Electrolux EWF147310W User manual

EWF 147310 W
................................................ .............................................
EN WASHING MACHINE USER MANUAL

Electrolux. Thinking of you.
Share more of our thinking at www.electrolux.com
CONTENTS
Safety information 2
Safety instructions 3
Product description 4
Special accessories for installation 5
Control panel 6
Table of symbols 6
First use 8
Personalisation 9
Daily use 9
Helpful hints and tips 12
Washing programmes 13
Consumption values 16
Care and cleaning 16
What to do if… 20
Technical data 22
Installation 22
Environment concerns 25
Subject to change without notice.
SAFETY INFORMATION
Before the installation and use of the appliance, carefully read
the supplied instructions. The manufacturer is not responsible
if an incorrect installation and use causes injuries and dam-
ages. Always keep the instructions with the appliance for fu-
ture reference.
CHILDREN AND VULNERABLE PEOPLE SAFETY
Warning! Risk of suffocation, injury or permanent disability.
• Do not let persons, children included, with reduced physical
sensory, reduced mental functions or lack of experience and
knowledge use the appliance. They must have supervision
or instruction for the operation of the appliance by a person
who is responsible for their safety.
• Do not let children play with the appliance.
• Keep all packaging away from children.
• Keep all detergents away from children.
• Keep children and pets away from the appliance door when
it is open.
• If the appliance has a child safety device, we recommend
you activate it.
GENERAL SAFETY
• Before maintenance, deactivate the appliance and discon-
nect the mains plug from the mains socket.
2 electrolux

• Do not change the specification of this appliance.
• Obey the maximum load volume of 8 kg (refer to the “Pro-
gramme chart” chapter).
• If the supply cord is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualified persons
in order to avoid a hazard.
• The operating water pressure (minimum and maximum)
must be between 0,5 bar (0,05 MPa) and 8 bar (0,8 MPa)
• The ventilation openings in the base (if applicable) must not
be obstructed by a carpet.
• The appliance is to be connected to the water mains using
the new supplied hose-sets. Old hose sets must not be
reused.
SAFETY INSTRUCTIONS
INSTALLATION
• Remove all the packaging and the transit
bolts.
• Keep the transit bolts. When you move
the appliance again you must block the
drum.
• Do not install or use a damaged appli-
ance.
•Donotinstalloruse the appliance where
the temperature is less than 0 °C or
where it is exposed to the weather.
• Obey the installation instruction supplied
with the appliance.
• Make sure that the floor where you install
the appliance is flat, stable, heat resistant
and clean.
• Do not install the appliance where the ap-
pliance door can not be fully opened.
• Always be careful when you move the
appliance because it is heavy. Always
wear safety gloves.
• Make sure that there is air circulation be-
tween the appliance and the floor.
• Adjust the feet to have the necessary
space between the appliance and the
carpet.
Electrical connection
Warning! Risk of fire and electrical
shock.
• The appliance must be earthed.
• Make sure that the electrical information
on the rating plate agrees with the power
supply. If not, contact an electrician.
• Always use a correctly installed shock-
proof socket.
• Do not use multi-plug adapters and ex-
tension cables.
• Make sure not to cause damage to the
mains plug and to the mains cable. Con-
tact the Service or an electrician to
change a damaged mains cable.
• Connect the mains plug to the mains
socket only at the end of the installation.
Make sure that there is access to the
mains plug after the installation.
• Do not pull the mains cable to disconnect
the appliance. Always pull the mains
plug.
• Do not touch the mains cable or the
mains plug with wet hands.
• This appliance complies with the E.E.C.
Directives.
Water connection
• Make sure not to cause damage to the
water hoses.
electrolux 3

• The appliance is to be connected to the
water mains using the new supplied
hose-sets. Old hose sets must not be
reused.
• Before you connect the appliance to new
pipes or pipes not used for a long time,
let the water flow until it is clean.
• The first time you use the appliance,
make sure that there is no leakage.
USE
Warning! Risk of injury, electrical
shock, fire, burns or damage to the
appliance.
• Use this appliance in a household envi-
ronment.
• Obey the safety instructions on the deter-
gent packaging.
• Do not put flammable products or items
that are wet with flammable products in,
near or on the appliance.
• Do not touch the glass of the door while
a programme operates. The glass can be
hot.
• Make sure that you remove all metal ob-
jects from the laundry.
• Do not put a container to collect possible
water leakage under the appliance. Con-
tact the Service to ensure which acces-
sories can be used.
CARE AND CLEANING
Warning! Risk of injury or damage to
the appliance.
• Do not use water spray and steam to
clean the appliance.
• Clean the appliance with a moist soft
cloth. Only use neutral detergents. Do
not use abrasive products, abrasive
cleaning pads, solvents or metal objects.
DISPOSAL
Warning! Risk of injury or suffocation.
• Disconnect the appliance from the mains
supply.
• Cut off the mains cable and discard it.
• Remove the door catch to prevent chil-
dren and pets to get closed in the appli-
ance.
SERVICE
• Contact the Service to repair the appli-
ance. We recommend only the use of
original spare parts.
PRODUCT DESCRIPTION
Your new appliance meets all modern requirements for effective treatment of laundry
with low water, energy and detergent consumption. Its new washing system allows
total use of detergent and reduces water consumption so saving energy.
4
5
12
3
6
1Detergent dispenser drawer
2Control panel
3Door opening handle
4Rating Plate
4 electrolux

