Electrolux EW6S6647C8 User manual

EW6S6647C8
EN Washing Machine User Manual

CONTENTS
1. SAFETY INFORMATION....................................................................................3
2. SAFETY INSTRUCTIONS..................................................................................4
3. PRODUCT DESCRIPTION................................................................................ 6
4. TECHNICAL DATA.............................................................................................7
5. INSTALLATION.................................................................................................. 7
6. ACCESSORIES................................................................................................11
7. CONTROL PANEL........................................................................................... 11
8. DIAL AND BUTTONS....................................................................................... 14
9. PROGRAMMES............................................................................................... 16
10. SETTINGS......................................................................................................21
11. BEFORE FIRST USE..................................................................................... 21
12. DAILY USE..................................................................................................... 21
13. HINTS AND TIPS........................................................................................... 26
14. CARE AND CLEANING..................................................................................27
15. TROUBLESHOOTING....................................................................................32
16. CONSUMPTION VALUES..............................................................................35
17. QUICK GUIDE................................................................................................37
18. ENVIRONMENTAL CONCERNS................................................................... 39
WE’RE THINKING OF YOU
Thank you for purchasing an Electrolux appliance. You’ve chosen a product that
brings with it decades of professional experience and innovation. Ingenious and
stylish, it has been designed with you in mind. So whenever you use it, you can
be safe in the knowledge that you’ll get great results every time.
Welcome to Electrolux.
Visit our website to:
Get usage advice, brochures, trouble shooter, service and repair information:
www.electrolux.com/support
Register your product for better service:
www.registerelectrolux.com
Buy Accessories, Consumables and Original spare parts for your appliance:
www.electrolux.com/shop
CUSTOMER CARE AND SERVICE
Always use original spare parts.
When contacting our Authorised Service Centre, ensure that you have the
following data available: Model, PNC, Serial Number.
The information can be found on the rating plate.
Warning / Caution-Safety information
General information and tips
Environmental information
Subject to change without notice.
www.electrolux.com2

1. SAFETY INFORMATION
Before the installation and use of the appliance, carefully
read the supplied instructions. The manufacturer is not
responsible for any injuries or damage that are the result
of incorrect installation or usage. Always keep the
instructions in a safe and accessible location for future
reference.
1.1 Children and vulnerable people safety
•This appliance can be used by children aged from 8
years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision or
instruction concerning the use of the appliance in a
safe way and understand the hazards involved.
•Children between 3 and 8 years of age and persons
with very extensive and complex disabilities shall be
kept away from the appliance unless continuously
supervised.
•Children of less than 3 years of age should be kept
away from the appliance unless continuously
supervised.
•Do not let children play with the appliance.
•Keep all packaging away from children and dispose of
it appropriately.
•Keep detergents away from children.
•Keep children and pets away from the appliance when
the door is open.
•If the appliance has a child safety device, it should be
activated.
•Children shall not carry out cleaning and user
maintenance of the appliance without supervision.
1.2 General Safety
•Do not change the specification of this appliance.
•This appliance is intended to be used in household
and similar applications such as:
ENGLISH 3

–staff kitchen areas in shops, offices and other
working environments;
–by clients in hotels, motels, bed & breakfast and
other residential type environments;
–areas for communal use in blocks of flats or in
launderettes.
•The appliance maximum load is 7 kg. Do not exceed
the maximum load of each programme (refer to the
“Programmes” chapter).
•The operating water pressure at the water entry point
from the outlet connection must be between 0.5 bar
(0.05 MPa) and 10 bar (1.0 MPa).
•The ventilation opening in the base must not be
covered by a carpet, mat, or any floor covering.
•The appliance must be connected to the water mains
using the new supplied hose sets, or other new hose
sets supplied by the Authorised Service Centre.
•Old hose sets must not be reused.
•If the mains power supply cable is damaged, it must
be replaced by the manufacturer, its Authorised
Service Centre or similarly qualified persons to avoid
an electrical hazard.
•Before any maintenance operation, deactivate the
appliance and disconnect the mains plug from the
socket.
•Do not use high pressure water sprays and/or steam
to clean the appliance.
•Clean the appliance with a moist cloth. Use only
neutral detergents. Do not use abrasive products,
abrasive cleaning pads, solvents or metal objects.
2. SAFETY INSTRUCTIONS
2.1 Installation
The installation must comply
with relevant national
regulations.
• Remove all the packaging and the
transit bolts including rubber bush
with plastic spacer.
• Keep the transit bolts in a safe place.
If the appliance is to be moved in the
future they must be reattached to lock
the drum to prevent an internal
damage.
• Always take care when moving the
appliance as it is heavy. Always use
safety gloves and enclosed footwear.
www.electrolux.com4

