Ellington E-BAS54CH5LKRW User manual

Federal regulations require ceiling fans
with light kits manufactured or imported
after January 1, 2009, to limit total
wattage consumed by the light kit to
190W. Therefore, this fan is equipped
with a wattage limiting device.
For Model:
E-BAS54CH5LKRW
net weight of fan: 27.8 lb (12.61 kg) PRINTED IN CHINA
READ THESE INSTRUCTIONS AND
SAVE THEM FOR FUTURE USE
Installation Guide
E192641
Table of Contents:
Safety Tips. pg. 1
Unpacking Your Fan. pg. 2
Parts Inventory. pg. 2
Installation Preparation. pg. 3
Hanging Bracket Installation. pg. 3
Fan Assembly. pgs. 4 - 5
Wiring. pgs. 5 - 6
Canopy Assembly. pg. 6
Blade Assembly. pg. 7
Light Kit Assembly. pgs. 7 - 8
Automated Learning Process./
Activating Code. pg. 9
Wall Control Operation. pg. 9
Remote Control Operation. pg. 10
Testing Your Fan. pg. 10
Troubleshooting. pg. 11
Warranty. pg. 11
Parts Replacement. pg. 11

SAFETY TIPS.
page 1
WARNING: To reduce the risk of electrical shock, turn off the electricity to the fan at the main fuse box or circuit
panel before you begin the fan installation or before servicing the fan or installing accessories.
1. READ ALL INSTRUCTIONS AND SAFETY INFORMATION CAREFULLY BEFORE INSTALLING YOUR FAN
AND SAVE THESE INSTRUCTIONS.
CAUTION: To avoid personal injury, the use of gloves may be necessary while handling fan parts with sharp
edges.
2. Make sure all electrical connections comply with Local Codes or Ordinances, the National Electrical Code,
and ANSI/NFPA 70-1999. If you are unfamiliar with electrical wiring or if the house/building wires are
different colors than those referred to in the instructions, please use a qualified electrician.
3. Make sure you have a location selected for your fan that allows clear space for the blades to rotate, and at
least seven (7) feet (2.13 meters) of clearance between the floor and the fan blade tips. The fan should
be mounted so that the tips of the blades are at least thirty (30) inches (76 centimeters) from walls or
other upright structures.
4. The outlet box and ceiling support joist used must be securely mounted, and capable of supporting at
least 35 pounds (16 kilograms). The outlet box must be supported directly by the building structure.
Use only UL listed outlet boxes marked "FOR FAN SUPPORT."
WARNING: To reduce the risk of fire, electrical shock, or personal injury, mount to the outlet box marked
"Acceptable for Fan Support of 15.9 kg (35 lbs) or less," and use the mounting screws provided with the outlet
box. Most outlet boxes commonly used for the support of lighting fixtures are not acceptable for fan support
and may need to be replaced. Consult a qualified electrician if in doubt.
WARNING: To reduce the risk of fire, electrical shock, or personal injury, wire connectors provided with this fan
are designed to accept only one12 gauge house wire and two lead wires from the fan.If your house wire is larger
than 12 gauge or there is more than one house wire to connect to the two fan lead wires, consult an electrician
for the proper size wire connectors to use.
5. Electrical diagrams are for reference only. Light kits that are not packed with the fan must be UL listed and
marked suitable for use with the model fan you are installing. Switches must be UL general use
switches. Refer to the instructions packaged with the light kits and switches for proper assembly.
6. After installation is complete, check that all connections are absolutely secure.
7. After making electrical connections, spliced conductors should be turned upward and pushed carefully up
into the outlet box. The wires should be spread apart with the grounded conductor and the
equipment-grounding conductor on opposite sides of the outlet box.
WARNING: To reduce the risk of electrical shock or fire, do not use this fan with any solid state speed control
device or control fan speed with a full range dimmer switch. [Using a full range dimmer switch to control fan
speed will cause a loud humming noise from fan.]
8. Do not operate the reverse switch until fan has come to a complete stop. [Note: If using remote control
with reverse capability, reverse fan blade direction only when on LOW speed.]
9. Do not insert anything between the fan blades while they are rotating.
WARNING: To reduce the risk of personal injury, do not bend the blade arms during assembly or after
installation. Do not insert objects into the path of the blades.
WARNING: To avoid personal injury or damage to the fan and other items, be cautious when working around or
cleaning the fan.
10. Do not use water or detergents when cleaning the fan or fan blades.A dry dust cloth or lightly dampened
cloth will be suitable for most cleaning.
WARNING: To reduce the risk of personal injury, use only parts provided with this fan. The use of parts OTHER
than those provided with this fan will void the warranty.
NOTE: The important safety precautions and instructions appearing in the manual are not meant to cover all
possible conditions and situations that may occur. It must be understood that common sense and caution are
necessary factors in the installation and operation of this fan.

