Endress+Hauser ASP 2000 User manual

BA080R/09/en/10.03
No.: 50092406
Stationary water sampler
asp-station 2000
Operating instructions

Brief operating instructions ASP station 2000
58 Endress+Hauser
Brief operating instructions
The following brief operating instructions will allow you to install and commission your
device in the correct order completely, quickly and easily:
Safety instructions → Section 1
1st step: Mount device → Section 3
2nd step: Connect hydraulics
Lay and connect sampling hose
→ Section 3.3.4
3rd step: Wiring → Section 4.1
4th step: Operation & calibration → Section 5
5th step: Commission device → Section 6
6th step: Operate device / device functions
Set device parameters and sampling programmes
→ Section 6.5
7th step: Maintain device
- Clean device
- Maintenance recommendation
→ Section 7

ASP station 2000 Table of contents
Endress+Hauser 59
Table of contents
1 Safety instructions . . . . . . . . . . . . . . . . 60
1.1 Designated use . . . . . . . . . . . . . . . . . . . . . . . 60
1.2 Installation, commissioning and operation . . 60
1.3 Operational safety . . . . . . . . . . . . . . . . . . . . . 60
1.4 Return . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
1.5 Notes on safety conventions and icons . . . . . 61
2 Identification . . . . . . . . . . . . . . . . . . . . . . 62
2.1 Device designation . . . . . . . . . . . . . . . . . . . . 62
2.1.1 Nameplate . . . . . . . . . . . . . . . . . . . . . 62
2.2 Scope of delivery . . . . . . . . . . . . . . . . . . . . . . 62
3 Installation . . . . . . . . . . . . . . . . . . . 63
3.1 Quick installation guide . . . . . . . . . . . . . . . . . 63
3.2 Incoming acceptance, transport, storage . . . 63
3.2.1 Incoming acceptance . . . . . . . . . . . . . 63
3.2.2 Storage . . . . . . . . . . . . . . . . . . . . . . . . 63
3.3 Installation conditions . . . . . . . . . . . . . . . . . . 64
3.3.1 Dimensions . . . . . . . . . . . . . . . . . . . . . 64
3.3.2 Installation site . . . . . . . . . . . . . . . . . . 64
3.3.3 Foundation plan . . . . . . . . . . . . . . . . . 65
3.3.4 Hydraulic connection . . . . . . . . . . . . . 65
3.3.5 Sampling with a flow assembly . . . . . . 66
3.4 Installation instructions . . . . . . . . . . . . . . . . . . 67
3.5 Post-installation check . . . . . . . . . . . . . . . . . . 67
4 Wiring . . . . . . . . . . . . . . . . . . . . . . . 67
4.1 Quick wiring guide . . . . . . . . . . . . . . . . . . . . . 67
4.1.1 Cable laying . . . . . . . . . . . . . . . . . . . . 67
4.1.2 Cable types . . . . . . . . . . . . . . . . . . . . . 67
4.1.3 Mounting the cover . . . . . . . . . . . . . . . 68
4.1.4 Mounting the rear panel . . . . . . . . . . . 68
4.1.5 Terminal assignment . . . . . . . . . . . . . . 68
4.1.6 Connecting the RS232 interface . . . . . 70
4.1.7 Connecting an RS232 interface. . . . . . 70
4.1.8 Connecting an RS485 interface . . . . . 71
4.1.9 Connecting PROFIBUS-DP (optional) . 71
4.2 Degree of protection . . . . . . . . . . . . . . . . . . . 71
4.3 Post-connection check . . . . . . . . . . . . . . . . . 71
5 Operation . . . . . . . . . . . . . . . . . . . . . 72
5.1 Quick operation guide . . . . . . . . . . . . . . . . . . 72
5.2 Display and operating elements . . . . . . . . . . 72
