1 Safety Precautions
• Servicing shall be carried out only by authorized personnel.
• Only authorized spare parts, accessories and consumables shall be used.
• Only use detergent intended for water-wash of textiles. Never use dry cleaning agents.
• The machine shall be connected with new water hoses. Re-used water hoses must not
be used.
• The machine's door lock must under no circumstances be bypassed.
• If the machine develops a fault, this must be reported to the person in charge as soon
as possible. This is important both for your safety and that of others.
• DO NOT MODIFY THIS APPLIANCE.
• When performing service or replacing parts, the power must be disconnected.
• When the power is disconnected, the operator must see that the machine is discon-
nected (that the plug is removed and remains removed) from any point to which he has
access. If this is not possible, due to the construction or installation of the machine, a
disconnection with a locking system in the isolated position shall be provided.
• In accordance with the wiring rules: mount a multi-pole switch prior to the machine to
facilitate installation and service operations.
• If different rated voltages or different rated frequencies (separated by a /) are stated at
the machine data plate, instructions for adjusting the appliance for operation at the re-
quired rated voltage or rated frequency are stated in the installation manual.
• Stationary appliances not fitted with means for disconnection from the supply mains
having a contact separation in all poles that provide full disconnection under overvolt-
age category III, the instructions state that means for disconnection must be incorpo-
rated in the fixed wiring in accordance with the wiring rules.
• The openings in the base, shall not be obstructed by a carpet.
• Maximum mass of dry cloth: 9 kg.
• A-weighted emission sound pressure level at working stations:
– Wash: <70 dB(A).
– Extraction: <70 dB(A).
• Maximum inlet water pressure: 1000 kPa
• Minimum inlet water pressure: 50 kPa
• Additional requirements for the following countries; AT, BE, BG, HR, CY, CZ, DK, EE,
FI, FR, DE, GR, HU, IS, IE, IT, LV, LT, LU, MT, NL, NO, PL, PT, RO, SK, SI, ES, SE, CH,
TR, UK:
– The appliance can be used in public areas.
– This appliance can be used by children aged from 8 years and above and persons
with reduced physical, sensory or mental capabilities or lack of experience and knowl-
edge if they have been given supervision or instruction concerning use of the appliance
in a safe way and understand the hazards involved. Children shall not play with the ap-
pliance. Cleaning and user maintenance shall not be made by children without
supervision.
• Additional requirements for other countries:
– This appliance is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction concerning use of the appliance by a

6Installation manual
person responsible for their safety. Children should be supervised to ensure that they
do not play with the appliance.
– This appliance is intended to be used in household and similar applications such as:
(IEC 60335-2-7) staff kitchen areas in shops, offices and other working environments,
farm houses, by clients in hotels, motels and other residential type environments, bed
and breakfast type environments, areas for communal use in blocks of flats or in
launderettes.
1.1 General safety information
The machine is only intended for water-wash use.
Do not hose down the machine with water.
In order to prevent damage to the electronics (and other parts) that may occur as the result of condensation, the ma-
chine should be placed in room temperature for 24 hours before being used for the first time.
1.2 Commercial use only
The machine/machines covered by this manual is/are made for commercial and industrial use only.
1.3 Symbols
Caution
Caution, high voltage
Read the instructions before using the machine

Installation manual 7
2 Warranty terms and exclusions
If the purchase of this product includes warranty coverage, warranty is provided in line with local regulations and sub-
ject to the product being installed and used for the purposes as designed, and as described within the appropriate
equipment documentation.
Warranty will be applicable where the customer has used only genuine spare parts and has performed maintenance
in accordance with Electrolux Professional user and maintenance documentation made available in paper or elec-
tronic format.
Electrolux Professional strongly recommends using Electrolux Professional approved cleaning, rinse and descaling
agents to obtain optimal results and maintain product efficiency over time.
The Electrolux Professional warranty does not cover:
• service trips cost to deliver and pick up the product;
• installation;
• training on how to use/operate;
• replacement (and/or supply) of wear and tear parts unless resulting from defects in materials or workmanship re-
ported within one (1) week from the failure;
• correction of external wiring;
• correction of unauthorized repairs as well as any damages, failures and inefficiencies caused by and/or resulting
from;
– insufficient and/or abnormal capacity of the electrical systems (current/voltage/frequency, including spikes and/
or outages);
– inadequate or interrupted water supply, steam, air, gas (including impurities and/or other that does not comply
with the technical requirements for each appliance);
– plumbing parts, components or consumable cleaning products that are not approved by the manufacturer;
– customer’s negligence, misuse, abuse and/or non-compliance with the use and care instructions detailed within
the appropriate equipment documentation;
– improper or poor: installation, repair, maintenance (including tampering, modifications and repairs carried out
by third parties not authorized third parties) and modification of safety systems;
– Use of non-original components (e.g.: consumables, wear and tear, or spare parts);
– environment conditions provoking thermal (e.g. overheating/freezing) or chemical (e.g. corrosion/oxidation)
stress;
– foreign objects placed in- or connected to- the product;
– accidents or force majeure;
– transportation and handling, including scratches, dents, chips, and/or other damage to the finish of the product,
unless such damage results from defects in materials or workmanship and is reported within one (1) week of deliv-
ery unless otherwise agreed;
• product with original serial numbers that have been removed, altered or cannot be readily determined;
• replacement of light bulbs, filters or any consumable parts;
• any accessories and software not approved or specified by Electrolux Professional.
Warranty does not include scheduled maintenance activities (including the parts required for it) or the supply of
cleaning agents unless specifically covered within any local agreement, subject to local terms and conditions.
Check on Electrolux Professional website the list of authorized customer care.

