Electrolux EWF12932 User manual

EWF12932
EWF12932S
EWF12832
EWF12832S
EN
IN
VI
WASHING MACHINE
MESIN CUCI
MÁY GIẶT
PANDUAN BAGI PENGGUNA
TÀI LIỆU HƯỚNG DẪN SỬ DỤNG
34
69
USER MANUAL 2
................................................... ....................................................................

CONTENTS
WE’RE THINKING OF YOU
CUSTOMER CARE AND SERVICE
2 www.electrolux.com
SAFETY INFORMATION
PRODUCT DESCRIPTION
CONTROL PANEL
BEFORE FIRST USE
DAILY USE
WASHING HINTS
INTERNATIONAL WASH CODE SYMBOLS
CARE AND CLEANING
TROUBLESHOOTING
................................................................................... 3
................................................................................ 5
............................................................................................ 6
...................................................................................... 12
.................................................................................................... 12
........................................................................................... 19
................................................... 22
.................................................................................. 22
.................................................................................... 27
1
2
3
4
5
6
7
8
9
TECHNICAL DATA ......................................................................................... 3010
INSTALLATION .............................................................................................. 3111
ENVIRONMENT CONCERNS ......................................................................... 3312
Thank you for purchasing an Electrolux appliance. You’ve chosen a product that
brings with it decades of professional experience and innovation. Ingenious and
stylish, it has been designed with you in mind. So whenever you use it, you can be
safe in the knowledge that you’ll get great results every time.
Welcome to Electrolux.
We recommend the use of original spare parts.
When contacting Service, ensure that you have the following data available.
The information can be found on the rating plate. Model, PNC, Serial Number.
Visit our website to:
Get usage advice, brochures, trouble shooter, service information:
www.electrolux.com
Warning / Caution-Safety information.
General information and tips.
Environmental information.
Subject to change without notice.
Being ensured permissible content limitaon of some toxic
chemicals (RoHS compliant)
RoHS
Compliant

ENGLISH 3
SAFETY INFORMATION1.
In the interest of your safety and to
ensure the correct use, before installing
and first using the appliance, read this
user manual carefully, including its hints
and warnings.
This appliance is intended to be used in
household and similar applications
such as:
Farm houses
By clients in serviced apartments,
holiday apartments and residential
type environments.
Conditions of use
To avoid unnecessary mistakes and
accidents, it is important to ensure that
all people using the appliance are
thoroughly familiar with its operation and
safety features.
Save these instructions and make sure
that they remain with the appliance if it
is moved or sold, so that everyone
using it through its life will be properly
informed on appliance use and safety.
1.1 GENERAL SAFETY
It is dangerous to alter the
specifications or attempt to modify this
product in anyway.
During high temperature wash
program the door glass may get hot.
Do not touch it!
Make sure that small pets do not
climb into the drum. To avoid this,
please check into the drum before
using the appliance.
Any objects such as coins, safety
pins, nails, screws, stones or any
other hard, sharp material can cause
extensive damage and must not be
placed into the machine.
Only use the advised quantities of
fabric softener and detergent. Damage
to the fabric or appliance can occur if
you overfill. Refer to the manufacturer’s
recommendations of quantities.
Wash small items such as socks,
laces, washable belts etc in a washing
bag or pillow case as it is possible for
such items to slip down between the
tub and the inner drum.
This appliance is not intended for use
by persons (including children) with
reduced physical, sensory or mental
capabilities, or lack of experience and
knowledge, unless they have been
given supervision or instruction
concerning use of the appliance by a
person responsible for their safety.
Do not use your washing machine to
wash articles with whalebones,
material without hems or torn material.
Always unplug the appliance and turn
off the water supply after use, clean
and maintenance.
This appliance is heavy. Care should
be taken when moving it.
When unpacking the appliance, check
that it is not damaged. If in doubt, do
not use it and contact the Service
Centre.
All packing and transit bolts must be
removed before use. Serious damage
can occur to the product and to
property if this is not adhered to. See
relevant section in the user manual.
Under no circumstances should you
attempt to repair the machine yourself.
Repairs carried out by inexperienced
persons may cause injury or serious
malfunctioning. Contact your local
Service Centre. Always insist on
genuine spare parts.
1.2 INSTALLATION
-
-

