Electrolux LAVAMAT 74650 A3 User manual

LAVAMAT 74650 A3
LAVAMAT 76650 A3
User manual Washing Machine
Benutzerinformation Waschmaschine

Thank you for choosing one of our high-quality products.
To ensure optimal and regular performance of your appliance please read this
instruction manual carefully. It will enable you to navigate all processes perfectly
and most efficiently. To refer to this manual any time you need to, we
recommend you to keep it in a safe place. And please pass it to any future owner
of the appliance.
We wish you much joy with your new appliance.
CONTENTS
OPERATING INSTRUCTIONS 3
SAFETY INFORMATION 3
General safety 3
Installation 4
Use 4
Child Safety 4
PRODUCT DESCRIPTION 5
Detergent dispenser drawer 6
CONTROL PANEL 6
Display (7) 7
Indicator pilot lights (10) 8
FIRST USE 8
PERSONALIZATION 8
Acoustic signals 8
Child safety lock 8
DAILY USE 9
Load the laundry 9
Measure out the detergent and the fabric
softener 9
Select the required programme by means
of programme selector dial (1) 10
Select the desired TEMPERATURE (Button 2)
10
Select the spin speed (SPIN Reduction) or
the RINSE HOLD option (Button 3) 11
Programme option buttons 11
Select the PREWASH option (Button 4)
11
Select the STAIN option (Button 5) 11
Select the TIME SAVING option (Button 6)
11
Select an additional rinse (EXTRA RINSE)
12
Select the START/PAUSE (Button 8) 12
Select the DELAY START (Button 9) 12
Altering an option or a running programme
13
Interrupting a programme 13
Cancelling a programme 13
Opening the door after the programme has
started 13
At the end of the programme 13
HELPFUL HINTS AND TIPS 14
Sorting out the laundry 14
Before loading the laundry 14
Removing stains 14
Detergents and additives 14
Quantity of detergent to be used 15
Degrees of water hardness 15
WASHING PROGRAMMES 15
CARE AND CLEANING 20
Descaling 20
After each wash 20
Maintenance wash 20
External cleaning 21
Detergent dispenser drawer 21
Washing drum 21
Door seal 22
Drain pump 22
Cleaning the water inlet filters 24
Frost precautions 25
Emergency emptying out 25
WHAT TO DO IF… 25
TECHNICAL DATA 28
CONSUMPTION VALUES 29
INSTALLATION INSTRUCTIONS 29
INSTALLATION 29
Unpacking 29
Positioning and levelling 32
Water inlet 32
2Contents

Water-stop device 33
Water drainage 33
ELECTRICAL CONNECTION 34
ENVIRONMENT CONCERNS 35
Packaging materials 35
Ecological hints 35
Subject to change without notice
OPERATING INSTRUCTIONS
SAFETY INFORMATION
Read carefully & keep for future reference.
• The safety of Your appliance complies with the industry standards and with legal re
quirements on the safety of appliances. However, as manufacturers, we feel it is our
duty to provide the following safety notes.
• It is most important that this instruction book should be retained with the appliance
for future reference. Should the appliance be sold or transferred to another owner, or
should you move house and leave the appliance, always ensure that the book is sup
plied with the appliance in order that the new owner can get to know the functioning
of the appliance and the relevant warnings.
• You MUST read them carefully before installing or using the appliance.
• Before first starting up, check the appliance for any damage incurred during transport.
Never connect up a damaged appliance . If parts are damaged, contact your supplier.
• If the appliance is delivered in the winter months when there are minus temperatures.
Store it at room temperature for 24 hours before using for the first time.
General safety
• It is dangerous to alter the specifications or attempt to modify this product in any way.
• During high temperature wash programmes the door glass may get hot. Do not touch
it!
• Make sure that small pets and children do not climb into the drum. To avoid this,
please check into the drum before using.
• Any objects such as coins, safety pins, nails, screws, stones or any other hard, sharp
material can cause extensive damage and must not be placed into the machine.
• Only use the advised quantities of fabric softener and detergent. Damage to the fabric
can ensue if you over-fill. Refer to the manufacturer’s recommendations of quantities.
• Wash small items such as socks, laces, washable belts etc in a washing bag or pillow
case as it is possible for such items to slip down between the tub and the inner drum.
• Do not use your washing machine to wash articles with whalebones, material without
hems or torn material.
• Always unplug the appliance and turn off the water supply after use, cleaning and
maintenance.
• Under no circumstances should you attempt to repair the machine yourself. Repairs
carried out by inexperienced people may cause injury or serious malfunctioning. Con
tact your local Service Centre. Always insist on genuine spare parts.
Safety information 3
132941021-A-362010