5.2.1 Display . . . . . . . . . . . . . . . . . . . . . . . . 73
5.2.2 Key assignment . . . . . . . . . . . . . . . . . 73
5.3 Local operation . . . . . . . . . . . . . . . . . . . . . . . 73
5.3.1 Enable configuration . . . . . . . . . . . . . . 73
5.3.2 Lock configuration . . . . . . . . . . . . . . . 73
5.4 Confirmation of error messages . . . . . . . . . . . 74
5.5 Communication using ReadWin®2000 . . . . . 74
5.6 Calibration . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
5.6.1 Tap calibration . . . . . . . . . . . . . . . . . . 74
5.6.2 Manual sample volume setting on stand-
ard device . . . . . . . . . . . . . . . . . . . . . . . 75
5.6.3 Dosing volume calibration for flow-propor-
tional sample using the “twiddle principle”
(optional) . . . . . . . . . . . . . . . . . . . . . . . . 76
6 Commissioning . . . . . . . . . . . . . . . . . . . 77
6.1 Function check . . . . . . . . . . . . . . . . . . . . . . . 77
6.2 Switching on the measuring device . . . . . . . 77
6.3 Quick Setup . . . . . . . . . . . . . . . . . . . . . . . . . 78
6.4 Device configuration . . . . . . . . . . . . . . . . . . . 79
6.4.1 Configuring the inputs . . . . . . . . . . . . 79
6.4.2 Configuring the internal datalogger
(optional) . . . . . . . . . . . . . . . . . . . . . . 80
6.4.3 Configuring the outputs . . . . . . . . . . . 81
6.4.4 Creating programmes . . . . . . . . . . . . 82
6.4.5 Creating a main programme . . . . . . . 84
6.4.6 Creating switching programmes . . . . 86
6.4.7 Creating an event programme . . . . . . 87
6.4.8 Creating parallel sampling programme 89
6.5 Description of device functions . . . . . . . . . . 90
6.6 Configuration using Profibus . . . . . . . . . . . . . 93
7 Maintenance . . . . . . . . . . . . . . . . . . . 94
7.1 Cleaning the device . . . . . . . . . . . . . . . . . . . 94
7.2 Cleaning parts which convey media . . . . . . . 94
7.3 Cleaning the sample compartment . . . . . . . . 95
7.4 Cleaning the ventilator and the liquefier . . . . 95
7.5 Maintenance recommendation . . . . . . . . . . . 95
8 Accessories . . . . . . . . . . . . . . . . . . . .96
9 Trouble-shooting . . . . . . . . . . . . . . .97
9.1 Trouble-shooting instructions . . . . . . . . . . . . 97
9.2 Process error messages . . . . . . . . . . . . . . . . 97
9.3 Process errors without messages . . . . . . . . . 98
9.4 Spare parts . . . . . . . . . . . . . . . . . . . . . . . . . . 99
9.5 Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . 102
10 Technical data . . . . . . . . . . . . . . . . . . . 103
10.1 Function and system design . . . . . . . . . . . . 103
10.2 Power supply . . . . . . . . . . . . . . . . . . . . . . . 106
10.3 Installation . . . . . . . . . . . . . . . . . . . . . . . . . . 106
10.4 Environment . . . . . . . . . . . . . . . . . . . . . . . . 107
10.5 Process . . . . . . . . . . . . . . . . . . . . . . . . . . . . 107
10.6 Mechanical construction . . . . . . . . . . . . . . . 107
10.7 Human interface . . . . . . . . . . . . . . . . . . . . . 108
10.8 Certificates and approvals . . . . . . . . . . . . . 109
10.9 Accessories . . . . . . . . . . . . . . . . . . . . . . . . 109
10.10 Documentation . . . . . . . . . . . . . . . . . . . . . . 109