4 www.electrolux.com
After having installed the appliance,
check that it is not standing on the
inlet and drain hose and the worktop
is not pressing the electrical supply
cable.
If the machine is situated on a
carpeted floor, please adjust the feet
in order to allow air to circulate freely.
Always be sure, that there is no water
leakage from hoses and their
connections after the installation.
Any plumbing work required to install
this appliance should be carried out by
a qualified plumber.
This washing machine is not intended
for use by young children or infirm
persons without supervision.
Young children should be supervised
to ensure that they do not play with
the appliance.
The packaging components (e.g.
plastic film, polystyrene) can be
dangerous to children - danger of
suffocation! Keep them out of
children’s reach.
Make sure that children or pets do not
climb into the drum.
To activate this device, rotate the
button (WITHOUT pressing it) inside
the door clockwise until the groove is
horizontal. If necessary use a coin.
When you activate this device, you
cannot close the door. This prevents
children or pets to be locked in the
drum.
To disable this device and restore the
possibility of closing the door, rotate
the button anti-clockwise until the
groove is vertical.
Keep all detergents in a safe place out
of children’s reach.
Any electrical work required to install
this appliance should be carried out by
a qualified electrician.
This appliance is designed for
domestic use. It must not be used for
purposes other than those for which it
was designed.
Only wash fabrics which are designed
to be machine washed. Follow the
instructions on each garment label.
Do not overload the appliance. See
the relevant section in the user
manual.
Before washing, ensure that all
pockets are empty and buttons and
zips are fastened. Avoid washing
frayed or torn articles and treat stains
such as paint, ink, rust, and grass
before washing. Underwired bras
must NOT be machine washed.
Garments which have been in contact
with volatile petroleum products
should not be machine washed. If
volatile cleaning fluids are used, care
should be taken to ensure that the
fluid is removed from the garment
before placing in the machine.
Never pull the power supply cable to
remove the plug from the socket;
always take hold of the plug itself.
Never use the washing machine if the
power supply cable, the control panel,
the working surface or the base are
damaged so that the inside of the
washing machine is accessible.
1.3 USE
1.4 CHILD SAFETY
1.5 CHILD SAFETY DEVICE

ENGLISH 5
PRODUCT DESCRIPTION2.
1
Worktop
2
Detergent/Softener Dispenser
3
Control Panel
4
Door Handle
5
Door
13
Child Safety Device
Rating Label
14
7
6
Level Adjustment Feet (Front)
8
Mains Cable
9
Water Inlet Hose
10
Water Drain Hose
11
Hose Support (2pcs)
12
Level Adjustment Feet (Back)
Transit Bolts (3pcs)
To connect the drain
hose on the edge of a
sink.
Plastic Caps
To close the holes on
the rear side of the
cabinet after the
removal of the transit
bolts.
ACCESSORIES
Plastic Hose Guide
3
5
4
2 1
9
8
7
1011
11
12
14
13
6
15
Drain Pump Filter
15

