Encore ENXUS User manual

Quick Installation Guide
ENXUS
USB 3.0 to SATA II
ADAPTER

1
Hardware Description
Power/Activity LED: The LED remains lit to show that the drive is on, and blinks to
indicate drive activity.
Power Button: Press the Power Button to power on the hard drive
Application Diagram
Connect SATA devices by the 22 pin SATA combo male
connector and connect to computers by USB 3.0 port
Power / Activity LED Power Button
USB 3.0
Port
4-Pin Molex Power
Connector
22-Pin SATA DATA / POWER
Connecto
r

2
Hardware Installation
1. Connect SATA data/power connector to 2.5’’ or 3.5’’
SATA drive or 5.24’’ SATA device.
2. Connect the system power source to the adapter’s
4-pin Molex power connector.
3. Connect the USB 3.0 cable from the adapter to an
available USB port on the computer system.
4. Press the power button on the top of the adapter.
The power LED should light up.
＊2.5” SATA device does not require external power. 3.5” and 5 ¼” SATA
devices require external power.
Driver Installation
Windows will automatically detect and install the drivers
for the USB 3.0 to SATA II Adapter
