Emmepi WOK-70 Assembly instructions

INSTALLATION, OPERATING
AND MAINTENANCE INSTRUCTIONS
700 PROFESSIONAL
mixerset07
cat n° 38
INDUCTION COOKERS
V 400 / 3
GB
WOK-70 702-M-I-D 702-M-I 704-M-I
ESWOK-70 ES702-M-I-D ES702-M-I ES704-M-I
WOK-70-2P WOK-70-6K WOK-70-3K
702-IND-7K 702-IND-12K 702-IMD-3K 702-IND-6K

Page2
CONTENTS
System plans Page 3
Generalinstructions Page 6
I. INSTALLATIONINSTRUCTIONS
1. Installationinstructions Page 7
1.1 Technicalplate Page 7
1.2 Technicaldata Page 8
1.3 Technicalfeatures Page 9
1.4 Generalnotes at delivery Page 9
1.5 Handling Page 9
1.6 Packaging Page 9
1.7 First start Page 9
2. Electric safety standards Page 9
3. Electric connection Page 10
II. OPERATINGINSTRUCTIONS
1. Inductiongenerator Page 11
1.1 Fields of use Page 11
1.2 Caution!Hazard! Page 11
1.3 Personnelqualification and training Page 11
1.4 Hazards caused by failure to observe the safety regulations Page 11
1.5 Safeusage Page 11
1.6 Safety of the user or personnel responsible for use Page 11
1.7 Safetyof the personnel responsible foruse Page 12
1.8 Safety during installation, maintenance and controls Page 12
1.9 Reproductionor use of unauthorised spare parts Page 12
1.10 Improperusage Page 12
III. ELECTRICOVENOPERATINGINSTRUCTIONS
1. Product-Technical data Page 13
1.1 Description of the product Page 13
1.2 Type and technical data Page 13
1.3 Running Page 13
2. Certifications Page 14
3. Transport Page 14
4. Installation Page 14
5. Pots and pans Page 14
6. Starting up Page 15
7. Switch off Page 15
8. Cleaningandmaintenance Page 15
8.1 Cleaning the glass Page 15
9. Procedure to follow if the appliance is not going to be used for some time Page 15
10. Procedureto follow in the event ofabreakdown Page 16
11. Assistance Page 17
12. Spare parts Page 17
13. Junkremoval Page 17

Page3
SYSTEMS PLAN
= V 400-3N
( WOK-70, 702-M-I-D, 702-M-I, 704-M-I )

Page4
(ESWOK-70,ES702-M-I-D,ES702-M-I,ES704-M-I)
= V 400-3N

Page5
= V 400-3N
(WOK-70-2P, WOK-70-6K, WOK-70-3K, 702-IND-7K, 702-IND-12K, 702-IND-3K, 702-IND-6K )