5Drain pump 6Adjustable feet
DETERGENT DISPENSER DRAWER
Compartment for detergent used for
prewash and soak phase or for stain re-
mover used during the stain action phase (if
available). The prewash and soak detergent
is added at the beginning of the wash pro-
gramme. The stain remover is added dur-
ing the stain action phase.
Compartment for powder or liquid de-
tergent used for main wash. If using liquid
detergent pour it just before starting the
programme.
Compartment for liquid additives (fabric
softener, starch).
Follow the product manufacturer’s recom-
mendations on quantities to use and do not
exceed the «MAX» mark in the detergent
dispenser drawer. Any fabric softener or
starching additives must be poured into the
compartment before starting the wash pro-
gramme.
CHILD SAFETY DEVICE
Make sure that children or pets do not
climb into the drum. To prevent children
and pets becoming trapped inside the
drum the machine incorporates a special
feature. To activate this device, rotate the
button (without pressing it) inside the door
clockwise until the groove is horizontal. If
necessary use a coin.
To disable this device and restore the pos-
sibility of closing the door, rotate the button
counterclockwise until the groove is vertical.
SPECIAL ACCESSORIES FOR INSTALLATION
RUBBER FEET KIT (4055126249)
Available from your authorized dealer.
The rubber feet are particularly recommen-
ded on floating, slippery and wooden floors.
Mount the rubber feet to prevent vibration,
noises and displacement of the appliance
during operation.
Read carefully the instructions supplied with
the kit.
FIXING PLATE KIT (4055171146)
Available from your authorized dealer.
If you install the appliance on a plinth, se-
cure the appliance in the fixing plates.
Follow the instructions supplied with the kit.
electrolux 5

CONTROL PANEL
Henceforth the programme selector dial, the buttons and the display will be indicated
with the numbers given in this table.
1 2 3 4 5 6 7 8
1Programme selector dial
2Spin reduction button
3Opties button
– Voorwas
–Kort
– Extra kort
4Extra Spoelen button
5Display
6Start/Pauze button
7Startuitstel button
8Indicator pilot light
TABLE OF SYMBOLS
= Night Cycle
= Rinse Hold
= Child Lock
= Wash
= Door
= End Cycle
PROGRAMME SELECTOR DIAL
It allows you to switch the appliance on/off
and/or to select a programme.
SPIN SPEED REDUCTION
By pressing this button you can reduce the
maximum spin speed allowed for the selec-
ted programme or to select the available
option(s).
NIGHT CYCLE
By selecting this function the machine will
not drain the water of the last rinse and all
spinning phases will be suppressed, so as
not to wrinkle the laundry. This washing cy-
cle is very quiet and it can be selected at
night or in times with a more economical
power rate. On some programmes the rin-
ses will be performed with more water. Be-
fore opening the door it will be necessary to
empty out the water. To empty out the wa-
ter, please read the paragraph «At the end
of the programme».
RINSE HOLD
By selecting this function the water of the
last rinse is not emptied out to prevent the
fabrics from creasing. Before opening the
door it will be necessary to empty out the
water. To empty out the water, please read
the paragraph «At the end of the pro-
gramme».
VOORWAS
By selecting this option the machine per-
forms a prewash cycle before the main
6 electrolux

wash phase. The washing time will be pro-
longed. This option is recommended for
heavily soiled laundry.
KORT
By pressing this button the washing dura-
tion will be reduced. To be used for lightly
soiled laundry.
EXTRA KORT
Short cycle for lightly soiled items or for
laundry which needs only freshening up.
We recommend you to reduce the fabrics
loading.
EXTRA SPOELEN
This appliance is designed to save energy.
If it necessary to rinse the laundry using an
extra quantity of water (extra rinse), select
this option. Some additional rinses will be
performed. This option is recommended for
people who are allergic to detergents, and
in areas where the water is very soft.
START/PAUZE
This button allows you to start or to inter-
rupt the selected programme.
STARTUITSTEL
The programme can be delayed from 30
min - 60 min - 90 min, 2 hours and then by
1 hour up to a maximum of 20 hours by
means of this button.
INDICATOR PILOT LIGHTS
8.1
8.2
8.3
After having pressed the button 6, the
WASHING pilot light (8.1) illuminates. When
the pilot light 8.1 illuminates this means that
the machine is operating.
The DOOR pilot light (8.2) illuminates when
the programme starts and indicates if the
door can be opened:
• light on: the door cannot be opened. The
machine is working or has stopped with
water left in the tub.
• light off: the door can be opened. The
programme is finished or the water has
been emptied out.
• light flashing: the door is opening in a few
minutes.
When the programme has finished the END
CYCLE pilot light (8.3) comes on.
electrolux 7