Installation
• This appliance is heavy. Care should be taken when moving it.
• When unpacking the appliance, check that it is not damaged. If in doubt, do not use it
and contact the Service Centre.
• All packing and transit bolts must be removed before use. Serious damage can occur
to the product and to property if this is not adhered to. See relevant section in the
user manual.
• After having installed the appliance, check that it is not standing on the inlet and
drain hose and the worktop is not pressing the electrical supply cable against the wall.
• If the machine is situated on a carpeted floor, please adjust the feet in order to allow
air to circulate freely under the appliance.
• Always be sure, that there is no water leakage from hoses and their connections after
the installation.
• If the appliance is installed in a location subject to frost, please read the “dangers of
freezing” chapter.
• Any plumbing work required to install this appliance should be carried out by a quali
fied plumber or competent person.
• Any electrical work required to install this appliance should be carried out by a quali
fied electrician or competent person.
Use
• This appliance is designed for domestic use. It must not be used for purposes other
than those for which it was designed.
• Only wash fabrics which are designed to be machine washed. Follow the instructions
on each garment label.
• Do not overload the appliance. See the Washing Programme Table.
• Before washing, ensure that all pockets are empty and buttons and zips are fastened.
Avoid washing frayed or torn articles and treat stains such as paint, ink, rust, and
grass before washing. Underwired bras must NOT be machine washed.
• Garments which have been in contact with volatile petroleum products should not be
machine washed. If volatile cleaning fluids are used, care should be taken to ensure
that the fluid is removed from the garment before placing in the machine.
• Never pull the power supply cable to remove the plug from the socket; always take
hold of the plug itself.
• Never use the appliance if the power supply cable, the control panel, the working sur
face or the base are damaged so that the inside of the washing machine is accessible.
Child Safety
• This appliance is not intended for use by person (including children) with reduced phys
ical sensory or mental capabilities or lack of experience and knowledge unless they
have been given supervision or instruction concerning use of the appliance by a per
son responsible for their safety.
• Children should be supervised to ensure that they do not play with the appliance.
• The packaging components (e.g. plastic film, polystyrene) can be dangerous to children
- danger of suffocation! Keep them out of children's reach.
• Keep all detergents in a safe place out of children’s reach.
4Safety information

• Make sure that children or pets do not
climb inside the drum. To prevent children
or pets becoming trapped inside the drum
the machine incorporates a special feature.
To activate this device, rotate the button
(without pressing it) inside the door clock
wise until the groove is horizontal. If neces
sary use a coin. To disable this device and
restore the possibility of closing the door,
rotate the button anticlockwise until the
groove is vertical.
PRODUCT DESCRIPTION
Your new appliance meets all modern requirements for effective treatment of laundry
with low water, energy and detergent consumption.
The NEW JET system allows total use of detergent and reduces water consumption so
saving energy.
1
6
3
4
5
2
1Detergent dispenser drawer
2Control panel
3Door opening handle
4Rating plate
Product description 5

5Drain pump
6Adjustable feet
Detergent dispenser drawer
Compartment for detergent used for pre-
wash . The prewash detergent is added at the be
ginning of the wash programme.
Compartment for powder or liquid detergent
used for main wash .
Compartment for liquid additives (fabric soft
ener, starch).
Compartment for stain remover used for
main wash with STAINoption .
CONTROL PANEL
Below is a picture of the control panel. It shows the programme selector dial as well as
the buttons and the pilot lights. These are presented by relevant numbers on the follow
ing pages.
1 2 3 4 5 6 7 8 9 10
1Programme selector dial
2Temperature button (TEMP.)
3SPIN reduction button (T/MIN-ESSORAGE)
4PREWASH button (VOORWAS-PRELAVAGE)
5STAIN button (VLEKKEN PLUS -TACHES PLUS)
6TIME SAVING button (TIJD-TEMPS)
7Display
8START/PAUSE button (START/PAUZE-DEPART/PAUSE)
6Control panel

