EMME 21021-1 User manual

REPRODUCTION IS PROHIBITED
21021-1 : Portable Fire Exnguisher, 2 Kg ABC Powder
Emme Anncendio S.r.l.
www.emme-italia.com
Use and Maintenance Technical Manual
File name Type of document Fire Exnguisher Model Date Rele. Check Rev. Pag.
21021-1_Technical manual Use and Maintenance technical manual 21021-1 12/09/2022 M.R 11 di 8
Scan QR Code
and visit the
website to see
more details
about our
products
Via del Molino, 40 - 52010 Corsalone (AR) - Italy - in[email protected] - Tel. [phone]
Other branches Emme Anncendio s.r.l. in Italy : Milano - Padova - Reggio Emilia - Roma - P.IVA/ C.F. 11208251006 - R.E.A. FI-632545
FIRE
RATING :
APPROVED/CERTIFIED FIRE EXTINGUISHER:
• CYLINDER
In high-strength alloy steel,
deep drawing, external powder
painng Red Ral 3000.
• EXTINGUISHING AGENT
ABC Powder - MAP 20 %.
• PROPELLANT
Dehumidied air or nitrogen (N2).
• VALVE
M. 30x1.5, brass body, levers with
red painng Ral 3000.
• USE
A B C re rang
(solid materials, ammable liquids,
ammable gas).
Note: image is for illustrave purpose only, the product purchased can has some dierence
2 Kg powder re exnguisher, temperature range from -30°C to +60°C, manufactured in accordance to UNI EN 3-7,
(D.M. 7.1.2005), approved Marine Equipment Direcve MED 2014/90/EU, cered according to the direcve for
pressure equipment PED 2014/68/EU.
Quality Product cercaon guaranteed by Bureau Veritas Italia.
Suitable for use on re involving electrical voltages up to 1.000 V, at a distance of 1 meter.
89
13
B CA

21021-1 : Portable Fire Exnguisher, 2 Kg ABC Powder
File name Type of document Fire Exnguisher Model Date Rele. Check Rev. Pag.
21021-1_Technical manual Use and Maintenance technical manual 21021-1 12/09/2022 M.R 12 di 8
REPRODUCTION IS PROHIBITED
TECHNICAL SPECIFICATIONS
FIRE RATING 13 A 89 B C
EXTINGUISHING AGENT ABC Powder - MAP 20 %
EPW 18462 (ABC Favorit Tera - Rühl)
PROPELLANT Dehumidied air or Nitrogen (N2), 15 bar at 20°C
TEMPERATURE RANGE -30°C / +60°C
NOMINAL CHARGE 2 Kg
FULL WEIGHT
~
3,7 Kg
DIMENSIONS Height (base - valve) 380 +/- 5 mm
Diameter (cylinder) 110 +/- 2 mm
DISCHARGE TIME
~ 13,3 seconds
VALVE TIGHTENING TORQUE Minimum 45 Nm, Maximum 68 Nm
CYLINDER PRESSURE TEST PT 27 bar
CYLINDER VOLUME 2,5 L.
SAFETY DEVICE Set between 20 and 26 bar
CYLINDER MATERIAL Alloy steel
EXTERNAL TREATMENT Sandblast and powder painng,
Red Ral 3000 colour
TRANSPORT DISPOSAL
Land transport : Exempon for the purposes of ADR disposal 594
Ship Transport : IMDG Code - UN 1044 class 2.2 Fire Exnguishers
PACKAGING
(Note: the packaging quanes and measurements are indicave and can be subject at changes)
STANDARD
Note: minimum 8 pieces
Maximum nr. 256 pieces for pallet
(32 boxes with 8 pieces for each one)
Pallet dimensions 100x120 cm
ON REQUEST: SINGLE PACKAGING
- maximum 192 pieces on pallet 100x120

21021-1 : Portable Fire Exnguisher, 2 Kg ABC Powder
File name Type of document Fire Exnguisher Model Date Rele. Check Rev. Pag.
21021-1_Technical manual Use and Maintenance technical manual 21021-1 12/09/2022 M.R 0
REPRODUCTION IS PROHIBITED
3 di 8
COMPONENTS AND SPARE PARTS LIST
Table 1
1
1.1
1.2
1.3
1.4
1.5
1.6
1.7
1.8
5
2
3
4
1.9
6
7
The spare part at number 1 includes already all others components indicated from 1.1 to 1.9
NUM. DESCRIPTION CODE
1Valve M. 30x1.5 0211
1.1 O-ring valve n.a.
1.2 Valve stem 0241R
1.3 Internal spring of the valve 0251R-1
1.4 Tamper seal (red) 0286
1.5 Test valve for pressure gauge 1163
1.6 Dip tube holder 0253R-1
1.7 Safety device 0261R
1.8 Safety pin 0282-1
NUM. DESCRIPTION CODE
1.9 Dispensing nozzle 0287
2Safety pin seal (green) 0285
3 PVC dip tube 0152
4 Cylinder 0102
5 Pressure gauge 0271-1
6 Bracket 0327
7 Label 0052-2
"n.a." mean that the component is not available as single spare part

