Electrolux concept counters
Refrigerators with upstand - 4 comp.
Electrolux Professional have designed and produced a complete range of refrigerated
tables, that combines the dual function of worktop and refrigerated table. This versatility
allows notable savings in space whilst offering functional and modular solutions to kitchen
requirements.
728297
• Height-adjustable feet.
• Internal and external
doors, front and side panels
and worktop in 304 AISI
stainless steel.
• Rounded internal corners
for ease of cleaning.
• Refrigerated compartment
designed to accommodate
GN 1/1 containers.
• Digital control panel.
• Suitable to operate in
ambient temperatures up to
+43°C. Temperature range:
-2/+10 °C.
• Forced air circulation for
rapid cooling and an even
temperature distribution.
• Drain outlet and automatic
evaporation of defrost water.
• Access to all components
from the front.
• In compliance with H
requirements.
• C.F.C. and H.C.F.C. free.
• High-density expanded
polyurethane foam 50 mm
in thickness with
cyclopenthane injection.
• Developed and produced
in ISO 9001 and ISO 14001
certified factory.

Electrolux concept counters
Refrigerators with upstand - 4 comp.
Internet: http://www.electrolux.com/foodservice
HBAC1002010-05-28Subject to change without notice
STRUCTURE TO SUPPORT 3 GRIDS(RIGHT+LEFT) 880047 880047
S/S STRUCTURE TO SUPPORT 6 GRIDS (R+L) 880140 880140
PRINTER FOR HACCP BASIC VERSION REFRIG. 881457 881457
LOCK KIT FOR REFRIGERATED TABLES 880130 880130
KIT INTEGRATED HACCP-DIG. REFR. (IR33) 880205 880205
KIT HACCP EKIS 922166 922166
KIT DOOR REVERSIBILITY FOR REF.TABLES 880046 880046
KIT 4 WHEELS (2 W/BRAKE)+4 (40MM)SPACERS 880025 880025
KIT 2 S/S GRIDS GN1/1 FOR REFRIG.TABLES 880139 880139
DRAWER KIT-1/3+2/3 (BOTTLES)-REF.TABLES 880126 880126
3x1/3 DRAWER KIT FOR REFRIGERATED TABLES 880115 880115
2x½ DRAWER KIT FOR REFRIGERATED TABLES 880118 880118
ACCESSORIES
1/1 GN GREY "RILSAN" GRID 4 3
INCLUDED ACCESSORIES
Power supply - V, phases, Hz 230 V, 1N, 50 230 V, 1N, 50
Net weight - kg. 187 191
installed-electric 0.34 0.34
Power - kW
at evaporation temperature - °C -20 -20
Refrigerant power
Refrigeration power - W 343 343
Refrigerant quantity - g. 210 210
Refrigerant type R404a R404a
N° defrost in 24 hrs. 4/20 4/20
Compressor power - HP 1/4 1/4
Door hinges 2 Left+2 Right 2 Left+1 Right
Door - n. 4 3
N° of drawers 2x1/2
Min/Max internal humidity - % 57 57
Upstand ● ●
height 543 543
depth 580 580
Internal dimensions - mm
height 950 950
depth/with open doors 700, 1102 700, 1102
width 2204 2204
External dimensions - mm
Cooling unit Built-In Built-In
Gross capacity (D.I.N. 8952) - l. 560 560
Operating mode Ventilated Ventilated
Operating temperature - min/max °C -2/10 -2/10
TECHNICAL DATA
HB4PU
728511
HB3P2CU
728543

Electrolux concept counters
Refrigerators with upstand - 4 comp.
Internet: http://www.electrolux.com/foodservice
HBAC1002010-05-28Subject to change without notice
EI - Electrical connection 230 V, 1N, 50 230 V, 1N, 50
D - Water drain 18mm 18mm
LEGEND
HB4PU
728511
HB3P2CU
728543
728511, 728543
