Electrolux EI32AR65JS Installation instructions

Built-In All Refrigerator
EI32AR65J S
19 CU. FT. BUILT-IN ALL REFRIGERATOR
Capacities
Total Capacity
Total Shelf Area
Exterior
Hidden Hinge Door Design
Signature Soft-Arc Handle Design
Features
IQ-Touch™Electronic Controls
Temp Alarm System
Door Ajar Alarm
Power Failure Alarm
PureAdvantage®Air Filtration
Adjustable Full-Width Glass Shelves (Silver Trim)
Luxury-Glide®Full-Extension Deli Drawer/Cool Zone™
Luxury-Glide®Full-Extension Crisper/Fresh Zone™
3-Position Adjustable Crisper Dividers
Removable Basket Trays
Adjustable Dairy Door Bin
Full-Width Gallon Storage with Tall Bottle Retainer
Clear Half-Width 2-Liter Adjustable Door Bins
Perfect Bins™Door Storage
Full-Width Condiment Shelf
Luxury-Design®LED Lighting
Door Closer
Luxury-Quiet™Design
Air Filter Indicator
Electronic Control Lock
Additional Features
ENERGY STAR®
Sabbath Mode (Star-K®Certified)
Accessories
84" Louvered Trim Kits: Single – PN# ECP8436SS
Double – PN# ECP8472SS
72" Collar Trim Kits: Single – PN# ECP7236SS
Double – PN# ECP7272SS
79" Louvered/75" Collar Trim Kits1:
Single – PN# TRIMKITSS1
Double – PN# TRIMKITSS2
PureAdvantage®Air Filter
Replacement Cartridge – PN# 241754001
Specifications
Color –
Stainless Steel
Product Dimensions –
Height (Cabinet)
(Including Door)
Width
Depth (Including Door)
(with 90° Door Open)
Power Supply Connection Location
Voltage Rating
Connected Load (kW Rating) @115 Volts‡
Minimum Circuit Required (Amps)
Shipping Weight (Approx.)
‡An electrical supply with grounded three-prong receptacle is required. The power
supply circuit must be installed in accordance with current edition of National Electrical Code
(NFPA 70) and local codes & ordinances.
NOTE: Always consult local and national electric and plumbing codes. Refer to Product Installation
Guide for detailed installation instructions on the web at electroluxappliances.com.
Specifications subject to change.
Sure-2-Fit®Capacity
Our most usable space inside gives you plenty
of space for everything from party platters and
beverages to kids’ snacks and juice boxes.
Perfect Organization System
Our organization system features Luxury-Glide®
drawers with removable/adjustable dividers
and two mini baskets, Perfect Bins™Door Storage
that tilts out for easy access and a condiment
shelf, so you can keep food organized and easily
at hand.
Luxury-Glide®Crisper Drawers
Drawers smoothly glide out and keep produce
fresh with adjustable humidity control and minimal
temperature variation.
Luxury-Design®LED Lighting
Our ramp-up designer LED lighting is as
beautiful as it is functional, keeping the
contents clearly visible.
electroluxappliances.com
18.51 Cu. Ft.
22.4 Sq. Ft.
Yes
Yes
Yes
Yes
Yes
Yes
Yes
3
1
1
2
2
1
1
3
2
1
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Optional
Optional
Optional
Optional
Optional
Optional
Optional
S
70-5/8"
71-3/8"
32"
26-1/2"
57-1/4"
Right Bottom Rear
120V/60 Hz/20A
0.55
20
250 Lbs.
Optional Trim Kits
84" Louvered Trim Kits
(ECP8436SS & ECP8472SS)
Designed as a replacement option for
the Sub-Zero®brand 650 Series
models and for new-build installation.
72" Collar Trim Kits
(ECP7236SS & ECP7272SS)
Designed as a replacement option for
the Sub-Zero®brand 601Series
models and for new-build installation.
79" Louvered/75" Collar Trim Kits1
(TRIMKITSS1 & TRIMKITSS2)
Designed as a replacement option
for Electrolux ICON®brand models
E32AR75FPS and E32AF75FPS
and for new-build installation.
1Kits are designed to fit either 79" or 75" opening
height. For 79" cutout opening height, installation
requires use of top louvered grille; for 75" cutout
opening height, installation requires use of top trim
piece and shortening of both side trim pieces.
Sub-Zero®is a registered trademark of Sub-Zero,Inc.
Shown with optional stainless
steel 72" Collar Trim Kit.
(Single – PN# ECP7236SS)
Built-In Side-by-Side
Configuration
Shown with companion, All-Freezer
model EI32AF65JS and optional
stainless steel 84" Louvered Trim Kit.
(Double – PN# ECP8472SS)