1. Unpacking Your Fan.
2. Parts Inventory.
a. canopy. 1 piece
b. hanging bracket. 1 piece
c. 8in. downrod and hanging ball. 1 piece
d. motor. 1 piece
e. remote control receiver. 1 piece
f. remote control transmitter. 1 piece
g. yoke cover. 1 piece
h. blade. 5 pieces
i. wall control and plate. 2 separate pieces
j. light kit fitter. 1 piece
k. blade plate. 5 pieces
l. blade arm. 5 pieces
m. canopy cover (in hardware pack). 1 piece
n. motor housing. 1 piece
o. finial (pre-attached to light kit fitter).
1 piece
p. glass shade. 1 piece
q. chrome shade cover. 1 piece
r. safety cable (already attached to motor).
1 piece
s. hardware packs
page 2
ab
d
c
Carefully open the packaging. Remove items
from Styrofoam inserts. Remove motor housing
and place on carpet or Styrofoam to avoid
damage to finish. Do not discard fan carton or
Styrofoam inserts should this fan need to be
returned for repairs.
Check against parts inventory that all parts have
been included.
p
bulbs required:
3 x 13 watt max. compact fluorescent bulbs,
size GU24 (included)
e
f
o
i
h
l
jk
mn
g
qr
w/ remote
w/ wall
control
s
IMPORTANT REMINDER: You must
use the parts provided with this fan for
proper installation and safety.

3. Installation Preparation.
page 3
ON
OFF
ON
OFF
Vaulted ceiling
angle is not to
exceed 25 degrees.
downrod
installation
flushmount
installation
4. Hanging Bracket Installation.
hanging bracket
spring washers
outlet box screws
flat washers
12ft. - 20ft.
12ft. - 20ft.
(3.66m - 6.1m)
(3.66m - 6.1m)
blade edge
7 feet
(2.13m)
(76cm)
30
inches
To prevent personal injury and damage, ensure
that the hanging location allows the blades a
clearance of 7 feet (2.13m) from the floor and
30in. (76cm) from any wall or obstruction.
This fan is suitable for room sizes up to 400 square
feet (37.2 square meters).
Installation requires these tools:
Phillips screwdriver, flathead screwdriver,
adjustable pliers or wrench, stepladder, wire
cutters, and rated electrical tape.
This fan can be mounted with a downrod
on a regular (no-slope) or vaulted ceiling. The
hanging length can be extended by purchasing
a longer downrod (0.5in./1.27cm diameter).
Other installation, such as flushmount, is not
available for this fan.
Turn off circuit breakers to current fixture from breaker
panel and be sure operating light switch is turned to the
OFF position.
WARNING: Failure to disconnect power supply prior to
installation may result in serious injury.
Remove existing fixture.
WARNING: When using an existing outlet box, be sure the
outlet box is securely attached to the building structure and
can support the full weight of the fan. Ensure outlet box is
clearly marked "Suitable for Fan Support." If not, it must be
replaced with an approved outlet box. Failure to do so can
result in serious injury.
CAUTION: Be sure outlet box is grounded properly and that a
ground wire (green or bare) is present.
Install hanging bracket to outlet box using original screws,
spring washers and flat washers provided with new or
original outlet box.* If installing on a vaulted ceiling, face
opening of hanging bracket towards high point of ceiling.
Arrange electrical wiring around the back of the hanging
bracket and away from the hanging bracket opening.
*Note: It is very important that you use the proper hardware
when installing the hanging bracket as this will support the
fan.

