Empava EMPV-36RH09 User manual

EMPAVA APPLIANCE INC.
Add: 15253 Don Julian Rd, City of Industry, CA 91745
Tel: [phone]
www.empava.com
RANGE HOOD
Installation and Operation
Manual

TECHNICAL CHARACTERISTICS ....................................1
IMPORTANT SAFETY INSTRUCTIONS .........................2-3
INSTALLATION REQUIREMENT........................................4
INSTALLATION PROCEDURES......................................5-7
OPERATING INSTRUCTION...........................................7-8
MAINTENANCE.................................................................9
TO REPLACE LIGHT ........................................................9
TROUBLE SHOOTINGS....................................................10
MAIN PARTS NAME .....................................................11-13
CONTENTS
READ AND SAVE THESE INSTRUCTIONS MANUAL
Please note that this product is marked with this symbol:
According to Wsate of Electrical and Electronic Equipment
(WEEE) directive, WEEE should be separately collected and
treated. If at any time in future you need to dispose of this
product, Please dp NOT dispose of this product with house hold
waste. Please send this productto WEEE collecting points where
available

Dear consumer,
Thanks for your purchase of our range hood and we hope
we can fully satisfy all of your needs. Please read the entire
instructions carefully before proceeding to obtain the best
results of operation the range hood.
Model number: EMPV-36RH09 EMPV-36RH10
Total power: 208W
Motor power: 200W
LED Lights: 4x2W
Voltage: 120V
Frequency: 60Hz
Filter: Baffle filter
Control: Touch Control
TECHNICAL CHARACTERISTICS
MAIN PARTS NAME
Glass
EMPV-36RH09
Ceiling cover
Inner duct cover
Outer duct cover
Expansion Hanger
Blower box
Vent pipe
Filter
EMPV-36RH10
Filter
Glass
Blower box
Vent pipe
Expansion Hanger
Outer duct cover
Inner duct cover
Ceiling cover

25"-47.64"
3"
23.62"
29.53"/35.43"
11.81"
12.4"
29.53"/35.43"
11.81"
12.4"
22.93"-45.47"
23.62"
2.36"
EMPV-36RH09 EMPV-36RH10
Dimentions
IMPORTANT SAFETY INSTRUCTIONS:
Do not connect the air
outlet to chimney flues or
combustion gas ducts
Do not leave naked
flames under the hood

In case of any damage
to power cable, replace
the broken cable with a
new one by qualified
person.
Do clean the hood
correctly in accordance
with instruction stated or it
might cause the possibility
of fire accident
To replace the light
should be undertaken by
a qualified electrician or a
competent person. Always
use the LED light no
more than 2W.
Wear the protective
glove before you start to
clean the hood. Remove
the components gently
during carrying out the
clearance.
Never wash the control
switch with water or other
kind of liquid for the liquid
might cause electrical
problem to the hood.

electrical shock.
range
INSTALLATION:
USE ONLY WITH RANGE HOOD CORD CONNECTION KITS THAT HAVE BEEN
INVESTIGATED AND FOUND ACCEPTABLE FOR USE WITH THIS MODEL
RANGE HOOD. A UTILISER SEULEMENT AVEC UNE TROUSSE DE
RACCORDEMENT DE CORDON DE HOTTE VERIFIEE ET APPROUVEE
POUR EMPLOI AVEC CE MODELE DE HOTTE.
INSTALLATION REQUIREMENT
1. Do not install the range hood where there are many doors ro windows
in order to avoid effecting the exhaust efficiency of the hood that caused
by air convection. (fig.1)
2. Install the range hood right above the cooking surface. The recommended
distance between the cooking surface and the lower edge of the range hood is
minimum 27.56" to maximum 31.5". (Fig.2)
3. In order to get the best performance, do not extend the vent pipe too long,
and try to make the bend of the vent pipe less and straight, make sure the vent
pipe connection is firm and air proof. (Fig.3)
4.After hanging the range hood on the wall, make sure the hood is level and
vertical. (Fig.4)
5. The air Outlet is not allowed to connect to chimney flues or combustion gas
ducts. The air outlet should under no circumstances be connected to ventilation
ducts for room in which fuel-burning appliances are installed.