6 www.electrolux.com
CONTROL PANEL3.
Child Lock Option (See Page 18)
1
On/Off Button
2
Program Knob
3
4
Temperature Touchpad
5
Spin Selection Touchpad
6
Adjust Time Touchpad
7
Delay Start Touchpad
8
Display
9
Rinse Plus Touchpad
10
Prewash Touchpad
11
Easy Iron Touchpad
12
Vapour Touchpad
13
Start/Pause Touchpad
3.1 On/Off Button
On/Off button is used to turn On
and turn Off your washing machine.
3.2 Program Knob
Turn this knob to set a program.
The related program indicator
comes on. The buzzer sounds.
(See page 10)
3.3 Temperature Touchpad
Press this touchpad repeatedly to
increase or decrease the wash
temperature if you want your laundry
to be washed at a temperature
different from the one proposed by
the washing machine (symbol “ ”
corresponds to cold wash).
3.4 Spin Selection Touchpad
Press this touchpad repeatedly to
increase or decrease the spin
speed, if you want your laundry to
be spun at a speed different from
the one proposed by the washing
machine.
No spin option eliminates all the
spin phases and increase the
number of rinses.
No Spin
By selecting this option the water of
the last rinse is not emptied out and
the drum turns regularly to prevent
the laundry creases.
Rinse Hold
The door is still locked to indicate
that the water must be emptied out.
112 5 6
2 4 97 813 10 113

ENGLISH 7
By selecting this option, the
machine will not drain the water of
the last rinse to avoid wrinkling the
laundry. All spinning phases are
suppressed.
Night Cycle
3.6 Delay Start Touchpad
This option makes it possible to
delay the start of the program by
30 min, 60 min or 90 min and
then by every hour from 2 to 20
hours.
The delay you have selected is
indicated on the display. The end
time will increase in order to show
you the selected delay.
You must select this option after
you have set the program and
before you press the Start/Pause
button.
The door stays locked with
the water in the drum. To
continue the cycle you must
press (Start/Pause).
The door stays locked with
the water in the drum. To
continue the cycle you must
press (Start/Pause).
3.5 Adjust Time Touchpad
This option allows you to reduce
washing time.
This washing cycle is very quiet,
and can be selected at night or
other appropriate times.
Press this touchpad repeatedly to
decrease or return to default
washing time.
This option will adjust the number
of rinse according to selected
washing time.
If you wish to add laundry in the
machine during the delay time
press Start/Pause touchpad to put
the machine in pause mode. Add
laundry, close the door and press
Start/Pause touchpad again.
You can cancel the delay time at
any moment, by pressing ‘Delay
Start’ touchpad repeatedly till the
display shows delay time ‘ ’, then
press the Start/Pause touchpad.
A
Digital Number;
will tell you:
The level of the Time Manager
( ).
B
-
Washing Phase icon
C
D
Delay Start icon
E
Child Lock icon
Door Lock icon
3.7 Display
Washing cycle time.
-It is on, you cannot open the
door.
-It is off, you can open the door.
-
-
The alarm codes. Refer to the
chapter “Troubleshooting” for
their description.
-Delay start time.
C DA
B E

8 www.electrolux.com
Select this option to add
approximately 45 minutes of
tumbling in vapour during the
wash cycle. Vapour helps open
fabric fibers up to allow laundry
additives to release tough stains.
3.11 Vapour Touchpad
The indicator of this option comes
on.
Vapour may not necessarily be
visible inside the drum during a
vapour wash cycle. Vapour is
created below the drum and
allowed to naturally rise into the
clothes.
NOTE:
At the end of the Vapour cycle
the clothes will be warmer,
softer and detached from the
drum.
If Vapour option is selected,
rinse temperatures will be
elevated.
During a vapour cycle you
may notice vapour exiting
from the drain hose of the
washing machine, this is
normal and there is no
cause for alarm.
Vapour may not be present
during the entire vapour wash
cycle.
Vapour function is more
effective with half load.
3.8 Rinse Plus Touchpad
3.9 Prewash Touchpad
3.10 Easy Iron Touchpad
This option is recommended for
people who are allergic to
detergents, and in areas where the
water is very soft.
Press it to add rinsing phases to a
program.
The indicator of this option comes
on.
Select this option if you wish your
laundry to be pre-washed before
the main wash. Use this option for
heavy soil.
The indicator of this option comes
on.
When you set this function, put
the detergent into the “ ”
compartment. (Refer page 14-15)
This function increases the
program duration.
When selecting this option the
laundry is gently washed and
spun to avoid creasing. In this
way ironing is easier.
The indicator of this option comes
on.

