Emilyrose OVATION SERIES User manual

ASSEMBLY INSTRUCTIONS
WARNING
Do not store or use gasoline or other
flammable vapors and liquids in the
vicinity of this or any other appliance.
An LP-cylinder not connected for use
shall not be stored in the vicinity of this
or any other appliance.
DANGER 
If you smell gas:
1. Shut off gas to the appliance.
2. Extinguish any open flame.
3. If odor continues, keep away from
the appliance and immediately call
your gas supplier or fire
WARNING:
USE FACTORYAPPROVED
REPLACEMENT PARTS AND
ACCESSORIES ONLY. USE
OF UNAPPROVED PART OR
ACCESSORIES CAN VOID
THE WARRANTY ON THIS
PRODUCTAND RESULT IN
AHAZARDOUS CONDITION.
PLEASE CONTACT US FOR
INFORMATION REGARDING
REPLACEMNT
HOSES,THERMOCOUPLES,
ELECTRODES,IGNITION
MODULES,LAVAROCKS,LO
GS, FIRE ICE, ETC.
WARNING:
Improper installation, adjustment alteration,
service or maintenance can cause injury or
property damage. Read the installation,
operating and maintenance instructions
thoroughly before installing or servicing this
equipment.
FOR USE WITH 20LB (9KG) PROPANE
CYLINDER WITH TYPE 1 CONNECTION OR FOR
USE WITH NATURAL GAS AFTER CONVERSION
KIT IS INSTALLED (MUST BE PROFESSIONALLY
INSTALLED) ALSO THE LP REGULATOR MUST
BE SUPPLIED BY THE MANUFACTURER.
May 2014
Installer: Leave these instructions with consumer.
Consumer: Keep these instructions for future reference .
WARNING: For Outdoor Use Only
Questions, Problems, Missing Parts? Before returning to
your retailer, call our customer service department in the
US and Canada at 1-800-325-2315, Monday-Friday, 8 a.m.–
5 p.m.Eastern Time.
Thi
s app
li
ance can pro
d
uce car
b
on
monoxide which has no odor.
Using it in an enclosed space can kill
you.
Never use this appliance in an enclosed
space such as a camper, tent, car or
home.
DANGER CARBON MONOXIDE HAZARD
CSA Model98900
DRS02403
OVATION SERIES FIRE TABLES

2
TABLE OF CONTENTS
ImportantSafetyInformation 3
Information about Propane 4
Specifications 4
Installation 5
Natural Gas Conversion 7
Lighting Instructions 8
Maintenance 9
Batteries 9
Parts List 9
Warranty 10

3
IMPORTANT SAFETY INFORMATION
The installation must conform with local codes or, in the absence of local codes, with the National
Fuel Gas Code, ANSI Z223.1/NFPA 54; International Fuel Gas Code. ; Natural Gas and Propane
Installation Code, CSA B149.1; or Propane Storage and Handling Code, B149.2, as applicable.
The appliance and its appliance main gas valve must be disconnected from the gas supply piping
system during any pressure testing of that system at test pressures in excess of 1/2 psi (3.5kPa).
The appliance must be isolated from the gas supply piping system by closing its equipment shutoff
valve during any pressure testing of the gas supply system at test pressure equal to or less than 1/2 psi
(3.5kPa).
The appliance area must be kept clear and free from combustible materials, gasoline and other
flammable vapors and liquids.
Do not use this appliance if any part has been under water. Immediately call a qualified service
technician to inspect the appliance and to replace any part of the control system and any gas control
which has been under water.
Children and adults should be alerted to the hazards of high surface temperatures and kept at a
safe distance to avoid burns or clothing ignition.
Young children should be carefully supervised when they are anywhere near the appliance.
Clothing or other flammable material should not be hung from the appliance, or placed on or
near the appliance.
Any screen or guard removed for servicing an appliance must be replaced prior to operating the
appliance.
Installation and repair should be done by a qualified service person. The appliance should be
inspected before use and at least annually by a professional service person. More frequent
cleaning may be required as necessary. It is imperative that the control compartments, burners
and circulating air passageways of the appliance be kept clean.
Do NOT burn solid fuels in this gas fireplace.
CAUTION: The propane gas pressure regulator provided with this appliance must be used. This
regulator is set for an outlet pressure of 11 inches water column.
This outdoor gas appliance is not intended to be installed in or on recreational vehicles and/or boats.
Before each use of this gas appliance, open the LP (Liquid Propane) Tank Drawer and inspect the LP
Hose. If there is evidence of excessive abrasion or wear, or the hose is cut, it must be replaced prior to
the gas appliance being put into operation. Use only the replacement hose assembly specified in this
manual. Inspect the burner before each use of the appliance. The burner must be replaced prior to the
appliance being put into operation if it is evident that the burner is damaged. Use only the burner listed
in these instructions.
Keep the fuel supply hose away from any heated surfaces.