NO T LE V ELNO T LE V EL
CO R R E CT N O T C O R R EC T
27.56-31.5"
27.56"-31.5"
Step 1:
Fix the position of the range hood
in accordance with the recommended
height between 27.56"-31.5" from
the cooking surface and the lower edge
of the hood.
Step 2:
Put vent pipe (set the vent pipe into
the outlet of the blower box, screw up
2pcs M4 screws to fix).
INSTA L L AT I O N P R O C E D U R E S
SAFETY WARNING
HOOD MAY HAVE VERY SHARP EDGES; PLEASE WEAR
PROTECTIVE GLOVES IF IT IS NECESSARY TO REMOVE
ANY PARTS FOR INSTALLING, CLEANING OR SERVICING.
Vent pipe
Air Outlet
M4 screws

7.76"
7. 76 "
Step 6:
As per the screw positions on the
upper support frame, drill 4 holes
(about Φ0.31"), then fill the
expanding rubber into the holes.
Aiming the holes on the ceiling, fix
the ceiling cover with the expanding
screws tightly and make sure it is firm.
Step 5:
Put the inner duct cover and outer
duct cover on the blower box.
The pull out the exhaust pipe to
the level of the inner duct cover.
Expansion hanger
Step 3
Match the 8pcs expansion hanger
with the hoods assembly.
16pcs screws
16pcs nuts
Step 4:
Use 16pcs M4 screws to fix the
hangers.
Step 7:
Install expansion strip with the ceiling
cover (Upper one).

Light Timer Speed down Speed up Max speed On/off
Turn on and turn off the light
Set time
Speed down, from speed 3 to speed 1
Speed up, from speed 1 to speed 3
To start max speed
To turn on and turn off the power
Time setting: Press for approximately 3 seconds.
Touch (Speed up) to set hour.
Touch (Speed down) to set minute.
OPERATING INSTRUCTION
1.How to use the Touch Control
Press to turn on /off the light.
Press to select the high speed.
Press to select the medium speed.
Press to select the low speed.
Press to select on/off.
1). Electronic Switch
2). Touch Control
Step 8:
Pull the inner cover to the
ceiling, aiming the upper support
frame, fix it with M4*12 screws
provided.
Step 9:
Install grease filter. Match the fix
pin to the fix hole and button the
filter gently as the direction of
arrow A.

To replace Led light (Pic.1)
Сaution: LED light can not replace a new bulb, just replace a new
LED light assembly.
Make sure all the control switches are off, and the range hood is
unplugged! Please follow below instructions:
1. Take out the filters, and cut off the wire connection of the light.
2. Press the spring according to the arrow direction, then you can take
off the LED light.
3. You can replace a new LED assembly no more than rating.
4. Then put the light assembly to the hood in reverse direction. Connect
the wire of the lamp.
5. Fit on the filters.
MA I N TE N A NC E
CAUTION: NEVER PUT YOUR HAND INTO THE AREA HOUSING
WHILE THE FAN IS OPERATING.
FOR THE OPTIMAL LEVEL FO OPERATION, CLEAN THE RANGE
HOOD SURFACE, AN AND ALUMINUM FILTER REGULARLY.
1. Use only mild soap or detergent solutions to clean the range hood
surface. Dry surfaces using soft cloth.
2. Using a stainless steel cleaner to bring the
glow back into a stainless finish.
3. Clean the filter once a week or according to use
status. Press the buckle of the filter slightly,
take off the filter and put it into warm soapy
water using mild detergent, wipe the filter with
soft brush. Replace the filter after it’s dry.
4. Clean the motor fan and other inside parts once half year or according
to use status by QUALIFIED PERSON.
5. DO NOT clean motor with water or other liquid.
TO R E PL A CE LI G H T