• Follow the installation instructions
supplied with the appliance.
• Do not install or use a damaged
appliance.
• Do not install or use the appliance
where the temperature can be less
than 0°C or where it is exposed to the
weather.
• The floor area on which the appliance
is to be installed must be flat, stable,
heat resistant and clean.
• Make sure that there is air circulation
between the appliance and the floor.
• When the appliance is in its
permanent position, check if it is
levelled correctly with the aid of a
spirit level. If it is not, adjust the feet
accordingly.
• Do not install the appliance directly
above a floor drain.
• Do not spray water on the appliance
and do not expose it to excessive
humidity.
• Do not install the appliance where the
appliance door cannot be fully
opened.
• Do not put a closed container to
collect possible water leakage under
the appliance. Contact the Authorised
Service Centre to ensure which
accessories can be used.
2.2 Electrical connection
WARNING!
Risk of fire and electric
shock.
• WARNING: This appliance is
designed to be installed / connected
to a grounding connection in the
building.
• Always use a correctly installed
shockproof socket.
• Make sure that the parameters on the
rating plate are compatible with the
electrical ratings of the mains power
supply.
• Do not use multi-plug adapters and
extension cables.
• Make sure not to cause damage to
the mains plug and to the mains
cable. Should the mains cable need to
be replaced, this must be carried out
by our Authorised Service Centre.
• Connect the mains plug to the mains
socket only at the end of the
installation. Make sure that there is
access to the mains plug after the
installation.
• Do not touch the mains cable or the
mains plug with wet hands.
• Do not pull the mains cable to
disconnect the appliance. Always pull
the mains plug.
2.3 Water connection
• The inlet water shall not exceed
25 °C.
• Do not cause damage to the water
hoses.
• Before connection to new pipes, pipes
not used for a long time, where repair
work has been carried out or new
devices fitted (water meters, etc.), let
the water flow until it is clean and
clear.
• Ensure that there are no visible water
leaks during and after the first use of
the appliance.
• Do not use an extension hose if the
inlet hose is too short. Contact the
Authorised Service Centre for the
replacement of the inlet hose.
• When unpacking the appliance, It is
possible to see water flowing from the
drain hose. This is due to the testing
of the appliance with the use of water
in the factory.
• You can extend the drain hose to
maximum 400 cm. Contact the
Authorised Service Centre for the
other drain hose and the extension.
• Make sure that there is access to the
tap after the installation.
2.4 Use
WARNING!
Risk of injury, electric shock,
fire, burns or damage to the
appliance.
• Follow the safety instructions on the
detergent packaging.
• Do not put flammable products or
items that are wet with flammable
products in, near or on the appliance.
• Do not wash fabrics which are heavily
soiled with oil, grease or other greasy
substances. It can damage rubber
ENGLISH 5

parts of the washing machine.
Prewash such fabrics by hand before
loading them into the washing
machine.
• Do not touch the glass door while a
programme operates. The glass can
get hot.
• Make sure that all metal objects are
removed from the laundry.
2.5 Service
• To repair the appliance contact the
Authorised Service Centre. Use
original spare parts only.
• Please note that self-repair or non-
professional repair can have safety
consequences and might void the
guarantee.
• The following spare parts will be
available for 10 years after the model
has been discontinued: motor and
motor brushes, transmission between
motor and drum, pumps, shock
absorbers and springs, washing drum,
drum spider and related ball bearings,
heaters and heating elements,
including heat pumps, piping and
related equipment including hoses,
valves, filters and aquastops, printed
circuit boards, electronic displays,
pressure switches, thermostats and
sensors, software and firmware
including reset software, door, door
hinge and seals, other seals, door
locking assembly, plastic peripherals
such as detergent dispensers. Please
note that some of these spare parts
are only available to professional
repairers, and that not all spare parts
are relevant for all models.
2.6 Disposal
WARNING!
Risk of injury or suffocation.
• Disconnect the appliance from the
mains electrical and water supplies.
• Cut off the mains electrical cable
close to the appliance and dispose of
it.
• Remove the door catch to prevent
children or pets from becoming
trapped in the drum.
• Dispose of the appliance in
accordance with local requirements
for the disposal of Waste Electrical
and Electronic Equipment (WEEE).
3. PRODUCT DESCRIPTION
3.1 Appliance overview
1 2 3 9
5
6
7
4
10
8
11
12
www.electrolux.com6