page 4
5. Fan Assembly.
set screw hole
set screw
hanging ball
stop pin
A
B
If you wish to extend the hanging length of your fan,
you must remove the hanging ball from the 8in.
downrod provided to use with an extended downrod
(sold separately). [If you wish to use the 8in. downrod,
please proceed to instructions following the dotted line
below.]
To remove hanging ball, loosen set screw on hanging
ball, lower hanging ball and remove stop pin. Slide
hanging ball off the original downrod, A, and slide it
down the longer downrod, B (the top of the downrod
should be noted as having a set screw hole; use this
hole when setting the set screw). Insert stop pin into
top of extended downrod and raise hanging ball. Be
sure stop pin aligns with slots on the inside of the
hanging ball.Tighten set screw securely.
Tip: To prepare for threading electrical wires through
downrod, apply a small piece of electrical tape to the
ends of the electrical wires--this will keep the wires
together when threading them through the
downrod.
Locate canopy cover in hardware pack. Loosen yoke
set screws and nuts in yoke at top of motor and
remove pin and clip from yoke at top of motor. Slide
downrod through canopy, canopy cover and yoke
cover. [Note: Canopy cover must be turned with shiny
side toward the motor.]
Thread safety cable and electrical wires through
downrod and pull extra wire slack from the upper
end of the downrod.
Place downrod into the yoke at top of motor and re-
insert pin and clip. Securely tighten yoke set screws
and nuts. Lower yoke cover onto the top of the
motor.
["Fan Assembly" continued on next page.]
NOTE: The important safety precautions and
instructions appearing in the manual are not meant to
cover all possible conditions and situations that may
occur. It must be understood that common sense and
caution are necessary factors in the installation and
operation of this fan.
canopy cover
downrod
yoke cover
canopy
pin
clip
motor
electrical wiring
yoke set screw
safety cable

5. Fan Assembly. (cont.)
page 5
With the hanging bracket secured to the outlet box
and able to support the fan, you are now ready to
hang your fan. Grab the fan firmly with two hands.
Slide downrod through opening in hanging bracket
and let hanging ball rest on the hanging bracket.
Turn the hanging ball slot until it lines up with the
hanging bracket tab.
Tip: Seek the help of another person to hold the
stepladder in place and to help lift the fan up to you
once you are set on the ladder.
Find a secure attachment point (wood ceiling joist
highly recommended) and secure safety cable. It will
be necessary to use a heavy duty wood screw,
washer and lock washer (not supplied) with the
safety cable loop. If necessary, adjust the loop at the
end of the safety cable. The loop at the end of the
safety cable should just fit over the threads on the
wood screw. Extra cable slack can be left in ceiling
area.
6.Wiring.
CAUTION: Be sure outlet box is properly grounded
and that a ground wire (GREEN or Bare) is present.
Make sure all electrical connections comply with
Local Codes or Ordinances and the National
Electrical Code. If you are unfamiliar with electrical
wiring or if the house/building wires are different
colors than those referred to in the diagram to the
right, please use a qualified electrician.
When downrod is secured in place on the
hanging bracket, wire the RECEIVER with wire
connectors provided as shown in diagram at
right.
Tip: While you are wiring, keep in mind that
wires must not obstruct receiver from sliding
into hanging bracket.
* Wrap each wire connector separately with
electrical tape as an extra safety measure.
Gently insert receiver (flat side up) into hanging
bracket and carefully push wires and taped wire
connectors into outlet box. Let antenna rest
outside of hanging bracket.
["Wiring" continued on next page.]
white supply wire
black supply wire
black
black
white
blue
blue
white
from receiver
black
AC IN L
AC IN N
white
white
ground (green
or bare)
from fan
from receiver
antenna
from ceiling
(wiring for receiver)
black
receiver
wood
ceiling
joist
hanging ball slot
hanging bracket tab
motor
safety cable
wood screw
and washer
safety cable loop
canopy