21021-1 : Portable Fire Exnguisher, 2 Kg ABC Powder
File name Type of document Fire Exnguisher Model Date Rele. Check Rev. Pag.
21021-1_Technical manual Use and Maintenance technical manual 21021-1 12/09/2022 M.R 0
REPRODUCTION IS PROHIBITED
Maintenance periods for eciency guarantee, methods
and subjects accredited for maintenance
3) INSTALLATION
1) Install the re exnguisher with the appropriate bracket, with the handle at a maximum recomended height
of 110 cm.
2) When installed in a vehicle the re exnguisher must be held in a specic truck bracket.
3) Do not expose the re exnguisher to the atmospheric agents or chemicals agents.
(Note: in these cases protect the re exnguisher with a special cabinet or protecve cover.)
4) Do not expose the re exnguisher to the direct sunlight.
5) Verify that the gauge pressure indicator is inside the green area.
6) Keep children away from re exnguisher.
7) For Marine equipment or outdoor installaon we recommend use of cover or cabinet.
1) GENERAL REQUIREMENTS
4 di 8
4) MODALITY AND PRECAUTIONS FOR THE USE
1) Follow the operang Instrucons printed on the main re exnguisher label
1) REMOVE SAFETY PIN 2) SQUEEZE GRIP LEVER 3) AIM THE JET AT
BASE OF FIRE
All Fire Fighng Fire Exnguishers produced by Emme Anncendio must be installed, inspected and maintained in
accordance with the following manual and with the rules in force in the country of desnaon.
All re exnguishers must be recharged aer paral use with original spare parts.
Every ordinary / extraordinary maintenance operaon must be carried out using original spare parts and compliant
with the declared cered prototype. The described below maintenance operaons must be carried out by
recognized personnel qualied by the company Emme Anncendio.
Fire exnguishers are classied into two categories that provide for specic construcon standards:
• portable re exnguishers: re exnguishers designed to be transported and operated by hand, with a mass not
exceeding 20 kg under operang condions. Reference standard: EN 3-7
• wheeled re exnguishers: wheel re exnguishers designed to be transported and operated by hand, with a mass
greater than 20 kg. Reference standards: EN 1866-1
Moreover, in relaon to the exnguishing agent contained in them, they are idened in:
• water based re exnguishers including foam exnguishers;
• powder re exnguishers;
• carbon dioxide re exnguishers;
• clean agent exnguishers
2)REFERENCE RULES
Fire Exnguishers produced by Emme Anncendio are manufactured in compliance with the following rules:
• EN 3-7: 2008 Portable re exnguishers;
• EN 1866-1: 2008 Wheeled re exnguishers;
• PED Direcve 2014/68/EU pressure equipment;
• MED Direcve 2014/90/EU devices for marine use (only for products bearing the relave MED cercaon
mark, see pag 1 of this document)

21021-1 : Portable Fire Exnguisher, 2 Kg ABC Powder
File name Type of document Fire Exnguisher Model Date Rele. Check Rev. Pag.
21021-1_Technical manual Use and Maintenance technical manual 21021-1 12/09/2022 M.R 0
REPRODUCTION IS PROHIBITED
5 di 8
2) Do not through the re exnguisher on to the direct ames.
3) This re exnguisher is a pressurized vessel and must not be pierced, dented or subjected to external damage.
4) Do not direct the jet on the people.
Ref. Periodicity Step Operaons
5.1 12 Months Ispecon Check internal pressure using an independent tool
5.2 5 Years Maintenance
Check the uidity of exnguishing agent.
Check the thread of the valve body
and if a non-compliance is detected, replace it.
5.3 10 Years
Hydrotest
Cylinder
Check the conservaon status and perform the hydraulic test
of the cylinder with suitable tool.
Is recommended the replacement of the dispensing valve
5.4 *20 Years Is recommended the replacement of the re exnguisher
5.2) Maintenance Steps
1Remove the re exnguisher from the bracket and check the xing stability.
Check the marking label and replace it if damaged
2 Discharge the re exnguisher from exnguishing agent, comply at rules for a correct disposal
3
Remove the dispensing valve.
Check the uidity of exnguishing powder, that agglomerates are not present in the cylinder
(if powder is suitable, can be reused for recharge the re exnguisher)
4Check internally the cylinder that no shows corrosion signs.
For the nozzle, check the internal passage with compressed air
5 Recharge the re exnguisher with exnguishing agent
6
Valve with
brass body
Check the thread of valve body with suitable tool and if damaged replace with a new valve.
For valves without safety device, replacement is recommended in any case.
Screw the valve with a ghtening torque as shown : min. 45 Nm - max 68 Nm
7 Pressurize the re exnguisher with dehumidied air or nitrogen (15 bar at 20 °C) and check for leaks
8Reset the safety pin and secure it with safety seal, screw the nozzle
9Record the inspecon acvity on the maintenance tag and on the re protecon register
* If it located in parcular environments the ming can be reduced.
(it is recommended to reduce to 10 years)
N.B. : All the operaons must be calculated from the date of placing on the market.
For the hydraulic test refer to the date stamped on the tank.
5.1) Inspecon Steps
1Remove the re exnguisher from the bracket and check the xing stability
2Check the internal pressure with an independent tool
3 Check the safety seal and the safety pin
4 Remove the hose and check the correct internal passage with compressed air
5 Record the inspecon acvity on the maintenance tag and on the re protecon register
5) STEPS AND FREQUENCY RELATED TO MAINTENANCE OPERATIONS
(For stored pressure re exnguishers)
Note: The user have to complies to the naonal or internaonal rules, if they are more restricve of the below table
Table 2