Built-In All Refrigerator
EI32AR65J S
High standards of quality at Electrolux Home Products, Inc. mean
we are constantly working to improve our products. We reserve the right
to change specifications or discontinue models without notice.
Electrolux Major Appliances, N.A.
USA
•10200 David Taylor Drive •Charlotte, NC 28262 •1-877-4electrolux (1-877-435-3287) •
electroluxappliances.com
CANADA
•5855 Terry Fox Way •Mississauga, ON L5V 3E4 •1-800-265-8352 •
electroluxappliances.ca
EI32AR65J 09/12 © 2012 Electrolux Home Products, Inc.
32" Built-In All-Refrigerator Specifications
•
Product Weight – 240 Lbs.
•
An electrical supply with grounded three-prong receptacle is
required. The power supply circuit must be installed in accordance
with current edition of National Electrical Code (NFPA 70) and
local codes & ordinances.
•
Voltage Rating – 120V/60 Hz/20 Amps
•
Connected Load (kW Rating) @115 Volts = 0.55kW
•
Amps @115 Volts = 5 Amps
•
Always consult local and national electric codes.
•
Minimum 25-1/4" depth requires recessed electrical outlet.
•
To allow for ease of installation, tape excess power cord to back of unit.
•
When installing refrigerator adjacent to wall, cabinet or other appliance
that extends beyond front edge of unit, 20" minimum clearance
recommended to allow for optimum 140° door swing, providing complete
drawer/crisper access and removal. (Absolute 4" minimum clearance will
ONLY allow for 90°door swing which will provide limited drawer /crisper
access with restricted removal.)
•
Refrigerator must be placed on level surface of hard material, same
height as flooring. Surface must support approximately 800 lbs. when
fully loaded. Unit equipped with 4-point leveling.
“Built-In Look” Specifications
•
Minimum opening of 72"H x 33"W x 25-1/4"D required for single-unit
“Built-In Look” installation; 66"W required for double-unit installation.
(72"H to be measured from finished floor to underside of soffit or
overhead cabinet.)
Optional Trim Kit Specifications
For planning information, refer to model-specific Trim Kit Installation
pages on web.
•
Optional Trim Kits available for built-in installation with All Refrigerator
and/or All Freezer – requiring different cutout dimensions.
•
Designed as built-in replacement option for any model(s) having
pre-existing opening(s) with same cutout dimensions as stated for
specific Trim Kit or for new-build installation.
•
Remove all wall/floor molding prior to built-in installation.
•
For detailed Trim Kit installation, refer to instructions packed with kit
or on web.
Note: For planning purposes only. Refer to Product Installation Guide
on the web at electroluxappliances.com for detailed instructions.
Optional Accessories
•
84" Louvered Trim Kits:
Single – (PN# ECP8436SS), Double – (PN# ECP8472SS).
•
72" Collar Trim Kits:
Single – (PN# ECP7236SS), Double – (PN# ECP7272SS).
•
79" Louvered/75" Collar Trim Kits:
Single – (PN# TRIMKITSS1), Double – (PN# TRIMKITSS2).
•
PureAdvantage®Air Filter
Replacement Cartridge – (PN# 241754001).

84" Louvered Trim Kits Installation Specifications
•
Louvered Trim Kits (PN# ECP8436SS & PN# ECP8472SS) are designed
as built-in replacement options for Sub-Zero®brand 650 Series models
when Trim Kits are installed with All Refrigerator and/or All Freezer models
EI32AR65JS/EI32AF65JS into pre-existing cutout opening(s); or for
new-build installation.
•
To use Single Louvered Trim Kit (PN# ECP8436SS), an enclosure
is required around All Refrigerator or All Freezer having an opening of
83-3/4"H x 35-1/2"W with minimum cabinet side panels of 24"D x 3/4"W.
•
To use Double Louvered Trim Kit (PN# ECP8472SS), an enclosure
is required around All Refrigerator and All Freezer having an opening of
83-3/4"H x 71-1/2"W with minimum cabinet side panels of 24"D x 3/4"W.
(Double Trim Kit includes hardware to secure side-by-side units together.)
•
Trim Kit attaches directly to unit(s) and can be secured to cutout opening.
•
Minimum 24" depth requires recessed electrical outlet(s) and water line.
•
Cabinet or soffit above unit must extend out to same depth as side panels.
•
Clear, adequate floor space required for Trim Kit assembly.
•
For detailed Trim Kit installation, refer to instructions packed with kit or
on web.
•
For detailed All-Refrigerator and/or All-Freezer installation, refer to
model-specific product page(s) and installation guide(s) on web.
Note: For planning purposes only. Refer to Product Installation Guide
on the web at electroluxappliances.com for detailed instructions.
84" Louvered Trim Kits Installation
All Refrigerator/All Freezer (Sub-Zero®Brand 650 Series Replacement)
High standards of quality at Electrolux Home Products, Inc. mean
we are constantly working to improve our products. We reserve the right
to change specifications or discontinue models without notice.
Electrolux Major Appliances, N.A.
USA
•10200 David Taylor Drive •Charlotte, NC 28262 •1-877-4electrolux (1-877-435-3287) •
electroluxappliances.com
CANADA
•5855 Terry Fox Way •Mississauga, ON L5V 3E4 •1-800-265-8352 •
electroluxappliances.ca
ARAF TRMKTS 84INST EL 09/12 © 2012 Electrolux Home Products, Inc.
Sub-Zero®is a registered trademark of Sub-Zero,Inc.