9DELAY START button (STARTUITSTEL-DEPART DIFFERE)
10 Indicator pilot lights
Table of Symbols
= Rinse hold
= Handwash
= Cold
= Child safety lock
Display (7)
7.1 7.2
7.3
7.4
7.5
7.1 Child safety lock symbol
7.2
•Duration of selected programme : after selecting a programme, the duration is dis
played in hours and minutes (for example 2.05). The duration is calculated automati
cally on the basis of the maximum recommended load for each type of fabric. After
the programme has started, the time remaining is updated every minute.
•Alarm codes : in the event of operating problems, some alarm codes can be displayed,
for example E20 (see chapter «What to do if...»).
•End of programme : when the programme has finished a blinking zero is dis
played, the symbol 7.5 (Door locked) disappears on the display, the pilot light of but
ton 8 goes out and the door can be opened.
•Incorrect option selection : if an option which is not compatible with the set wash
programme is selected, the message Err is displayed for a few seconds and the yellow
pilot light of button 8light starts blinking.
•Delay Start : the selected delay (20 hours max) set by the relevant button appears on
the display for a few seconds, then the duration of the previously selected programme
is displayed. The symbol 7.3 will appear on the display. The delay time value decreases
by one unit every hour. When only 1 hour remains, the time decreases every minute.
7.3 Delay Start - symbol
7.4 Programme progress display : the display shows the different washing pro
gramme phases. After the appliance starts operating, the display show the relevant sym
bol of the washing phase which is running: = WASHING, = RINSING, = DRAIN
ING, = SPINNING - symbols
7.5 Door lock symbol
This symbol indicates if the door can be opened:
7

• symbol on: the door cannot be opened. The appliance is running or the appliance has
stopped with water left in the tub.
• symbol off: the door can be opened. The washing programme is finished.
Indicator pilot lights (10)
If the OVERDOSAGE (OVERDOSERING SURDOS
AGE) pilot light 10.1 goes on at the end of the
programme, it indicates that too much deter
gent has been used.
When the appliance is performing additional rin
ses the EXTRA RINSE (EXTRA SPOELEN RINCAGE
PLUS) pilot light 10.2 illuminates. To add an ad
ditional rinse, please see chapter «Select an addi
tional rinse».
FIRST USE
• Ensure that the electrical and water connections comply with the installation instruc
tions.
• Remove the polystyrene block and any material from the drum.
• Before the first wash, run a cotton cycle at the highest temperature without any laun
dry in the machine, to remove any manufacturing residue from the drum and tub.
Pour 1/2 a measure of detergent into the main wash compartment and start the machine.
PERSONALIZATION
Acoustic signals
The machine is provided with an acoustic device, which sounds in the following cases:
• at the end of the cycle
• in the event of operating problems.
By pressing the 3and 4buttons simultaneously for about 6 seconds, the acoustic signal
is deactivated (except for the events of operating problems). By pressing these 2 buttons
again, the acoustic signal is reactivated.
Child safety lock
This device permits you to leave the appliance unattended and not to worry that children
might be injured by or cause damage to the appliance.
This function remains able also when the washing machine is not working.
There are two different ways to set this option:
•Before pressing button 8: it will be impossible to start the machine.
•after pressing button 8: it will be impossible to change any other programme or option.
To enable or disable this option press simultaneously for about 6 seconds buttons 4and
5until the symbol 7.1 appears or disappears on or from the display.
8

DAILY USE
Load the laundry
1. Open the door by carefully pulling the
door handle outwards. Place the laundry
in the drum, one item at a time, shaking
them out as much as possible.
2. Close firmly the door. You must hear a
click during closing.
WARNING!
Do not embed the laundry between the door
and the rubber joint.
Measure out the detergent and the fabric softener
Your new appliance was designed to reduce water, energy and detergent consumption.
1. Pull out the dispenser drawer until it
stops. Measure out the amount of deter
gent required, pour it into the main
wash compartment and, if you wish
to carry out the prewash phase, pour
the detergent into the compartment
marked .
If you wish to perform the stain func
tion, pour the stain remover into the com
partment marked with an arrow.
Daily use 9

