ELTEC TRAPSOUND Quick setup guide
ORGDRIVE CP25
ACCESSORIES
INFORMATIVE MANUAL
Rev. 02 of 20/07/2011
1
INDEX
1 - TRAPSOUND RECORDER pag. 3
1.1 - Parts of the system.............................................................................................pag. 4
1.2 - List of the functions.............................................................................................pag. 5
1.3 - Trapsound recorder with automatic start of the organ
(Code TS25USB-MRA)
..................................................................................................
pag. 5
1.4 - "Trapsound Manager".........................................................................................pag. 6
1.5 - Trapsound Programmer......................................................................................pag. 7
1.6 - Coding of different models..................................................................................pag. 10
2 - CONTROL SYSTEM FOR SWELL BOX pag. 12
2.1 - Parts of the system.............................................................................................pag. 13
2.2 - List of the functions.............................................................................................pag. 14
2.3 - Coding of the products........................................................................................pag. 15
2.4 - Configurations of the system...............................................................................pag. 16
3 - RADIO TRANSMISSION SYSTEM pag. 17
3.1 - Radio/cable transmission system........................................................................pag. 17
3.2 - Coding of different models..................................................................................pag. 18
3.3 - Selectors.............................................................................................................pag. 19
4 - MIDI INTERFACE (Code MIDIKIT) pag. 20
5 - TUNING KEYBOARD pag. 21
5.1 - List of the functions.............................................................................................pag. 21
5.2 - Accessories of the tuning keyboard ....................................................................pag. 22
5.3 - Coding of different models..................................................................................pag. 23
6 - CAPTURES MODULE pag. 25
7 - CONTROL BOARD FOR MAGNETS OF THE STOPS
(Code ORGMARE)
pag. 26
8 -
CONTROL BOARD FOR MAGNETS OF THE VERTICAL STOPS
(Code ORGMARE-V) pag. 27
9 - TRANSPOSER BOARD pag. 28
10 - 61 POWER AMPLIFIERS BOARD pag. 29
11 - 3 POWER AMPLIFIERS BOARD (Code ORG5A) pag. 30
12 - INVERTER BOARDS pag. 30
13 - BUTTON CONTROL BOARD WITH LAMP (Code RELED) pag. 31
2
14 - CONTROL CARD FOR SLIDING STOPS (Code RESCOR) pag. 31
15 - CONTROL CARD FOR REVERSERS (Code ORGREV) pag. 32
16 - STRIP 128 LED FOR SIMULATION pag. 32
17 - POWER SUPPLIES pag. 33
18 - SERIAL CABLE pag. 36
18.1 - Technical board ............................................................................................... pag. 36
19 - CONNECTORS FOR SERIAL CABLE pag. 38
20 - ORGDRIVE CONFIGURATION CABLE pag. 38
21 - USB - SERIAL CONVERTER pag. 38
22 - POCKET (Code ORGPK) pag. 39
23 - DRILL GAUGE (Code DIMA61) pag. 39
24 - REGULATION BOARD FOR HALL SENSORS (Code HALTA TEST ) pag. 40
3
1 - TRAPSOUND RECORDER
The TRAPSOUND recorder is an equipment that allows to do the recording and the
reproduction of single pieces or whole concerts on the organ.
Connected through the serial line to the ORGDRIVE unit in console, it memorize and
reproduce faithfully the condition of input and output.
Optional very easy to install and very reliable, TRAPSOUND offers the following advantages:
•Recording of single pieces or whole concerts.
•Possibilità to listen the recorded pieces.
•Store up pieces recorded in the inner memory (max 90 pieces x 99 archives).
•Store up pieces on a PC through the use of a FLASH DISK USB key memory and the
proper programme “TRAPSOUND MANAGER”.
•Use of the organ for maintenance.
•Use of the organ when the organist is absent.
