52X DDS CD-RW Drive
1
INTRODUCTION
Thank you for the purchase of this perfect and compact dual digital storage
drive with the combination of an IDE CD-ReWritable drive and a USB-
connected card reader.
This drive backs up all writing modes and different CD formats. It supports
maximum 52x speed writing ability on CD-R discs, 32x speed on CD-RW
discs and 52x speed reading performance. Other than that, the built-in 7 in
1card reader which offers read-write capabilities of 7 memory card types
simplifies the process of exchanging data between digital cameras, voice
recorders, PDAs, MP3s… and your computer.
With this multi-functional solution and the bundled software package, you
can view, archive, or write files/photos/video/music directly from the drive
and enjoy the fascinating digital entertainment on your desktop.
Here are some important features:
♦ Easy installation with CD-RW drive of EIDE and card reader of USB
2.0 interface (on-board connection)
♦ 8X, 16X, 24X, 32X, 40X, 48X and 52X writing speed on CD-R media
♦ 4X, 10X, 12X, 16X, 20X, 24X and 32X writing speed on CD-RW
media
♦ Adopts “MTKSuperLink” to prevent Buffer Underrun
♦ Supports MultiRead function
♦ Supports writing modes of TAO, DAO, SAO and packet writing
♦ Four-slot integration of the card reader works with CompactFlash,
MicroDrive, Memory Stick, Memory Stick Pro, MultiMediaCard,
Secure Digital, and SmartMedia
♦ Convenient connection with A-Type USB Extension Port on the front
panel

52X DDS CD-RW Drive
2
System Requirements
For IBM compatible PCs, the system requirements recommended are as
follows:
♦ Pentium II 350MHz above with at least 64MB of memory
♦ Fast and sufficient hard disk space (minimum 200MB for installation,
1GB or more is recommended.)
♦ IDE host interface supporting ATAPI MMC command & USB host
interface (if you don’t have USB on-board connection)
♦ Operating system: Microsoft Windows 98SE/ME/2000/XP
Package Contents
♦ 52X DDS CD-RW Drive
♦ Audio cable
♦ Application software disc
♦ Quick Installation Guide

52X DDS CD-RW Drive
3
INSTALLATION
Host Interface Connections
Most current motherboards have two IDE ports (primary and secondary)
which can connect two IDE cables. Two IDE cables allow you to connect
up to four devices, but it is recommended that you separate IDE ports for
your hard disk and your CD-ReWritable drive. This will ensure that your
hard disk’s performance and speed won’t be affected by having the CD-
RW drive on the same cable.
Cable Select
Slave
Master
If you connect only one device on the cable, you can set the jumper as
“MASTER” or “SLAVE”.
If you connect two devices (e.g. CD-ROM & CD-RW) on the same cable,
set different jumpers for each device (CD-ROM as “MASTER”, CD-RW as
“SLAVE” and vice versa.) The same rule applies to the connection of
having your hard disk and another device on the same cable.
Master
Cable Select
Slave
Jumper

52X DDS CD-RW Drive
4
Hardware Installation
1. Turn off the power to the computer system.
2. Disconnect the power cord and all cables from the back of your
computer, and then remove the cover of the computer.
3. Insert the drive into one of the vacant 5.25" drive bays and secure it
with screws to your PC.
4. Connect one end of the 40-pin IDE cable to the IDE connector of this
drive and the other end to the IDE port on your motherboard. Also,
connect the power supply cable to the back of the drive.
Power In
Audio Out
Digital
Audio Output red edge
 Make sure to align and connect the red-edge of the IDE Cable to Pin
1 on the drive.
5. If you have a sound card that can be connected to this drive, you can
connect the drive (as Audio-out) and the sound card (as Audio-in)
with a 4-pin audio cable.
If your motherboard is integrated with built-in sound system, plug the
4-pin audio cable into the CD-IN connector on the motherboard as
Audio-in.

52X DDS CD-RW Drive
5
6. Connect the USB cable at the back of the drive to the USB header
on the computer’s motherboard. The red wire of the cable needs to
be plugged into Pin 1 on the board.
 This drive supports USB 2.0 and if you connect to USB 1.1
connector, only transfer rate of USB 1.1 will be available.
If the connection is correct, the lower right LED on the front panel
will light green.
7. Re-attach the cover of your computer, and reconnect the power
cord and all cables.
USB Header
2 / 7
White/D-
Braided Shield Ground
Error-Proof Pin
Black/Ground
Green/D+
5
10
4 / 9
3 / 8
Mother
Board
Signal
Red/Vcc
Pin#
1 / 6
IDE
Red Wire
Error-Proof Pin
USB
Red Wire

52X DDS CD-RW Drive
6
Software Installation
The bundled mastering software gives you the complete solution for
making audio/data CDs. With the user-friendly interface, it guides you
through the creation and backup of files/photos/video/music from your
computer to a recordable compact disc. Combining of the card reader
capabilities, no matter you are a novice or an experienced user; you can
enrich your digital life with this best recording tool.
Windows Environment
1. Insert the application CD and the installation program will run
automatically. Then follow the on-screen procedures.
Or
2. Run:\setup.exe on the application CD.