21021-1 : Portable Fire Exnguisher, 2 Kg ABC Powder
File name Type of document Fire Exnguisher Model Date Rele. Check Rev. Pag.
21021-1_Technical manual Use and Maintenance technical manual 21021-1 12/09/2022 M.R 0
REPRODUCTION IS PROHIBITED
6 di 8
5.3) Hydraulic test step
At least every 10 years from the producon date the re exnguisher must be overhauled by a hydraulic pressure
test in accordance with the pressure values “PT” stamped on the cylinder.
1Remove the re exnguisher from the bracket and check the xing stability.
Check the marking label and replace it if damaged
2 Discharge the re exnguisher from exnguishing agent, comply at rules for a correct disposal
3
Remove the dispensing valve.
Check the uidity of exnguishing powder, that agglomerates are not present in the cylinder
(if powder is suitable, can be reused for recharge the re exnguisher)
4Check internally the cylinder that no shows corrosion signs.
For the hose, check the internal passage with compressed air
5
Hydraulic test of the cylinder with suitable tool:
maintain hydraulic pressure at "PT" for 30 seconds and proceed with depressurizaon.
Check that the cylinder does not show any deformaon, breakage or stability anomalies
6 Proceed with the cylinder drying with suitable tool
7 Recharge the re exnguisher with exnguishing agent
8
Valve with
brass body
Is recommended the replacement of dispensing valve.
Screw the valve with a ghtening torque as shown : min. 45 Nm - max 68 Nm
9Pressurize the re exnguisher with dehumidied air or nitrogen (15 bar at 20 °C) and check for leaks
10 Reset the safety pin and secure it with safety seal, screw the nozzle
11 Record the inspecon acvity on the maintenance tag and on the re protecon register

21021-1 : Portable Fire Exnguisher, 2 Kg ABC Powder
File name Type of document Fire Exnguisher Model Date Rele. Check Rev. Pag.
21021-1_Technical manual Use and Maintenance technical manual 21021-1 12/09/2022 M.R 0
REPRODUCTION IS PROHIBITED
7 di 8
Execuve details Inspecon steps, Maintenance, Hydraulic test
1 - Remove the re
exnguisher from the
bracket; check marking label
and replace it if damaged,
check stability of the
bracket, cleaning,
general condions
2 - Discharge completely the
re exnguisher with
suitable tool.
Comply at local rules for the
correct disposal.
3 - Remove the valve.
Check the uidity of
exnguishing powder.
If necessary, replace with
new powder
4 - Perform an internal check of
the cylinder with an inspecon
lamp.
Verify that the
nozzle allows a correct air
passage and replace it
if necessary.
Replace the o-ring, clean and
grease the parts.
5- Hydraulic cylinder test:
maintain hydraulic pressure at
"PT" for 30 seconds and
proceed with depressurizaon.
6 - Cylinder drying
7- Recharge the
re exnguisher
with checked or new
exnguishing agent.
8 - Reinstall the dip tube and
dispensing valve.
Perform the operaon with
suitable torque wrench, making
sure you have set the correct
ghtening torque
9- Pressurize the re
exnguisher with a suitable
pneumac gripper and check
for any pressure loss using a
"leak detector";
to secure the device with
safety pin and safety seal
10 - Screw the nozzle,
check for the correct
pressure gauge
reading
11 - Record the inspecon acvity on the maintenance
tag and on the re protecon register
Note: images are for illustrave purpose only.

21021-1 : Portable Fire Exnguisher, 2 Kg ABC Powder
File name Type of document Fire Exnguisher Model Date Rele. Check Rev. Pag.
21021-1_Technical manual Use and Maintenance technical manual 21021-1 12/09/2022 M.R 0
REPRODUCTION IS PROHIBITED
8 di 8
6.1)Spare parts list
For the spare parts list see the table 1 at pag 3.
For more details see web site www.emme-italia.com
5.4) Twenty-year control
End-of-life re exnguishers must be disposed in accordance with local waste management rules.
Before disposal or disassembly, the re exnguisher MUST BE DEPRESSURIZED by a competent person.
Fire exnguishers should always be disposed of through an approved disposal company and in accordance with
applicable local and naonal codes.
* If the re exnguisher is located in parcular environments, the "life me" ming can be reduced
(see table 2 at point 5.4).
6.2)Inspecon/Maintenance Tools
For a complete list of recommended tools see web site www.emme-italia.com.
It is recommended to use instruments with controlled calibraon and periodically veried (at least every 12
months) with cered sample instrument.
6)SPARE PARTS LIST AND MAINTENANCE TOOLS