1Worktop
2Detergent dispenser
3Control panel
4Door handle
5Rating plate
6Drain pump filter
7Feet for levelling the appliance
8Drain hose
9Inlet hose connection
10 Mains cable
11 Transit bolts
12 Hose support
00000000
00A
Mod. xxxxxxxxx
000V ~ 00Hz 0000 W
910000000 00
A
B
C
Prod.No.
D
The rating plate reports the model name (A) ,
product number (B), electrical ratings (C) and
serial number (D).
4. TECHNICAL DATA
Dimension Width/ Height/ Total
depth
59.5 cm / 84.3 cm / 48.2 cm
Electrical connection Voltage
Overall power
Fuse
Frequency
230 V
2200 W
10 A
50 Hz
Level of protection against ingress of solid parti‐
cles and moisture ensured by the protective cov‐
er, except where the low voltage equipment has
no protection against moisture
IPX4
Water supply pressure Minimum
Maximum
0.5 bar (0.05 MPa)
10 bar (1.0 MPa)
Water supply 1) Cold water
Maximum Load Cotton 7 kg
Spin Speed Maximum spin speed 1351 rpm
1) Connect the water inlet hose to a water tap with a 3/4'' thread.
5. INSTALLATION
WARNING!
Refer to Safety chapters.
5.1 Unpacking
1. Remove the external film. If
necessary, use a cutter.
ENGLISH 7

2. Remove the cardboard top and the
polystyrene packaging materials.
3. Open the door. Remove all the items
from the drum.
Montageanweisung
Achtung!LesenSievorBeginnderInstallationdie
SicherheitshinweiseinderGebrauchsanweisung.
InstallationInstruction
Warning!
thesafetyinformationintheUserManual.
Montageanweisung
Achtung!LesenSievorBeginnderInstallationdie
SicherheitshinweiseinderGebrauchsanweisung.
InstallationInstruction
Warning!
thesafetyinformationintheUserManual.
Montageanweisung
Achtung!LesenSievorBeginnderInstallationdie
SicherheitshinweiseinderGebrauchsanweisung.
InstallationInstruction
Warning!
thesafetyinformationintheUserManual.
Montageanweisung
Achtung!LesenSievorBeginnderInstallationdie
SicherheitshinweiseinderGebrauchsanweisung.
InstallationInstruction
Warning!
thesafetyinformationintheUserManual.
4. Put the front polystyrene packaging
element on the floor behind the
appliance. Carefully put down the
appliance onto its rear side.
5. Remove the polystyrene protection
from the bottom.
1
2
6. Remove the bottom cover from the
worktop. Using clips fix, that you find
in the user manual bag, attach the
cover to the bottom of the appliance.
7. Put the appliance back into an
upright position. Remove the power
supply cable and the drain hose from
the hose holder.
WARNING!
It is possible to see
water flowing from the
drain hose. This is
because the washing
machine has been
tested at the factory.
8. Remove the four transit bolts and pull
out the plastic spacers.
www.electrolux.com8

1
2
9. Put the plastic caps, that you find in
the user manual bag, in the holes.
We recommend that you
keep the packaging and
the transit bolts for any
transport of the appliance.
5.2 Positioning and levelling
Adjust the appliance correctly to prevent
vibration, noise and movement of the
appliance when it operates.
x4
1. Install the appliance on a flat hard
floor. The appliance must be levelled
and stable. Make sure that the
appliance does not touch the wall or
other units and there is air circulation
below the appliance.
2. Loosen or tighten the feet to adjust
the level. All feet must rest firmly on
the floor.
WARNING!
Do not put cardboard,
wood or equivalent
materials below the
appliance feet to adjust
the level.
5.3 The inlet hose
WARNING!
Make sure there is no
damage to hoses and there
are no leaks from the
couplings. Do not use an
extension hose if the inlet
hose is too short. Contact
the service centre for a
replacement inlet hose.
1. Connect the water inlet hose to the
back of the appliance.
20º20º
45º45º
2. Position it toward left or right
depending on the position of the
water tap. Make sure that the inlet
hose is not in vertical position.
3. If necessary, loosen the ring nut to
set it in the correct position.
4. Connect the water inlet hose to the
cold water tap with 3/4'' thread.
ENGLISH 9