4
IMPORTANT SAFETY INFORMATION ABOUT
PROPANE (LP) GAS
A self contained LP-gas cylinder for use with this appliance must have a capacity of 20 lbs. and must
be equipped with a Type 1 connector and an OPD (overfill protection device). See Fig. 1.
The LP-gas supply cylinder to be used must be constructed and marked in accordance with the
specification for LP-gas cylinders of the U.S. Department of Transportation (DOT) or the National
Standard of Canada, CAN/CSA-B339, Cylinder, Sphere and Tubes for the Transportation of Dangerous
Goods.
The cylinder supply system must be arranged for vapor withdrawal.
The cylinder used must include a collar to protect the cylinder valve.
This appliance shall be used only outdoors in a well-ventilated space and shall not be used in a
building, garage or any other enclosed space.
When this appliance is not is use, the gas must be turned off at the supply cylinder.
Storage of this appliance indoors is permissible only if the cylinder is disconnected and removed
from the appliance.
Cylinders must be stored outdoors in a well-ventilated area out of the reach of
children .Disconnected cylinders must have threaded valve plugs tightly installed and must not be
stored in a building, garage or any other enclosed areas.
CSA (Canadian Standards Association) certified to ANSI Z21.97•CSA 2.41-2012 “ Outdoor
Decorative Gas Appliances” The gas hose is routed through a “U” bolt to prevent the hose from
coming in contact with the burner. DO NOT remove the hose from the “U” bolt. See Fig. 2.
Figure 1 Figure 2
SPECIFICATIONS
INPUT 40,000 Btu/hr 30,000 Btu/hr Low fire
Propane Regulator Pressure 11 inches water column
Natural Gas Minimum Inlet
Pressure
7 inches water column
Clearances to combustible surfaces Sides 24in./61cm Top: 72 in. / 183 cm

5
INSTALLATION
1. With the help of another person, carefully place the natural stone table top (not included) onto
the table base. After making any necessary adjustments to the alignment of the natural stone table
top and the top connector bracket, use bolts and washers as shown in Figure 3. Guide the bolt
through the top connector bracket into the pre-drilled hole on the underside of the natural stone
table top. Do not tighten completely. Repeat on other three holes of the top leg connector bracket.
(Note: holes do not go through to the top of the table. Holes shown for illustration purposes only.)
Figure 3
2. Pour all of the lava rocks into the burner pan. Completely cover the burner tube with lava rocks
as shown in Figure 4.
Figure4
3. Remove cardboard cover from the ignition well as shown in Figure 5.

6
Figure 5
Cardboard cover
4. Open the tank door, place the tank in the holder and use the chain to hold the tank. Connect the
regulator as shown in Figure 6. Turn the handle clock-wise to tighten. Turn the handle counter
clock-wise to remove. The hose must point down. Open the control door and check that the valve
is turned all the way clockwise to the “OFF” position. Open the tank valve. Apply a solution of
soapy water to the tank-regulator connection and to the valve-hose connection to check for leaks.
If soap bubbles continue to form, the connection has a leak. If a leak is found, close the tank
valve and tighten all connections. NEVER USEA FLAME TO CHECK FOR LEAKS.
Figure 6

NATURAL GAS CONVERSION
Natural gas conversion must be performed only by natural gas provider or service company.
1. Disconnect the gas hose from the gas valve. See Figure 7.
Figure 7
2. Disconnect the gas tube from the orifice and remove the orifice holder as shown in Figure 8.
Figure 8
3. Replace the propane orifice (See Figure 9) with the natural gas orifice from the kit and reinstall the
orifice holder by tightening the nuts as shown in Figure 10. Reconnect and tighten the gas tube to
the orifice.
Figure 9Figure10
Apply a solution of soapy water to all connections to check for leaks. If soap bubbles continue to form,
the connection has a leak. If a leak is found, close the tank valve and tighten all connections.
NEVER USEA FLAME TO CHECK FOR LEAKS.