Page6
GENERAL INSTRUCTIONS
• Read the instructions contained in this booklet carefully as they provide important
information to ensure safe installation, use and maintenance.
•Keepthis bookletforany furtherreferenceby theoperators.
•After removing the packing, checkthat theappliance is not damaged.
•Shouldyou haveanydoubts, don’tusethe applianceandaddress toskilledtechnicians.
•Never leave thepacking components(plastic bags, foamedpolystyrene, nails,etc.) within the
reachof children since they are a sourceof potentialdanger.
•Before connectingthe appliancecheck thatthe specificationsindicated onthe dataplate (Pic. 1)
correspondto thoseindicated on the electrical mainssystem.
•Theappliance shouldbe used bytrained personnel only.
•Beforecarrying outanycleaning ormaintenanceoperations, insulatethe appliance fromthe
electricalmains system.
•Incase of damageor malfunctioning, alwaysdisconnectthe appliance.
•Any repair interventionshould be carriedout only byan authorizedafter-saleservicing centre.
•Always request theuse of originalspare parts.
•Thenon-compliance with theabovementioned instructions maycompromise the safetyofthe
appliance.
•This appliancemust beused forthe purpose for which it was designed.
•Theinstallation shouldbecarried outbyqualified personnelincompliance withtheinstructions
providedbythemanufacturer and withtheregulations inforce.
•Never wash theappliance withdirect high-pressure bolts of water.
•Don’tobstruct theopeningsand theheatinlets andoutlets.
•Always keep all the appliance elements cleanto avoid any risk of corrosion orany damage by
irritating agent.
•Always disconnect theappliance whenit is not in use.
•Electric safety ofthis appliance isassured only whenit isproperly connected toan efficient
earthingsystem, as provided by the electric safetyregulations inforce.
•It is necessaryto checkthis basic safetyqualification of thesystem byhighly skilled personnel.
Themanufacturercannot be consideredresponsible foranydamages causedby the non-earthing
ofthe installation.
•As forthe electricsystem itis necessary to provide for a switch having a controls opening
distance equal or superior to 3 mm: forexample:
-manual switch of proper capacity equipped withplug fuses;
-automaticswitch with propermagnetothermic relays.
•The appliance is to be furthermore includedin anequipotential system,whose efficiencymust be
checkedfollowingthe regulationsin force.
•The connection is made by a ven markedby " Equipotential "
•Thetrailing cableforthe connectionto the electricline should havelower characteristics thanthe
onewithH07RN-Frubber insulation.

Page7
ATTENTION
•Thisinstructionmanual is referred to " INDUCTION COOKERS " 700 Professional series.
• It is necessary to refer to it for any information concerning the appliance installation, use and maintenance.
•TheManufacturerdeclines any responsibility for damages resulting from the non-observance of the operating and
installation instructions or from an unsuitable use of the appliance.
• The Manufacturer doesn’t assume any responsibility in case the appliance connection shouldn’t be carried out
according to the regulations in force.
• This manual must be kept for all the life of the appliance and it should be kept at the disposal of the users in case of
need.
• The manufacturing co. declines every responsability for possible mistakes contained in this booklet imputable to
printing or transcription errors.
• It also reserves the right to bring changes to the product if retained useful or necessary whitout jeopardizing the
essential characteristics.
• The manufacturing co. declines any responsability for damages caused directly or indirectly due to erroneous
assembly, tampering, bad maintenance, lack of skill.
N.B. : “ If the equipment is placed against walls, dividing panels, wooden furnitures, etc....., these must be
of fire-proof material; if not, these must be covered with fire-proof material. In case of central
positioning of the equipment, their rear part should be protected with cohibented panels in order to
prevent accidents due to burns. Fire preventions rules must be carefully followed.
I. INSTALLATION INSTRUCTIONS
1. INSTALLATION INSTRUCTIONS
• Before proceeding with the installation peel off the protection film, remove any residual with a product suitable to
clean the stainless steel.
• Install the equipment orizontally obtaining the correct level bu means of the adjustable feet.
• The equipment can be installed alone or in a set taking care not to place it beside combustible products.
1.1 TECHNICALPLATE
• The identification plate (Pic. 1) is positioned externally, on the left side of the machine.
• The identification plate indicates all machine data necessary in case of failure or maintenance.
Pic. 1