2. If required, pour fabric softener into the
compartment marked (the amount
used must not exceed the MAX mark in
the drawer).
Close the drawer gently.
Select the required programme by means of programme selector dial (1)
You can choose the right programme for any type of laundry following the descriptions
on the washing programme tables (see «Washing Programmes»).
Turn the programme selector dial to the required programme. The programme selector
determines the type of washing cycle (e.g. water level, drum movement, number of rin
ses) and the washing temperature according to the type of laundry.
The pilot light of button 8starts blinking.
The selector dial can be turned either clockwise or anticlockwise. On position the pro
gramme is reset and the machine is switched off.
At the end of the programme the selector dial must be turned to position , to
switch the machine off.
If you turn the programme selector dial to another programme when the machine is work
ing, the yellow pilot light of button 8will blink 3 times and the message Err is displayed
on the display to indicate a wrong selection. The machine will not perform the new selec
ted programme.
Select the desired TEMPERATURE (Button 2)
When selecting a programme, the appliance automatically proposes the default tempera
ture provided for that programme.
Press this button repeatedly to increase or decrease the temperature, if you want your
laundry to be washed at a temperature different from the one proposed by the washing
machine.
By selecting position (Cold) the machine will wash with cold water. To be used for
extremely delicate items, such as curtains.
For the maximum and the minimum available wash water temperature, see «Washing pro
grammes».
10 Daily use

Select the spin speed (SPIN Reduction) or the RINSE HOLD option (Button 3)
When the required programme has been selected, your appliance automatically proposes
the maximum spin speed provided for that programme.
Press this button repeatedly to change the spin speed, if you want your laundry to be
spun at a speed different from the one proposed by the washing machine. The relevant
light will light up.
RINSE HOLD : by selecting this option the water of the last rinse is not emptied out to
prevent the fabrics from creasing. When the programme has finished the display shows a
blinking , the symbol 7.5 appears on the display and the pilot light of button 8is off.
The door is locked to indicate that the water must be emptied out.
To empty the water out please read chapter «At the end of the programme».
Programme option buttons
Depending on the programme, different functions can be combined. These must be selec
ted after choosing the desired programme and before pressing the button 8.
When these buttons are pressed, the corresponding pilot lights come on. When they are
pressed again, the pilot lights go out.
If an incorrect option is selected, the in yellow pilot light of the button 8blinks for 3
times and the Err message appears on the display for some seconds.
For the compatibility among the washing programmes and the options see chapter «Wash
ing Programmes».
Select the PREWASH option (Button 4)
Select this option if you wish your laundry to be prewashed at 30°C before the main
wash. The Prewash ends with a short spin in programmes for cotton and synthetic fab
rics, whereas in the programmes for delicate fabrics the water is only drained.
The relevant light will light up.
Select the STAIN option (Button 5)
Select this option to treat heavily soiled or stained laundry with stain remover (extended
main wash with time optimized stain action phase). The relevant light will light up.
This option is not available with a temperature lower than 40°C.
If you wish to perform a programme with the stain option, pour stain remover into stain
compartment marked with an arrow.
Select the TIME SAVING option (Button 6)
This option allows you to modify the washing time, automatically proposed by the appli
ance.
DAILY : by pressing button 6once , the relative pilot light comes on and the washing
duration will be reduced to wash daily soiled laundry.
SUPER QUICK : by pressing button 6twice the relative pilot light remains lit, the wash
ing duration will be reduced to wash lightly soiled laundry or items that have been used
or worn for a short time. On the display will be visualized the decreased washing time.
Daily use 11