DISPLAY
5.1:
•Duration of selected programme
After selecting a programme, the duration
is displayed in hours and minutes (for ex-
ample ). The duration is calculated
automatically on the basis of the maxi-
mum recommended load for each type of
fabric. After the programme has started,
the time remaining is updated every mi-
nute.
•Alarm codes
In the event of operating problems, some
alarm codes can be displayed, for exam-
ple (see chapter «What to do if...»).
•End of programme
When the programme has finished three
blinking zeros ( ) are displayed, the
Door pilot light (8.2), the Washing pilot
light (8.1) and the pilot light of button 6
go out and the door can be opened.
•Incorrect option selection
If an option which is not compatible with
the set wash programme is selected, the
message Err is displayed for a few sec-
onds and the red pilot light of button 6
light starts blinking.
•Delay Start
The selected delay set by means of the
relevant button appears on the display for
a few seconds. The delay time value de-
creases by one unit every hour. When
only 1 hour remains, the time decreases
every minute.
5.2:
•Heating Phase
During the washing cycle the display
shows a temperature icon (5.2) to indi-
cate that the appliance has started the
heating phase of the water in the tub.
5.3:
•Child safety lock
This device permits you to leave the ap-
pliance unsupervised without having the
worry that children might be injured by or
cause damage to the appliance. This
function remains able also when the
washing machine is not working.
There are two different ways to set this
option:
– before pressing button 6: it will be im-
possible to start the machine;
– after having pressed the button 6: it will
be impossible to change any other
programme or option.
To enable (disable) this option press si-
multaneously for about 6 seconds 3and
4buttons until the symbol 5.3 appears
(disappears) on the display.
FIRST USE
• Ensure that the electrical and water
connections comply with the installa-
tion instructions.
• Remove the polystyrene block and
any material from the drum.
• Pour 2 litres of water into the main
wash compartment of the deter-
gent drawer in order to activate the
ECO valve. Then run a cotton cycle
at the highest temperature without
any laundry in the machine, to re-
8 electrolux

move any manufacturing residue
from the drum and tub. Pour 1/2 a
measure of detergent into the main
wash compartment and start the
machine.
PERSONALISATION
ACOUSTIC SIGNALS
The machine is provided with an acoustic
device, which sounds in the following ca-
ses:
• at the end of the cycle
• if there is a fault.
By pressing the 2and 3buttons simultane-
ously for about 6 seconds, the acoustic
signal is deactivated (except if there is a
fault). By pressing these 2 buttons again,
the acoustic signal is reactivated.
CHILD SAFETY LOCK
This device permits you to leave the appli-
ance unattended and not to worry that chil-
dren might be injured by or cause damage
to the appliance. This function remains ena-
bled also when the washing machine is not
working.
There are two different ways to set this op-
tion:
1. Before pressing button 6: it will be im-
possible to start the machine.
2. After pressing button 6: it will be im-
possible to change any other pro-
gramme or option.
To enable or disable this option press si-
multaneously for about 6 seconds buttons
3and 4until on the display, the icon ap-
pears or disappears.
DAILY USE
Load the laundry
Open the door by carefully pulling the door
handle outwards. Place the laundry in the
drum, one item at a time, shaking them out
as much as possible. Close the door.
Make sure that no laundry stays between
the seal and the door. There is a risk of wa-
ter leakage or damage to the laundry.
Measure out the detergent and the fab-
ric softener
Pull out the dispenser drawer until it stops.
Measure out the amount of detergent re-
quired, pour it into the main wash compart-
ment or in the appropriate compartment
if the selected programme/option it requires
(see more details in «Detergent dispenser
drawer»).
If required, pour fabric softener into the
compartment marked (the amount used
must not exceed the «MAX» mark in the
drawer). Close the drawer gently.
electrolux 9

