Electrolux EI23BC36IB User manual

French Door Refrigerators
EI23BC36I S, EI23BC36I W, EI23BC36I B
Cool Zone™Drawer
This drawer keeps contents chilled, so it’s
perfect for wine and beer or even snacks and
juice boxes.
Luxury-Glide™Freezer Drawer
Two Luxury-Glide™ , full-width baskets are
fully-extendable and have adjustable dividers.
There’s room to store everything, making it
easy to always have frozen pizza and snacks
on hand for an impromptu gathering.
Luxury-Design™Glass Shelves
Removable, all-glass shelves crafted for
exceptional beauty and function.
PureAdvantage®Filtration Systems
Our filtration system keeps clean, filtered air
circulated throughout to prevent odor transfer
and keeps fresh, clean ice at your fingertips.
Replacement Water Filter – PN# EWF01
Replacement Air Filter – PN# EAFCBF
electroluxappliances.com
Wall OvensRefrigerators Warmer DrawersCooktopsBuilt-In Ranges
Freestanding
Ranges
MicrowavesVent HoodsFreezers
Wine Tower/
Under Counter
Washers / Dryers Dishwashers /
Kitchen Cleanup
23 CU. FT. COUNTER-DEPTH
FRENCH DOOR REFRIGERATORS
Capacities
Total Capacity
Fresh Food Volume
Freezer Volume
Total Shelf Area
Fresh Food Shelf Area
Freezer Shelf Area
Exterior
Signature Soft-Arc Doors and Handle Design
IQ-Touch™Electronic Controls
Door Hinge Covers
Fresh Food Conveniences
PureAdvantage®Water & Ice / Air Filtration
Water Filter Location
Temp Alarm System / Door Ajar Alarm / Power Failure Alarm
Luxury-Design™Glass Shelves
Luxury-Glide™Humidity-Controlled Left Crisper
Luxury-Glide™Humidity-Controlled Right Crisper
Cool Zone™Drawer
Perfect Temp Drawer™
Wine Rack
Clear Gallon Adjustable Door Bins
Clear 2-Liter/1/2-Gallon Removable Door Bins
Locking Clear Utility Bin
Tilt-Out Can Racks
Luxury-Design™Ramp-Up Multilevel Lighting – Incandescent
Freezer Conveniences
Automatic Ice Maker
Ice Maker On/Off
Fast Ice™
Lock
Self-Closing Drawer
Sliding Full-Width Freezer Baskets
Plastic Basket Tray
Tilt-Out Wire Door Racks
Luxury-Design™Ramp-Up Multilevel Lighting – Incandescent
Additional Features
ENERGY STAR®
Sabbath Mode (Star-K®Certified)
Specifications
Color –
Stainless Steel
White
Black
Overall Exterior Dimensions –
Height (with Hinges and 3/8" Rollers)
Width
Depth (to Center of Arc)
(with 90° Door Open)
(with Drawer Fully Extended Including Handle)
Power Supply Connection Location
Water Inlet Location
Voltage Rating
Connected Load (kW Rating)@120 Volts ‡
Minimum Circuit Required (Amps)
Shipping Weight (Approx.)
‡An electrical supply with grounded three-prong receptacle is required. The power supply circuit
must be installed in accordance with current edition of National Electrical Code (NFPA 70) and
local codes & ordinances.
NOTE: Always consult local and national electric & plumbing codes. Refer to Product
Installation Guide for detailed installation instructions on the web at electroluxappliances.com.
Specifications subject to change.
22.6 Cu. Ft.
15.7 Cu. Ft.
6.9 Cu. Ft.
25.7 Sq. Ft.
20.5 Sq. Ft.
5.2 Sq. Ft.
Yes
Yes
Yes
Yes
Bottom Left
Yes
4 Half Width
Yes
Yes
Yes
2
3
Yes
2
Yes
Yes
Yes
Yes
Yes
Yes
2 Luxury-Glide™
(with Dividers)
1
Yes
Yes
Yes
S
W
B
69-1/2"
35-5/8"
28-3/16"
42-9/16"
45-7/8"
Right Bottom Rear
Left Bottom Rear
120V/60Hz/15 or 20A
1.02
15
345 Lbs.

French Door Refrigerators
EI23BC36I S, EI23BC36I W, EI23BC36I B
High standards of quality at Electrolux Home Products, Inc. mean
we are constantly working to improve our products. We reserve the right
to change specifications or discontinue models without notice.
Electrolux Major Appliances, N.A.
USA
•250 Bobby Jones Expressway •Augusta, GA 30907 •1-877-4electrolux (1-877-435-3287) •
electroluxappliances.com
CANADA
•5855 Terry Fox Way •Mississauga, ON L5V 3E4 •1-800-265-8352 •
electroluxappliances.ca
EI23BC36I 09/09 © 2009 Electrolux Home Products, Inc. Printed in the U.S.A.
Counter-Depth French Door Refrigerator Specifications
•
Product Weight – 335 Lbs.
•
An electrical supply with grounded three-prong receptacle is required.The
power supply circuit must be installed in accordance with current edition
of National Electrical Code (NFPA 70) and local codes & ordinances.
•
Voltage Rating –120V/60Hz/15 or 20 Amps
•
Connected Load (kW Rating) @120 Volts = 1.02kW
•
Amps @120 Volts = 8.5 Amps
•
Always consult local and national electric & plumbing codes.
•
Floor should be level surface of hard material, capable of supporting fully
loaded refrigerator.
•
When installing refrigerator adjacent to wall, cabinet or other appliance
that extends beyond front edge of unit, 20" minimum clearance
recommended to allow for optimum 120° to 180° door swing, providing
complete drawer/crisper access and removal. (Absolute 4-1/2" minimum
clearance will ONLY allow for 90°door swing which will provide
drawer/crisper access with restricted removal.)
•
To ensure optimum performance, avoid installing in direct sunlight or
close proximity to range, dishwasher or other heat source.
•
For proper ventilation, front grille MUST remain unobstructed.
•
Recess electrical outlet when possible.
•
Water recess on rear wall recommended to prevent water line damage.
•
Water Pressure – Cold water line must provide between 30 and 100
pounds per square inch (psi).
•
Copper tubing with 1/4" O.D. recommended for water supply line with
length equal to distance from rear of unit to household water supply line
plus 7 additional feet. Optional Water Supply Installation Kits available.
•
Adjustable front rollers to assist with door alignment.
“Built-In Look” Specifications
•
Minimum opening of 70-1/4"H x 36"W x 25"D required to allow for ease
of installation, proper air circulation, and plumbing/electrical connections.
•
Remove all wall/floor molding prior to installation.
Note: For planning purposes only. Refer to Product Installation Guide
on the web at electroluxappliances.com for detailed instructions.
B
C
A
307/8"
42 9/16"(with doors
90°open)
68 3/16"
with
3/8"
rollers
26 7/8"
23 5/8"
355/8"
69 1/2"
with
3/8"
rollers
Power
cord
location
(right
bottom
rear)
Water
line inlet
location
(left
bottom
rear)
Overall depth at center
of arc – 283/16"
45 7/8"
(with drawer
fully extended
including handle)
47/8"
C
L
Top View
24"
Cabinet
25"Side Panels,1/2"min. width
25"
Countertop
Allow 1" min. clearance at rear
for proper air circulation and
water/electrical connections
Recessed
water line Recessed electrical outlet
“Built-In Look”
Cutout Dimensions
(A) 70 1/4" (B) 36" (C) 25"
Standard Depth
Standard
Refrigerator Depth
vs. Counter Depth
235/8"
Counter Depth
281/2"