5.4 Water drainage
The drain hose should stay at a height of
no less than 600 mm and not more than
1000 mm.
You can extend the drain
hose to maximum 4000 mm.
Contact the authorised
service centre for the other
drain hose and the
extension.
It is possible to connect the drain hose in
different ways:
1. Make a U shape with the drain hose
and put it around the plastic hose
guide.
2. On the edge of a sink - Fasten the
guide to the water tap or to the wall.
Make sure that the
plastic guide cannot
move when the
appliance drains and the
drain hose end is not
immersed in the water.
There may be a return of
dirty water into the
appliance.
3. If the end of the drain hose looks like
this (see the picture), you can push it
directly into the stand pipe.
4. To a stand pipe with vent-hole -
Insert the drain hose directly into a
drain pipe. Refer to the illustration.
The end of the drain
hose must always be
ventilated , i.e. the inner
diameter of the drain
pipe (min. 38 mm - min.
1.5") must be larger than
the external diameter of
the drain hose.
5. Without the plastic hose guide, to a
sink spigot- Put the drain hose in the
spigot and tighten it with a clamp.
Refer to the illustration.
Make sure that the drain hose makes
a loop to prevent particles going into
the appliance from the sink.
6. Position the hose directly to a built-in
drain pipe in the room wall and
tighten it with a clamp.
www.electrolux.com10

5.5 Electrical connection
At the end of installation you can connect
the mains plug to the mains socket.
The rating plate and the 'Technical Data'
chapter indicate the necessary electrical
ratings. Make sure that they are
compatible with the mains power supply.
Check that your domestic electrical
installation can take the maximum load
required, also taking into account any
other appliances in use.
Connect the appliance to an earthed
socket.
The power supply cable must be easily
accessible after installing the appliance.
For any electrical work required to install
this appliance, contact our Authorised
Service Centre.
The manufacturer does not accept any
responsibility for damage or injury
through failure to comply with the above
safety precaution.
6. ACCESSORIES
6.1 Available in
www.electrolux.com/shop or
from authorised dealer
Read carefully the instructions supplied
with the accessory.
Only appropriate
accessories approved by
ELECTROLUX ensure the
safety standards of the
appliance. If unapproved
parts are used, any claims
will be invalidated.
6.2 Fixing plate kit
If you install the appliance on a plinth
that is not an accessory supplied by
ELECTROLUX, secure the appliance in
the fixing plates.
Read carefully the instructions supplied
with the accessory.
7. CONTROL PANEL
7.1 Special features
Your new washing machine meets all
modern requirements for an effective
treatment of laundry with low water,
energy and detergent consumption and
will care for fabrics.
• Thanks to the Soft Plus option, the
fabric softener is uniformly spread out
in the laundry and deeply penetrates
the fabric fibres favouring a perfect
softness.
• The SensiCare System automatically
adjusts the programme duration to the
laundry in the drum to achieve perfect
washing results in the minimum
possible time.
ENGLISH 11

7.2 Control panel description
23 4 5 6 7
13 12 9
1
81011
1Programme dial
2Spin reduction options touch button
3Temp. touch button
4Display
5Delay Start touch button
6Time Manager touch button
7Start/Pause touch button
8Easy Iron touch button
9Soft Plus touch button
10 Extra Rinse touch button
11 Stain touch button
12 Prewash touch button
13 On/Off push button
7.3 Display
The Temperature area:
Temperature indicator
Cold water indicator
Child safety lock indicator.
www.electrolux.com12

Delay start indicator.
Door locked indicator.
The digital indicator can show:
• Programme duration (e. g. ).
• Delay time (e. g. ).
• Cycle end ( ).
• Warning code (e.g. ).
Time Manager bars level indicator.
Maximum laundry weight indicator.
Add garments indicator. Lights on during the beginning of the
Wash phase, while the user can still pause the appliance and
add more laundry.
Drum clean indicator.
Night indicator.
Rinse Hold indicator.
The spin area:
Spin speed indicator
No Spin indicator. Spin phase is off.
7.4 Multilingual badges
Adhesive badges in different languages
are supplied with the appliance.
The desired badge can be glued next to
the programme dial.
Outdoor
Puuvilla
Puuvilla
Koneenpuhdistus
Silkki
Villa
Tyhjennys/Linkous
Huuhtelu
Pika 14 min.
Hienopesu
Synteettiset
Denim
UltraWash
Anti-Allergy
ENGLISH 13

