Encore ENPWI-SG User manual

Wireless 802.11 Super-G PCMCIA Adapter
ENPWI-SG
Product Description
The Super-G PCMCIA Wireless Adapter is capable of transferring file at 108Mbps. That’s
2x faster than normal 802.11g. Supports WPA and WEP for your protection and is
backwards compatible with 802.11b and 802.11g devices. Installation is quick and easy
using the included software. Perfect for increasing wireless speed and performance on
your laptop.
Product Features
• Compatible with IEEE 802.11g high rate standard to provide wireless Ethernet speeds
of 54Mbps data ratestandards
• Dynamic date rate scaling at 54, 48, 36, 24, 18, 12, 9 and 6Mbps for 802.11g
• Dynamic date rate scaling at 11, 5.5, 2 and 1Mbps for 802.11b
• Supports Super GTM technology data rate up to 108Mbps
• Maximum reliability, throughput and connectivity with automatic data rate s witching
• Supports wireless data encryption with 64/128-bit WEP standard for security
• Supports WPA-PSKu Integrated microstrip dual diversity antenna for the multi-path
environment
• Drivers support Windows 98(SE), 2000, ME and XP
• Simple user setup & diagnostics utilities
• Type approval compliant with FCC Part 15.247 for US, ETS 300 328 for Europe
Encore Electronics 2006
www.encore-usa.com
ENPWI-SG

Figure 1 Usage Diagram
Specifications
Radio Technology
IEEE 802.11g Orthogonal Frequency Division
Multiplexing (OFDM) IEEE 802.11b Direct
Sequence Spread Spectrum (DSSS)
Interface
CardBus Type II specification 32bit data bus
Transmission Rate 1, 2, 5.5, 6, 11, 12, 18, 24, 36,
48, 54Mbps (auto sense) 108Mbps for Super G™
Technology
Receiver Sensitivity
54Mbps: Typical - 75dBm @ 10% PER 11Mbps:
Typical - 85dBm @ 8% PER Wireless LAN
Frequency Range 2412 ~ 2484 MHz ISM band
(channels 1 ~ 14)
Modulation Schemes
DBPSK/DQPSK/CCK/OFDM
Media Access Protocol
CSMA/CA with ACK
Transmit Power
Minimum 17dBm typically @ 802.11b
Minimum 14dBm typically @ 802.11g
Channel
USA: 11
Europe: 13
Japan: 14
Driver Support
Windows 98(SE)
Windows 2000
Windows ME
Windows XP
Security
64/128-bits WEP Encryption/Decryption
WPA-PSK (Wi-Fi Protected Access Pre-Shared
Key) WPA
Range Coverage
Indoor: 35 ~ 100 meters (depends on
environment) Outdoor: 100 ~ 300 meters
(depends on environment)
Roaming
Full mobility and seamless roaming from cell to
cell
Antenna
Integrated Microstrip dual diversity antennas
Continuous Current Consumption
250mA typ. for receive mode
350mA typ. for transmit mode
Diagnostic LEDs
Power & Link status
Dimensions (W x H x D) 118 x
54 x 7 mm (W x H x D)
Operation Temperature
0 ~ 40 oC
Storage Temperature
-10 ~ 70 oC
Humidity
10% ~ 95% RH, no condensation
Certifications
FCC Part 15.247 for US ETS 300 328 for Europe