Select an additional rinse (EXTRA RINSE)
This appliance is designed for saving water. However, for people with a very delicate skin
(allergic to detergents) it may be necessary to rinse the laundry using an extra quantity
of water.
Press simultaneously buttons 2and 3for some seconds: the pilot light 10.2 comes on.
This function stays permanently on. To remove it press the same buttons again until the
pilot light 10.2 goes off.
Select the START/PAUSE (Button 8)
To start the selected programme, press the button 8, the corresponding red pilot light
stops blinking.
The symbols 7.4 and 7.5 appear on the display to indicate that the appliance starts oper
ating and that the door is locked.
To interrupt a programme which is running, press the button 8: the corresponding red
pilot light starts blinking.
To restart the programme from the point at which it was interrupted, press the button 8
again. If you have chosen a delayed start with button 9, the machine will begin the count
down. If an incorrect option is selected, the yellow pilot light of the button 8blinks for 3
times the message Err is displayed for about a few seconds.
Select the DELAY START (Button 9)
Before you start the programme , if you wish to delay the start, press the button re
peatedly, to select the desired delay.
The selected delay time value (up to 20 hours) will appear on the display for a few sec
onds, then the duration of the programme will appear again.
You must select this option after you have set the programme and before you press the
button 8.
The wash programme can be delayed from 30 min - 60 min - 90 min, 2 hours and then
by 1 hour up to a maximum of 20 hours by means of this button.
The door will be locked throughout the delay time. If you wish to add laundry in the ma
chine during the delay time you will press button 8to put the machine in pause. Add the
laundry, close the door and press button 8again.
Selecting the delayed start.
• Select the programme and the required options.
• Select the delay start.
•Press button 8: the appliance starts its hourly countdown. The programme will start
after the selected delay has expired.
Cancelling the delayed start
•Set the washing machine to PAUSE by pressing the button 8;
•Press button 9once until the symbol ’ is displayed;
•Press the button 8again to start the programme.
The selected delay can be changed only after selecting the washing programme again.
The Delay Start can not be selected with the draining programme.
12 Daily use

Altering an option or a running programme
It is possible to change some options before the programme carries them out. Before you
make any change, you must pause the washing machine by pressing the button 8.
Changing a running programme is possible only by resetting it . Turn the programme
selector dial to and then to the new programme position. Start the new programme
by pressing the 8button again. The washing water in the tub will not emptied out.
Interrupting a programme
Press the button 8to interrupt a programme which is running, the corresponding light
starts blinking. Press the button again to restart the programme.
Cancelling a programme
Turn the selector dial to to cancel a programme which is running. Now you can select
a new programme.
Opening the door after the programme has started
When the machine is working and through the delay time, the door is locked. If, for any
reason, it is necessary to open it, set firstly the machine to pause by pressing the button
8. If the symbol 7.5 goes off, the door can be opened.
If the symbol 7.5 stays on and the door remains locked, this means that the machine is
already heating or that the water level is too high. In this case the door can not be
opened. If you cannot open the door but you need to open it you have to switch the
machine off by turning the selector dial to . After a few minutes the door can be
opened (pay attention to the water level and temperature !) .
After closing the door, it is necessary to select the programme and options again and to
press button 8 .
At the end of the programme
The machine stops automatically, the pilot light of button 8and the symbol 7.5 go off. A
blinking will appear on the display. Some acoustic signals sound. The door can be opened.
If a programme or an option that ends with water left in the tub has been selected, a
blinking will appear on the display, the pilot light of button 8goes off and the door
remains locked to indicate that the water must be emptied out before opening the door.
Follow the below instructions to empty out the water:
• Turn the programme selector dial to
• Select the draining or spinning programme
• Reduce the spin speed, if needed, by pressing the relevant button
•Press button 8 to start the programme
• When the programme has finished the display shows a blinking . When the symbol
7.5 goes off, the door can be opened.
Turn the programme selector dial to to switch the machine off. Remove the laundry
from the drum and carefully check that the drum is empty. If you do not intend to carry
out another wash, close the water tap. Leave the door open to prevent the formation of
mildew and unpleasant smells.
Stand by : once the programme has finished after a few minutes the energy saving sys
tem will be enabled. The brightness of the display is reduced. By pressing any button the
appliance will come out of the energy saving status.
13