72"Collar Trim Kits Installation
All Refrigerator/All Freezer (Sub-Zero®Brand 601 Series Replacement)
High standards of quality at Electrolux Home Products, Inc. mean
we are constantly working to improve our products. We reserve the right
to change specifications or discontinue models without notice.
Electrolux Major Appliances, N.A.
USA
•10200 David Taylor Drive •Charlotte, NC 28262 •1-877-4electrolux (1-877-435-3287) •
electroluxappliances.com
CANADA
•5855 Terry Fox Way •Mississauga, ON L5V 3E4 •1-800-265-8352 •
electroluxappliances.ca
ARAF TRMKTS 72INST EL 09/12 © 2012 Electrolux Home Products, Inc.
72" Collar Trim Kits Installation Specifications
•
Collar Trim Kits (PN# ECP7236SS & PN# ECP7272SS) are designed as
built-in replacement options for Sub-Zero®brand 601 Series models
when Trim Kits are installed with All Refrigerator and/or All Freezer models
EI32AR65JS/EI32AF65JS into pre-existing cutout opening(s); or for
new-build installation.
•
To use Single Collar Trim Kit (PN# ECP7236SS), an enclosure is required
around All Refrigerator or All Freezer having an opening of 72-3/4"H x
35-1/2"W with minimum cabinet side panels of 24"D x 3/4"W.
•
To use Double Collar Trim Kit (PN# ECP7272SS), an enclosure is required
around All Refrigerator and All Freezer having an opening of 72-3/4"H x
71-1/2"W with minimum cabinet side panels of 24"D x 3/4"W. (Double
Trim Kit includes hardware to secure side-by-side units together.)
•
Trim Kit attaches directly to unit(s) and can be secured to cutout opening.
•
Minimum 24" depth requires recessed electrical outlet(s) and water line.
•
Cabinet or soffit above unit must extend out to same depth as side panels.
•
Clear, adequate floor space required for Trim Kit assembly.
•
For detailed Trim Kit installation, refer to instructions packed with kit or
on web.
•
For detailed All-Refrigerator and/or All-Freezer installation, refer to
model-specific product page(s) and installation guide(s) on web.
Note: For planning purposes only. Refer to Product Installation Guide
on the web at electroluxappliances.com for detailed instructions.
Sub-Zero®is a registered trademark of Sub-Zero,Inc.

79"Louvered/75"Collar Trim Kits Installation
All Refrigerator/All Freezer (E32AR75FPS/E32AF75FPS Replacement)
High standards of quality at Electrolux Home Products, Inc. mean
we are constantly working to improve our products. We reserve the right
to change specifications or discontinue models without notice.
Electrolux Major Appliances, N.A.
USA
•10200 David Taylor Drive •Charlotte, NC 28262 •1-877-4electrolux (1-877-435-3287) •
electroluxappliances.com
CANADA
•5855 Terry Fox Way •Mississauga, ON L5V 3E4 •1-800-265-8352 •
electroluxappliances.ca
ARAF TRMKTS 79INST EL 09/12 © 2012 Electrolux Home Products, Inc.
15/16" Optional top collar trim piece
Optional 75" Collar Trim Kit Dimensions
A
79" Louvered/75" Collar Trim Kits Installation Specifications
•
Louvered/Collar Trim Kits (PN# TRIMKITSS1 & PN# TRIMKITSS2) are
designed as built-in replacement options for Electrolux ICON®brand
All-Refrigerator/All-Freezer models E32AR75FPS/E32AF75FPS when
Trim Kits are installed with models EI32AR65JS/EI32AF65JS into
pre-existing cutout opening(s) requiring 79"opening height and use of
louvered grille; or as built-in replacement option for any other built-in
model(s) having pre-existing 79" or 75" opening height; or for new-build
installation. New-build installation can use 79" opening height with use of
louvered grille; or 75" opening height with use of optional top collar trim
piece which also requires side trim pieces to be shortened by 4".
•
To use Single Louvered/Collar Trim Kit (PN# TRIMKITSS1), an enclosure
is required around All Refrigerator or All Freezer having an opening of 79"
or 75"H x 33"W with minimum cabinet side panels of 25-1/4"D x 3/4"W.
•
To use Double Louvered/Collar Trim Kit (PN# TRIMKITSS2), an
enclosure is required around All Refrigerator and All Freezer having an
opening of 79"or 75"H x 66"W with minimum cabinet side panels of
25-1/4"D x 3/4"W. (Double Trim Kit includes hardware to secure
side-by-side units together.)
•
Trim Kit attaches directly to cutout opening through louvered grille or
optional top collar trim piece to stabilize unit(s).
•
Minimum 25-1/4" depth requires recessed electrical outlet(s) and
water line.
•
Cabinet or soffit above unit must extend out to same depth as side panels.
•
Clear, adequate floor space required for Trim Kit assembly.
•
For detailed Trim Kit installation, refer to instructions packed with kit or
on web.
•
For detailed All-Refrigerator and/or All-Freezer installation, refer to
model-specific product page(s) and installation guide(s) on web.
Note: For planning purposes only. Refer to Product Installation Guide
on the web at electroluxappliances.com for detailed instructions.