SELECT THE REQUIRED PROGRAMME
BY TURNING THE PROGRAMME
SELECTOR DIAL (1)
You can choose the right programme for
any type of laundry following the descrip-
tions on the washing programme tables
(see «Washing Programmes»). Turn the
programme selector dial to the required
programme. The programme selector de-
termines the type of washing cycle (e.g.
water level, drum movement, number of rin-
ses) and the washing temperature accord-
ing to the type of laundry. The pilot light of
button 6starts blinking and the display
shows the duration of the selected pro-
gramme. The selector dial can be turned ei-
ther clockwise or counterclockwise. Posi-
tion to Reset programme/Switching OFF
the machine.
For the description of each washing
programmes of the selector dial, con-
sult the chapter «Washing pro-
grammes».
At the end of the programme the selec-
tor dial must be turned to position ,
to switch the machine off.
Caution! If you turn the programme
selector dial to another programme
when the machine is working, the red
pilot light of button 6will blink 3 times
and the message Err is displayed on
the display to indicate a wrong
selection. The machine will not perform
the new selected programme.
REDUCE THE SPIN SPEED BY
PRESSING BUTTON 2
When the required programme has been
selected, your appliance automatically pro-
poses the maximum spin speed provided
for that programme.
Press button 2repeatedly to change the
spin speed, if you want your laundry to be
spun at a speed different from the one pro-
posed by the washing machine. The rele-
vant light will light up.
SELECT THE AVAILABLE OPTIONS BY
PRESSING BUTTONS 2, 3 AND 4
Depending on the programme, different
functions can be combined. These must be
selected after choosing the desired pro-
gramme and before starting the pro-
gramme. When these buttons are pressed,
the corresponding pilot lights illuminate.
When they are pressed again, the pilot
lights go out. If an incorrect option is selec-
ted, the integrated red pilot light of the but-
ton 6flashes for 3 times.
For the compatibility among the wash-
ing programmes and the options see
chapter «Washing Programmes».
SELECT THE DELAY START BY
PRESSING BUTTON 7
Before you start the programme, if you wish
to delay the start, press the button 7re-
peatedly, to set the desired delay. The set
delay time value (up to 20 hours) will appear
on the display a few seconds, then the du-
ration of the programme will appear again.
You must select this option after you have
set the programme and before you press
button 6.
You can cancel or modify the delay time at
any moment, before you press button 6.
Selecting the delayed start:
1. Set the programme and the required
options.
2. Press button 7to set the delay start .
3. Press button 6:
– the machine starts its hourly count-
down.
– The programme will start after the
selected delay has expired.
Cancelling the delayed start after having
pressed button 6:
1. Press button 6to set the washing ma-
chine to PAUSE.
2. Press button 7once until the value ’
is displayed
10 electrolux

3. Press button 6again to start the pro-
gramme.
Important! The selected delay can be
changed only after selecting the washing
programme again.
The Delay Start can not be selected with
the DRAIN programme.
START THE PROGRAMME BY
PRESSING BUTTON 6
To start the selected programme, press the
button 6, the corresponding green pilot light
stops blinking. The pilot lights 8.1 and 8.2
illuminate to indicate that the appliance
starts operating and the door is locked.
To interrupt a programme which is running,
press the button 6: the corresponding
green pilot light starts blinking.
To restart the programme from the point at
which it was interrupted, press the button 6
again. If you have chosen a delayed start,
the machine will begin the countdown.
If an incorrect option is selected, the red pi-
lot light of the button 6blinks for 3 times
the message Err is displayed for a few sec-
onds.
ALTERING AN OPTION OR A RUNNING
PROGRAMME
It is possible to change some options be-
fore the programme carries them out.
Before you make any change, you must
PAUSE the appliance by pressing the but-
ton 6.
Changing a running programme is possible
only by resetting it. Turn the programme se-
lector dial to and then to the new pro-
gramme position. Start the new programme
by pressing the button 6again. The wash-
ing water in the tub will be not emptied out.
INTERRUPTING A PROGRAMME
Press the button 6to interrupt a pro-
gramme which is running, the correspond-
ing green pilot light starts blinking.
Press the button again to restart the pro-
gramme.
CANCELLING A PROGRAMME
Turn the selector dial to to cancel a pro-
gramme which is running.
You can select now a new programme.
OPENING THE DOOR
After the programme has started (or during
the delay time) the door is locked. If you
need to open the door, press first the but-
ton 6to set the machine to PAUSE. After a
few minutes the light 8.2 goes out. It is pos-
sible to open the door.
If this light remains lit and the door is
locked, this means that the machine is al-
ready heating or that the water level is too
high. In any case, do not try to force the
door!
If you cannot open the door but you need
to open it you have to switch the machine
off by turning the selector dial to . After a
few minutes the door can be opened (pay
attention to the water level and temper-
ature!).
After closing the door, it is necessary to set
the programme and options again. Press
button 6to start the machine.
AT THE END OF THE PROGRAMME
The machine stops automatically. The dis-
play shows three blinking zeros ( ).
Some acoustic signals sound. The light of
button 6, the lights 8.1 and 8.2 go off.
After some minutes the light 8.3 illuminates.
The door can be opened.
If you have set a programme or an option
that ends with water left in the tub, the light
8.2 remains on. The door is locked. The
water must be emptied out before opening
the door. During this time the drum contin-
ues to rotate at regular intervals.
Follow the below instructions to empty out
the water:
1. Turn the programme selector dial to
.
2. Set the draining or spinning pro-
gramme.
3. If needed reduce the spin speed.
4. Press button 6.
At the end of the programme, the light 8.2
goes off. The door can be now opened.
Turn the programme selector dial to to
switch the machine off.
Remove the laundry from the drum and
carefully check that the drum is empty. If
you do not intend to carry out another
wash, close the water tap. Leave the door
electrolux 11