page 6
6.Wiring. (cont.)
7. Canopy Assembly.
Locate 2 screws on underside of hanging bracket and
remove screw closest to the open end of the hanging
bracket. Partially loosen the other screw. Lift canopy to
hanging bracket. Place rounded part of slotted hole in
canopy over loosened screw in hanging bracket and
push up.Twist canopy to lock. Re-insert screw that was
removed and then tighten both screws securely. Slide
canopy cover up to canopy, aligning rounded part of
slotted holes in canopy cover with screwheads in
bottom of canopy.Turn canopy cover to the right
(clockwise) until it stops.
*Remember that antenna for remote control receiver
must rest outside of hanging bracket. canopy cover
screw
canopy
hanging bracket
screw
antenna
IN ORDER TO WIRE WALL CONTROL, remove
existing wall switch.Wire the WALL CONTROL with
wire connectors provided as shown in diagram at
right.
* Wrap each wire connector separately with electrical
tape as an extra safety measure. Gently push wires
and taped wire connectors into outlet box.
Use a ballpoint pen or a small screwdriver to set the
code switches 1 through 4 on the wall control.
Factory setting is pre-set and not recommended for
use. Write down number sequence for use in Section 10.
Locate dimmer switch to the right of the code
switches labled "D" and "X." Because this fan requires
compact fluorescent GU24 bulbs, the dimmer switch
must be set in the "off" (X) position. [Note: Most
Compact fluorescent bulbs (including the ones
provided with this fan) are not compatible for use
with dimmer controls.]
Attach wall control to outlet box and secure with
screws from original wall switch. Attach front plate to
wall control using 2 screws provided with the wall
control.
black (OUT to fan)
green
black
(AC IN from
breaker box)
black
(TO POWER supply)
(wiring for wall control)
black
gr
gr
een/
een/
bar
bar
e
e
gr
gr
ound
ound
green/
bare
ground
outlet box
wall
control plate
1234X
D
code
switches
dimmer
switch

blade plate
Time Saver: Washers for blade screws can
be set on each blade screw prior to installing
blades.
Locate 15 blade attachment screws and
washers in one of the hardware packs. Hold
blade plate up to blade aligning holes in
blade plates with holes in blade as shown,
and then lower blade arm over blade holes.
Insert 3 blade attachment screws (along
with washers) with fingers first, and then
tighten screws securely with Phillips
screwdriver. Repeat procedure for remaining
blades.
Remove blade arm screws and lock washers
from fan motor (save blade arm screws and
lock washers to secure blade arms). Align
blade arm holes with motor screw holes (on
topside of the motor) and attach blade arm
with lock washers and blade arm screws.
Before securing screws permanently, repeat
this procedure with remaining blade arms.
Secure all screws.
Note:Tighten blade arm screws twice a year.
blade
arm
screws
blade
arm
screw lock washer
lock
washer
motor
blade arm
blade
blade attachment
screws and washers
8. Blade Assembly.
9. Light Kit Assembly.
motor
housing
chrome
shade
cover
metal tab
outermost
edge
page 7
Remove 3 screws located on outermost edge
of motor housing. Place chrome shade cover
over motor housing. Align holes in metal tabs on
chrome shade cover with the screw holes on
motor housing rim where the screws were
previously removed.
Partially re-insert screws. Once all 3 screws have
been partially inserted, tighten screws securely
with Phillips screwdriver. (diagram 1)
diagram 1

