INSTALLATION GUIDE
RAINWATER
FILTER KIT C
42
-SIZES -
FOR FLEXIBLE
INSTALLATION
[email protected]
01778 562810
INLET
OUTLET OUTLET
OVERFLOW OVERFLOW
INLET

INSTALLING YOUR
RAINWATER FILTER KIT
CORRECTLY
Congratulations on your purchase of an Enduramaxx
Rainwater Filter Kit.
Correct installation and regular maintainance should
provide trouble free service for many years.
Please follow these instructions carefully as correct
installation is the sole responsibility of the purchaser.
CONTENTS OF RAINWATER FILTER KIT C
•Twin Filter with lid
•Overflow siphon tube
•Calmed inlet
•Enough pipe to go from the bottom of the filter to the
bottom of the tank (calmed inlet)
WE’RE
HERE TO
HELP
CALL US
01778
562810
Further pipe and fittings may be required to finish
connecting the unit to existing drainpipes and also
drainage to a soakaway etc.
OUR SIMPLE, RELIABLE AND AFFORDABLE RAINWATER
SYSTEMS ARE ALL BACKED BY THE ENDURAMAXX
SOLID GUARANTEE
IF YOU HAVE ANY QUESTIONS REGARDING THE
OPERATION OR WARRANTY OF THIS PRODUCT, PLEASE
CONTACT US DIRECT ON THE NUMBER ABOVE, OR
EMAIL US
INSTALLATION STEPS - KIT C
Locate the tank into position and identify where you
would like the filter to sit in relation to current pipe work
on the building.
Ensure the pipes entering the filter have a shallow
incline in order to allow water to flow over the weir
within the filter.
Mount the filter to the wall as photo A.
Decide whether you would like to use the hole from the
screw lid on the water tank or whether you would be
better to drill a purpose made hole to the side of the
screw lid.
A typical point would be at the letter ‘C’ as illustrated right.
Drill a 4” round hole at your point ‘C’.
Put the drainage pipe through the hole.
With the aid of the inspection screw lid put the calmed
inlet on the end of the pipe.
Continue to lower the pipe until the calmed inlet is
touching the base of the tank.
Insert the filter unit onto the top of the pipe.
You will have something like the illustration shown on
the right…
The purpose of the siphon tube is to siphon away any
floating algae from the top of the water. It should
therefore be fitted as high as possible on the tank wall.
Drill a 4” hole, remove the plastic nut and insert the
siphon tube through from the inside of the tank.
With the aid of the inspection screw lid put the calmed
inlet on the end of the pipe.
With the nut – tighten up from outside the tank.
Silicone around where any pipe and fittings come out of
the tank.