open to prevent the formation of mildew
and unpleasant smells.
Stand by : once the programme has finish-
ed after a few minutes the energy saving
system will be enabled. The brightness of
the display is reduced. By pressing any but-
ton the appliance will come out of the ener-
gy saving status.
HELPFUL HINTS AND TIPS
SORTING OUT THE LAUNDRY
Follow the wash code symbols on each
garment label and the manufacturer’s
washing instructions. Sort the laundry as
follows: whites, coloureds, synthetics, deli-
cates, woollens.
BEFORE LOADING THE LAUNDRY
Never wash whites and coloureds together.
Whites may lose their «whiteness» in the
wash.
New coloured items may run in the first
wash; they should therefore be washed
separately the first time.
Button up pillowcases, close zip fasteners,
hooks and poppers. Tie any belts or long
tapes.
Remove persistent stains before washing.
Rub particularly soiled areas with a special
detergent or detergent paste.
Treat curtains with special care. Remove
hooks or tie them up in a bag or net.
REMOVING STAINS
Stubborn stains may not be removed by
just water and detergent. It is therefore ad-
visable to treat them prior to washing.
Blood: treat fresh stains with cold water.
For dried stains, soak overnight in water
with a special detergent then rub in the
soap and water.
Oil based paint: moisten with benzine
stain remover, lay the garment on a soft
cloth and dab the stain; treat several times.
Dried grease stains: moisten with turpen-
tine, lay the garment on a soft surface and
dab the stain with the fingertips and a cot-
ton cloth.
Rust: oxalic acid dissolved in hot water or a
rust removing product used cold. Be careful
with rust stains which are not recent since
the cellulose structure will already have
been damaged and the fabric tends to hole.
Mould stains: treat with bleach, rinse well
(whites and fast coloureds only).
Grass: soap lightly and treat with bleach
(whites and fast coloureds only).
Ball point pen and glue: moisten with
acetone
1)
, lay the garment on a soft cloth
and dab the stain.
Lipstick: moisten with acetone as above,
then treat stains with methylated spirits.
Treat any residual marks with bleach.
Red wine: soak in water and detergent,
rinse and treat with acetic or citric acid,
then rinse. Treat any residual marks with
bleach.
Ink: depending on the type of ink, moisten
the fabric first with acetone
1)
, then with
acetic acid; treat any residual marks on
white fabrics with bleach and then rinse
thoroughly.
Tar stains: first treat with stain remover,
methylated spirits or benzine, then rub with
detergent paste.
DETERGENTS AND ADDITIVES
Good washing results also depend on the
choice of detergent and use of the correct
quantities to avoid waste and protect the
environment.
Although biodegradable, detergents contain
substances which, in large quantities, can
upset the delicate balance of nature.
The choice of detergent will depend on the
type of fabric (delicates, woollens, cottons,
etc.), the colour, washing temperature and
degree of soiling.
All commonly available washing machine
detergents may be used in this appliance:
• powder detergents for all types of fabric
• powder detergents for delicate fabrics
(60°C max) and woollens
• liquid detergents, preferably for low tem-
perature wash programmes (60°C max)
for all types of fabric, or special for wool-
lens only.
1) do not use acetone on artificial silk
12 electrolux