Page8
1.2 TECHNICAL DATA
DIMENSIONS TOTAL WEIGHT VOLUME
mm nr. Kw. Kw. Kg m³
WOK-70 400x700x900H 1 3 3 400/3N+T 50-60 50 0,38
702-M-I-D 400x700x900H 1 3 3 400/3N+T 50-60 56 0,38
702-M-I 400x700x900H 23,5 7400/3N+T 50-60 56 0,38
704-M-I 800x700x900H 43,5 14 400/3N+T 50-60 102 0,75
GENERATORS
MODEL V. - Hz.
DIMENSIONS TOTAL WEIGHT VOLUME
mm nr. Kw. Kw. Kg m³
WOK-70-2P 400x1400x900H 2 3 6 400/3N+T 50-60 100 0,76
WOK-70-6K 400x1400x900H 2 3 6 400/3N+T 50-60 106 0,76
WOK-70-3K 400x1400x900H 1 3 3 400/3N+T 50-60 106 0,76
702-IND-7K 400x1400x900H 23,5 7400/3N+T 50-60 106 0,76
702-IND-12K 400x1400x900H 2 6 12 400/3N+T 50-60 106 0,76
702-IND-3K 400x1400x900H 1 3 3 400/3N+T 50-60 106 0,76
702-IND-6K 400x1400x900H 1 6 6 400/3N+T 50-60 106 0,76
MODEL GENERATORS V. - Hz.
DIMENSIONS TOTAL WEIGHT VOLUME
mm nr. Kw. Kw. Kg m³
ESWOK-70 400x700x270H 1 3 3 400/3N+T 50-60 32 0,38
ES702-M-I-D 400x700x270H 1 3 3 400/3N+T 50-60 32 0,38
ES702-M-I 400x700x270H 23,5 7400/3N+T 50-60 32 0,38
ES704-M-I 800x700x270H 43,5 14 400/3N+T 50-60 42 0,75
MODEL GENERATORS V. - Hz.

Page9
1.3 TECHNICALFEATURES
• Glazed 18/10 stainless steel .
• Feet adjustable in height in stainless steel.
1.4 GENERALNOTESAT DELIVERY
• On delivering it is necessary to check:
- the external packaging conditions;
- the general conditions of the machine;
- the conformity of this model with the data on the identification plate and in the users’manual;
- the conformity of the machine and its components with the order.
In case you have problems with the machine run, please apply to the reponsible of this supply.
1.5 HANDLING
• The instrument should be handled with a fork lift truck, but care should be taken not to damage the parts positioned
on the bottom of the instrument.
• Do not drag the instrument on the floor because you could damage the internal or external parts.
• When handling the instrument, protect your hands with heavy gloves.
1.6 PACKAGING
• Be careful not to damage the machine when you take it out of the packaging.
• Remove the protection film and clean the eventual glue marks with petrol or kerosene, don’t smoke, carry out the
operation away from heat sources.
• Do not spread in the environment or leave at children’s reach the packaging material.
1.7 FIRST START
• Clean the machine as indicated in the " Cleaning and Maintenance " chapter.
2. ELECTRICSAFETY STANDARDS
• The electric safety of the machine will be guaranteed only if the following basic conditions are respected:
- the power supply must be the same as the one indicated on the plate (± 10 %);
- connection to a suitable earth plug;
- connection to an equipotential protection system;
- connection to a switch complete with fuses for each pole;
- connection to a differential magnetothermic switch.
• Insert the plug into the socket or directly into the electric system ( with the apposite protection ).
• The cable does not have to be subjected to traction.
The manufacturer cannot be held responsible for eventual damages or losses caused by not having
operated in accordance both with the a.m. basic warnings and with all other conditions relating to the use
and the maintenance contained herein.

Page10
3. ELECTRICCONNECTION
• The electric connection must be performed by authorized pesonell in accordance with CEI standards.
• Before connecting the appliance check that the specifications indicated on the data plate (Pic. 1) correspond to
those indicated on the electrical and gas mains system.
• The electric connection is fixed type.
• Electric safety of this appliance is assured only when it is properly connected to an efficient earthing system, as
provided by the electric safety regulations in force.
•As for the electric system it is necessary to provide for a switch having a controls opening distance equal or superior
to 3 mm: for example:
- manual switch of proper capacity equipped with plug fuses;
- automatic switch with proper magnetothermic relays.
• It is necessary to check this basic safety qualification of the system by highly skilled personnel.
• The manufacturer cannot be considered responsible for any damages caused by the non-earthing of the
installation.
• The appliance is to be furthermore included in an equipotential system, whose efficiency must be checked following
the regulations in force.
• All equipments, when supplied without cable, must be connected with cable with a section suitable for the maximum
charge.
• In case the item is placed against a wall make sure that the latter is made of fire-proof material or high temperatures
resistant, in defect leave a 100 mm. space in between or insert a fire-proof insulating panel.
• The equipment must be included in a equipotential system : the connection is made through a terminal marked by
the symbol ( ) situated close to the terminal. The equipotential wire must have a minimum section of 6 mm².
WARNING: NEVER DISCONNECT THE EARTH WIRE (yellow-green)
• It is essential to earth the appliances: for this reason, it is necessary to connect the terminals marked by the
symbols (PE ; ) placed by the line arrival terminal boards to an efficient earthing, realised according to the
regulations in force.
THE MANUFACTURER DOESN’T ASSUME ANY RESPONSIBILITY IN CASE THIS SAFETY RULES
SHOULDN’T BE RESPECTED.