WARNING – TO REDUCE THE RISK OF A RANGE TOP GREASE FIRE:
a) Never leave surface units unattended at high settings. Boilovers cause smoking and greasy
spillovers that may ignite. Heat oils slowly on low or medium settings.
b) Always turn hood ON when cooking at high heat or when flambeing food (i.e.Crepes Suzette,
Cherries Jubilee, Peppercorn Beef Flambe’).
c) Clean ventilating fans frequently. Grease should not be allowed to accumulate on fan or filter.
d) Use proper pan size. Always use cookware appropriate for the size of the surface element.
WARNING – TO REDUCE THE RISK OF INJURY TO PERSONS IN THE EVENT OF A RANGE
TOP GREASE FIRE, OBSERVE THE FOLLOWING: SMOTHER FLAMES with a close-fitting lid,
cookie sheet, or metal tray, then turn off the burner. BE CAREFUL TO PREVENT BURNS.
If the flames do not go out immediately, EVACUATE AND CALL THE FIRE DEPARTMENT.
b) NEVER PICK UP A FLAMING PAN – You may be burned.
c) DO NOT USE WATER, including wet dishcloths or towels – a violent steam explosion will result.
d) Use an extinguisher ONLY if:
1) You know you have a Class ABC extinguisher, and you already know how to operate it.
2) The fire is small and contained in the area where it started.
3) The fire department is being called.
4) You can fight the fire with your back to an exit.
WARNING: TO PROVIDE PROTECTION AGAINST ELECTRIC SHOCK, CONNECT TO
PROPERLY GROUNDED OUTLETS ONLY.
A UTILISER SEULEMENT AVEC UNE TROUSSE DE RACCORDEMENT DE CORDON DE
HOTTE VÉRIFIÉE ET APPROUVÉE POUR EMPLOI AVEC CE MODÈLE DE HOTTE.
WARNING - To Reduce The Risk Of Fire Or Electric Shock, Do Not Use This Fan With Any
Solid-State Speed Control Device. AVERTISSEMENT : NE CONVIENT PAS A DES
REGULATEURS DE VITESSE A SEMI-CONDUCTEURS.
GROUNDING INSTRUCTIONS
This appliance must be grounded. In the event of an electrical short circuit, grounding
reduces the risk of electric shock by providing an escape wire for the electric current. This
appliance is equipped with a cord having a grounding wire with a grounding plug. The plug
must be plugged into an outlet that is properly installed and grounded.
WARNING – Improper grounding can result in a risk of electric shock.
Consult a qualified electrician if the grounding instructions are not completely understood,
or if doubt exists as to whether the appliance is properly grounded.
Do not use an extension cord. If the power supply cord is too short, have a qualified electrician
install an outlet near the appliance
CONSIGNES DE MISE A LA TERRE
Cet appareil doit être mis à la terre. En cas de court-circuit, le fil de mise à la terre limite le
risqué de choc électrique parce qu’il assure le retour du courant à la terre. L’appareil est
livré avec un cordon muni d’un fil de terre et d’une fiche de mise à la terre, qui doit être
branchée sur une prise mise à la terre correctement installée.
AVERTISSEMENT — Une mise à la terre incorrecte peut entraîner des risques de choc
électrique. Consulter un électricien compétent en cas de doute sur ces consignes de mise
à la terre ou en cas d’incertitude concernant la mise à la terre correcte du circuit sur lequel
l’appareil est branché.
Ne pas utiliser de cordon de rallonge. Si le cordon d’alimentation est trop court, faire installer
une prise par un électricien compétent à proximité de l’appareil.
WARNING - TO REDUCE THE RISK OF FIRE, USE ONLY METAL DUCT WORK.

TROUBLE SHOOTING
CAUTION: Disconnect the power supply before servicing.
Status Cause and Method of Repairing
Tools required
No power
Check circuit breakers
If the power supply is damaged,
please call for a qualified person
Philips
Screwdriver
Philips
Screwdriver
Philips
Screwdriver
Philips
Screwdriver
Philips
Screwdriver
Philips
Screwdriver
The motor
does not run
a).The motor is broken, replace motor.
b). The switch control is broken, replace switch.
c). The capacitor is broken, replace capacitor.
Body
vibration
a).The installation is not correct, check it and
make sure the hood is level.
b). The fan is broken, replace motor assembly.
c). The fan motor was not properly installed,
check and make sure it is firmly installed.
Noise
vibration
Something dropped into the blower, check
and clean blower.
Weak
suction
a). The distance from the range hood to cooking
surface is too far, make sure the distance
between bottom of the hood to cooking surface
is minimum 24" to maximum 27".
b). Windows, doors and drafts can effect the
performance of the range hood.
c). There are other air conditions effecting the
vent pipe, make sure lower vent pipe’s exit
is in a downward direction.
d). The running rate of the motor slows down,
replace the motor or capacitor.
If the range hood is near the window,
the best solution is to protect the back of the
range hood from draft caused by a window or
door.
Light does
not work Replace LED lamp.