•Planning of the automatic execution of one or more pieces at a given hour of a given day
(only with the temporal programmer of events “Trapsound PROGRAMMER”)
Moreover, also during the LISTENING function of a recorded piece, the console remains
enabled. In this way it is possible to use it in parallel to the recorder, activating or
deactivating all the functions and playing at the same time with the piece that one is listening.
4
1.1 - PARTS OF THE SYSTEM
The TRAPSOUND recorder consists of the following parts:
Base unit (Code TSPC25USB)
Aluminium case. Dimensions: 215 x 220 x 80 mm. Power: 220 V - 50 Hz.
It has inside an industrial Pc board (with static hard disk) and a ELTEC manufacture board
(Code TSRE) that interfaces the PC board with the ORGDRIVE system.
LCD display plate and USB connector (Code TSFD2)
Brass plate to install at sight on the console. On this plate there is the USB connector and
the display board (Code TSLCD-USB) for the visualization of the command messages.
To activate these commands four solutions are offered:
1 - Command plate by cable (Code TSTE1F)
Aluminium plate with all the control buttons connected to the base unit TSPC25USB
through a 3 wires shielded cable. It can be installed on the console or at a distance.
It is powered through the cable.
2- Remote control by infrareds (Code TSTE1)
Remote control by infrareds to steer toward the plateTSFD2.
It has to be used in front of the console. 6V battery power supply.
3 - Remote control by radio (Code TSTE1R)
Remote control via radio used at a distance, without having to be directed towards the
plate TSFD2. 6V battery power supply.
It is always possible to use the infrared transmission.
Radio receiver module (Code TSMR1)
It is connected to the base unit TSPC25USB.
4 - Remote control by radio (Code TSTE1R)
Remote control by radio used at a distance, without having to be directed towards the
plate TSFD2. 6V battery power supply.
It is always possible to use the infrared transmission.
Radio receiver module with automatic starting of the organ (Code TSMRA12)
It is connected to the base unit TSPC25USB.
Relay card for the automatic starting of the organ (Code TSRELE12)
It has 2 contacts to use with 220V power for the starting of the console and so of the
organ.
5
1.2 - LIST OF THE FUNCTIONS
LOAD To load pieces to listen.
PLAY To listen a piece.
PAUSE To interrupt the listening of a piece.
INTERMEDIATE To listen a piece from an intermediate value preset.
CONTINUOUS To listen all the pieces in sequence.
ARCHIVE To store the contents of the recording archive or flash disk in an
internal archive.
COPY To copy the contents of the recording archives or of an internal
archives on the flash disk.
DELETE To delete the pieces from the recording archives, from an internal
archives, from the flash disk.
RECORD To record a piece.
TEST To record a test piece without memorizing it in the recording archives.
To listen a test piece without loading it in the listen archives.
DIR (F1) To visualize the number of pieces that are in the internal archives, in
the recording archives, in the flash disk.
OFF (F2) To stop CONSOLE/ORGAN (only mod. TS25MRA).
INFO (F3) To visualize the information of the pieces (title, author, time)
STOP To stop the listening or the recording, to cancel a control.
To visualize the data and the system hour.
ENTER To confirm the controls.
To switch on CONSOLE/ORGAN (only mod. TS25MRA).
1.3 - TRAPSOUND RECORDER WITH AUTOMATIC
STARTING OF THE ORGAN (Code TS25USB-MRA)
Sometimes for using the TRAPSOUND recorder it can be rather uncomfortable to reach the
console, open it and switch on the organ.
The TRAPSOUND recorder with AUTOMATIC STARTING (Code TS25USB-MRA) gives the
possibility to switch on and switch off the console (and therefore the organ) directly with the
use of the remote control.
It is necessary to use an appropriate radio module (Code TSMR2) and a relay card (Code
TSRELE).
6
1.4 - "TRAPSOUND MANAGER"
The programme “TRAPSOUND MANAGER” allows to store up the recording file of a
TRAPSOUND recorder on the hard disk of one’s own PC, with the possibility to give to each
file useful information concerning the recording (Title, Author, Performer, Category, Liturgical
Time, Creation date, Comment).