Page11
II. OPERATING INSTRUCTIONS
1SAFETY
1.1 FIELDS OF USE
Inductiongeneratorscan be installed in fitted hobs and free-standing cookersandshouldbe used for cooking, heating,
keeping things warm and roasting.
Allthe specific saucepans recommended for usefor induction cooking can be usedwith induction generators, such as
saucepans in cast iron and chrome-plated iron, as well as enamelled pans.
Theyshould have a diameter ofbetween 16 and 26 cm.
Induction generators should not be used to heat objects other than those listed above.
1.2 CAUTION- HAZARD
CAUTION
Incorrect usage and failure to comply with the instructions provided could cause injury or damage to people and
property.
CAUTION
Before using or carrying out maintenance work on the appliance, please read this use, maintenance and installation
manualcarefully.
HAZARD
Failure to follow the relative safety regulations, laws and directives could expose you to hazard.
HAZARD
The incorrect use or handling of the generators poses a hazard to people, animals and property.
Failure to ready and study this use and installation manual exposes you to hazard
1.3 PERSONNELQUALIFICATIONAND TRAINING
The personnel responsible for installing, commission, using and maintaining the appliance must be QUALIFIED or
AUTHORISEDby the manufacturer.
1.4 HAZARDS CAUSED BY FAILURE TOOBSERVE THE SAFETYREGULATIONS
Failuretoobservethe safety regulations can pose a hazard to people to the surroundingenvironmentandtheinduction
generatoritself. Failure to observe thesafety regulations causes the guarantee to become null and void, meaningthat
youwillno longer be entitled to replacements for damagedparts.Inparticular, failure to observe the regulations entails:
·risks of all kinds to people and property.
·hazards of all kinds to people and property.
1.5 SAFE USAGE
It is important to observe the safety regulations in the manual, and the relative national and international laws and
regulationsregardingelectricalsafety,nationalandinternationallawsandregulationsregardingsafetyintheworkplace,
and national and international laws and regulations on accident prevention.
1.6 SAFETY OF THE USER OR PERSONNEL RESPONSIBLE FOR USE
Electricalhazards should be excluded. Theinduction generator should be used by qualified personnel and it shouldbe
installedby a certifiedprofessionalincompliance with specific international,nationaland regional regulations onelectrical
and electronic appliances for collective use and civil and industrial electrical installations.