8Installation manual
3 Technical data
3.1 Drawing
A
1
2
C
3
B
E
G
I
J
F
H
L
K
N
MO
8
9
5
10
4
6
7
D2
D1
fig.7792
1 Operating panel
2 Door opening, ⌀310 mm
3 Detergent container
4 Cold water
5 Hot water
6 Liquid detergent supply
7 Drain valve
8 Electrical connection
9 Steam connection
10 Re-used water
mm A B C D1 D2 E F G
720 1130 1113 352 406 721 831 80
mm H I J K L M N O
1030 224 124 1010 910 278 98 239

Installation manual 9
3.2 Technical data
Weight, net kg 135
Drum volume litres 75
Drum diameter mm 520
Drum speed during wash rpm 52
Drum speed during extraction rpm 1015
G-factor, max. 300
Heating: Electricity kW 5.4
Heating: Hot water x
Frequency of the dynamic force Hz 16.9
Floor load at max extraction kN 1.4 ± 0.5
Sound power/pressure level at extraction* dB(A) 75/61
Sound power/pressure level at wash* dB(A) 60/46
Heat emission of installed power, max % 5
* Sound power levels measured according to ISO 60704.
3.3 Connections
Water valves DN
BSP
20
3/4”
Recommended water pressure kPa 150–400
Continuous operating pressure kPa 50–800
Capacity at 300 kPa l/min 16
Drain valve ⌀outer mm 50/75
Draining capacity
Electrical drain
Pump drain
l/min
160
30
4 Setup
4.1 Unpacking
Remove the front and rear panel.
Remove the four transport supports. Save the transport supports if the machine needs to be moved in the future.
Note!
Once the transport supports have been removed, handle the machine carefully to avoid damage to the sus-
pension components.
fig.7788

10 Installation manual
Remove the bolts between the machine and pallet. There is one to the right in the front of the machine and another
diagonally opposed to it, at the back of the machine.
fig.7651
Remove the machine from the pallet.
Note!
When moving the machine, handle it with care. Make sure that the machine does not come down on the floor
with either of the rear corners first. The side panel of the machine can be damaged.
Place the machine on its final position.
Mount the supporting feet.
fig.7189B
Remount the panels.

Installation manual 11
4.2 Recycling instruction for packaging
45
6
7
3
1
2
fig.X02395
Fig. Description Code Type
1 Wrapping film LDPE 4 Plastics
2 Corner protection PS 6 Plastics
3 Cardboard packaging PAP 20 Paper
4 Pallet FOR 50 Wood
5Screw FE 40 Steel
6 Nut FE 40 Steel
7 Plastic bag PET 1 Plastics

12 Installation manual
4.3 Siting
Install the machine close to a floor drain or open drain.
The machine should be positioned so that there is plenty of room for working, both for the user and service personnel.
The figure shows minimum distance to a wall and/or other machines.
500 mm /
20 inch
25 mm /
1 inch
25 mm /
1 inch
fig.W00176D
4.4 Mechanical installation
If the machine is not to be mounted on a base the machine must be fastened to the floor.
The table shows the correct drilling points.
Mark and drill two holes (⌀8 mm) about 40 mm deep in the positions shown.
C A
D
G
FE
B
H
FRONT = drilling points
= position of feet
fig.5358
mm A B C D E F G H
495 460 110 130 375 170 40 100

