ENRTR-514
4 Ports Broadband Router
The ENRTR-514 4 Ports Broadband Router is specially designed for small enterprise, office
and SOHO (Small Office / Home Office) to connect the Internet. ENRTR-514 uses advanced
WavePlus broadband router solution and provides a set of completely industry standard
features for high-speed Internet access. ENRTR-514 offers Quick Setup Wizard for easy
installation and friendly Help pages for each step.
The ENRTR-514 Broadband Router provides maximum transfer rate up to 90Mbps from
WLAN to LAN and 100Mbps from LAN to LAN. The ENRTR-514 Broadband Router also
provides many management functions and flexible access control; including DHCP Server,
Virtual Server, DMZ host, firewall, static routing table and limiting staff or user to browse
selected Web sites.
This product is made in ISO9001 approved factory and complies with FCC Part 15
regulations and CE approval.

Features and Benefits
Maximum transfer rate up to 90Mbps from WAN to LAN, 100Mbps LAN to LAN
Friendly GUI Configuration and Management software
Supports IEEE 802.3 full duplex flow control
Built-in DHCP server automatically assigns IP address to all workstations on your LAN.
Supports MAC filter, URL filter, Client and IP filter blocking and Hacker pattern setting
and detection
Supports ALGs (Microsoft NetMeeting, MSN Messenger, Windows Media Player,
DirectX 8.0, PPTP pass through, IPSec pass through, FTP, ICMP, SMTP, POP3, DNS,
Telnet, HTTP, HTTPS, H.323, SIP, Real Audio, CuSeeMe, AOL, and Games)
Specification
Data Transfer Rates WAN to LAN : up to 90Mbps, LAN to LAN : 100Mbps
Standard IEEE 802.3 10Base-T, IEEE 802.3u 100Base-Tx, RFC 2516 (PPP over
Ethernet)
Bridging IEEE 802.1x
Routing
Static Routing
RIP version 1 (RFC 1058) and version 2 (RFC 1723)
NAT (Network Address Translation)
NAPT (Network Address and Port Translation)
DHCP (Dynamic Host Configuration Protocol) Server/Client
Security & Management
Functions
Clone MAC
Supports DDNS
Configuration of NAT/NAPT
Supports Virtual Server and Virtual DMZ
Provides MAC filter, URL filter, and Client/IP filter
WAN, LAN, DMZ and AP statistics
Restore to Factory Default
System Log
UPnP, ALG and Help
Software Upgrade through Web
Firewall
Interface LAN x 4, WAN x 1

LED Indicators Power x 1, Status x 1, WAN x 1, LAN x 4
Power AC 9V, 1A
Dimension (L x W x H) 150mm x 75mm x 28mm
Net Weight 125g
Operating Temperature 0°C ~ 40°C (ambient)
Humidity 5 % ~ 95 %
Storage Temperature 0°C ~ 70°C
Supported OS Windows® 7/XP/2000, Windows Vista®, Mac® OS, UNIX®, Linux®
Web Browser Internet Explorer® 5.0, Firefox® 2.0 or Safari® 1.4 or higher
Broadband connection and Cable/DSL modem
Computers with wired network adapters
System Requirements
CD-ROM Drive
Regulations FCC Part 15 class B, CE
Package Contents
One 4 Ports Broadband Router
One External Power Adapter
One CD-ROM including user’s manual
※ The specifications and picture are subject to change without prior notice! Please refer to the directions in product package
