ELEKTRA Health+ 8074 User manual

Read these instructions before use and keep them safe. If you pass the appliance
on, pass on the instructions too. Remove all packaging, but keep it until you are
satisfied.
SOLE THERAPY
IMPORTANT SAFETY INSTRUCTIONS:
When using an electrical appliance, basic precautions should always be followed, including the
following: Read all instruction before using this appliance.
DANGER -To reduce the risk of electric shock:
1. Always unplug this appliance from the electrical outlet immediately after using and
before cleaning.
2. Do not reach for an appliance that has fallen into water. Unplug it immediately.
3. Do not use or store the appliance where it can fall or be pulled into a tub or sink. Do not
place or drop into water or other liquid.
WARNING: -To reduce the risk of burns, fire, electric shock or injury to persons:
1. An appliance should NEVER be left unattended when plugged in. Unplug from outlet
when not in use and before putting on or taking off parts or attachments.
2. DO NOT operate under a blanket or pillow. Excessive heating can occur and cause fire,
electrical shock or injury.
3. Close supervision is necessary when this appliance is used by or near children, invalids
or disabled persons.
4. This appliance is not intended for use by children and people with reduced physical,
sensory and mental capacity.
5. Do not let children play with this appliance as there is the possibility that it could lead to
serious injury and electrocution. This appliance should only be used by an adult or a
person qualified to do so.
6. Use this appliance only for its intended use as described in this manual. Do not use
attachments not recommended; specifically any attachments not provided with the unit.
7. Never operate this appliance if it has a damaged cord or plug, if it is not working
properly, if it has been dropped or damaged, or dropped into water. Return it to the
Service Center for examination and repair.
8. Do not carry this appliance by the supply cord or use the cord as a handle.
9. Keep the cord away from heated surfaces.
10. Never operate the appliance with the air openings blocked. Keep the air openings free of
lint, hair and other debris.
11. Never drop or insert any object into any opening.
12. Do not attempt to plug or unplug the unit when you have wet hands.
13. Never operate on a soft surface, such as a bed or couch, where air openings may be
blocked.
14. Do not use outdoors.
15. Connect the appliance to a properly grounded outlet only.
16. If the supply cord is damaged, contact the Consumer Service Centre for repair and
replacement, do not attempt to repair yourself.
17. All servicing of this appliance must be performed by authorized service personnel only.
18. Keep all packaging and plastic bags out of the reach of children as these pose the risk
as a choking hazard.
19. Use only normal tap water. Do not add anything to the water (e.g. salt, oils, perfumes,
etc …)

FOR HOUSEHOLD USE ONLY
Additional Safeguards
1. Do not try to repair the appliance yourself. Contact the approved Service Centre
for examination and repair.
2. This product has been designed to operate safely when used according to the
instruction guide.
3. If the electrical circuit is overloaded with other electrical appliances, your
Humidifier may not operate properly. It should then be operated on a separate
circuit from other appliances.
Additional Note
1. Should you find after extensive use that the floor around the humidifier is wet,
please turn the humidity setting down to a lower setting.
2. As the steam generated from your humidifier is not a HOT steam, it will settle
rather than rise, and when the humidity is too high over long periods larger
amounts of vapour will settle on the floor causing it to get wet.

KNOW YOUR ELEKTRA HEALTH HUMIDIFIER
1. Nozzle
2. Tank Handle
3. Water tank
4. Tank lid
5. Power cord
6. Air outlet
7. Water protection switch
8. Transducer
9. LED board
10. Machine panel
11. LCD display
12. Ioniser generator
13. Aroma oil holder
14. Inlet grid
15. Mist funnel
16. PTC heater
17. Skin icon
18. Care icon
19. Mode
20. Mist
21. Ioniser / LED
22. Ioniser icon
23. Environmental humidity icon
24. Mist level
25. Power switch
26. Humidity icon
27. Timer
28. Humidity
29. Heat
30. Water icon
31. Heat icon