ENGLISH 9
3.12 Start/Pause Touchpad
To start the selected program,
press the ‘Start/Pause’.
To interrupt a program which is
running, press the ‘Start/Pause’
to pause the machine.
To restart the program from the
point at which it was interrupted,
press the ‘Start/Pause’ again.
If you have chosen a delayed
start, after pressing ‘Start/Pause’
the machine will begin the
countdown.
3.13 Buzzer Sounds
The program is completed.
The appliance has a malfunction.
The buzzer sounds operate when:
If you want to disable the buzzer
sound (except for event of
appliance malfunction), press
“Rinse +” and “Vapour” touchpads
at the same time for 3 seconds,
and listen for ‘BEEP, BEEP’.
To return to default configuration
press these 2 touchpads at the
same time for 3 seconds, and listen
for ‘BEEPS’.

10 www.electrolux.com
3.14 Programs + Options
Program;
Temperature
Cottons (***);
90 °C to
(cold water)
White and coloured cotton
with heavy level of soil;
max. load ;
EWF12932, EWF12932S : 9 kg
EWF12832, EWF12832S : 8 kg
Spin Reduction: 1200 to 400 rpm,
No Spin, Rinse Hold, Night Cycle,
Prewash, Easy Iron, Rinse +, Vapour 1) ,
Adjust Time, Delay Start
Spin Reduction: 1200 to 400 rpm,
No Spin, Rinse Hold, Night Cycle,
Prewash, Easy Iron, Rinse +, Vapour 1) ,
Adjust Time, Delay Start
Spin Reduction: 1200 to 400 rpm,
No Spin, Rinse Hold, Night Cycle,
Prewash, Rinse +, Vapour 1) ,
Adjust Time, Delay Start
Spin Reduction: 1200 to 400 rpm,
No Spin,
Delay Start
Spin Reduction: 1200 to 400 rpm,
No Spin, Rinse Hold,
Delay Start
Type of load; Max. weight
of load (dry clothes)
Cycle
description
Options can be
combined
Mixed;
60 °C to
(cold water)
Synthetic or mixed
fabric items with
normal level of soil;
max. load 4 kg.
Delicates;
40 °C to
(cold water)
Quick 18;
30 °C
Delicate fabrics as
acrylics, viscose,
polyester items with
normal soil;
max. load 4 kg
Synthetic and mixed
fabric items. Light soil
and items to freshen
up;
max. load 1.5 kg
Spin Reduction
- 800 to 400 rpm
No Spin, Rinse Hold,
Spin
To spin the laundry and
drain the water in the drum;
max. load ;
EWF12932, EWF12932S : 9 kg
EWF12832, EWF12832S : 8 kg
Delay Start
Rinse
To rinse and spin the
laundry;
max. load ;
EWF12932, EWF12932S : 9 kg
EWF12832, EWF12832S : 8 kg
Wash
Rinses
Long spin
Wash
Rinses
Short spin
Wash
Rinses
Short spin
Wash
Rinses
Short spin
Drain
Spin phase
-
-
-
-
-
-
-
-
-
-
-
-
-
-
Three
rinses with
softener
Spin phase
-
-
Energy
Saver
60 °C 2) ,
40 °C
White and fast colourfast,
cotton with normal soil. Set
this program to have a good
washing results and decrease
the energy consumption. The
time of the washing program
is extended;
max. load ;
EWF12932, EWF12932S : 9 kg
EWF12832, EWF12832S : 8 kg
- Wash
- Rinses
- Long spin
Spin Reduction: 1200 to 400 rpm,
No Spin, Rinse Hold,
Prewash, Rinse +, Vapour 1) ,
Adjust Time, Delay Start