HELPFUL HINTS AND TIPS
Sorting out the laundry
Follow the wash code symbols on each garment label and the manufacturer’s washing
instructions. Sort the laundry as follows: whites, coloureds, synthetics, delicates, woollens.
Before loading the laundry
Never wash whites and coloureds together. Whites may lose their «whiteness» in the wash.
New coloured items may run in the first wash; they should therefore be washed separate
ly the first time.
Button up pillowcases, close zip fasteners, hooks and poppers. Tie any belts or long tapes.
Remove persistent stains before washing.
Rub particularly soiled areas with a special detergent or detergent paste.
Treat curtains with special care. Remove hooks or tie them up in a bag or net.
Removing stains
Stubborn stains may not be removed by just water and detergent. It is therefore advisa
ble to treat them prior to washing.
Blood: treat fresh stains with cold water. For dried stains, soak overnight in water with a
special detergent then rub in the soap and water.
Oil based paint: moisten with benzine stain remover, lay the garment on a soft cloth
and dab the stain; treat several times.
Dried grease stains: moisten with turpentine, lay the garment on a soft surface and
dab the stain with the fingertips and a cotton cloth.
Rust: oxalic acid dissolved in hot water or a rust removing product used cold. Be careful
with rust stains which are not recent since the cellulose structure will already have been
damaged and the fabric tends to hole.
Mould stains: treat with bleach, rinse well (whites and fast coloureds only).
Grass: soap lightly and treat with bleach (whites and fast coloureds only).
Ball point pen and glue: moisten with acetone
1)
, lay the garment on a soft cloth and
dab the stain.
Lipstick: moisten with acetone as above, then treat stains with methylated spirits. Treat
any residual marks with bleach.
Red wine: soak in water and detergent, rinse and treat with acetic or citric acid, then
rinse. Treat any residual marks with bleach.
Ink: depending on the type of ink, moisten the fabric first with acetone
1)
, then with ace
tic acid; treat any residual marks on white fabrics with bleach and then rinse thoroughly.
Tar stains: first treat with stain remover, methylated spirits or benzine, then rub with
detergent paste.
Detergents and additives
Good washing results also depend on the choice of detergent and use of the correct quan
tities to avoid waste and protect the environment.
Although biodegradable, detergents contain substances which, in large quantities, can up
set the delicate balance of nature.
1) do not use acetone on artificial silk
14 Helpful hints and tips

The choice of detergent will depend on the type of fabric (delicates, woollens, cottons,
etc.), the colour, washing temperature and degree of soiling.
All commonly available washing machine detergents may be used in this appliance:
• powder detergents for all types of fabric
• powder detergents for delicate fabrics (60°C max) and woollens
• liquid detergents, preferably for low temperature wash programmes (60°C max) for all
types of fabric, or special for woollens only.
The detergent and any additives must be placed in the appropriate compartments of the
dispenser drawer before starting the wash programme.
If using liquid detergents, a programme without prewash must be selected.
Your appliance incorporates a recirculation system which allows an optimal use of the
concentrated detergent.
Follow the product manufacturer’s recommendations on quantities to use and do not
exceed the «MAX» mark in the detergent dispenser drawer .
Quantity of detergent to be used
The type and quantity of detergent will depend on the type of fabric, load size, degree of
soiling and hardness of the water used.
Follow the product manufacturers’ instructions on quantities to use.
Use less detergent if:
• you are washing a small load
• the laundry is lightly soiled
• large amounts of foam form during washing.
Degrees of water hardness
Water hardness is classified in so-called “degrees” of hardness. Information on hardness
of the water in your area can be obtained from the relevant water supply company, or
from your local authority. If the water hardness degree is medium or high we suggest
you to add a water softener following always the manufacturer’s instructions. When the
degree of hardness is soft, readjust the quantity of the detergent.
WASHING PROGRAMMES
Programme - Maximum and Minimum Temperature
- Cycle Description - Maximum Fabrics Load - Type
of Laundry
Options
Detergent
Compart
ment
COTTON
(KATOEN/BLANC COULEURS)
95° - Cold
Main wash - Rinses - Long spin at the maximum
spin speed
Max. load 7 kg - Reduced load 3,5 kg
1)
White and coloured cotton (normally soiled items).
SPIN REDUCTION
RINSE HOLD
PREWASH
2)
STAIN
3)
EXTRA RINSE
TIME SAVING
1)
Washing programmes 15