page 8
Remove 1 screw from fitter plate on underside of
motor and partially loosen the other 2 screws. Align
slotted holes in center of motor housing with
loosened screws in fitter plate, allowing the molex
connection from motor to come through hole in
middle of motor housing. Twist motor housing to
lock. Re-insert screw that was previously removed
and securely tighten all 3 screws with Phillips
screwdriver. (diagram 2)
Remove screw from 1 of the posts located on
underside of motor housing and partially loosen the
screws in the other 2 posts.
Connect the WHITE wire from the light kit fitter to
the WHITE wire from the motor. Connect the
BLACK wire from the light kit fitter to the BLACK
wire from the motor. Be sure that the molex
connections snap together securely.
Align slotted holes in light kit fitter with loosened
screws in motor housing. Twist light kit fitter to lock.
Re-insert screw that was previously removed and
tighten all 3 screws securely. (diagram 3)
Remove finial from light kit fitter. (diagram 3)
Install 3 compact fluorescent 13 watt max. bulbs,
size GU24 (included). (diagram 3)
Important: When replacing bulbs, please allow
bulb(s) and glass shade to cool down before
touching them.
Align threaded rod on light kit fitter with hole in
middle of glass shade and push up gently allowing
threaded rod to come through hole. Secure glass
shade to light kit fitter by tightening finial.
(diagram 4)
Note: Do NOT overtighten finial as glass may crack or
break.
Hg LAMP CONTAINS MERCURY
Manage in accordance with Spills,Disposal and Site Cleanup
Requirements. In case of breakage, follow clean-up
procedures provided by contacts below.
www.epa.gov/cflcleanup
1-866-284-4010
fitter plate
motor
diagram 2
motor
housing
chrome
shade
cover
9. Light Kit Assembly. (cont.)
finial
diagram 4
bulb
finial
diagram 3
glass
shade
motor
housing
motor
housing
motor
housing
post
molex
connections
light kit fitter
threaded
rod
motor housing
post screw
chrome
shade
cover

10. Automated Learning Process./
Activating Code.
CAUTION:The remote control transmitter can be
programmed to multiple receivers or fans.If this is
not desired, turn wall switch off to any other
programmable receiver or fan.
Remove battery cover on back side of remote
control transmitter.
Use a ballpoint pen or a small screwdriver to set
the code switches 1 through 4 for the
transmitter. Use the same number sequence used
when wiring the wall control in Section 6.
Locate dimmer switch to the right of the code
switches labled "D" and "X." Because this fan
requires compact fluorescent GU24 bulbs, the
dimmer switch must be set in the "off" (X)
position. [Note: Most Compact fluorescent bulbs
(including the ones provided with this fan) are
not compatible for use with dimmer controls.]
Install one 9-volt battery (sold separately) in
transmitter. Note: Leave battery connected but
outside of battery compartment until learning
process is complete.
Restore electrical power and then set slider
switch on wall control to the ON position.Within
30 seconds of turning on the wall control, press
the "OFF" button, located on the front of the
transmitter, for 5 seconds.Test the fan functions
to confirm the learning process is complete--see
Section 13.
Place battery in battery compartment and then
re-attach battery cover on transmitter.
battery
cover
dimmer
switch
code
switches
Transmitter
(back)
Transmitter
(front)
Wall Controller
(front)
11.Wall Control Operation.
ON/OFF slider switch - turns wall control ON or OFF
HI button - turns fan to HIGH speed
MED button - turns fan to MEDIUM speed
LOW button - turns fan to LOW speed
FAN OFF button - turns fan OFF
REV button - used to REVERSE blade direction (fan must
be set on low before reversing blade direction)
LIGHT button - turns light ON/OFF when pressed once
page 9

page 10
12. Remote Control Operation.
HI button - turns fan to HIGH speed
MED button - turns fan to MEDIUM speed
LOW button - turns fan to LOW speed
OFF button - turns fan OFF
REV button - used to REVERSE blade direction (fan
must be set on low before reversing blade direction)
button - turns light ON/OFF
13.Testing Your Fan.
It is recommended that you test fan before
finalizing installation. Restore power from circuit
box and light switch (if applicable). Locate
ON/OFF slider switch on wall control and set to
the ON position. Test light and dimmer function
and then test fan speeds. Next, locate remote
control. Start with the light OFF and test the
light ON/OFF function by pressing on the
button. Test fan speeds with the different fan
speed buttons. If the remote control operates all
of the functions of the fan, battery has been
installed correctly. If the wall and/or remote
controls do (does) not operate all of the fan
functions, refer to "Troubleshooting" section to
solve any issues before contacting Customer
Service.
Fan must be set on LOW before setting the fan in
reverse. Reverse blade rotation to recirculate air
depending on the season.