ENGLISH 11
Program;
Temperature
Type of load; Max. weight of
load (dry clothes)
Cycle
description
Options can be
combined
Bedding
60 °C to
(cold water)
Special program for one
synthetic blanket, duvet,
bedspread and so on;
max. load 3 kg.
- Wash
- Rinses
- Long spin
Spin Reduction
- 800 to 400 rpm
No Spin,
Vapour 1) , Adjust Time, Delay Start
1) Vapour option can be combined with temperature 40 to 90 °C only.
Wool;
40 °C to
(cold water)
Specially tested program for
woollen garments bearing the
‘Pure new wool, non-shrink,
machine washable’ label;
max. load 2 kg.
- Wash
- Rinses
- Short spin
Refresh
Cottons
Vapour program for White and
coloured cotton. This cycle
removes odours and helps to
dewrinkle the laundry;
max. load 1.5 kg.
Refresh
Mixed
Vapour program for synthetic
or mixed fabric items. This
cycle removes odours and
helps to dewrinkle the laundry;
max. load 1.5 kg.
Baby Wear;
40 °C to
(cold water)
Baby cotton clothes and
delicate knitting items
with normal soil;
max. load 4 kg
- Wash
- Rinses
- Short spin
2)
(***) For Vietnam: “Cottons” program with cold water option selected is recommended for a full load of normally
soiled cottons, and is the energy rating label program.
“Energy Saver” program with 60 °C option selected is recommended for a full load of normally soiled cottons,
and is the water and energy rating label program.
Spin Reduction: 1200 to 400 rpm,
No Spin, Rinse Hold, Night Cycle,
Delay Start
Delay Start
Delay Start
Clothes
tumble in
vapour
-
Clothes
tumble in
vapour
-
The wool wash cycle of this machine has been approved by The Woolmark
Company for the washing of machine washable wool products provided
that the products are washed according to the instructions on the garment
label and those issued by the manufacturer of this washing machine.
M1354
WOOLMARK CERTIFICATE
Spin Reduction: 1200 to 400 rpm,
No Spin, Rinse Hold, Night Cycle,
Prewash, Rinse +, Vapour 1) , Delay Start

12 www.electrolux.com
DAILY USE5.
Step 1 - Setting A Program For Washing
Connect the mains plug to the mains socket.
5.1 4 Steps Start Up Guide
Turn the water tap on.
1.
Press the On/Off button to turn on the
washing machine.
2.
Turn the program selector dial
to the required program.
The relevant light will light up.
-
The buzzer will sound.
-
Once you selected a wash
program, the program selected
will stay at that position for the
whole of the wash.
-
The selector dial can be
turned either clockwise or
anticlockwise.
-
The display shows the level of
the Time Manager, the
program duration and the
indicators of the phases of the
program.
-
BEFORE FIRST USE4.
Ensure that the electrical and water
connections comply with the
installation instructions.
Put 2 litres of water in the detergent
compartment for washing phase.
This activates the drain system.
1.
2.
3. Select a Cottons cycle at 90 °C,
without any laundry in the machine,
to remove any manufacturing residue
from the drum and tub then start the
machine.
13
5
4
2

ENGLISH 13
3.
pess the Spin ‘ ’ and the tempera-
ture ‘ ’ touchpads repeatedly to
change the spin speed and
temperature.
If you want your laundry to be spun
or use temperature different from
the one proposed by the washing
machine,
4.
Press the option touchpads, if you
want your laundry to be washed
with special functions.
Different functions can be combined
which is dependent on the program
selected.
When these touchpads are pressed,
the corresponding pilot lights come
on. When they are pressed again,
the pilot lights go out.
5.
If you want to reduce washing time,
press the ‘Adjust Time ’ touchpad
repeatedly to reduce washing time.
If you want to delay the start of the
washing program
, press the ‘Delay
Start ’ touchpad repeatedly to
choose your washing machine delay
time.
Step 2 - Loading The Laundry
Place the laundry in the drum,
one item at a time, shaking them
out as much as possible.
3.
Open the door by carefully pulling
the door handle outwards.
Check and remove objects (if
there are any) that could be
trapped in the fold.
2.
Wash bras, pantyhose and
other delicates in a mesh
laundry bag, which you can
purchase from your
supermarket.
1.
Make sure that you wash lint
collectors separately from lint
producers.
IMPORTANT!
Button up pillowcases, close zip
fasteners, hooks and poppers.
Tie any belts or long tapes.
Make sure that no metal
objects are left in the laundry
(e.g. hair clips, safety pins,
pins).
Before loading the laundry, please
make sure:

