Electrolux EI23CS35KS Installation instructions

Luxury-Glide®Crispers
Drawers smoothly glide out and keep produce
fresh with adjustable humidity control and
minimal temperature variation.
IQ-Touch™Controls
For those who like to have their options always
visible, the IQ-Touch™control panel displays
your options at all times.
9"-Tall Water/Ice Dispenser
Our tall water and ice dispenser is specially
designed to accommodate a variety of large
containers, from a 16-ounce tumbler to a
pitcher or a coffee carafe.
PureAdvantage®Air Filter
Keeps clean, filtered air circulated throughout
to prevent odor transfer.
Counter-Depth Refrigerators
EI23CS35K S, EI23CS35K W, EI23CS35K B
Featuring IQ-Touch™Electronic Controls
Wall OvensRefrigerators Warmer DrawersCooktopsBuilt-In Ranges
Freestanding
Ranges
MicrowavesVent HoodsFreezersUnder CounterWashers / Dryers Dishwashers /
Kitchen Cleanup
23 CU. FT. COUNTER-DEPTH REFRIGERATORS
Capacities
Total Capacity
Fresh Food Volume
Freezer Volume
Total Shelf Area
Fresh Food Shelf Area
Freezer Shelf Area
Exterior
Signature Soft-Arc Doors and Handle Design
IQ-Touch™Electronic Controls
Door Hinge Covers
Ice/Water Dispenser
Perfect Set®Temperature Control System and Display
Crushed/Cubes/Water
Air and Water Filter Indicator/Reset
Fast Ice™
Fast Freeze™
Dispenser Lock
Dispenser Light Control
Fresh Food Conveniences
PureAdvantage®Water & Ice / Air Filtration
Water Filter Location
Temp Alarm System / Door Ajar Alarm / Power Failure Alarm
SpillSafe®Sliding Glass Shelves
Luxury-Glide®Humidity-Controlled Upper Crisper
Luxury-Glide®Humidity-Controlled Lower Crisper
Luxury-Glide®Soft-Closing Perfect Temp®Drawer
Luxury-Glide®Chill Zone™Drawer
Wine Rack
Clear Condiment Bottle Door Storage
Clear Adjustable Gallon Door Bins
Clear Adjustable 2-Liter Door Bins
Perfect Bin™Door Storage
Tall Bottle Retainers
Clear In-Door Can Racks
Luxury-Design®LED Ramp-Up Multilevel Lighting
Freezer Conveniences
Automatic Ice Maker with Ice Server
Glass Shelves
Luxury-Glide®Sliding Full-Width Freezer Baskets
Luxury-Glide®Sliding Half-Width Freezer Baskets
Clear Door Bins
Tilt-Out Wire Door Racks
Ice Cream Shelf
Soft Freeze Bin
Pizza Shelf
Luxury-Design®LED Ramp-Up Multilevel Lighting
Additional Features
ENERGY STAR®
Sabbath Mode (Star-K®Certified)
A.D.A. Compliant*
Specifications
Color –
Stainless Steel
White
Black
Product Dimensions –
Height (with Hinges and 3/8" Rollers)
Cabinet Width / Door Width
Depth (to Center of Arc)
(with 90° Door Open)
Power Supply Connection Location
Water Inlet Location
Voltage Rating
Connected Load (kW Rating)@120 Volts‡
Minimum Circuit Required (Amps)
Shipping Weight (Approx.)
*When properly installed, meets the appliance standards in the Americans with Disabilities Act
and the Architectural Barriers Act Accessibility Guidelines as published by the United States
Access Board on June 23, 2004, as amended August 5, 2005.
‡An electrical supply with grounded three-prong receptacle is required. The power supply circuit
must be installed in accordance with current edition of National Electrical Code (NFPA 70) and
local codes & ordinances.
NOTE: Always consult local and national electric & plumbing codes. Refer to Product
Installation Guide for detailed installation instructions on the web at www.electroluxappliances.com.
Specifications subject to change.
22.6 Cu. Ft.
14.06 Cu. Ft.
8.52 Cu. Ft.
22.1 Sq. Ft.
16 Sq. Ft.
6.1 Sq. Ft.
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Right Rear
Yes
3
Yes
Yes
Yes
Yes
2
1
Yes
Yes
Yes
2
2
1
4
Yes
Yes
Yes
Yes
Yes
Yes
S
W
B
69-1/2"
35-5/8" / 36"
28-3/16"
45"
Right Bottom Rear
Left Bottom Rear
120V/60Hz/15 or 20A
1.02
15
310 Lbs.
electroluxappliances.com