Then these file can be organized in some listen folder, ready to be reproduced from the
TRAPSOUND recorder.
The main functions of the programme are three:
Import record
[Flash disk USB] [Archives PC]
Display record folder
[Archives PC]
Create new listen folder
[Archives PC] [Flash disk USB]
Available in English, Italian and French, "TRAPSOUND MANAGER" also allows you to print
a printout containing the list of files (and associated additional information) of stored folders
and listen folder.
7
1.5 - TRAPSOUND PROGRAMMER
“Trapsound PROGRAMMER” is a time programmer of events: it allows to plan the
automatic playing of one or more pieces at a certain time on a given day.
The fields of application of this equipment can be several:
- Use of the organ for maintenance and preservation (for example on organs which
have played little, whose lack of use, with the passing of time, compromises its
working).
- Use of the organ for the enhancement of itself and the environment in which it is
located (for example in places of tourist interest, where it is often possible to see the
organ as an aesthetic monument, but one can't appreciate the most important
features: the sound.
- Listening to recorded pieces without direct access to the console and using the
Trapsound recorder.
Trapsound PROGRAMMER is available into two different versions: one for the internal
installation in console, one for the external wall installation (maximum distance from the
console: 200 m).
The potential of the "Trapsound PROGRAMMER" are added to those of the "Recorder
TRAPSOUND", offering a more complete product and able to meet the needs of the final
user.
Base unit PROGRAMMER
for external installation
(Code PROGEXT).
8
Base unit PROGRAMME for external
installation (Code PROGEXT)
connection side.
WORKING
First of all it is important to create an archives of pieces from which to take for the
programming. Pieces must be first recorded on an organ with the "TRAPSOUND Recorder",
stored and named with the "Trapsound MANAGER" software.
All the programming operations are executed on the terminal of the "Trapsound
PROGRAMMER, a TFT 5.7' touch screen monitor, which, thanks to its simple and intuitive
graphical interface, offers ease of use and immediacy of understanding.
Furthermore, the big flexibility of the programming system, allows to create personalized
programmes with different levels of priority, according to the desires of the location and
period of the year.
Once the programming is done and the desired programmes are enabled, it is "Trapsound
PROGRAMMER" that thinks to start the organ at the right time, to control the execution of
one or more pieces and finally to switch off the organ after the playing.
In case "Trapsound PROGRAMMER" finds the console (and so the organ) that is already
started, no control is executed, even if it is programmed. The manual use of the organ is
always priority on the automatic one.
Base unit PROGRAMMER for the installation in console (Code PROGINT ) with display TFT touch
screen 5,7' plate (Code PD5.7).
9
EXAMPLES OF SCREENS
Main screen of "Trapsound PROGRAMMER".
Screen of creation of a programming line
Trapsound Programmer
MENU PRIN
CIPALE
SOSPENDI
PROGRAMMAZIONE
RIPRENDI
PROGRAMMAZIONE
PROGRAMMA ABILITATO
NOME PROGRAMMA
PROSSIME LINEE DI PROGRAMMAZIONE
10:30 Linea n. 01 00:05:17
12:00 Linea n. 02 00:12:05
15:00 Linea n. 03 01:01:29
D
ettagli
Dettagli
Dettagli
TIPO
Programmi
\
Base (o Prioritari)
\
Crea 2 di 2
HH:MM:SS
+ + + +
- - -- -
+
!
