use the Kenmore part number to order part, not the illustration number.

253.60722005
# Functional Parts 7 03/09
* Non-Illustrated Parts
SYSTEM
CAUTION: Use the Kenmore part number to order part, not the illustration number.
POS. NO PART NO. DESCRIPTION
1 # 5300083897 Condenser
2 5308000110 Strap-evap/heater, aluminum, (2)
4 # 216938600 Drier-filter
5 # 297244600 Harness-main
5* 216695300 Relay
14 297216100 Heater-defrost
14A# 297222900 Heater
15 # 216997300 Evaporator
15A 297231800 Heat Exchanger
18 297078701 Insulator-evap, styrofoam, RH
19 297078801 Insulator-evap, styrofoam, LH
20 216731001 Thermostat, defrost
23 # 216744500 Timer-defrost
24 216968501 Bracket-timer
24A 297207900 Guard, timer
27 5308002681 Grommet, compressor
29 # 297224800 Compressor, w/o electricals
30 216954208 Controller, compressor, 5 speed
32 297030500 Clip, controller
35 297177200 Bolt, compressor
43B 297048400 Clip
55 218909911 Capacitor, run
86 216036601 Screw, RWHD, 8-32A x 0.500, GX-CA
87 5304463290 Screw, hi-lo blunt, #8-18X1/2
130 297244700 Support, evaporator mtg
* 216502500 Sleeve, suction line
* 216683900 Thermostat, Service part
* 240555002 Screw-#8-32 X 3/8
* 297174300 Screw, #8, 18x.63, self pierce
*# 297169904 Cord-power