The detergent and any additives must be
placed in the appropriate compartments of
the dispenser drawer before starting the
wash programme.
If using liquid detergents, a programme
without prewash must be selected.
Your appliance incorporates a recirculation
system which allows an optimal use of the
concentrated detergent.
Follow the product manufacturer’s recom-
mendations on quantities to use and do
not exceed the «MAX» mark in the de-
tergent dispenser drawer.
QUANTITY OF DETERGENT TO BE
USED
The type and quantity of detergent will de-
pend on the type of fabric, load size, de-
gree of soiling and hardness of the water
used.
Follow the product manufacturers’ instruc-
tions on quantities to use.
Use less detergent if:
• you are washing a small load
• the laundry is lightly soiled
• large amounts of foam form during wash-
ing.
DEGREES OF WATER HARDNESS
Water hardness is classified in so-called
“degrees” of hardness. Information on hard-
ness of the water in your area can be ob-
tained from the relevant water supply com-
pany, or from your local authority. If the wa-
ter hardness degree is medium or high we
suggest you to add a water softener follow-
ing always the manufacturer’s instructions.
When the degree of hardness is soft, read-
just the quantity of the detergent.
WASHING PROGRAMMES
Programme
Maximum and Minimum Temperature
Cycle Description
Maximum Spin Speed
Maximum Fabrics Load
Type of Laundry
Options Detergent
Compartment
Katoen
90°-60°
Main wash - Rinses
Maximum spin speed 1400 rpm
Max. load 7 kg - Reduced load 3.5 kg
For white cottons (heavily soiled items).
Centrifugeren
Night cycle
Rinse hold
Voorwas
Kort
Extra kort
1)
Extra spoelen
2)
Katoen Eco
60°
3)
Main wash - Rinses
Maximum spin speed 1400 rpm
Max. load 7 kg
For white and fast coloured cotton
This programme can be selected for slightly or normally
soiled cotton items. The temperature will decrease and the
washing time will be extended. This allows to obtain a
good washing efficiency so saving energy.
Centrifugeren
Night cycle
Rinse hold
Voorwas
Extra spoelen
2)
electrolux 13

Programme
Maximum and Minimum Temperature
Cycle Description
Maximum Spin Speed
Maximum Fabrics Load
Type of Laundry
Options Detergent
Compartment
Katoen Eco
40°
3)
Main wash - Rinses
Maximum spin speed 1400 rpm
Max. load 7 kg
For coloured cotton
This programme can be selected for slightly or normally
soiled cotton items. The temperature will decrease and the
washing time will be extended. This allows to obtain a
good washing efficiency so saving energy.
Centrifugeren
Night cycle
Rinse hold
Voorwas
Extra spoelen
2)
Katoen
40°- Cold
Main wash - Rinses
Maximum spin speed 1400 rpm
Max. load 7 kg - Reduced load 3.5 kg
For coloured cottons (lightly soiled items).
Centrifugeren
Night cycle
Rinse hold
Voorwas
Kort
Extra Kort
1)
Extra spoelen
2)
Synthetica
60°- Cold
Main wash - Rinses
Maximum spin speed 900 rpm
Max. load 3.5 kg - Reduced load 2 kg
Synthetic or mixed fabrics: underwear, coloured gar-
ments, non-shrink shirts, blouses.
Centrifugeren
Night cycle
Rinse hold
Voorwas
Kort
Extra kort
1)
Extra spoelen
2)
Fijne was
40°-30°
Main wash - Rinses
Maximum spin speed 700 rpm
Max. load 3.5 kg - Reduced load 2 kg
Delicate fabrics: acrylics, viscose, polyester.
Night cycle
Rinse hold
Voorwas
Kort
Extra kort
1)
Extra spoelen
2)
Wol
Handwas
40°- Cold
Main wash - Rinses
Maximum spin speed 900 rpm
Max. load 2 kg
Washing programme for machine washable wool as well
as for hand washable woollens and delicate fabrics with
«hand washing» care symbol. Note : A single or bulky item
may cause imbalance. If the appliance doesn’t perform the
final spin phase, add more items, redistribute the load
manually and then select the spinning programme.
Centrifugeren
Night cycle
Rinse hold
14 electrolux

Programme
Maximum and Minimum Temperature
Cycle Description
Maximum Spin Speed
Maximum Fabrics Load
Type of Laundry
Options Detergent
Compartment
Spoelen
Rinse - Long spin
Maximum spin speed 1400 rpm
Max. load 7 kg
With this programme it is possible to rinse and spin cotton
garments which have been washed by hand. To intensify
the rinsing action, select the Extra spoelen option. The ap-
pliance will add some additional rinses.
Centrifugeren
Night cycle
Rinse hold
Extra spoelen
Pompen
Draining of water
Max. load 7 kg
For emptying out the water of the last rinse in programmes
with the Night cycle and Rinse hold option selected.
Centrifugeren
Drain and long spin
Maximum spin speed 1400 rpm
Max. load 7 kg
Separate spin for hand washed garments and after pro-
grammes with the Rinse hold and Night cycle option se-
lected. You can choose the spin speed by pressing the
relevant button to adapt it to the fabrics to be spun.
Centrifugeren
Mini 30
30°
Main wash - Rinses
Maximum spin speed 700 rpm
Max. load 3 kg
Ideal for laundry which is lightly soiled or which only needs
freshening up.
= OFF
For cancelling the programme which is running or to switch the machine off .
1) If you select the Extra kort option by pressing button 3, we recommend that you reduce the maximum load as
indicated. Full loading is possible however with somewhat reduced cleaning results.
2) If using liquid detergents, a programme without Voorwas must be selected.
3) Standard programmes for the Energy Label consumption values. According to regulation 1061/2010, the “Katoen
Eco 60 °C” and “Katoen Eco 40 °C” are respectively the “standard 60 °C cotton programme” and the “standard
40 °C cotton programme”. They are the most efficient programmes in terms of combined energy and water
consumptions for washing normally soiled cotton laundry.
Information:
The water temperature of the washing phase may differ from the temperature declared for the selected pro-
gramme.
WOOLMARK CERTIFICATE The wool wash cycle of this machine has
been approved by The Woolmark Company
for the washing of machine washable wool
products provided that the products are
washed according to the instructions on the
garment label and those issued by the
manufacturer of this washing machine.
M1027
electrolux 15