1 Safety instructions ASP station 2000
60 Endress+Hauser
1Safetyinstructions
1.1 Designated use
Designated use The ASP station 2000 is a stationary sampler for liquid media. The samples are taken
discontinuously using the vacuum principle, distributed to sampling containers and
stored cooled.
The manufacturer does not accept liability for damage caused by improper or non-
designated use. The device can cause danger if used improperly or other than
intended. If it is obvious that safe operation is no longer possible (e.g. visible damage),
please take the device immediately out of service. Secure the device against
unintentional start-up.
1.2 Installation, commissioning and operation
Installation,
commissioning and
operation
Installation, electrical connection, commissioning, operation and maintenance of the
device must only be carried out by specially trained personnel who have been
authorised to do so by the system operator. The personnel must have read and
understood these Operating Instructions and follow the instructions contained within.
Before connecting the device, ensure that the power supply corresponds to the value
specified on the nameplate. Before switching on the system, again check that all
connections are correct.
1.3 Operational safety
Operational safety Repairs
Repairs that are not described in these Operating Instructions may only be carried out
directly at the manufacturer's or by the ENDRESS+HAUSER service department.
Hazardous areas
The standard version of the ASP station 2000 (RPS20-) is not suitable for mounting in Ex
areas.
As an option, the ASP station 2000 (RPS22) can be obtained with certification for
mounting in Ex areas of ATEX Zone 2 (ATEX II3G EEx nA/C IIC T4).
EMC
The measuring system meets the general safety requirements of EN 61010 and the
EMC requirements of EN 61326.
Technical improvement
The manufacturer reserves the right to adapt technical data to the most up-to-date
technical developments without any special announcement. Ask ENDRESS+HAUSER
for information about activities and possible extensions to these Operating Instructions.

ASP station 2000 1 Safety instructions
Endress+Hauser 61
1.4 Return
Return You should take the following measures before sending the device back to
Endress+Hauser, for example for repair:
•Always enclose a fully-completed “Dangerous Goods Sheet”with the device. Only
then can Endress+Hauser transport, test or repair a returned device.
•If necessary, include special handling regulations with the returned product, e.g. a
safety datasheet in accordance with EN 91/155/EEC.
•Remove all signs of fluids. Pay special attention to the grooves for seals and crevices
which could contain residues. This is particularly important if the substance is
hazardous to health, e.g. flammable, toxic, caustic, carcinogenic, etc.
!Note!
You can find a copy of the “Dangerous Goods Sheet”at the end of this Operating
Instructions.
"Caution!
•Do not return any devices if you cannot be entirely sure that you have completely
removed all traces of hazardous substances, e.g. any media which have penetrated
crevices or diffused through plastic.
•Costs incurred for waste disposal and injury (burns, etc.) due to inadequate cleaning
will be charged to the owner-operator.
1.5 Notes on safety conventions and icons
Notes on safety
conventions and icons
Perfect and reliable device operation is only guaranteed if you observe the safety
instructions in these Operating Instructions . The safety instructions contained in these
Operating Instructions are indicated using the following symbols:
#Warning!
“Warning”draws attention to activities or procedures that can lead to injuries to persons
or to safety risks if not carried out properly. Observe the work instructions closely and
proceed with care.
"Caution!
“Caution”draws attention to activities or procedures that can lead to defective operation
or to destruction of the device if not carried out properly. Follow the instructions carefully.
!Note!
“Note”draws attention to activities or procedures that have an indirect effect on
operation, or can trigger an unforeseen device reaction if not carried out properly.

2 Identification ASP station 2000
62 Endress+Hauser
2 Identification
2.1 Device designation
Device designation 2.1.1 Nameplate
Compare the nameplate on the device with the following diagram:
a: Device designation
b: Order code
c: Device serial number
d: Order number
e: Power supply data
f :Power consumption data
g: Software version
Fig. 1: Nameplate data for the
“ASP station 2000”
2.2 Scope of delivery
Scope of delivery The sampler's scope of delivery consists of:
•ASP station 2000
•Operating Instructions
•RS232 interface cable (optional)
•ReadWin 2000 device software (optional)
!Note!
Refer to Section 8 for the accessories of the sampler.
ASP 2000
Order Code:
RPS20-xxxxxxx
Ser. No.: 123456789B5
Spec.: 30010110/0001
U: 230V 50/60Hz
P: 600 W
Software: LDU003A
ENDRESS+HAUSER
87484 Nesselwang / Germany 2002
a
b
c
d
e
f
g