Installation manual 13
Place the machine over the two drilled holes. The holes are at the front of the machine.
Level the machine with the feet of the machine. Screw in the feet as much as possible before starting to level the ma-
chine. This will make the machine stand steadier.
Insert the expansion bolts supplied into the holes drilled in the floor. Fit the washers and nuts and tighten well.
It is of the upmost importance that the machine is placed in level, from side to side as well as front to rear.
5 Water connection
All water intake connections to the machine should be fitted with manual shut-off valves and filters, to facilitate instal-
lation and servicing.
Water pipes and hoses should be flushed clean before installation.
The machine shall be connected with new water hoses. Re-used water hoses must not be used.
Hoses are to be of an approved type and grade and comply with IEC 61770.
After installation hoses must hang in gentle arcs.
All connectors present on the machine must be connected. The table shows the possible connection options, which
will depend on the water types to be connected to the machine. Information is also available on the panel above the
connections.
Water type Water connection
1
2
• Cold and hot 1. Cold
2. Hot
Water pressure:
Continuous operating pressure: 50–800 kPa (0.5-80 kp/cm2)
Maximum: 1000 kPa (10 kp/cm2)
Recommended: 200–600 kPa (2–6 kp/cm2)
Note!
If the water pressure is below the minimum value, the wash result can not be guaranteed for certain program.
For WRAS-approved machines; always check connection requirements on WRAS website.
For KIWA-approved machines; always check connection requirements on KIWA website.
For NSF-approved machines; always check connection requirements on NSF website.
Plumbing
This machine is approved for all UK applications as suitable for category 5.
The product is listed in the WRAS regulations advisory scheme directory and is suitable for direct connection to
mains drinking water. No special plumbing arrangements e.g. break tanks are required.
Water Council approved double check valves should be fitted in between the stopcocks and the water inlet hoses.
FOR AUSTRALIA:
The appliance shall be installed in accordance with AS / NZS 3500.1
The appliance need to be installed using dual check valves.
Contact details for after sales service: [email protected]

14 Installation manual
6 Drain connection
Drain valve
Connect a 75 mm (alt. 50 mm) pipe or rubber hose to the machine’s drain pipe, ensuring a downward flow from the
machine. Avoid sharp bends which may prevent proper draining.
The drainage pipe should be located over a floor drain, drainage channel or the like so that the distance between the
outlet and the drain is at least 25 mm.
fig.5330
Drain pump
The drainage pipe should be located over a floor drain, drainage channel or the like.
The highest part of the drain hose shall be positioned according to the figure.
Make sure there is no kinks in the hose.
700 mm ± 50 mm /
27 9/16 inch ±
1 15/16 inch
fig.6318B

Installation manual 15
7 Electrical connection
7.1 Electrical installation
The electrical installation may only be carried out by qualified personnel.
Machines with frequency-controlled motors can be incompatible with certain types of earth leakage circuit break-
er. It is important to know that the machines are designed to provide a high level of personal safety, which is why
items of external equipment such as earth leakage circuit breakers are not necessary but is recommended. If you
still want to connect your machine across an earth leakage circuit breaker, please remember the following:
• contact a skilled, authorised installation company to ensure that the appropriate type of breaker is chosen and
that the dimensioning is correct
• for maximum reliability, connect only one machine per earth leakage circuit breaker
• it is important that the earth wire is properly connected.
In accordance with the wiring rules: mount a multi-pole switch prior to the machine to facilitate installation and service
operations.
The connecting cable shall hang in a gentle curve.
7.2 Electrical connections
Heating alternative Main voltage Hz Heating power
kW
Total power
kW
Recommended fuse
A
Electric heated 220-240V 1 ~ 50/60 5.4/7.5 5.5/7.6 25/35
220-240V 1 ~ 50/60 2.0/3.0 2.1/3.1 10/16
220-240V 3 ~ 50/60 5.4/7.5 5.5/7.6 16/20
220-240V 3 ~ 50/60 3.0/4.3 3.1/4.5 10/16
380-415V 3N ~ 50/60 5.4/7.5 5.5/7.6 10/16
380-415V 3N ~ 50/60 3.0/4.3 3.1/4.5 10
440V 3 ~ 60 7.5 7.6 16
480V 3 ~ 60 7.5 7.6 10
Non heated/Steam
heated
220-480V 1 ~ 50/60 -1.0 10

16 Installation manual
7.3 Machine connection
Connect the earth and other two wires as shown.
Single-phase connection Three-phase connection
1NAC
Electrical heated
N T1 T2 T3
3AC
N T1 T2 T3
1AC
Electrical heated
N T1 T2 T3
3N AC
N T1 T2 T3
1AC
Non heated

Installation manual 17
7.4 Converting heating elements
7.4.1 The machine can be converted from 380–415V 3AC to 220-240V 3AC
Disconnect the power to the machine.
Demount the front panel and remove the cover to the heating elements.
Remove the blue cables.
Move cables 357/BN, 356/BK and 358/GY from the red to the white terminals on each element.
Remount the cover to the heating elements and remount the cover panel.
400V/3~ 230V/3~
E1 E2 E3
355/BN
357/BN 354/BK 356/BK 353/GY 358/GY
E1 E2 E3
355/BN
357/BN 354/BK 356/BK 353/GY 358/GY
fig.7909
Demount the cover panel to the contactors.
Machines with one contactor:
• Reconnect K21 according to the figure.
355/BN
358/GY
354/BK
357/BN
353/GY
356/BK
K21
L1
L2
L3
355/BN
357/BN
354/BK
356/BK
353/GY
400V/3~ 230V/3~
358/GY
K21
L1
L2
L3
fig.7907
Machines with two contactors:
• K21 does not need to be reconnected.
• Reconnect K22 according to the figure.
K22
L1
L2
L3
357/BN
356/BK
400V/3~ 230V/3~
358/GY
358/GY
357/BN
356/BK
K22
L1
L2
L3
fig.7908
Remount the cover panel to the contactors.
Connect the power to the machine.
Check that all terminals and wires are secure and test run the machine on a short program with 60°C to ensure that it
does heat up.