In UK, Eire, Hong Kong and India the Wool-
mark symbol is a certification trademark.
CONSUMPTION VALUES
The data of this table are approximate. Different causes can change the data: the
quantity and type of laundry, the water and ambient temperature.
Programmes Load
(kg)
Energy con-
sumption
(kWh)
Water con-
sumption (li-
tre)
Approximate
programme
duration (mi-
nutes)
Remaining
moisture
(%)
1)
Cottons 60 °C 71.30 59 120 52
Cottons 40 °C 70.77 60 120 52
Synthetics 40 °C 3.5 0.50 54 80 35
Delicates 40 °C 3.5 0.60 63 65 35
Wool/Hand wash
30 °C 20.25 55 60 30
Standard cotton programmes
Standard 60 °C
cotton 71.05 49 183 52
Standard 60 °C
cotton 3.5 0.70 40 155 52
Standard 40 °C
cotton 3.5 0.57 40 155 52
1) At the end of spin phase.
Off Mode (W) Left On Mode (W)
0.98 0.10
The information given in the charts above are in compliance with the EU Commission regulation
1015/2010 implementing directive 2009/125/EC.
CARE AND CLEANING
Warning! You must disconnect the
appliance from the electricity supply,
before you can carry out any cleaning
or maintenance work.
DESCALING
The water we use normally contains lime. It
is a good idea to periodically use a water
softening powder in the machine. Do this
separately from any laundry washing, and
according to the softening powder manu-
facturer's instructions. This will help to pre-
vent the formation of lime deposits.
AFTER EACH WASH
Leave the door open for a while. This helps
to prevent mould and stagnant smells form-
ing inside the appliance. Keeping the door
open after a wash will also help to preserve
the door seal.
MAINTENANCE WASH
With the use of low temperature washes it
is possible to get a build up of residues in-
side the drum.
We recommend that a maintenance wash
be performed on a regular basis.
To run a maintenance wash:
• The drum should be empty of laundry.
• Select the hottest cotton wash pro-
gramme.
• Use a normal measure of detergent,
must be a powder with biological proper-
ties.
16 electrolux

EXTERNAL CLEANING
Clean the exterior cabinet of the appliance
with soap and water only, and then dry
thoroughly.
Important! Do not use methylated spirits,
solvents or similar products to clean the
cabinet.
CLEANING THE DISPENSER DRAWER
The detergent dispenser drawer should be
cleaned regularly.
The washing powder and additive dispens-
er drawer should be cleaned regularly.
Remove the drawer by pressing the catch
downwards and by pulling it out.
1
2
Flush it out under a tap, to remove any
traces of accumulated powder.
To aid cleaning, the top part of the additive
compartment should be removed. Clean all
parts with water.
Clean the chamber of dispenser drawer
with a brush.
WASHING DRUM
Rust deposits in the drum may occur due
to rusting foreign bodies in the washing or
tap water containing iron.
Important! Do not clean the drum with
acidic descaling agents, scouring agents
containing chlorine or iron or steel wool.
1. Remove any rust deposits on the drum
with a cleaning agent for stainless steel.
2. Run a washing cycle without any wash-
ing to clean off any cleaning agent resi-
dues.
Programme: Short Cotton Programme
at maximum temperature and add ap-
prox. 1/4 measuring cup of detergent.
DOOR SEAL
Check from time to time the door seal and
eliminate eventual possible objects that
could be trapped in the fold.
DRAIN PUMP
Regularly examine the drain pump and
make sure that it is clean.
Clean the pump regularly and/or if:
• The appliance does not drain the water.
• The drum cannot turn.
• The appliance makes an unusual noise
because of the blockage of the drain
pump.
• A problem with water draining is detected
(see chapter “What to do if...” for more
details).
electrolux 17