ASP station 2000 3 Installation
Endress+Hauser 63
3 Installation
3.1 Quick installation guide
Quick installation guide a: Electronics compartment
b: Hose connection
(optional: on right or hose
entry from below)
c: Distribution pans
d: Bottle distributors
e: Sample compartment
f: Doors
g: RS232 (optional)
h: Controller
i: Cabinet cover
j: Dosing unit
k: Tap
Fig. 2: ASP station 2000 installation overview
3.2 Incoming acceptance, transport, storage
3.2.1 Incoming acceptance
After receiving the goods, check the following points:
•Is the packaging or the contents damaged?
•Is the delivery complete? Compare the goods delivered with what you ordered.
3.2.2 Storage
Observe the following points:
•The device must be packed in shockproof packaging for storage (and transport). The
original packaging offers the best protection for this.
•The permitted storage temperature is -20...+60 °C (preferably +20 °C).
!Note!
Always transport the cabinet vertically. Do not tilt it!

3 Installation ASP station 2000
64 Endress+Hauser
3.3 Installation conditions
Installation conditions 3.3.1 Dimensions
You can find the dimensions of the sampler in the Section “Mechanical construction”on
page 107.
3.3.2 Installation site
Fig. 3: Notes on mounting the device
When mounting the device, please observe the following points:
❑Position the device on a level surface.
❑Protect the device against additional heat (e.g. radiators).
❑Protect the device against mechanical vibration.
❑Protect the device against strong magnetic fields.
❑Ensure that air can circulate unhindered at the back of the cabinet. Do not position
the device directly against a wall (the distance between the wall and the rear side of
the cabinet should be at least 100 mm).
❑Do not position the cabinet directly above the channel of the inflow to the wastewater
treatment plant (sulphurous vapours!).

ASP station 2000 3 Installation
Endress+Hauser 65
3.3.3 Foundation plan
Fig. 4: Foundation plan (all data in mm)
A: Fixing points (4 x M10)
B: Cable pit
C: Outflow for condensation water
D: Bottom hose entry (optional)
E: Outflow for overflow
3.3.4 Hydraulic connection
•Maximum suction height: standard 6 m; optional: 8 m
•Maximum hose length: 30 m
•Hose connection diameter: 13 mm, 16 mm or 19 mm internal diameter
•Suction velocity: >0.5 m/s, acc. to EN 25667
Caution!
•Always lay the sampling hose in such a way that it rises from the sampling point to the
sampler.
•The sampler must be above the sampling point.
•Avoid siphon formation in the sampling hose.
Sampling point
Requirements of the sampling point:
"Caution!
•Do not connect the sampling hose to pressurised systems.
•Use the suction filter to impede coarse and abrasive solids and solids which can
cause clogging.
•Immerse the suction hose in the direction of flow.
•Take the samples at a representative point (turbulent flow; not directly at the bottom of
the channel).
Useful sampling accessories
•Suction filter:
Impedes the entry of coarse solids and solids which can cause clogging.
•Immersion assembly: the adjustable immersion assembly fixes the sampling hose at
the sampling point.
•Hose end piece
Order numbers, see “Accessories”on page 96.

