Elmo Annotation Module EVR-100 User instructions

ELMO ANNOTATION MODULE EVR-100
SETTING UP
Stretch the film over the stage.
Stick the end of the film on the core of the empty roll by using adhesive tape.
Wind the film by turning the take-up knob.
Prace the EVR-100 on the stage of your ELMO Presenter for use.
Caution: Do not write on top surface directly, only write on Acetate.
Dimensions : 12.4"(W) x 14.8"(D) x 2.4"(H)
315mm(W) x 376mm(D) x 61mm(H)
Weight : 1.5 lbs (0.68 kg)
OPTIONAL ACCESSORIES
Writing Roll Film (Code 4367)
Base Light Unit SV-450 :
The combination of the EVR-100 and the SV-450 converts the ELMO EV-2000AF
or HV-3000XG as well as EV-200 or HV-100XG notebooks from standard
analog/digital document cameras to enhanced units with simplified,
easy
-
to
-
use annotation capabilities.
Take-up Knob Adhesive tape