Programme - Maximum and Minimum Temperature
- Cycle Description - Maximum Fabrics Load - Type
of Laundry
Options
Detergent
Compart
ment
SANITIZE
(HYGIËNE/HYGIENE)
60°
Main wash - Rinses - Long spin at the maximum
spin speed
Max. load 7 kg
The washing programme for white cottons. This pro
gram eliminates the micro-organisms thanks to the
washing by 60°C and an additional rinse. In this way
the action is more effective. Put into the compart
ment Stain a special additive for hygiene and select
the option Stain.
SPIN REDUCTION
RINSE HOLD
PREWASH
2)
STAIN
40 60 MIX
40°
Main wash - Rinses - Long spin at the maximum
spin speed
Max. load 7 kg
White and coloured cotton This programme can
be used for laundry, which should be washed at
40°C or 60°C separately. The maximum load capaci
ty can be put into the drum in order to save energy
and water. The same good washing result will be ob
tained as for normal programme at 60°C.
SPIN REDUCTION
RINSE HOLD
PREWASH
2)
STAIN
EXTRA RINSE
JEANS
60° - Cold
Main wash - Rinses - Long spin at 1200 rpm
Max. load 3,5 kg
With this programme it is possible to wash items
like pants, shirts or jackets in Jeans and also jersey
realized with hi-tech materials. (The Extra Rinse op
tion will be activated automatically).
SPIN REDUCTION
RINSE HOLD
PREWASH
2)
SYNTHETICS
(SYNTHETISCH/SYNTHETIQUE)
60° - Cold
Main wash - Rinses - Short spin at 1200 rpm
Max. load 3,5 kg - Reduced load 2 kg
Synthetic or mixed fabrics: underwear, coloured
garments, non-shrink shirts, blouses.
SPIN REDUCTION
RINSE HOLD
PREWASH
2)
STAIN
EXTRA RINSE
TIME SAVING
1)
16 Washing programmes

Programme - Maximum and Minimum Temperature
- Cycle Description - Maximum Fabrics Load - Type
of Laundry
Options
Detergent
Compart
ment
EASY IRON
(STRIJKVRIJ PLUS/REPASSAGE FACILE PLUS)
60° - Cold
Main wash - Rinses - Short spin at 1200 rpm
Max. load 1,5 kg
Synthetic fabrics to be gentle washed and spun.
Selecting this programme the laundry is gently wash
ed and spun to avoid any creasing. In this way iron
ing is easier. Furthermore the machine will perform
additional rinses.
SPIN REDUCTION
RINSE HOLD
PREWASH
2)
EXTRA RINSE
DELICATES
(FIJNE WAS/DELICATS)
40° - Cold
Main wash - Rinses - Short spin at 1200 rpm
Max. load kg 3,5 - Reduced load kg 2
Delicate fabrics: acrylics, viscose, polyester.
SPIN REDUCTION
RINSE HOLD
PREWASH
2)
STAIN
EXTRA RINSE
TIME SAVING
1)
VISCOSE
40° - Cold
Main wash - Rinses - Short spin at 1200 rpm
Max. load kg 3,5
Special gentle programme for fabrics such a viscose,
cupro, lyocell. It performs an cleaning action more
intensive than the handwash programme.
SPIN REDUCTION
RINSE HOLD
PREWASH
2)
STAIN
EXTRA RINSE
DELICATE RINSES
(KORT SPOELEN/RINÇAGES DELICATS)
Rinses - Short spin at 1200 rpm
Max. load 7 kg
With this programme it is possible to rinse and spin
cotton garments which have been washed by hand.
The machine performs some rinses, followed by a fi
nal spin.
SPIN REDUCTION
RINSE HOLD
EXTRA RINSE
DRAIN
(POMPEN/VIDANGE)
Draining of water
Max. load 7 kg
For emptying out the water of the last rinse in pro
grammes with the option selected, which ends with
water left in the tub.
Washing programmes 17

Programme - Maximum and Minimum Temperature
- Cycle Description - Maximum Fabrics Load - Type
of Laundry
Options
Detergent
Compart
ment
SPIN
(CENTRIFUGEREN/ESSORAGE)
Drain and long spin at the maximum spin speed
Max. load 7 kg
Separate spin for hand washed cotton garments
and after programmes with the option selected
which ends with water left in the tub. Before select
ing this programme the selector dial must be turned
to . You can choose the spin speed by pressing
the relevant button to adapt it to the fabrics to be
spun.
SPIN REDUCTION
BLANKET
(DECKENS/COUETTE)
40° - 30°
Main wash - Rinses - Short spin at 800 rpm
Max. load 2 kg
Special programme for a single synthetic blanket, du
vet, bedspread and so on.
SPIN REDUCTION
WOOL PLUS
(WOL PLUS/LAINE PLUS)
= HANDWASH
40° - Cold
Main wash - Rinses - Short spin at 1200 rpm
Max. load 2 kg
Washing programme for machine washable wool as
well as for hand washable woollens and delicate fab
rics.
Note : A single or bulky item may cause imbalance.
If the appliance doesn’t perform the final spin
phase, add more items, redistribute the load manual
ly and then select the spinning programme.
SPIN REDUCTION
RINSE HOLD
LINGERIE
= HANDWASH
40° - Cold
Main wash - Rinses - Short spin at 1200 rpm
Max. load 1 kg
This programme is suitable for very delicate items,
as lingerie, bras and underwear etc.
SPIN REDUCTION
RINSE HOLD
SPORT JACKETS
(SPORTKLEDING/BLOUSONS)
40° - Cold
Main wash - Rinses - Short spin at 800 rpm
Max. load 3 kg
Special programme for sport clothes. By selecting
this programme, we recommend that you not add
any additives.
SPIN REDUCTION
RINSE HOLD
EXTRA RINSE
18 Washing programmes