4 . Stick the conversion label on the rating plate as shown in Figure 11.
Metal Rating Plate
4.
5.
6.
7.
8.
9.
10.
Figure 11ConversionLabel
LIGHTING INSTRUCTIONS
1. Locate the control and igniter panel. Make sure the
control knob is in the “OFF” position. See
Figure 12. Open the tank door and open the tank
valve all the way.
2. Push in the igniter button. You will hear a slight
clicking sound. With the igniter button pushed in,
push and turn the control knob to the “ON” position.
The fire should light within
a few seconds. Once the flame is lit, release the
igniter button and continue to hold the control knob
in for 10 to 15 seconds. Release the control knob.
The control knob should pop back out and the fire
should remain lit. Note: If the fire does not light,
turn the knob to the “OFF” position and wait five (5)
minutes before trying again.
3. To turn down the flame, push the control knob in
slightly and turn to the Medium (medium flame) or
Low (small flame).
4. To shut down the fire pit, turn the control knob to the
“OFF” position and turn off the tank valve
Figure 12
Serial Number _________________ Model Number: 98900
CAUTION: The gas pressure regulator provided with this appliance must be used. This regulator is set for an outlet pressure of
11 inches water column.
(2.7 kPa). The gas supply must be turned off at the LP-gas supply cylinder when this appliance is not in use.
Gas: Propane Input: 40,000Btu/hr
Minimum clearance from combustible constructions: Sides: 24 in.609 mm. Top 72 in. 1828 mm.
FOR OUTDOOR USE ONLY. If stored indoors, detach and leave cylinder outdoors.
This appliance has been converted to use Natural Gas. Input 40,000 Btu/hr.
Max Gas Supply Pressure 7 inch w.c. (1.74 kPa) Min. Gas Supply Pressure 5 inch w.c. (1.24 kPa)

9
MAINTENANCE
The flames should look like those in Figure 13. To clean the
burner, use a soft brush after the burner and lava rocks have
cooled completely. Never use a vacuum cleaner on the lava rocks.
It is recommended that the lava rocks be stored indoors during
the winter if they will be subjected to freezing temperatures. The
propane cylinder must be disconnected and removed from the
appliance before the appliance can be stored indoors.
Figure 13
BATTERIES
Make sure the control knob is in the “OFF” position. Unscrew
the push button cap on the ignition module located on the control
panel to access the battery compartment. The ignition module
requires one AAA size battery. See Figure 14.
Figure14
Parts List
Part Number Description
FP0002 LAVA ROCKS
FP0003 ELECTRODE
FP0004 THERMOCOUPLE
FP0006 IGNITION MODULE
FP0008 NATURAL GAS FLEXIBLE CONNECTION HOSE
HW0036 1/4 X 20MM STEEL BOLT
HW0591 Ø6.5 X 2.0MM WASHER
HW0006 HEX BOLT DRIVER
FP1105 FIREPIT BASE
FC0553 FOOT CAP

10
90-DAY LIMITED WARRANTY
What is Covered Under This Warranty?
The item you have purchased is warranted against defects inmaterials and workmanship for the following parts as
outlined below only when unit is installed and operated in accordance with the instructions in this Owner’s
Manual and in compliance with local building and fire codes:
Burner Assembly
Firepit Base
Firepit Top
How Do I Obtain Warranty Service?
To obtain warranty service, you must contact our customer service center within the relevant warranty period and
provide us with a copy of your dated register receipt as proof of the purchase date. We reserve the right to request
photographs and/or return of the defective item(s) and/or such other evidence relating to any claim as we shall
reasonably require. Please call our customer service center at 713-690-1919 for additional warranty claim details
and procedures.
What are the Limitations and Exclusions of this Warranty?
Warranty Limitations:
This warranty is subject to the limitation set forth above. In addition, this warranty is made to the original
purchaser only and is effective only if items are purchased from one of our authorized dealers. This warranty is not
transferable. For warranty replacements based on warranty claims submitted within ninety (90) days of purchase,
we will not be responsible forcharges associated with shipments outside continental NorthAmerica at any time or
for any reason.
Warranty Exclusions:This warranty is subjected to the exclusions set forth above. In addition, the following are
excluded from coverage under this warranty: any item used for commercial, contract or any other non-residential
purpose; clearance items, display models or items purchased “as is”; freight damage; items subject to misuse,
abuse, neglect or lack of proper care or maintenance (including without limitation as provided in any “care and
maintenance guide” or similar information we provide); normal wear and tear; damage caused by acts of nature,
acts of force majeure, vandalism, fire or other causality, or improper assembly; hardware against corrosion or
rusting; purchased or replacement parts; andall plastic parts.Also excluded are loss of use or time; inconvenience;
money; travel; packaging; or incidental, special or consequential damages of any kind. Replacement of defective
items or parts as provided herein shall constitute your sole and exclusive remedy for items which are not as
warranted. In no event shall our responsibility exceed the purchase price of the item found to be other than as
warranted. This warranty is the exclusive statement of your rights with respect to items you have purchased and
supersedes any other express warranty or statement, written or oral, made in connection with the purchase and sale
of such items. The term ”item” when used herein in the singular refers to the specific piece found to be defective,
and not to the entire set of which the item is a part.
Some states do not allow exclusion or limitation of incidental or consequential damage, so that limitation may not
apply to you. This warranty gives you specific legal rights, and you may also have other rights that vary from state
to state
