COUNTER-DEPTH REFRIGERATOR E23CS78EPS

E23CS78EPS professional series
E23CS78EPS 04/05 © 2005 Electrolux Home Products, NA Printed in the U.S.A.
Counter-Depth Refrigerator Specifications
•Product Weight – 300 Lbs.
•When installing next to wall where handle may make
contact, allow 3" clearance on side of refrigerator.
Standard “Built-In Look” Specifications
•For standard “Built-In Look,” enclosure around
refrigerator must have minimum opening of
70-1/4" H x 36" W x 24" D.
•The height dimension of 70-1/4" is minimum, and is
to be measured from finished floor to underside of
soffit or overhead cabinet.
•All wall /floor molding should be removed prior to
installation.
•Water recess on rear wall recommended to prevent
water line damage. Water line tubing recommended
is 48" minimum length by 1/4" diameter.
•When possible, recess both copper water line and
electrical outlet (See Local Electrical Codes.)
•Front rollers are adjustable for “Built-In Look.”
•If optional Collar Trim Kit (ECK23CDS) is to be used
or anticipated, refer to Collar Trim Kit Specifications
and drawings for different rough-in dimensions.
OPTIONAL –Collar Trim Kit Specifications
•To use optional Collar Trim Kit, an enclosure is
required around refrigerator having a minimum
opening of 70-1/4" H x 36-1/8" W x 24-1/2" D
with 1/2" minimum side panels.
•Add maximum of 1/4" to 70-1/4" opening height
when installed with frameless-style overhead
cabinets, to allow for door opening clearance.
•The cabinet or soffit above refrigerator must extend
out to same depth as side panels.
•To provide additional clearance for overhead cabinet
doors when in open position, allow 1" between
bottom of cabinet door and top of collar trim piece.
•A minimum width of 36-1/8" is required for
refrigerator installation with an additional 1/2"
or 3/4" added for each side panel.
•If 1/2" side panels are used, then side collar trim
piece and panel will be even. If 3/4" side panels are
used, then 1/4" of side panel will extend beyond
collar trim and must be finished.
Smudge-Resistant™
Real Stainless Steel
Real stainless steel exterior with a coating
resistant to fingerprints, smudges and
smears. Finish covers the cabinet,
dispenser fascia, toe kick and hinge cover.
PureAdvantage™Filtration System
The most advanced water filtration system
available offers cleaner, fresher ice and
water. And it is simple to operate,
providing a light that alerts when the filter
needs to be changed. With one touch, the
drip-free cartridge is replaced.
Dynamic Cool™with Easy Set™
Digital Temperature Control System
Amazingly consistent interior temperature
will keep your food fresher longer.
Illumination Solutions
Transition lighting that is so thoughtfully
designed that it gradually illuminates the
interior of the refrigerator with soft but
ample light.
Smooth-Glide™
Full-Extension System
Crispers, deli drawer and freezer basket
slide in and out with ease, extending
completely for convenient access to
stored food.
Express Ice™/Express Freeze™
Creates ice according to your family’s
needs and quickly freezes food to lock
in flavors and nutrients, with the touch
of a button.
SmartFit™/SpillSafe™Shelf
Top shelf height can be raised or lowered
without removing your foods. Stores tall
items easily. Shelf depth will contain a spill
of up to 24 ounces.
ENERGY STAR®
UltraQuiet variable-speed, energy-efficient
compressor conserves energy.
Note: Refer to Product Installation Guide for detailed
instructions on the web at www.electroluxusa.com.
COUNTER-DEPTH REFRIGERATOR
ENERGY STAR®Yes
CAPACITIES
Total Capacity 22.6 Cu. Ft.
Fresh Food Volume 14.06 Cu. Ft.
Freezer Volume 8.50 Cu. Ft.
Total Shelf Area 23.70 Sq. Ft.
Fresh Food Shelf Area 17.26 Sq. Ft.
Freezer Shelf Area 6.40 Sq. Ft.
ICE / WATER DISPENSER
Control Panel Buttons 7
Lighted Actuators Yes
Night Light Yes
Crushed /Cubes / Water Yes
Express Ice™Yes
Express Freeze™Yes
Lock Yes
Filter Reset Yes
FRESH FOOD CONVENIENCES
Filtration System PureAdvantage™
Filter Location Front
Temperature Alarm Yes
Door Ajar Alarm Yes
Power Failure Alarm Yes
Sliding SpillSafe™Glass Shelf 2
Smooth-Glide™Full-Extension Crispers 2
Smooth-Glide™Full-Extension Deli Drawer 1
SmartFit™Sliding SpillSafe™Glass Shelf 1
Clear 1-Gallon Removable Door Bin 1
Clear 2-Liter Adjustable Door Bin 2
Removable Dairy Compartment with Clear Door 1
Clear Temperature-Controlled Deli /Meat Drawer 1
Condiment Bottle Door Storage 1
Dual Humidity-Controlled Clear Crisper 1
Lower Humidity-Controlled Clear Crisper 1
Clear Can / Wine Rack 1
Clear Tall Bottle Retainer 1
In-Door Can Rack 1
Illumination Solutions Lighting Yes
Dynamic Cool™Digital Temperature Control System Yes
FREEZER CONVENIENCES
Automatic Ice Maker with Ice Server Factory Installed
Ice Maker On /Off Switch Yes
Glass Shelf 2
Smooth-Glide™Full-Extension Freezer Basket 1
Full Basket 1
Half Basket 1
Fixed Door Bin 1
Tilt-Out Wire Door Rack 3
Ice Cream Shelf Yes
Dual-Level Lighting Yes
INSTALLATION
Adjustable Rollers Yes
Door Stops Yes
ACCESSORIES
Collar Trim Kit – ECK23CDS Optional
SPECIFICATIONS
Rough-In Dimensions –
Height 70-1/4"
Width 36"
Depth 24"
Product Weight 300 Lbs.
Shipping Weight 325 Lbs.
UPC (0-12505-) 69143-0
NOTE: Always consult local and /or national electric codes. Refer to Product
Installation Guide for detailed installation instructions on the web at
www.electroluxusa.com.
High standards of quality at Electrolux Home Products mean we are constantly working to improve
our products. We reserve the right to change specifications or discontinue models without notice.
USA •250 Bobby Jones Expressway •Augusta, GA 30907
1-877-4electrolux (1-877-435-3287) •
www.electroluxusa.com
CANADA •5855 Terry Fox Way •Mississauga, ON L5V 3E4
1-800-668-4606 •
www.electroluxca.com
6915/16"
3/8" (rollers)
683/16"
6713/16"
291/2"
267/8"
235/8"
451/4"
267/8"
355/8"
235/8"