3 Installation ASP station 2000
66 Endress+Hauser
3.3.5 Sampling with a flow assembly
The sample is taken directly from the flow assembly which is installed in the cabinet
base.
The flow assembly is used for taking samples from pressurised systems, e.g.:
•Tanks at a height
•Pressure piping
•Conveyance using external pumps
Connections
Fig. 5: Flow assembly
a Flow assembly inflow: ¾"
b Flow assembly outflow: 1 ¼"
c Flow rate: 1000 l/h to 1500 l/h
"Caution!
The outlet of the flow assembly must be unpressurised (e.g. drain, open channel).
Application example: sampling from pressure piping
Fig. 6: Sampling from pressure piping
Use the ball valve V1 to set the flow rate to 1000 l/h...1500 l/h. When the sampling cycle
begins, you can use one of the relay outputs to control and open valve V2. The medium
flows through the pipe and the flow assembly into the outflow. When a settable delay
time has elapsed, the sampler then takes the sample directly from the flow assembly.
Valve V2 is closed again once the sample has been taken.
!Note!
Valves V1 and V2 are not contained in the scope of delivery.

ASP station 2000 4 Wiring
Endress+Hauser 67
3.4 Installation instructions
Water connections
1. Mount the device according to the installation conditions → Section 3.3.
2. Lay the sampling hose from the sampling point to the device.
!Note!
Please observe the requirements of a sampling point, as specified in
3.3 “Installation conditions”.
3. Screw the sampling house to the hose connection of the device (see Fig. 2, item d).
3.5 Post-installation check
Check that the sampling hose is firmly connected to the device. Visually check that the
sampling hose is correctly laid between the sampling point and the device see Fig. 3.
4Wiring
"Caution!
Before wiring, please compare the supply voltage with the information specified on the
nameplate.
If safe operation is no longer possible (e.g. visible damage) please take the device out
of service and secure it against unintentional start-up.
Category II overvoltage protection is integrated into the system. If requirements are
tighter, additional overvoltage protection equipment must be installed. To this end, the
connection compartment contains a top-hat rail.
Please provide a suitable switch or circuit breaker when installing in a building.
An overcurrent protection device (nominal current I=10 A) is required for the power
cable. The protective earth connection must be made before all other connections. Any
interruption in the protective earth can cause danger.
4.1 Quick wiring guide
4.1.1 Cable laying
•Lay the cable so that it is protected behind the rear panel of the device.
•Use cable ties to keep the cables out of the way.
•You should plan a cable length of approx. 1.7 m between the foundation to the
terminal connection.
4.1.2 Cable types
- Power supply: e.g. NYY-J; 3-core; max. 2.5 mm2
- Analogue, signal and message lines e.g. LiYY 10 x 0.34 mm2
- Interface RS485: e.g. LiYCY 2 x 0.25 mm2

4 Wiring ASP station 2000
68 Endress+Hauser
!Note!
The terminal connection is in a protected position beneath the cabinet cover in the
electronics compartment. Therefore to connect the power supply, you must remove the
rear panel and the cover of the device before commissioning. To install the rear panel
and the cover, proceed in reverse order to the descriptions in the following two sections.
4.1.3 Mounting the cover
Fig. 7: Mounting the cover
4.1.4 Mounting the rear panel
Fig. 8: Mounting the rear panel
4.1.5 Terminal assignment
Fig. 9: Position of the terminal board in the electronics compartment
1. Loosen the fixing
screws.
2. Lift the cabinet
cover at the front.
3. Pull the cabinet
cover forwards and
lift.
1. Loosen the fixing
screws.
2. Lift the rear panel up and remove it.