14 www.electrolux.com
Make sure that no laundry
remains between the seal and
the door.
4.
Close the door.
5.
The detergent dispenser is divided
into three compartments.
Detergent Dispenser Drawer
Model: EWF12932, EWF12932S
Step 3 - Using Detergent And Additives
Compartment ‘SOFTENER’
Compartment ‘PREWASH’
This compartment is used for
fabric conditioner and starching
agent.
This compartment is only used
for detergent when a Prewash
is selected.
1.
-
-
Compartment ‘MAIN WASH’
This compartment is used for
detergent on all programs.
Detergeant flap
Flap for powder or liquid
detergent.
-
Powder or liquid detergent.
3
1
POSITION USING
POWDER DETERGENT
Position down :
for liquid
detergent.
Position up :
for powder
detergent
(factory setting).
2
Position down :
for liquid
detergent.
Position up :
for powder
detergent
(factory setting).

ENGLISH 15
The detergent dispenser is divided
into three compartments.
Compartment ‘SOFTENER’
Compartment ‘PREWASH’
This compartment is used for
fabric conditioner and starching
agent.
This compartment is only used
for detergent when a Prewash
is selected.
-Do not use gelatinous or thick
liquid detergents.
-
Do not put more liquid than the
maximum level.
-
Do not set the DELAY START.
-
Do not set the PREWASH phase.
-
-
Compartment ‘MAIN WASH’
This compartment is used for
detergent on all programs.
Detergeant flap
Flap for powder or liquid
detergent.
-
Powder or liquid detergent.
When you use the liquid
detergent:
Model: EWF12832, EWF12832S
1
2
3
Position down :
for liquid
detergent.
Position up :
for powder
detergent
(factory setting).
Position down :
for liquid
detergent.
Position up :
for powder
detergent
(factory setting).
4

16 www.electrolux.com
Measure out the amount of
detergent required, pour it into
the main wash compartment
( ) and, if you wish to carry
out the “Prewash” phase,
pour it into the compartment
marked .
Pull out the dispenser drawer
until it stops.
-
If required, pour fabric softener
into the compartment marked
(the amount used must not
exceed the “MAX” mark in the
drawer).
-
Close the drawer gently.
-
-
Measure Out The Detergent And The Fabric Softener
2.
ATTENTION !
If you turn the program selector
dial to another program when the
machine is working, the message
“ ” will appear on the
display to indicate a wrong
selection. The machine will not
perform the new selected
program.
The appliance will automatically
adjust the selected program
duration according to the type
and size of the load.
-
The display will show adjusted
program duration.
-
Step 4 - Starting a program
To start a program, press the
Start/Pause ( ) touchpad, the
corresponding pilot light will stop
flashing and a default program
duration will be displayed on the
screen.
After approx. 15 minutes
from the start of a program:
After washing cycle
finish, residues of
detergent, softener and
water may remain in the
dispenser.
It is recommended to
clean the dispenser
regularly to remove any
residue.
If you use thick softeners it
is recommended to dilute
with water.

