Puretec CFS Series User manual

For correct operation & installation, it is essential to observe these instructions.
User Guide
Water Treatment Systems
CFS / IRS / IRX / SFS Series
SET
SEPT2020
ATS5200.103
Licence No. WM 74593
Australian Certication
Services
DO NOT
DO NOT USE
LIQUID SEALANTS.
SURGE PROTECTION
REQUIRED /
NO EXTENSION CORDS.
SURGE PROTECTION
REQUIRED /
NO EXTENSION CORDS.

2 Installation & Operation Manual Copyright © Puretec Pty Ltd 2020
What's Inside
Puretec Customer Service
Thank you for purchasing a Puretec Water Treatment System. Your system is a proven
performer manufactured from only quality materials and components. It will give years
of reliability and trouble free operation if maintained properly.
This user guide is designed for Puretec Water Treatment Systems. Be careful to ensure
the information and illustration is applicable to your particular unit.
Caution: Do not use with water that is microbiologically unsafe or without
adequate disinfection before or aer the system.
These systems are designed for metropolitan supply water but can be used in other
situations. For other types of water supply, please contact your local Puretec dealer.
Puretec Treatment Systems are designed to run economically for many years, dependent
on the initial installation and periodic maintenance.
Flush system for 5 minutes or more, aer any period of non-use, more than 2 weeks.
What's Inside
Puretec Customer Service ............................................................................................................................2
Installation Record ............................................................................................................................................3
Before Installation..............................................................................................................................................4
Warnings..................................................................................................................................................................5
Specications........................................................................................................................................................6
Exploded Diagram..............................................................................................................................................8
Diagram Identication .....................................................................................................................................9
Installation Procedure......................................................................................................................................8
Programming .....................................................................................................................................................15
Start-Up ................................................................................................................................................................17
Regeneration......................................................................................................................................................17
Media Replacement........................................................................................................................................18
Bypass Valve Operation - (optional accessory) ..............................................................................19
Troubleshooting Guide ..................................................................................................................................20
Warranty...............................................................................................................................................................23

3Copyright © Puretec Pty Ltd 2020 CFS / IRS / IRX / SFS Series User Guide
Product Information
Model Number:
Serial / Batch Number:
Purchased from:
Date of Installation:
Installer / Plumber Details:
Regen Frequency: ________ Days
Water Analysis Information
Hardness: ___________ ppm / mg/L
Iron: ___________ ppm / mg/L
Manganese: ___________ ppm / mg/L
pH: ___________
TDS (Total Dissolved Salts): ___________ ppm / mg/L
Hydrogen Sulde: ___________ ppm
TOC (Total Organic Carbons): ___________ %
Dissolved Oxygen: ___________ ppt
Installation Record
For future reference, ll in the following data:
Installation Record

4 Installation & Operation Manual Copyright © Puretec Pty Ltd 2020
Before Installation
Professional Installation Required
• Installation requires shutting water o, cutting the water supply pipe and using a
welding torch to add piping and ttings. Specialised tools and skills are required.
Installation should only be performed by a qualied tradesperson.
Make Sure the Water Has Been Thoroughly Tested
• An analysis of the water should be made prior to the selection of the water
treatment equipment. Puretec dealers can usually perform this service and may
send a sample for analysis and recommendations. Enter analysis information on
page 4 for a permanent record.
Before Installation
Facts to Remember While Planning Your Installation:
• All installation procedures MUST conform to local plumbing codes.
• If lawn sprinkling, a swimming pool, or geothermal heating/cooling or water for other
devices/activities are to be treated by the water system, a larger model MUST be
selected to accommodate the higher ow rate plus the back washing requirements.
Contact Puretec for assistance.
Installation Note: A water lter system/tap, like any product, has a limited lifespan
and if not replaced, will eventually fail. Failure can happen early due to unforeseen
circumstances. To avoid possible property damage, this product should be regularly
examined for leakage and/or deterioration and replaced when necessary. We strongly
recommend that a drain pan, plumbed to an appropriate drain or outtted with a leak
detector, be used in those applications where any leakage could cause property damage.
We also strongly recommend that the water supply be turned o, upstream to the water
lter system/tap, if no one is home for an extended period of time.
INSTALLATION SHOULD BE COMPLETED BY QUALIFIED TRADESPEOPLE. FAULTY
OPERATION DUE TO UNQUALIFIED PERSONS WILL RESULT IN VOIDED WARRANTY
COVERAGE.
Note: For point of entry installations an approved dual check backow prevention device
must be installed. When line pressure exceeds 860 kPa, a pressure limiting valve must be
installed.

5Copyright © Puretec Pty Ltd 2020 CFS / IRS / IRX / SFS Series User Guide
• The control valve, ttings and/or bypass are designed to accommodate minor plumbing
misalignment but are not designed to support the weight of a system or the plumbing.
• Do not use petroleum jelly, oils, other hydrocarbon lubricants or spray silicone anywhere.
A silicon lubricant may be used on the black o-rings but it is not necessary.
• Do not use pipe dope or other sealants on threads. Thread seal tape is the preferred
sealant but is not necessary on the nut connection or caps because of o-ring seals.
• All plumbing should be done in accordance with local plumbing codes. The pipe size for
the drain line should be a minimum of 1”.
• Avoid getting primer and solvent cement on lter system.
• Install grounding strap on metal pipes if required.
• Ensure the system is protected against high pressure and extreme temperatures.
WARNINGS
Warnings