"
ANNULLA TERMINA
CANCELLA
10
1.6 - CODING OF DIFFERENT MODELS
TRAPSOUND recorder with command plate by cable (TS25USB-RC)
The model TS25USB
-
RC includes:
(reference to the price list)
N. 1 Base unit TRAPSOUND (Code TSPC25USB)
N. 1 Display panel LCD and USB connector (Code TSFD2)
N. 1 Control plate (Code TSTE1F)
N. 1 Shielded cable connection plate TSFD2 L = 2 m (Code 5018)
N. 1 Shielded cable connection Orgdrive unit L = 2,5 m (Code 5006)
N. 2 Flash disk USB (Cod. USB-2G)
N. 1 Power supply cable 220 V (Code 5020)
N. 1 Installation CD "Trapsound Manager"
TRAPSOUND recorder with remote control by infrareds (TS25USB-IR)
The model
TS25USB
-
IR includes:
(reference to the price list)
N. 1 Base unit TRAPSOUND (Code TSPC25USB)
N. 1 Display panel LCD and USB connector (Code TSFD2)
N. 1 Infrared ray remote control (Code TSTE1)
N. 1 Shielded cable connection plate TSFD2 L = 2 m (Code 5018)
N. 1 Shielded cable connection Orgdrive unit L = 2,5 m (Code 5006)
N. 2 Flash disk USB (Cod. USB-2G)
N. 1 Power supply cable 220 V (Code 5020)
N. 1 Installation CD "Trapsound Manager"
TRAPSOUND recorder with remote control by radio (TS25USB-MR)
The model
TS25USB
-
MR includes:
(reference to the price list)
N. 1 Base unit TRAPSOUND (CodeTSPC25USB)
N. 1 Display panel LCD and USB connector (CodeTSFD2)
N. 1 Remote control with radio transmitter (CodeTSTE1R)
N. 1 Radio receiver module (CodeTSMR1)
N. 1 Aerial for the receiver TSMR1
N. 1 Shielded cable connection plate TSFD2 L = 2 m (Code5018)
N. 1 Shielded cable connection Orgdrive unit L = 2,5 m (Code5006)
N. 2 Flash disk USB (Cod. USB-2G)
N. 1 Power supply cable 220 V (Code 5020)
N. 1 Installation CD "Trapsound Manager"
TRAPSOUND recorder with remote control by radio and self-starting of the
organ (TS25USB-MRA)
The model
TS25USB
-
MRA includes:
(reference to the price list)
N. 1 Base unit TRAPSOUND (Code TSPC25USB)
N. 1 Display panel LCD and USB connector (Code TSFD2)
N. 1 Remote control with radio transmitter (Code TSTE1R)
N. 1 Radio receiver with automatic starting of the organ (Code TSMR2)
N. 1 Aerial for the radio receiver TSMR2
N. 1 Relay board for the automatic starting of the organ (Code TSRELE)
N. 1 Flat cable connection receiver TSMR2/card TSRELE(Code 5019)
N. 1 Shielded cable connection plate TSFD2 L = 2 m (Code 5018)
N. 1 Shielded cable connection Orgdrive unit L = 2,5 m (Code 5006)
N. 2 Flash disk USB (Cod. USB-2G)
N. 1 Power supply cable 220 V (Code 5020)
N. 1 Installation CD "Trapsound Manager"
11
TRAPSOUND recorder with remote control by radio, self-starting of the organ
and PROGRAMMER for the external assembly (TS25USB-PROGEXT)
The model
TS25USB
-
PROGEXT
includes
:
(reference to the price list)
N. 1 Base unit TRAPSOUND (Code TSPC25USB)
N. 1 Display panel LCD and USB connector (Code TSFD2)
N. 1 Remote control with radio transmitter (Code TSTE1R)
N. 1 Radio receiver with automatic starting of the organ and arrangement
for the PROGRAMMER (Code TSMRP12)
N. 1 Aerial for the radio receiver TSMRP12
N. 1 Relay board for the automatic starting of the organ (Code TSRELE12)
N. 1 Flat cable connection receiver TSMRP12 / TSRELE12 L = 1 m (Code 5008)
N. 1 Shielded cable connection plate TSFD2 L = 2 m (Code 5018)
N. 1 Shielded cable connection unit L = 2,5 m (Code 5006)
N. 2 Flash disk USB (Code USB-2G)
N. 1 Power supply cable 220 V (Code 5020)
N. 1 Installation CD "Trapsound Manager" (Code TSMCD)
--------------------------------------------------------------------------------------------------------
N. 1 Base unit PROGRAMMER (Code PROGEXT)