8. DIAL AND BUTTONS
8.1 Introduction
The options/functions are
not available with all
washing programmes.
Check the compatibility
between options/functions
and washing programmes in
the "Programme Chart". An
option/function can exclude
another one, in this case the
appliance doesn't allow you
to set incompatible options/
functions.
8.2 On/Off
Press this button for a few seconds to
activate or deactivate the appliance. Two
different tunes sound while switching the
appliance on or off.
As the Stand-by function automatically
deactivates the appliance after several
minutes to reduce the energy
consumption, you may need to activate
the appliance again.
For more details, refer to Stand-by
paragraph in Daily Use chapter.
8.3 Temp.
When you select a washing programme,
the appliance automatically proposes a
default temperature.
Touch this button repeatedly until the
desired temperature value appears on
the display.
When the display shows the indicators
, the appliance does not heat the
water.
8.4 Spin
When you set a programme, the
appliance automatically sets the
maximum spin speed allowed, except for
programme Denim. With this option you
can change the default spin speed.
Touch repeatedly this button to:
•Decrease the spin speed. The
display shows only the spin speeds
available for the set programme.
• Additional spin options No Spin
.
Set this option to deactivate all spin
phases. The appliance performs the
only draining phase of the selected
washing programme. Set this option
for very delicate fabrics. The rinses
phase uses more water for some
washing programmes
• Activate the Rinse Hold option.
The final spin is not performed. The
water of the last rinse is not drained
out to prevent the fabrics from
creasing. The washing programme
ends with water in the drum.
The display show the indicator .
The door stays locked and the drum
turns regularly to reduce creasing.
You must drain the water to unlock
the door.
If you touch the Start/Pause button,
the appliance performs the spinning
phase and drains the water.
The appliance empties
the water out
automatically after 18
hours approximately.
• Activate the Night option.
The intermediate and the final
spinning phases are suppressed and
the programme ends with water in the
drum. This helps to reduce creasing.
The display shows the indicator .
The door stays locked. The drum
turns regularly to reduce creasing.
You must drain the water to unlock
the door.
As the programme is very quiet, it is
suitable for use at night time when
cheaper electricity tariffs are
available. In some programmes the
rinses are performed with more water.
If you touch the Start/Pause
button, the appliance performs the
only draining phase.
The appliance empties
the water out
automatically after 18
hours approximately.
www.electrolux.com14

8.5 Prewash
With this option you can add a prewash
phase to a washing programme.
The corresponding indicator above the
touch button illuminates.
• Use this option to add a pre-wash
phase at 30 °C before the washing
phase.
This option is recommended for
heavily soiled laundry, especially if
containing sand, dust, mud and other
solid particles.
The options can increase the
programme duration.
8.6 Stain
Touch this button to add the stain phase
to a programme.
The corresponding indicator above the
touch button illuminates.
Use this option for laundry with hard
stains to remove.
When you set this option, put the stain
remover into compartment .
This option increases the
programme duration.
This option is not available
with a temperature lower
than 40 °C.
8.7 Permanent Extra Rinse
With this option you can add a few rinses
according to the selected washing
programme.
Use this option for people with allergies
to detergent residues and with sensitive
skin.
This option increases the
programme duration.
The corresponding indicator above the
touch button illuminates and also stays
permanently on during next cycles until
this option is deactivated.
8.8 Permanent Soft Plus
Set this option to optimise the fabric
softener distribution and improve fabric
softness.
Recommended when you use fabric
softener.
This option increases the
programme duration.
The corresponding indicator above the
touch button illuminates and also stays
permanently on during next cycles until
this option is deactivated.
8.9 Easy Iron
The appliance carefully washes and
spins the laundry to prevent the creases.
The appliance decreases the spin speed,
uses more water and adapts the
programme duration to the type of
laundry.
The related indicator comes on.
8.10 Delay Start
With this option you can delay the start of
a programme to a more convenient time.
Touch the button repeatedly to set the
required delay. The time increases in
steps of 1 hour up to 20 hours.
The display shows the indicator and
the selected delay time. After touching
the Start/Pause button, the appliance
begins the countdown and the door is
locked.
8.11 Time Manager
With this option you can reduce the
programme duration depending on the
load size and the degree of soiling.
When you set a washing programme, the
display shows the default duration and
dashes.
Touch Time Manager button to reduce
the programme duration according to
your needs. The display shows the new
programme duration and a number of
dashes will decrease accordingly:
ENGLISH 15