Counter-Depth Refrigerators
EI23CS35K S, EI23CS35K W, EI23CS35K B
High standards of quality at Electrolux Home Products, Inc. mean
we are constantly working to improve our products. We reserve the right
to change specifications or discontinue models without notice.
Electrolux Major Appliances, N.A.
USA
•10200 David Taylor Drive •Charlotte, NC 28262 •1-877-4electrolux (1-877-435-3287) •
electroluxappliances.com
CANADA
•5855 Terry Fox Way •Mississauga, ON L5V 3E4 •1-800-265-8352 •
electroluxappliances.ca
EI23CS35K 06/11 © 2011 Electrolux Home Products, Inc. Printed in the U.S.A.
Counter-Depth Refrigerator Specifications
•
Product Weight – 300 Lbs.
•
An electrical supply with grounded three-prong receptacle is required.The
power supply circuit must be installed in accordance with current edition
of National Electrical Code (NFPA 70) and local codes & ordinances.
•
Voltage Rating –120V/60Hz/15 or 20 Amps
•
Connected Load (kW Rating) @120 Volts = 1.02kW
•
Amps @120 Volts = 8.5 Amps
•
Always consult local and national electric & plumbing codes.
•
Floor should be level surface of hard material, capable of supporting fully
loaded refrigerator.
•
When installing refrigerator adjacent to wall, cabinet or other appliance
that extends beyond front edge of unit, 20" minimum clearance
recommended to allow for optimum 120° to 180° door swing, providing
complete drawer/crisper access and removal. (Absolute 4-1/2" minimum
clearance will ONLY allow for 90°door swing which will provide
drawer/crisper access with restricted removal.)
•
To ensure optimum performance, avoid installing in direct sunlight or
close proximity to range, dishwasher or other heat source.
•
For proper ventilation, front grille MUST remain unobstructed.
•
Recess electrical outlet when possible.
•
Water recess on rear wall recommended to prevent water line damage.
•
Water Pressure – Cold water line must provide between 30 and 100
pounds per square inch (psi).
•
Copper tubing with 1/4" O.D. recommended for water supply line with
length equal to distance from rear of unit to household water supply line
plus 7 additional feet. Optional Water Supply Installation Kits available.
•
Adjustable front rollers to assist with door alignment.
“Built-In Look” Specifications
•
Minimum opening of 70-1/4"H x 36"W x 25"D required to allow for ease
of installation, proper air circulation, and plumbing/electrical connections.
•
Remove all wall/floor molding prior to installation.
Note: For planning purposes only. Refer to Product Installation Guide
on the web at electroluxappliances.com for detailed instructions.

General Installation Guidelines
with Side-by-Side Refrigerator
High standards of quality at Electrolux Home Products, Inc. mean
we are constantly working to improve our products. We reserve the right
to change specifications or discontinue models without notice.
Electrolux Major Appliances, N.A.
USA
•10200 David Taylor Drive •Charlotte, NC 28262 •1-877-4electrolux (1-877-435-3287) •
electroluxappliances.com
CANADA
•5855 Terry Fox Way •Mississauga, ON L5V 3E4 •1-800-265-8352 •
electroluxappliances.ca
INSTGDLNS_SSR EL 10/10 © 2010 Electrolux Home Products, Inc. Printed in the U.S.A.
Use these dimensions and clearance instructions for planning purposes only. For detailed installation
instructions, refer to installation guide, packed with product, or on the web at electroluxappliances.com.