Page12
1.7 SAFETY OF THE PERSONNEL RESPONSIBLE FOR USE
The pyroceram area is heated by the heat of the saucepan.
To avoid burns, do not touch the heating zone.
To avoid excessive overheating, do not leave the empty saucepan on the heat or heat it for no reason.
When cooking with several saucepans at the same time, make sure that the handles do not cross each other and that
they are outside the field of induction.
The handles may become very hot depending on the type of material of which they are made.
Riskofburns!Werecommendusing oven gloves.
Saucepans must always be kept a small distance apart.
They should not touch each other.
When you remove the saucepan, it is advisable to switch off the cooking zone to prevent the heating system from
switching back on automatically should you happen to replace the saucepan.
Donotplace other material (paper, card, fabric, etc.) between thesaucepanand the cooking zone as it could catchfire.
Metal objects heat up very quickly if placed in the heating zone when it is in operation.
It is therefore advisable not to place objects other than saucepans on the induction hob (cans, closed tins, aluminium
trays, cutlery, rings, keys, watches, etc.)
People with pace makers should consult their doctor to find out whether they can work in the vicinity of a hob with
inductiongenerator.
Do not place credit cards, phone cards, tapes or other magnetic objects on the pyroceram plate with induction system.
The induction generator has an internal cooling system.
Make sure that the air inlet and outlet holes are not blocked by objects (paper, rags or other).
Thiscould cause overheating andlead the induction generator to switch itself off.
Do not allow liquids (water, oil or other) to enter the induction generator.
Do not clean the generator with a jet of water.
If the pyroceram top is cracked or broken, switch off the generator and disconnect the electricity supply.
Do not touch any of the internal parts of the induction generator.
1.8 SAFETYDURING INSTALLATION, MAINTENANCEAND CONTROLS
Thepersonnelresponsible for use must be qualified.
All installation, maintenance and control operations must be performed by personnel qualified to issue the relative
certificates requested by the relative authorities as regards safety
in the workplace.
Said personnel must study this manual in depth.
Only highly qualified personnel may install, maintain, service, repair and collect the induction generator component.
Said personnel must be trained by means of a specific training course authorised by the manufacturer as regards the
inductiongenerator.
Moreover,theymust meet the requirements set by the relative authoritiesasregardsthe electrical and electronic safety
of installations.
Generallyspeaking, workshouldonly becarriedouton theinductiongenerator componentafterit has beendisconnected
from the electricity supply.
The induction generator must be switched off and disconnected from the power supply and electricity network.
The safety and protection installations must be replaced and reinstalled at the end of the above operations, according
with the international, national and regional regulations and laws on safety,thusensuring correct and safe usage of the
component.
1.9 REPRODUCTION OR USE OF UNAUTHORISED SPARE PARTS
Reproductionsor changes to the induction generator component arenotpermitted.
Contact the manufacturer if you observe any changes to the induction generator.
To ensure safety, always use original spare parts, authorised by the manufacturer.
Themanufacturer declines responsibility in theevent in which non-original spareparts have been used.
1.10 IMPROPER USAGE
The proper working order of the induction generator components is only guaranteed in the event of correct usage as
describedinthis manual and as regulated by the international, nationalandregionallaws and regulations on safety and
electromagnetic compatibility, which regulate components such as the induction generator.

Page13
III. TECHNICAL FEATURES
1. PRODUCT - TECHNICAL DATA
1.1 DESCRIPTION OF THE PRODUCT
Theelectromagnetic induction generators are used inprofessionalcatering.
Thanking to their compact dimensions they can be used in cooking plans and in support ovens with small dimensions
and they can be mounted in professional kitchen.
The electronic parts of the induction generator are covered by many protections in order to prevent any damages.
Thankingto this protections no noise canbebe heard even using different powers.
1.2 TYPESANDTECHNICAL DATA
-TypeRELD V3S R6000-R6000
-Power(KW)12000 Watt
-Voltage(VAC):400 VAC/3F+N+T
-Current(A): 8.6Ampère
-Frequency(HZ):50/60Hz
-Dimensions: See technical layouts
-Thickness:ceramic glass:6 mm
-Derating insertion :0 kw at 220°on the coil
-Maximumtemperature equipment: as for EN standard
TYPE WOK
-Type: REBS: V3S W6000
-Power(KW):6000 Watt
-Voltage(VAC):400 VAC/3F+N+T
-Current(A): 8.6Ampère
-Frequency(HZ):50/60Hz
-Dimensions: See technical layouts
-Thickness:ceramic glass:6 mm
-Derating insertion :0 kw at 220°on the coil
-Maximumtemperature equipment: as for EN standard
1.3 RUNNING
Max tolerance in voltage:
RatedVoltage:+6%
RatedVoltage:-10%
Frequency(HZ):50/60Hz
Minimumdiameter of the pan:160 mm
Environnmenttemperaturerange:from+5°to+40°
Max dampness air : from 30% to 90%