suitable for a full load of normally
soiled garments.
a quick cycle for a full load of lightly
soiled garments.
very quick cycle for a smaller lightly
soiled load (max. half load
recommended).
the shortest cycle to freshen up a
small amount of laundry.
The Time Manager is available only with
the programmes in the table.
indicator
Eco 40-60
Cottons
Synthetics
1) ■■ ■
■ ■ ■
indicator
Eco 40-60
Cottons
Synthetics
■■ ■
■ ■ ■
■ ■ ■
1) Default duration for all programmes.
In some appliances the
programme duration is
reduced without showing
any dashes.
8.12 Start/Pause
Touch the Start/Pause button to
start, pause the appliance or interrupt a
running programme.
9. PROGRAMMES
9.1 Programme Chart
Programme
Default tem‐
perature
Temperature
range
Reference
spin
speed
Spin
speed
range
[rpm ]
Maxi‐
mum
load
Programme description
(Type of load and level of soiling)
Eco 40-60
40 °C 1)
1400 rpm
(1400-
400)
7 kg White cotton and fast-coloured cotton. Nor‐
mally soiled items. The energy consumption
decreases and the time of the washing pro‐
gramme is extended, ensuring good washing
results.
Cottons
40 °C
90 °C - Cold
1400 rpm
(1400-
400)
7 kg White cotton and coloured cotton. Normal
and heavy soil.
Synthetics
40 °C
60 °C - Cold
1200 rpm
(1200 -
400)
3 kg Synthetic items or mixed fabric items. Nor‐
mally soiled items.
www.electrolux.com16

Programme
Default tem‐
perature
Temperature
range
Reference
spin
speed
Spin
speed
range
[rpm ]
Maxi‐
mum
load
Programme description
(Type of load and level of soiling)
Delicates
30 °C
40 °C - Cold
1200 rpm
(1200-
400)
1,5 kg Delicate fabrics such as acrylics, viscose
and mixed fabrics requiring gentler wash‐
ing. Normally and lightly soiled items.
Rapid 14min
30 °C
800 rpm
(800- 400)
1 kg Synthetic and mixed fabric items. Lightly
soiled items and items to freshen up.
Rinse 1400 rpm
(1400-
400)
7 kg All fabrics, except woollens and very deli‐
cate fabrics. Programme for rinsing and spin‐
ning the laundry. The default spin speed is the
one used for cotton programmes. Reduce the
spin speed according to the type of laundry. If
necessary, set the Extra Rinse option to add
rinses. With a low spin speed, the appliance
performs delicate rinses and a short spin.
Drain/Spin 1400 rpm
(1400
-400)
7 kg All fabrics, except woollens and delicate
fabrics. To spin the laundry and to drain the
water in the drum.
Anti-Allergy
60 °C
1400 rpm
(1400 -
400)
7 kg White cotton items. This programme re‐
moves micro-organisms thanks to a washing
phase with the temperature maintained above
60°C for some minutes. This helps in remov‐
ing germs, bacteria, micro-organism and parti‐
cles. The addition of vapour together with an
additional rinsing phase ensures a proper re‐
moval of detergent residues and pollens/aller‐
genic items, making it suitable for delicate and
sensitive skins .
Duvet
40 °C
60 °C - Cold
800 rpm
(800 - 400)
2 kg Single synthetic blanket, padded clothes,
duvets, down jackets and similar items.
Silk
30 °C
800 rpm
(800 - 400)
0,5 kg Special programme for silk and mixed syn‐
thetic items.
Wool
40 °C
40 °C - Cold
1200 rpm
(1200-
400)
1,5 kg Machine washable wool, hand washable
wool and other fabrics with «hand washing»
care symbol2).
Sport
30 °C
40 °C - Cold
1200 rpm
(1200 -
400)
3 kg Mixed fabric sportswear. Lightly soiled items
or items to refresh.
ENGLISH 17