N. 1 Kit connectors for cable connection PROGEXT / TSMRP12
(cable of variable length to order separately)
N. 1 Cable connection TRAPSOUND / TSMRP12 L = 1,5 m (Code 5024)
N. 1 Power Supply 9V
TRAPSOUND recorder with remote control by radio, self-starting of the organ
and PROGRAMMER for the internal assembly in console (TS25USB-PROGINT)
The model TS25USB
-
PROGINT includes
:
(reference to the price list)
N. 1 Base unit TRAPSOUND (Code TSPC25USB)
N. 1 Display panel LCD and USB connector (Code TSFD2)
N. 1 Remote control with radio transmitter (Code TSTE1R)
N. 1 Radio receiver with automatic starting of the organ and arrangement
for the PROGRAMMER (Code TSMRP12)
N. 1 Aerial for the radio receiver TSMRP12
N. 1 Relay board for the automatic starting of the organ (Code TSRELE12)
N. 1 Flat cable connection receiver TSMRP12 / TSRELE12 L = 1m (Code 5008)
N. 1 Shielded cable connection plate TSFD2 L = 2 m (Code 5018)
N. 1 Shielded cable connection unit L = 2,5 m (Code 5006)
N. 2 Flash disk USB (Code USB-2G)
N. 1 Power supplì cable 220 V (Code 5020)
N. 1 Installation CD "Trapsound Manager" (Code TSMCD)
--------------------------------------------------------------------------------------------------------
N. 1 Base unit PROGRAMMER (Code PROGINT)
N. 1 Display panel TFT touch screen 5,7'(Code PD5.7)
N. 1 Cable connection plate PD5.7/ PROGINT L = 2 m (Code 5022)
N. 1 Cable connection PROGINT / TSMRP12 L = 1,5 m (Code 5023)
N. 1 Cable connection TRAPSOUND / TSMRP12 L = 1,5 m (Code 5024)
N. 1 Power supply 9V
12
2 - CONTROL SYSTEM FOR SWELL BOX
The control system ESP10 allows the movement of the shutters of a swell box.
Speed, precision, sweetness, power, noiselessness and adaptability are the main
characteristics of this equipment:
Speed: The revision of the system in 2009 produced an increase of about 25%
of the speed. The total course of 18cm is practicable in less than 1 sec.
Precision: The resolution of the inner potentiometer of position allows to obtain a
resolution of 0,8 mm.
Sweetness: The regulation of the acceleration and deceleration ramps allows to
give the utmost sweetness, during the leaving and the arrival, to the
movement of the shutters.
Power: The robustness of the inner engine and the mechanics allows to obtain
a power of 78 N.
Noiseless: The wooden case (25 mm thick) assurse a good soundproofing.
Adaptability: Thanks to several regulations that are carried out from the control unit,
the system can perfectly adapt itself to every type of swell box.
Moreover the control system in solid oak and plywood assures robustness and elegance and
it is easy to integrate in the organ.
Two models of control system are available:
STANDARD CONTROL SYSTEM:
For organ where the swell box is driver in an electric way only.
FREE ROD CONTROL SYSTEM:
For organ where the swell box can be driver both electric and mechanical
way. (Ex: organ with two console, one electric and one mechanical)
13
2.1 - PARTS OF THE SYSTEM
CONTROL UNIT (Code ESC10A - ESC10M)
Sheet box with door that can be opened inside which there is an electronic card and a power
supply transformer. It must be installed in an easily accessible place, where it is possible to
see the pulling system. In this way the adjustment and learning phase will be simplified.
CHARACTERISTICS:
Power supply: 220 VAC
Sheet box with door that can be opened and key
Dimensions: 200 x 400 x 125 mm
Weight: 7 kg
PULLING SYSTEM (Code EST10A - EST10M)
Wooden box with movable rod. It contains a motor that transmits the motion to the rod with
the pinion - rack system.