18 Installation manual
7.4.2 The machine can be converted from 400–415V 3AC to 230-240V 1AC with reduced
power
Disconnect the power to the machine.
Demount the front panel and remove the cover to the heating elements.
Remove the blue cables.
Move cables 357/BN on E1 and 358/GY on E3 from the red to the white terminals on each element.
Remount the cover to the heating elements and remount the cover panel.
400V/3~ 230V/1~
E1 E2 E3
355/BN
357/BN 354/BK 356/BK 353/GY 358/GY
E1 E2 E3
355/BN
357/BN 354/BK 356/BK 353/GY 358/GY
fig.8023
Demount the cover panel to the contactors.
• Reconnect K21 by switching position of 357/BN and 358/GY.
• At the main switch, reconnect L3 to N.
355/BN
358/GY
354/BK
357/BN
353/GY
356/BK
K21
L1
L3 => N
355/BN
357/BN
354/BK
356/BK
353/GY
400V/3~ 230V/1~
358/GY
K21
L1
L2
L3
fig.8024
Remount the cover panel to the contactors.
Connect the power to the machine.
Check that all terminals and wires are secure and test run the machine on a short program with 60°C to ensure that it
does heat up.

Installation manual 19
8 At first power up
When the installation is complete and the power is connected for the first time you will be forced to make the following
settings. When one setting is ready you will automatically enter the next one.
• Select language
• Set time and date
• Activate/deactivate the service alarm
For more information about the following settings please refer to the Programming and configuration manual.
8.1 Select language
Select language from the list on the display.
This will be the language that all display messages, program names etc will be presented in.
8.2 Set time and date
Select YES and press the control knob to get to the menu TIME/DATE.
Activate the SET TIME menu and set the correct time.
Save the settings.
Activate the SET DATE menu and set the correct date. Start by setting the year.
• Set the year. Exit to continue with a long press on the control knob.
• Set the month. Exit to continue with a long press on the control knob.
• Set the day. Exit with a long press on the control knob and then save with a long press on the control knob.
Exit the menu when ready.
9 Function check
May only be carried out by qualified personnel.
A function check must be made when the installation is finished and before the machine can be ready to be used.
Open the manual water valves.
Start a program.
• Check that the drum rotates normally and that there are no unusual noises.
• Check that there are no leaks in water supply/drain connections.
• Check that water passes through the detergent container.
• Check that the door cannot be opened during a program.
Ready to use
If all tests are OK the machine is now ready to be used.
If some of the tests failed, or deficiencies or errors are detected, please contact your local service organisation or
dealer.

20 Installation manual
10Disposal information
10.1 Disposal of appliance at end of life
Before disposing of the machine, make sure to carefully check its physical condition, and in particular any parts of
the structure that can give or break during scrapping.
The machine’s parts must be disposed of in a differentiated way, according to their different characteristics (e.g. met-
als, oils, greases, plastic, rubber, etc.).
Different regulations are in force in the various countries, therefore comply with the provisions of the laws and com-
petent bodies in the country where scrapping takes place.
In general, the appliance must be taken to a specialised collection/scrapping centre.
Dismantle the appliance, grouping the components according to their chemical characteristics, remembering that the
compressor contains lubricant oil and refrigerant fluid which can be recycled, and that the refrigerator and heat pump
components are special waste assimilable with urban waste.
The symbol on the product indicates that this product should not be treated as domestic waste, but must be correctly disposed
of in order to prevent any negative consequences for the environment and human health. For further information on the recy-
cling of this product, contact the local dealer or agent, the Customer Care service or the local body responsible for waste
disposal.
Note!
When scrapping the machine, any marking, this manual and other documents concerning the appliance
must be destroyed.
10.2 Disposal of packing
The packing must be disposed of in compliance with the current regulations in the country where the appliance is
used. All the packing materials are environmentally friendly.
They can be safely kept, recycled or burned in an appropriate waste incineration plant. Recyclable plastic parts are
marked as following examples.
PE
Polyethylene:
• Outer wrapping
• Instructions bag
PP
Polypropylene:
• Straps
PS
Polystyrene foam:
• Corner protectors