ENGLISH 17
To pause press Start/ Pause.
The indicator will start flashing.
-
Press the Start/Pause again.
The program will continue.
-
Changing a running program is possible
only by switching off the appliance.
Press the ‘On/Off’ button to cancel
the program and to turn off the
appliance.
-
5.2 Interruption Of A Program
5.3 Changing A Program
It is possible to change only some option
after the program has started.
Press the touchpad Start/Pause. The
indicator will start flashing.
1.
Change the options.2.
Press Start/Pause again. The program
will continue.
3.
While a program or the Delay Start is
operating, the appliance door is locked
and the display shows the indicator ‘ ’.
Press the ‘On/Off’ button again to start
the appliance. Now, you can set a new
washing program.
The appliance will not drain the
water.
-
5.4 Changing The Options
5.5 Opening The Door
First set the machine to PAUSE by pressing
the “Start/Pause” touchpad. Wait until the
door lock indicator ‘ ’ goes off, then the
door can be opened.
If the door lock indicator ‘ ’ does not
disappear, this means that the machine is
already heating and the water level is above
the bottom edge of the door or the drum is
turning. In this case the door CAN NOT be
opened.
If you can not open the door but you
need to open it you have to switch
the machine off by pressing the
‘On/Off’ button to deactivate the
appliance. After about 5 minutes the
door can be opened.
Pay attention to the water
level and water temperature.
CAUTION!
The appliance stops automatically.
The acoustic signal will operate.
The display will show ‘ ’.
The indicator of the touchpad
Start/Pause goes off.
-
-
-
-
-
-
-
-
The door lock indicator ‘ ’
goes off.
Remove the laundry from the
appliance. Make sure that the
drum is empty.
Keep the door ajar, to prevent the
mildew and odours.
Turn off the water tap.
5.6 At The End Of The Program
At the end of the program the
time remaining can suddenly
decrease from 7 minutes or less
to 0 due to the overestimated
total program time during the
load sensing phase. In some
cases (with perfectly balanced
load) the program time can be
shorter than the time estimated
after the load sensing phase is
completed. This is a normal
behavior of the machine and
not a cause for concern as it
does not compromise its
performance.

18 www.electrolux.com
1.
3.
2.
When The Washing Program
Is Completed, But There Is
Water In The Drum
The drum turns regularly to prevent
the creases in the laundry.
You must drain the water to open the
door.
The door lock indicator ‘ ’ is on.
The door stays locked.
To drain the water:
Press the touchpad Start/Pause.
The appliance will drain the water
and spin.
If necessary, decrease the spin
speed.
Set the “Spin” program.
-
-
5.7
When the program is completed
and the door lock indicator ‘ ’
goes off, you can open the door.
4.
Press the ‘On/Off’ button to
deactivate the appliance.
5.
5.9 Child Lock Feature
Your appliance is provided with
CHILD SAFETY LOCK which
permits you to leave the appliance
unsupervised with the door closed
without having to worry that children
might be injured by or cause
damage to the appliance.
Set this option before pressing the
Start/Pause and after having
selected the required wash program.
This function remains enabled even
after the appliance is switched off.
To activate the function, press
“Prewash” and “Rinse +”
touchpads at the same time until
the display shows the symbol .
Setting Child Lock option:
To deactivate the function, press
“Prewash” and “Rinse +”
touchpads at the same time until
the symbol goes off.
AUTO Stand-by Option
5.8
The AUTO Stand-by option
automatically deactivates the
appliance to decrease the energy
consumption when:
Turn the program knob to set a new
cycle.
You do not press any buttons
for 5 minutes before you press
“Start/Pause”.
Press the “On/Off” button to
activate the appliance again.
After 5 minutes from the end of
the washing program.
Press the “On/Off” button to
activate the appliance again.