Warning!
1. Disconnect the mains plug from
the mains socket.
2. Do not remove the filter while the
appliance operates. Do not clean
the drain pump if the water in the
appliance is hot. The water must
be cold before you clean the drain
pump.
To clean the drain pump:
1. Open the pump door.
2. Put a container below the recess of the
drain pump to collect the water that
flows out.
3. Press the two levers and pull forward
the drainage duct to let the water flow
out.
4. When the container is full of water, put
the drainage duct back again and emp-
ty the container. Do steps 3 and 4
again and again until no more water
flows out from the drain pump.
5. Pull back the drainage duct.
6. Unscrew the filter and remove it.
12
7. Remove fluff and objects from the
pump.
8. Make sure that the impeller of the
pump can turn. If this does not occur,
contact the service centre.
9. Clean the filter under the water tap and
put it back in the pump into the special
guides.
10. Make sure that you tighten correctly the
filter to prevent leakages.
2
1
18 electrolux

11. Close the drain pump door.
Warning!
Never remove the pump cover during a
wash cycle, always wait until the appliance
has finished the cycle, and is empty. When
refitting the pump cover, ensure it is se-
curely re-tightened so as to stop leaks and
young children being able to remove it.
CLEANING THE WATER INLET
FILTERS
If you notice that the machine is taking lon-
ger to fill, check that the filter in the water
inlet hose is not blocked.
1. Turn off the water tap.
2. Unscrew the water inlet hose.
3. Clean the filter in the hose using a hard
bristle brush.
4. Screw the hose back onto the tap.
5. Unscrew the hose from the machine.
Keep a rug nearby because some wa-
ter may flow.
6. Clean the filter in the valve with a stiff
brush or with the piece of cloth.
7. Screw the hose back to the machine
and make sure the connection is tight.
8. Turn on the water tap.
EMERGENCY EMPTYING OUT
If the appliance cannot drain the water, pro-
ceed as follows to empty out the machine:
1. pull out the plug from the power sock-
et;
2. close the water tap;
3. if necessary, wait until the water has
cooled down;
4. open the pump door;
5. place a container on the floor below the
recess of the drain pump;
6. press the two levers and pull forward
the drainage duct to let the water flow
out;
7. when the container is full of water, put
the drainage duct back again and emp-
ty the container;
repeat this operation until water stops
flowing out;
8. if necessary clean the pump (refer to
the section ‘Drain pump’ );
9. close the drain pump door.
When you drain the water with the emer-
gency drain procedure, you must activate
again the drain system:
1. Put 2 litres of water in the main wash
compartment of the detergent dispens-
er.
2. Start the programme to drain the wa-
ter.
FROST PRECAUTIONS
If the machine is installed in a place where
the temperature could drop below 0°C, re-
move the remaining water from the inlet
hose and the drain pump.
1. disconnect the mains plug from the
mains socket.
electrolux 19

2. close the water tap
3. unscrew the water inlet hose from the
tap;
4. put the two ends of the inlet hose in a
container and let the water flow out of
the hose.
5. empty the drain pump as described in
the ‘Emergency drain’ section.
6. when the drain pump is empty, install
the water inlet hose again.
Warning!
Make sure that the temperature is more
than 0 °C before you use the appliance
again.
The manufacturer is not responsible for
damages caused by low temperatures.
WHAT TO DO IF…
Certain problems are due to lack of simple
maintenance or oversights, which can be
solved easily without calling out an engi-
neer. Before contacting your local Service
Centre, please carry out the checks listed
below.
During machine operation it is possible that
the red pilot light of button 6blinks, one of
the following alarm codes appears on the
display and at the same some acoustic sig-
nals sound every 20 seconds to indicate
that the machine is not working:
•:problem with the water supply.
•:problem with the water draining.
•:door open.
Once the problem has been eliminated,
press the button 6to restart the pro-
gramme. If after all checks, the problem
persists, contact your local Service Centre.
Problem Possible cause/Solution
The washing machine does
not start:
The door has not been closed.
•Closefirmlythedoor.
The plug is not properly inserted in the power socket.
• Insert the plug into the power socket.
There is no power at the socket.
• Please check your domestic electrical installation.
The main fuse has blown.
• Replace the fuse.
The selector dial is not correctly positioned and the button 6has
not been depressed.
• Please turn the selector dial and press the button 6again.
The delay start has been selected.
• If the laundry are to be washed immediately, cancel the delay
start.
The Child Safety Lock has been activated.
• Deactivate the Child Safety Lock.
The machine does not fill:
The water tap is closed.
• Open the water tap.
The inlet hose is squashed or kinked.
• Check the inlet hose connection.
The filter in the inlet hose or the inlet valve filter are blocked.
• Clean the water inlet filters (See "Cleaning the water inlet filters"
for more details).
The door is not properly closed.
•Closefirmlythedoor.
20 electrolux