Programme
Default tem‐
perature
Temperature
range
Reference
spin
speed
Spin
speed
range
[rpm ]
Maxi‐
mum
load
Programme description
(Type of load and level of soiling)
Outdoor
30 °C
40 °C - Cold
1200 rpm
(1200-
400)
2 kg3)
1 kg4)
Do not use fabric softener and
make sure that there is no soften‐
er residue in the detergent dis‐
penser.
Synthetic sport items. This programme is
designed to gently wash modern outdoor
sportswear and is also suitable for gym, cy‐
cling or jogging clothes or similar. The recom‐
mended laundry load is 2 kg.
Waterproof, waterproof-breathable and wa‐
ter repellent fabrics. This programme can al‐
so be used as a water repellency restoring cy‐
cle, specifically tailored for treating clothes
with a hydrophobic coating. To perform the
water repellency restoring cycle, proceed as
follows:
• Pour the washing detergent in the compart‐
ment .
• Pour a special water repellency restorer for
fabric into the softener compartment of the
drawer .
• Reduce the laundry load to 1 kg.
To further improve the water re‐
pellency restoring action, dry the
laundry in a tumble dryer by set‐
ting the Outdoor drying pro‐
gramme (if available and if the
garment care label permits tum‐
ble drying).
www.electrolux.com18

Programme
Default tem‐
perature
Temperature
range
Reference
spin
speed
Spin
speed
range
[rpm ]
Maxi‐
mum
load
Programme description
(Type of load and level of soiling)
Denim
30 °C
40 °C - Cold
800 rpm
(1200 -
400)
2 kg Special programme for Denim clothing
with delicate washing phase to minimize
colour fading and marks. For better care a
reduced load size is recommended.
1) According to Commission Regulation EU 2019/2023, this programme at 40 °C is able to
clean normally soiled cotton laundry declared to be washable at 40 °C or 60 °C, together in
the same cycle.
For the reached temperature in the laundry, the programme duration and other
data, please refer to 'Consumption Values' chapter.
The most efficient programmes in terms of energy consumption are generally
those that perform at lower temperatures and longer duration.
2) During this cycle the drum rotates slowly to ensure a gentle wash. It can seem that the
drum doesn't rotate or doesn't rotate properly, but this is normal for this programme.
3) Washing programme.
4) Washing programme and waterproofing phase.
Programme options compatibility
Programme
Spin
Prewash
Stain
Extra Rinse
Soft Plus
Easy Iron
Delay Start
Time Manager
Eco 40-60 ■ ■ ■ ■ ■ ■ ■ ■ ■
Cottons ■ ■ ■ ■ ■ ■ ■ ■ ■ ■ ■
Synthetics ■ ■ ■ ■ ■ ■ ■ ■ ■ ■ ■
Delicates ■ ■ ■ ■ ■ ■ ■
Rapid 14min ■ ■ ■ ■
Rinse ■ ■ ■ ■ ■
Drain/Spin ■ ■ ■
Anti-Allergy ■ ■ ■ ■ ■ ■ ■ ■
Duvet ■ ■ ■ ■
Silk ■ ■ ■
ENGLISH 19

Programme
Spin
Prewash
Stain
Extra Rinse
Soft Plus
Easy Iron
Delay Start
Time Manager
Wool
®
■ ■ ■ ■
Sport ■ ■ ■ ■ ■ ■
Outdoor ■ ■ ■ ■ ■
Denim ■ ■ ■ ■ ■ ■ ■ ■ ■
Suitable detergents for washing programmes
Programme Universal
powder1)
Liquid Uni‐
versal
Liquid for
coloureds
Delicates
woollens
Special
Eco 40-60 ▲ ▲ ▲ -- --
Cottons ▲ ▲ ▲ -- --
Synthetics ▲ ▲ ▲ -- --
Delicates -- -- -- ▲ ▲
Rapid 14min -- ▲ ▲ -- --
Anti-Allergy ▲ ▲ -- -- ▲
Duvet -- ▲ ▲ -- ▲
Silk -- -- -- ▲ ▲
Wool -- -- -- ▲ ▲
Sport -- ▲ ▲ -- ▲
Outdoor -- -- -- ▲ ▲
Denim -- -- ▲ ▲ ▲
1) At temperature higher than 60 °C the use of powder detergent is recommended.
▲ = Recommended -- = Not recommended
www.electrolux.com20