ENGLISH 19
WASHING HINTS6.
Follow the wash code symbols on
each garment label and the
manufacturer’s washing instructions.
Sort the laundry as follows: whites,
coloureds, synthetics, delicates,
woollens.
6.1 Sorting The Laundry
6.2 Temperatures
90°C
60°C
50°C
40°C
30°C
Cold
For normally soiled,
colourfast garments (e.g.
shirts, night dresses,
pyjamas....) in linen, cotton
or synthetic fibres and for
lightly soiled white cotton
(e.g.underwear).
For delicate items (e.g. net
curtains), mixed laundry
including synthetic fibres
and woollens bearing the
label pure new wool,
machine washable,
non-shrink.
For normally soiled white
cottons and linen
(e.g. teacloths, towels,
tablecloths, sheets...).
Never wash whites and coloureds
together. Whites may lose their
“whiteness” in the wash.
New coloured items may run in the
first wash; they should therefore be
washed separately the first time.
Button up pillowcases, close zip
fasteners, hooks and poppers. Tie
any belts or long tapes.
Remove persistent stains before
washing.
Rub particularly soiled areas with a
special detergent or detergent paste.
Treat curtains with special care.
Remove hooks or tie them up in a
bag or a net.
Make sure that no metal objects
are left in the laundry (e.g. hair
clips, safety pins, pins).
6.3 Before Loading The
Laundry
Recommended loads are indicated
in the program charts. General
rules:
Washing a maximum load makes
the most efficient use of water and
energy. For heavily soiled laundry,
reduce the load size.
Cotton, linen: drum full but not
too tightly packed;
Synthetics: drum no more
than half full;
Delicate
fabrics and
woollens:
drum no more
than one third full.
6.4 Maximum Loads
Blood: treat fresh stains with cold
water. For dried stains, soak
overnight in water with a special
detergent then rub in the soap and
water.
Oil based paint: moisten with
benzine stain remover, lay the
garment on a soft cloth and dab
the stain; treat several times.
Dried grease stains: moisten with
turpentine, lay the garment on a
soft surface and dab the stain with
the fingertips and a cotton cloth.
Stubborn stains may not be
removed by just water and
detergent. It is therefore advisable
to treat them prior to washing.
6.5 Removing Stains

20 www.electrolux.com
Rust: oxalic acid dissolved in hot
water or a rust removing product
used in cold water. Be careful with
rust stains which are not recent
since the cellulose structure will
already have been damaged and
the fabric tends to hole.
Mould stains: treat with bleach,
rinse well (whites and fast
coloureds only).
Grass: soap lightly and treat with
bleach (whites and fast coloureds
only).
Ball point pen and glue: moisten
with acetone (*), lay the garment on
a soft cloth and dab the stain.
Lipstick: moisten with acetone (*)
as above, then treat stains with
methylated spirits. Remove any
residual marks from white fabrics
with bleach.
The detergent and any additives
must be placed in the appropriate
compartments of the dispenser
drawer before starting the wash
program.
Red wine: soak in water and
detergent, rinse and treat with
acetic or citric acid, then rinse.
Treat any residual marks with
bleach.
Ink: depending on the type of ink,
moisten the fabric first with
acetone (*), then with acetic acid;
treat any residual marks on white
fabrics with bleach and then rinse
thoroughly.
Tar stains: first treat with stain
remover, methylated spirits or
benzine, then rub with detergent
paste.
Good washing results also depend
on the choice of detergent and use
of the correct quantities to avoid
waste and protect the
environment.
Although biodegradable, detergents
contain substances which, in large
quantities, can upset the delicate
balance of nature.
The choice of detergent will depend
on the type of fabric (delicates,
woollens, cottons, etc.), the colour,
washing temperature and degree of
soiling.
Only low suds Front load washer
detergents should be used in
this appliance:
(*) do not use acetone on artificial
silk.
6.6 Detergents and Additives
powder detergents for all types
of fabric,
powder detergents for delicate
fabrics (60 °C max) and woollens,
liquid detergents, preferably for
low temperature wash program
(60 °C max) for all types of fabric,
or special for woollens only.
If using concentrated powder
or liquid detergents, a program
without PREWASH must be
selected.
Pour liquid detergent into the
dispenser drawer compartment
marked ‘ ’ just before starting
the program.