User Instructions
1. Place the base of the unit on a smooth level surface.
2. Remove the water tank and unscrew the tank lid underneath the tank.
3. Pour plain cold tap water into the tank.
4. Always use ordinary tap water and never add anything to the water (e.g. salt, oils,
perfumes, etc …)
5. Ensure that you tighten the tank lid securely.
6. Place the tank onto the base.
7. Place the nozzle into the recess on top of the tank, and direct it away from walls and
furniture.
8. Plug the appliance into the power outlet and depress the power switch.
9. The screen will illuminate.
Different Functions
1. The MODE button (19) will allow you to select from the HEALTH / SKIN CARE modes.
- HEALTH: The humidity level will automatically be set at 60% relative
humidity.
- SKIN CARE: The humidity level will be controlled at approximately 70%
relative humidity.
2. The MIST button (20) allows you to set 3 different levels of mist output intensity.
3. The ION/LED button (21) has two features.
(i) LED light –the light can be used with or without the ioniser function. To use the
light only press the button once. If you wish to use the ioniser and LED light push
the button three times.
(ii) Ioniser –the ioniser can be used with or without the LED light. To use the ioniser
only, press the button twice. If you wish to use the ioniser and the LED light press
the button three times.
(iii) To turn all off, push the button four times.
(iv) When the ionizer is functioning the ionizer indicator light will illuminate (22).
4. To select warm steam simply press the HEAT button (29). Should you wish to turn off
the warm steam function press the button a second time.
5. Should you select the warm steam setting it my take a few minutes before warm steam
is emitted.
6. You may set the humidity level to your needs, by using the HUMIDITY button (28). The
available range is 40 –80% room humidity.
7. The TIMER button (27) allows you to set the timer ranging from 1 hour to 16 hours.
8. When the humidifier runs out of water, the appliance will automatically switch off the
steam production mechanism.
9. The steam production time and emission quantity may vary depending on the water
hardness.
10. Remote Control –The remote control functions in the same manner as described above
for the humidifier.
Aroma Therapy
Should you wish to include an essential oil for health reasons, or just to enhance the
atmosphere:
1. Remove the Aroma oil holder (13).
2. Fill with Aroma oil / Essential oil.
3. Replace the Aroma oil holder.

Care and Maintenance
1. Switch the appliance off and unplug it.
2. Wipe the body of the appliance off with a soft damp cloth. If necessary use a little
washing-up liquid.
3. Rinse the water tank with clean water after each use. To dry for storage, wipe with a soft
clean cloth.
4. Do not use detergents to clean any part of the unit that normally contains water.
Detergents can interfere with the performance of the unit.
5. Do not immerse the humidifier in water or any other liquid.
6. Do not use harsh or abrasive cleaning agents or solvents.
7. Keep the transducer clean by brushing with a soft brush.
8. Do not store with water in the tank.
9. When cleaning the base, beware not to get water in the air outlet.
PROBLEM
CAUSE
REPAIR
1. The Humidifier does not turn
on. There is no mist output and
no air emission
Not connected to the power
supply
Connect the humidifier to the
power supply
Humidifier not on.
Switch on the unit
2.Power on, air emission, but
no mist output
No water in the water tank
Fill tank with water
3.Malodourous mist
New humidifier
Open water tank, and leave to
air for 12 hours
Dirty water used or old water in
the water tank
Clean the water tank, fill with
clean water
4.Power on, no air emission
and no mist output
Too much water in the base
Empty the flume, and tighten
the tank lid
5.Poor mist emission
Dirty ultrasonic transducer
Clean the transducer
Dirty water used or old water in
the water tank
Clean the water tank, fill with
clean water
6.Abnormal noise / Noisy
Low water level in the tank.
Fill water tank.
Resonance from table-board
Place on a stable level surface.
After Sales Service
The appliance is not user-serviceable. If it is not working properly check:
1. You have followed the instructions properly.
2. The outlet supply is switched on.
3. The main supply fuse/circuit breaker has not blown/tripped.
If the appliance still does not work, contact the Service Centre.
TEL: [phone]
FAX: [phone]
EMAIL: [email protected]

Guarantee
Any defect affecting the functionality of the appliance which becomes apparent within
one (1) year of its purchase, will be corrected by free repair or replacement, provided
that the appliance has been used and maintained in accordance with the instructions,
and has not been altered/modified, abused or misused in anyway, and is accompanied
with a Proof of Purchase to validate the age of the appliance.
Specification
220 - 240V 50Hz 38 - 90W
The Environment
This appliance is rated at an operating input of 38 –90 watts.
Please consider the environment when disposing of packaging. Recycle wherever possible.
When you want to dispose of this appliance please do so responsibly, or contact us to assist
with the disposal, or disposal advice.