Page14
2. CERTIFICATIONS
The induction generators must be considered “components” and not “finished products” and so they are submittted to
the controls of the IMQ, “Istituto del Marchio di Qualità”(Quality Brand Institution), in order to obtain the SCV-IMQ, the
“certificatodi sorveglianza” ( “the supervision certificate”) according to the following regulations:
STANDARDONELECTROMAGNETIC COMPATIBILITY
EN 61000 3-2::1995+A1; 1998+A2: 1998+A14: 2000
EN61000 –3-3 1995
EN55011: 1998
EN55014: 1997
STANDARDONELECTRICAPPLIANCEFORCOLLECTIVE UTILISATIONANDSIMILAR
En 60335-2-36: 2000 (PAR10,17, 19.11, 24,25,26)
-markCSV-IMQ
3. TRANSPORT
-Theinductiongeneratorsarecarefullypacked.Handlewithcare,andcheck the conditions of the packaging as soon as
you receive the goods. In case of damage, please contest the forewarder at the soonest.
-Storage: if the induction generator is not installed immediately, please store it without removing the packaging, at a
temperature range between 20° and 50°and dampness from 10% to 90%.
-Remove the packaging only in case of immediate installation.
-Keep the packagings materials in case of return of the goods to the supplier.
4. INSTALLATION
Theinduction generators must be considered “components”and not “finished products” soyou must respect the laws,
the regulations and the standards in force in the different countries as far as low and medium voltage are concerned.
You also must respect the regulations on security of electric appliances for collective utilisation and the regulations on
electromagnetic compatibility.
Tofind copy oftheseregulations please contacttheauthorizedinstitutions in thedifferentcountries where the installations
will be done.
Each generator is equipped with its electric layout showing the harness and its relatives connections.
On the layouts there are all the indications and all the references you can find also in the electrical and electronic
parts, in order to avoid any mistake in connecting the parts.
The layouts are attached to this manual”
5. POTS AND PANS
Induction generators only work properly with saucepans with an iron, cast iron or chrome-plated iron base.
These pans may also be enamelled.
The generators accept all the above type of saucepans and adapt in real time to supply the same power.
The pans must have a diameter of between 160 mm and 260 mm.
It is best for the bans to have a flat base.
The generator does not accept unsuitable pans.
Any other product no mentioned in this paragraph should be considered automatically excluded and unsuitable for use
with induction generators.

Page15
6. STARTING UP
CAUTION: The heating zone is heated by the heat emanated by the base of the saucepan. To avoid burns
and injury, do not touch the heating zone.
a) Connect the appliance to the power supply after making sure that the voltage corresponds to that used by the
inductiongeneratorand indicated on the manufacturer’s plaque.
b) Place the saucepan directly above the cooking zone where the inductors are located.
c) Turnthe knob/potentiometer in a clockwise direction.To activate the power supply: the GREEN LED turnson.
Absence of the saucepan: the GREEN LED flashes.
d) Select the desired power using the knob/potentiometer, which will set the power immediately.
Whenyou remove the pan for awhile, theinductorwill stop supplying power, and when youreplacethe pan the
power will be restored immediately at the same level as before.
For safety reasons, if the pan is removed for more than 600 seconds, the induction is switched off completely
and will need to be switched back on if the pan is replaced, restoring the knob/potentiometer to the “OFF”
position and then back to the desired power by turning the knob in a clockwise direction.
7. SWTCH OFF
-Turn the knob/potentiometer in a clockwise or anticlockwise direction until it is in the rest position [OFF]
-Certain parts of the generator are still powered even when the cooker is switched off.
Therefore, if carrying out maintenance work, disconnect the appliance from the power supply first.
-Make sure that no liquid penetrates the induction generator, either during normal use or during cleaning and
maintenanceof the component.
8CLEANING AND MAINTENANCE
CAUTION: During cleaning, do not wash the external parts of the appliance with direct or high pressure
water jets.
Everyevening, after use, cleanthe appliance thoroughly.
Daily cleaning after switching off the appliance ensures the perfect functioning and long life of the appliance.
Before starting to clean the appliance, disconnect the power supply.
The steel parts must be washed with hot water and neutral detergent, then rinsed thoroughly in order to eliminate all
traces of detergent.
They should then be dried with a dry cloth.
Do not use abrasive or corrosive detergents.
8.1 CLEANING THE GLASS
Theglass should be washed withvinegar or lemon-based degreasers, suitable for cleaning ceramics and glass.
Duringthis operation, it is bestfor the glass not tobe completely cold, so thatspilt food, burnt fat andother substances
canbesoftened with a damp cloth and removedwhilststill warm with a scraper, so as topreventtheglass surface from
deteriorating.
Do not use abrasive or corrosive detergents.
9. PROCEDURE TO FOLLOW IF THE APPLIANCE IS NOT GOING TO BE USED FOR SOME TIME
Clean and dry the appliance carefully according to the instructions. Disconnect the power supply.