The EST10A model is connected to the control unit through 5 wires.
The EST10M model has a mechanism inside controlled by an electromagnet that, when the
system is powered, pull the gear of the motor against the pinion - rack system.
This system can be controlled both electrically and mechanically and it is connected to the
control unit through 7 wires.
Both models can be installed in any positions: horizontal, vertical, on a horizontal plane, on a
vertical plane.
CHARACTERISTICS:
Solid oak box
Base and top in plywood
Positioning resolution: 0,8 mm
Power: 78 N
Stroke of the rod: 18 cm
Length of the rod: 800 mm
Base dimensions: 300 x 230 mm
Total height: 195 mm
Weight: 6,7 kg
14
2.2 - LIST OF THE FUNCTIONS
Learning of the STROKE OF THE PEDAL
It allows to keep the total stroke of the pedal installed in console or to reduce
the stroke.
Learning of the STROKE OF THE ROD
It allows to regulate the stroke of the rod according to the needs of opening of
the swell box.
Regulation of the MINIMUM SPEED of movement of the engine
It allows to regulate set the minimum speed of movement of the engine
according to the minimum power necessary to move the doors of the swell box.
Regulation of the MAXIMUM SPEED of movement of the engine
It allows to reduce the maximum speed of movement of the engine
preset as maximum value.
Regulation of the ACCELERATION/BRAKING RAMP of the engine
It allows to regulate the slope of the acceleration/braking ramps, namely to
establish the sweetness of the movement of the swell box, in departure and
arrival.
STANDARD OPENING CURVE
Preset opening curve, not linear: the first steps are very short, the last ones
are longer.
Memorization of a PERSONALIZED OPENING CURVE
It allows to memorize, step by step, a personalized opening curve according to
one's own needs.
Selection of the POSITION OF THE SWELL BOX AT THE STOP OF THE ORGAN
At the stop of the organ it is possible to open the doors of the swell box
automatically, close or leave them unchanged (namely in the position
where they are in the moment of the stop of the organ).
Selection of the kind of CONTACTS: TRUE OR FALSE
It allows to adapt the system to the two types of existing contact pedal: with
opened contacts that close themselves, with closed contacts that open
themselves.
INTERNAL POTENTIOMETER FOR THE SIMULATION OF THE PEDAL
It is available, on the board inside the command panel, a potentiometer that, with
the appropriate settings, can simulate the pedal of the console. In this way, some
test and regulations can be made directly to the control unit, without using the
console.
WORKING TEST
Series of tests and useful functions that offer a support during the testing phase:
15
- stroke of the rod step by step
- total stroke of the rod between minimum and maximum limits.
- manual forward/back.
- test of the switch, buttons and inputs of the pedal.
- test of the position of the rod.
- test of the internal/external potentiometer of the pedal.
- manual forward/back (visualization of the peak current of the engine).
Switch for the selection of the TYPE OF PEDAL
It allows to use, on the pedal of the expression in console, a slider or
contacts in the following modes:
- 7 contacts with hexadecimal code (max 128 positions)
- 16 contacts (max 16 positions)
- Analogue (max 16 positions)
- Analogue (max 128 positions)
- 4 contacts with Gray code (max 16 positions)
PROTECTION AGAINST MECHANICAL BLOCK
If the engine stops on the mechanical stops of the pulling system, after 2
seconds, a safeguard protection of the engine and internal mechanisms
intervenes. The equipment is locked and the display of the control unit
visualizes an error message: it is necessary to solve the problem.