ASP station 2000 4 Wiring
Endress+Hauser 69
Terminal assignment of the terminal board
Fig. 10: Terminal assignment of the terminal board
You can set the following signals at the terminal board:
Input signals:
•3 digital signals >20 ms
•1 analogue signal 0 to 1 V, 0 to 20 mA, 4 to 20 mA
Output signals:
•3 relay outputs, max. 250 V/3 A
Power
230 VAC
50/60 Hz
L
N
max.250V/3A Relay 1
Relay 2
Relay 3
Digital in (DI)
PE
PE
>20 ms
RS 485
printer
RxD/TxD(A)
Ω
RxD/TxD(A)1
2
3
4
5
6
RxD/TxD(B)
GND
GND via 100 (int.)Ω
Shield
Shield
Gnd1
2
3
4
5
6
Digital 1
U+
U+
Digital 2
Digital 3
RxD/TxD(A)
45
2
5
9pol.
Interface
1
RC
cable
resistance
R=
C
Further units RxD/TxD(B)
RxD/TxD(B)
0...20 mA,
4...20 mA
int. Shunt: 50
Analoque input
Interface RS485
Outputs
VoltageCurrent
+
Terminal board
19
20
1
2
X8
X3
X4
X6
X5
X2
X1 X7
max.250V/3A
max.250V/3A
1
111
1
11
2
222
2
22
3
33
3
33
4
44
5
5
6
6
+
-
+
-
+
-
+
12..24VDC
30mA
0...1 V
R>1MΩ

4 Wiring ASP station 2000
70 Endress+Hauser
4.1.6 Connecting the RS232 interface (standard)
The standard version contains an RS232 as a service interface. Remove the controller
as follows.
Fig. 11: Connecting a standard RS232 (interface behind controller)
A PC (9-pin SUB-D plug) is connected to the connection socket (3.5 mm, jack socket)
for the RS232 digital interface using the RS232 interface cable (3.5 mm, jack plug). The
Endress+Hauser device software ReadWin 2000 allows remote configuration and
measuring data polls.
Fig. 12: Pin assignment of RS232 interface cable
4.1.7 Connecting an RS232 interface (option -> see Fig. 2,
item g)
The ASP station 2000 is optionally available with an outer RS232 interface.
Fig. 13: Connecting RS232 option with outer interface
1. Loosen the
fixing screws.
2. Pull the controller
forwards.
3. RS232 plug
behind front panel.
1
2
3
5
3
2
1
4
6
7
8
n.c.
n.c.
n.c. 9
n.c.
n.c.
RxD
TxD
Gnd
Screened wire 9-pin socket
RS232 interface
on front panel

ASP station 2000 4 Wiring
Endress+Hauser 71
A PC (9-pin SUB-D plug) is connected to the connection socket (4-pin, female) for the
RS232 digital interface using the RS232 interface cable (4-pin, male). The
Endress+Hauser device software ReadWin 2000 allows remote configuration and
measuring data polls.
4.1.8 Connecting an RS485 interface (optional)
The RS485 interface is located on the terminal board.
(Wiring diagram →Page 69: terminal board)
4.1.9 Connecting PROFIBUS-DP (optional)
With Profibus coupler on top-hat rail in electronics compartment, connection via RS232;
baudrate 9600 kBaud.
Fig. 14: Profibus coupler
For additional information on the connection and wiring of the Profibus-DP module, see
the additional description in the Operating Instructions of the ASP2000 Profibus coupler
(see 10.10 “Documentation”).
4.2 Degree of protection
The individual components meet the requirements of the following protection types:
Controller: IP 65
Sample compartment with closed doors: IP 54
Electronics compartment: IP 43
4.3 Post-connection check
After completing the device's electrical connections, carry out the following checks:
Device status and specifications Notes
Is the device or cable damaged (visual inspection)? −
Electrical connection Notes
Does the supply voltage match the information on the nameplate? Compare nameplate on the
device
Do the cables used meet the relevant specifications? → Section 4.1
Are the mounted cables relieved of tension? −

5 Operation ASP station 2000
72 Endress+Hauser
5Operation
5.1 Quick operation guide
!Note!
Before switching on, please read Sections 6.1 “Function check”and 6.2 “Switching on
the measuring device”.
Quick operation guide
Fig. 15: Quick operation guide
5.2 Display and operating elements
Display and operating
elements
Fig. 16:Display and operating
elements
Start manual
sample
Start sampling
programme
Switch unit on
and off
Scroll
buttons
“Quick Setup”;
Setup; Basic
settings;
Service;
Sampling
programmes
Report list
Sample
statistics
LC display:
32 characters, 8 lines
Operating keys