page 11
Troubleshooting. Warranty.
WARNING: Failure to disconnect power supply
prior to troubleshooting any wiring issues may
result in serious injury.
Parts Replacement.
For parts and information, please refer to
"Parts Inventory" on page 2.
Ellington Customer Support:
1-800-527-1292
www.ellingtonfans.com
ELLINGTON LIMITED LIFETIME WARRANTY:
ELLINGTON/LITEX INDUSTRIES, LTD. warrants this fan to the
original household purchaser for indoor use under the
following provisions:
1-YEAR WARRANTY: ELLINGTON/LITEX INDUSTRIES, LTD.
will replace or repair any fan which has faulty performance
due to a defect in material or workmanship. Contact Litex
Customer Service at 1-800-527-1292 to arrange for return
of fan. Return fan, shipping prepaid, to Litex Industries, Ltd.
We will repair or ship you a replacement fan, and we will
pay the return shipping cost.
5-YEAR WARRANTY: ELLINGTON/LITEX INDUSTRIES, LTD.
will repair or replace at no charge to the original purchaser
any fan motor that fails to operate satisfactorily when
failure results from normal use.
RETURN FAN MOTOR ONLY, shipping prepaid, to Litex
Industries.We will repair or ship purchaser a replacement
motor and Litex will pay the return shipping cost.
6-YEAR to LIFETIME LIMITED WARRANTY: ELLINGTON/
LITEX INDUSTRIES, LTD. will repair the fan, at no charge for
labor only to the original purchaser, if the fan motor fails to
operate satisfactorily when failure results from normal use.
Parts used in the repair will be billed to the purchaser at
prevailing prices at time of repair.
The purchaser shall be responsible for all costs incurred
in the removal, reinstallation and shipping of the product
for repairs.
This warranty does not apply when damage from
mechanical, physical, electrical or water abuse results in
causing the malfunction. Deterioration of finishes or other
parts due to time or exposure to salt air is specifically
exempted under this warranty.
Neither Litex Industries nor the manufacturer will
assume any liability resulting from improper installation or
use of this product. In no case shall the company be liable
for any consequential damages for breach of this, or any
other warranty expressed or implied whatsoever.This
limitation as to consequential damages shall not apply in
states where prohibited.
Problem: Fan fails to operate.
Solutions:
1. Check power to wall switch/wall control.
2. Check to be sure code switches in remote control transmitter
and wall control are set properly.
3.Verify that receiver is wired properly.
4.Verify that wall control is wired properly.
5. Check to be sure fan is wired properly.
6. Check that red light on remote control transmitter turns on
when a button is pressed indicating that the battery is good.
7. Learning process between fan, remote control transmitter and
wall control may not have been successful and code was not
activated.Turn off power and repeat instructions in next to last
paragraph of Section 10 (page 9).
Problem: Light kit not lighting.
Solutions:
1. Check wall switch to fan.
2. Check that bulbs are installed correctly.
3. Check that wires in canopy are wired properly.
4. Check to be sure code switches are set properly in
remote control transmitter and wall control.
5. Check to be sure that bulbs total no more than 190W.
[Note: Lamping light kit with bulb that totals more than
190W will cause the wattage limiting device to interrupt
the flow of electricity to the light kit.]
Problem: Fan operates but lights fail.
Solutions:
1. Check that bulbs are installed correctly.
2. Check that wires in canopy are wired properly.
3. Replace defective bulb with same type of bulb.
4. Check to be sure that bulbs total no more than 190W.
[Note: Lamping light kit with bulbs that total more than
190W will cause the wattage limiting device to interrupt
the flow of electricity to the light kit.]
5.Verify that molex connections in light kit fitter are
connected properly.
Problem: Fan and light fail to operate with remote control.
Solutions:
1. Check that red light on remote control transmitter turns
on when a button is pressed indicating that the battery is
good.
2. Check to be sure code switches are set properly in
remote control transmitter and wall control.
7. Learning process between fan, remote control transmitter and
wall control may not have been successful and code was not
activated.Turn off power and repeat instructions in next to last
paragraph of Section 10 (page 9).
Problem: Fan wobbles.
Solutions:
1. Use the balancing kit in one of the hardware packs. If no
blade balancing kit is provided, please call Customer Support,
1-800-527-1292, to request one.
2. Check to be sure set screw(s) on motor housing yoke is
(are) tightened securely.
3. Check to be sure set screw on hanging ball is tightened
securely.