Page16
10. PROCEDURE TO FOLLOW IN THE EVENT OF A BREAKDOWN
−CAUTION:NEVERcarry out any work on the induction generatorswithoutfirsthaving disconnected them from the
power supply .
−HAZARD: high voltage present in induction generators powered by the electricity supply .
−Theinduction generators should only be openedbyQUALIFIED,AUTHORISED PERSONNEL IN COMPLIANCE
WITHINTERNATIONAL,NATIONALANDREGIONALSAFETYLAWSANDREGULATIONS.
POSSIBLE CAUSE STEPS TO BE TAKEN
Green LED off
Red LED off. No power
Check that the generator is connected to
the power supply
Green LED on
Red LED off. Make sure you have turned the knob in a clockwise direction Turn the knob
Make sure you have positionned the
suitable saucepan correctly Position a suitable saucepan correctly
Defect control form Call a technician
Air inlet or outlet blocked. Check and clean air inlet and outlet
Defective fan Call a technician
Unsuitable saucepan Use a suitable saucepan
Empty cooking protection triggered it to
cool down. The fan is over 220°C. Verify that the generatur is power supplied
Cooking point sensor defective Call a technician
Saucepan diameter under 160 mm
saucepan. Use a suitable saucepan
Saucepan not positioned correctly and
thus not recognised Position the saucepan correctly
The power component is too hot and
has switched on the power reduction
automatically
Make sure that the saucepan is suitable.
Internal temperature high due to
insufficient cooling
Unsuitable saucepan Replace with a suitable saucepan
Green LED on
Red LED on
Fast increase in pyroceram
temperature. You may be using an
empty saucepan
Adjust the power on the basis of the
quantity of food
Green LED flashing
Red LED off Saucepan recognition not correctly regulated Call a technician
TYPE OF FAULT
Green LED flashing
Red LED off.
Poor heating
Green LED on
Red LED flashing
No heating (the power part of the generator is too hot)
Green LED on
Red LED on
Green LED on
Red LED flashing
Heating of small metal objects on the zone
Green LED flashing
Red LED off.
No heating
No heating (the induction component under the pyroceram is too hot)

Page17
11. ASSISTANCE
The user must be sure that all the components always work properly
The induction generators must be checked at least once a year by a qualified technician.
12. SPARE PARTS
The customer can’t install or replace spare parts.
13. JUNKREMOVAL
When a component of induction generator is out of use , it must be removed properly in compliance with the regional,
national,international regulations in force in the different countries asfar as junk removal isconcerned.
Avoidimproper use:
Thecomponents of induction generators must not be used byunauthorized personnel.
Preventanycomponent ready to be removed to work again.
Thesecomponents are made of electric,electronic, mechanic, electromechanic parts
The user is responsible of the safe and correct removal of the induction generator and of its components too.
Any kind of maintenance must only be done by qualified personnel.