Programme - Maximum and Minimum Temperature
- Cycle Description - Maximum Fabrics Load - Type
of Laundry
Options
Detergent
Compart
ment
SPORT INTENSIVE
(OUTDOOR/SPORT)
40° - Cold
Prewash - Main wash - Rinses - Short spin at 1200
rpm
Max. load 3 kg
Special programme is suitable for washing heavily
soiled sport items. The machine will add automati
cally a prewash phase before the main wash to elim
inate mud stains. For this phase we recommend
that you NOT put the detergent into the com
partment of the detergent drawer in order to wash
the items with water only.
SPIN REDUCTION
RINSE HOLD
EXTRA RINSE
20 MIN. 3 KG
30°
Main wash - Rinses - Short spin at 1200 rpm
Max. load 3 kg
This programme may be used for a quick washing of
sport items or cotton and synthetic items , lightly
soiled or worn once.
SPIN REDUCTION
QUICK INTENSIVE
(KORT INTENSIEF/INTENSIF)
60° - 40°
Main wash - Rinses - Short spin at 1200 rpm
Max. load 5 kg
Quick washing programme, to be used for lightly
soiled white/fast coloured cottons and mixed fabrics.
SPIN REDUCTION
RINSE HOLD
EXTRA RINSE
SUPER ECO
Cold
Main wash - Rinses - Short spin at 1200 rpm
Max. load 3 kg
Mixed fabrics (cotton and synthetic) . Cold wash
programme designed for saving energy, water and
time. This programme is suitable with detergents
that becomes effective at low temperature. The de
tergent must be used with the supplied or a suitable
detergent dosing cap (use the amount of the deter
gent recommended by detergent's manufacturer).
The appliance automatically runs a short heating
phase if the water temperature is lower than 6°C only.
SPIN REDUCTION
RINSE HOLD
EXTRA RINSE
Washing programmes 19

Programme - Maximum and Minimum Temperature
- Cycle Description - Maximum Fabrics Load - Type
of Laundry
Options
Detergent
Compart
ment
COTTON ECONOMY
(ECO/ECONOMIQUE)
60°
Main wash - Rinses - Long spin at the maximum
spin speed
Max. load 7 kg
White and fast coloured cotton .
This programme can be selected for slightly or nor
mally soiled cotton items. The temperature will de
crease and the washing time will be extended. This
allows to obtain a good washing efficiency so sav
ing energy.
SPIN REDUCTION
RINSE HOLD
PREWASH
2)
STAIN
EXTRA RINSE
= OFF
For cancelling the programme which is running or
to switch the machine off .
1) If you select the Super Quick option by pressing button 6, we recommend that you reduce the maximum
load as indicated. Full loading is possible however with somewhat reduced cleaning results.
2) If using liquid detergents, a programme without prewash must be selected.
3) Stain option can be selected only at the temperature of 40°C or higher.
CARE AND CLEANING
You must DISCONNECT the appliance from the electricity supply, before you can carry
out any cleaning or maintenance work.
Descaling
The water we use normally contains lime. It is a good idea to periodically use a water
softening powder in the machine. Do this separately from any laundry washing, and ac
cording to the softening powder manufacturer's instructions. This will help to prevent
the formation of lime deposits.
After each wash
Leave the door open for a while. This helps to prevent mould and stagnant smells form
ing inside the appliance. Keeping the door open after a wash will also help to preserve
the door seal.
Maintenance wash
With the use of low temperature washes it is possible to get a build up of residues inside
the drum.
We recommend that a maintenance wash be performed on a regular basis.
To run a maintenance wash:
• The drum should be empty of laundry.
• Select the hottest cotton wash programme.
• Use a normal measure of detergent, must be a powder with biological properties.
20 Care and cleaning