2.3 - CODING OF THE PRODUCTS
PULLING SYSTEM FOR STANDARD SWELL BOX (Code ESP10-A)
The
ESP10
-
A
model includes
:
(reference to the price list)
N. 1 Command Panel (Code ESC10A)
N. 1 Pulling system (Code EST10A)
PULLING SYSTEM FOR SWELL BOS WITH FREE ROD (Code ESP10-M)
The
ESP10
-
M
model includes
:
(reference to the price list)
N. 1 Command Panel (Code ESC10M)
N. 1 Pulling system with free rod (Code EST10M)
16
2.4 - CONFIGURATIONS OF THE SYSTEM
With SLIDER With SLIDER
without ORGDRIVE system and ORGDRIVE system
With CONTACT With CONTACT
without ORGDRIVE system and ORGDRIVE system
ESC10
ESC10
ESC10 ESC10
17
3 - RADIO TRANSMISSION SYSTEM
The RADIO TRANSMISSION SYSTEM allows to do the transmission of data between the
MASTER unit (console) and SLAVE unit (organ) without using the serial cable. It is enough
to install a transmitter in console and a receiver in organ.
The advantages that this kind of transmission offers are:
•Elimination of the serial cable between the console and the organ, that it is not always
easy to stretch out.
•Possibility to freely move the console, without being tied to the length of the cable or to
the location of the sockets.
3.1 - RADIO / CABLE TRANSMISSION SYSTEM
It is also possible to provide for both the RADIO TRANSMISSION and the CABLE
TRANSMISSION. In this case, using a selector (Code ORGSRC), the selection happens
automatically by the insertion of the cable, namely:
- When the cable is plugged in: working with CABLE TRANSMISSION
- When the cable is not plugged in: working with RADIO TRANSMISSION
The MASTER unit provides an output for a signalling lamp to install on the console:
- Lamp switches off: working with CABLE TRANSMISSION
- Lamp switches on : working with RADIO TRANSMISSION
18
3.2 - CODING OF DIFFERENT MODELS
RADIO TRANSMITTER for ON/OFF system (Code MTX800-ST)
RADIO TRANSMITTER for PROPORTIONAL system (Code MTX800-PR)
It is installed inside the console and it is connected to the MASTER unit through a serial
cable.
CHARACTERISTICS:
Frequency band: UHF 869 MHz
Power: 220 VAC (8 VA)
Dimensions: 75 x 125 x 30 mm
Length of the aerial: 65 mm
RADIO RECEIVER for ON/OFF system (Code MRX800-ST)
RADIO RECEIVER for PROPORTIONAL system (Code MRX800-PR)
It receives signals from the transmitter and it transfers them to the SLAVE unit by which it is
connected through a serial cable. It actives, with an internal rélé, the starting of the organ.
CHARACTERISTICS:
Frequency band: UHF 869 MHz
Power: 220 VAC (8 VA)
Dimensions: 75 x 125 x 30 mm
Length of the aerial: 65 mm
Each model of radio includes
:
(reference to the price list)
N. 1 Transmitter / Receiver for ON/OFF or PROPORTIONAL system
N. 1 Aerial
N. 1 Connection serial cable L = 3 m (Code 5013-300)
19
3.3 - SELECTORS
RADIO/CAVO SELECTOR for ON/OFF system (Code ORGSRC)
RADIO/CAVO SELECTOR for PROPORTIONAL system (Code ORGSRC-PR)
SELECTOR for the automatic commutation between
RADIO and CABLE. It allows to enable the radio
transmission when the cable is disconnected.
It is installed in console, near the MASTER unit.
The supply also includes:
N.1 Kit connectors 9 pole (male + female + case).
CHARACTERISTICS:
Baseboard with screw holes
Dimensions: 75 x 125 x 30 mm
SERIAL SELECTOR for ON/OFF system (Code ORGTAS)
SERIAL SELECTOR for PROPORTIONAL system (Code ORGTASP)
SERIAL SELECTOR that cuts the serial connection
between the MASTER and the SLAVE (with the
possibility to insert another MASTER, a RADIO or a
TUNING KEYBOARD) and executes an automatic
commutation between the two input lines. The first line
(connector on the left) has priority over the second one
(central connector).
The supply also includes:
N.1 Kit connectors 9 poles (male + female + case).
CHARACTERISTICS:
Baseboard with screw holes
Dimensions: 75 x 125 x 30 mm
This manual suits for next models
1
Table of contents