ASP station 2000 5 Operation
Endress+Hauser 73
5.2.1 Display
Set the sampler using four operating keys. The
function of the keys is shown on the display.
Operation is menu-guided.
Fig. 17:Display
Picklists automatically display the possible
settings. The selected setting (here time,
quantity, ext. sig.) is indicated by a black bar
(time in the figure).
Fig. 18: Picklists (example: 'Quick Setup')
5.2.2 Key assignment
The assignment of the function keys is as follows:
Fig. 19: Key assignment
5.3 Local operation
Local operation 5.3.1 Enable configuration
If necessary, enter the 4-character user code (see Section 5.3.2).
5.3.2 Lock configuration
Enter a 4-character user code on the control console to lock the device configuration
(see “Description of device functions”on page 90.). Enter the user code using the
CODE function in the menu level SET - BASIC SETTINGS.
Exit the menu
level
Move bar up;
increase
active
character or
value
Move bar
down;
decrease
active
character or
value
Accept selected
setting or value

5 Operation ASP station 2000
74 Endress+Hauser
5.4 Confirmation of error messages
Confirmation of error
messages
Acknowledge error messages on the controller display by pressing the operating key
beneath the OK field.
5.5 Communication using ReadWin®2000
Communication using
ReadWin®2000
Besides by means of local operation, you can also remotely configure the device and
poll measured values using a PC with the Endress+Hauser operating software
ReadWin®
2000. ReadWin® 2000 is a universal PC programme for remote device
operation. The interface for remote configuration is the RS232 connection socket. You
can find detailed information on operating the device using ReadWin®
2000 on the CD-
ROM with the device software supplied.
5.6 Calibration
Calibration 5.6.1 Tap calibration
You must calibrate the tap if:
•The tap motor was replaced
•The error message: <Tap calibration> appears in the display.
Carry out the calibration as follows:
Fig. 20: Tap calibration
1. Switch the device on (see Section 6.2).
2. Under < SET -> SERVICE - CALIBRATION>, select
the item < DIST. TAB >.
3. When you select “Start”, the tap turns and stops just
before the calibration position.
4. At the controller, keep selecting <1 step> until the
arrow on the front side of the tap is located exactly in
the notch in the middle of the distribution pan (point
A). In the picklist, select the menu option <SAVE>.
5. The tap is calibrated.

ASP station 2000 5 Operation
Endress+Hauser 75
5.6.2 Manual sample volume setting on standard device
Set the required sample volume by shifting the dosing pipe manually.
Calibrate the sample volume as follows:
Fig. 21: Sample volume calibration
1. Check the set sample volume of the active
programme.
2. Loosen the clamping lever and the air tube to remove
the dosing glass.
3. Pull the dosing glass forwards and remove it.
4. Unscrew the bayonet lock and open the dosing
glass.
5. Set the sample volume by moving the dosing pipe.
Then put the dosing glass back together and install it in
the reverse order.

5 Operation ASP station 2000
76 Endress+Hauser
5.6.3 Dosing volume calibration for flow-proportional sample
using the “twiddle principle”(optional)
You must always calibrate the sample volume for flow-proportional sampling if:
–The device is being commissioned for the first time or in a new location
–The sample conditions have changed (e.g. length of the sampling hose)
–The dosing glass has been replaced.
Calibrate the sample volume as follows:
Fig. 22: Sample volume calibration for
flow-proportional sampling
1. Place an empty measuring flask (volume: approx.
500 ml) beneath the outflow hose of the dosing glass.
2. Under SET -> SERVICE - CALIBRATION -> DOSING
VOL, select the item “3 SAMPLES”.
The sampler deposits three samples in quick
succession into the prepared measuring flask.
3. In the item <DOSING VOL.>, select “Save”and in the
item <VOLUME>, enter the volume in the measuring
flask in ml.