6 Installation & Operation Manual Copyright © Puretec Pty Ltd 2020
Specications
Operating Pressure Min/Max: 140 - 860 kPa
Operating Temperature Min/Max: 0 - 43°C
Electrical Connection: 230V AC / 50hz
Inlet/Outlet Connection: 1" / 1" BSPM
Drain Connection: ¾" BSPM
IRS2000/
IRX2000
IRS3000/
IRX3000
IRS4000/
IRX4000
Width (A) 245 mm 270 mm 320 mm
Height (B) 1,400 mm 1,500 mm 1,600 mm
Specications
Operating Pressure Min/Max: 140 - 860 kPa
Operating Temperature Min/Max: 0 - 43 °C
Electrical Connection: 230V AC / 50hz
Inlet/Outlet Connection: 1" / 1" BSPM
Drain Connection: ¾" BSPM
CFS2000 CFS3000 CFS4000
Width (A) 245 mm 270 mm 320 mm
Height (B) 1,400 mm 1,500 mm 1,600 mm
IRS / IRX Models
CFS Models

7Copyright © Puretec Pty Ltd 2020 CFS / IRS / IRX / SFS Series User Guide
SET
B
A
Specications
Operating Pressure Min/Max: 140 - 860 kPa
Operating Temperature Min/Max: 0° - 43°C
Electrical Connection: 230V AC / 50hz
Inlet/outlet Connection: 1" / 1" BSPM
Drain Adaptor: 1" BSPM
Dimentions SFS2000 SFS3000 SFS4000
Height (A) 1,400 mm 1,500 mm 1,600 mm
Width (B) 245 mm 270 mm 320 mm
SFS Models

8 Installation & Operation Manual Copyright © Puretec Pty Ltd 2020
Parts Identication
Exploded Diagram
6
1
8
11
4
3
2
5
7a
9
10
7b
or

9Copyright © Puretec Pty Ltd 2020 CFS / IRS / IRX / SFS Series User Guide
Z
Parts Identication
Item Description Product Code
1 Pressure Tank -
2 Riser Pipe WTD2130
3 Top Screen WTD1010
4 Pressure Tank Collar / UV Shield WTV3030
5 Automatic Time Valve WTV4100
6 Transformer, Suits Auto Valves WTV5135
7a Drain Tube Assembly (CFS / IRS / IRX Models) WTV5930
7b Drain Tube Adaptor (SFS Models) WTV5080
8 DLFC -
9 1" Plastic Fitting Kit WTV5070
10 Bypass Assembly (If Purchased) WTV5000
11 Controller Weathershield -
Diagram Identication
Outlet 1"
Control Panel
Inlet 1"
Drain 1”
Z
Outlet 1"
Control Panel
Inlet 1"
Drain ¾”
CFS / IRS /IRX Models SFS Models

10 Installation & Operation Manual Copyright © Puretec Pty Ltd 2020
Installation Procedure
Ensure Water Has Been Tested
Input values into table on Page 3 and the analysis has been inspected by Puretec.
3
Water Analysis Information
Hardness ___________ ppm / mg/L
Iron ___________ ppm / mg/L
Manganese ___________ ppm / mg/L
pH ___________
TDS (Total Dissolved Salts) ___________ ppm / mg/L
Conductivity ___________ EC / uS/cm
Chloride ___________ ppm / mg/L
Sodium ___________ ppm / mg/L
130
0.3
0.1
7
275
404
121
96
✓✓
Customer Service Helpline
1300 140 140 (AU) 0800 130 140 (NZ)
✓
1
SET
Forcorrect operation & installation it is essential to observe these instructions.
User Guide
Iron Removal Systems
IRS Series
SET
MAR2019
Treatment System
Media
(refer to page 12) User Guide
Installation
Drain Tube Assembly
or Drain Tube Adaptor
(depending on model)
Bypass Assembly
(purchased separately)
Unpack the Equipment
Ensure all parts are present and have not been damaged in transport.
You should have:
or
SFS Models: 1" drain tube required.
CFS / IRS/ IRX Models: ¾" tube supplied (500 mm). If longer length required, tube may
be purchased separately.
Extra Items Required
2

11Copyright © Puretec Pty Ltd 2020 CFS / IRS / IRX / SFS Series User Guide
4
Installation
Media Installation
The Media has been shipped separately to avoid damage in transit.
The length of the internal riser pipe is pre-set and does not need adjustment.
Install Water Treatment Equipment Correctly
1. Select the location of your water treatment system with care. Various conditions
which contribute to proper location are as follows:
2. Install as close as possible to a drain on a level surface.
3. Install in correct relationship to other water treatment equipment. Contact
Puretec for assistance.
4. Install the treatment system in the supply line BEFORE the water heater.
Temperatures above 110°F (43.3°C) will damage the system and void the
warranty.
5. DO NOT install the treatment system in a location where freezing temperatures
occur. Freezing may cause permanent damage and will also void the warranty.
6. DO NOT install where water hammer conditions may occur without installing an
arrestor
7. Allow sucient space around the installation for easy servicing. Provide a non-
switched 240V power source for the control valve.
Continued next page.
1. Position the system on a at surface close to a
drain or a properly trapped outlet, in a position
when the system can service all lines requiring
treated water. The system should be placed far
enough away from any water heaters to avoid
any hot water back ow into the system. A
weatherproof power point and surge protector is
recommended.
2. Plug or cover the top end of the riser pipe in the
tank making sure no media can enter the tube.
3. Ensure that the riser pipe is sitting in the cradle
at the base of the tank. Then using a wide
mouth funnel, place the media in the tank as per
the vessel media lling order chart (page 12).
5

12 Installation & Operation Manual Copyright © Puretec Pty Ltd 2020
Installation
4. Remove the plug or cover from the riser pipe making sure you do not li the riser
pipe. Top up tank with water. Screw valve onto the tank (hand tight is usually
sucient), making sure the distributor tube is properly inserted into the valve.
Continued..
Fill vessel with media in the following order, according to your system model.
Model 1st 2nd 3rd 4th 5th
CFS2000 5L - WTM7550 10L - WTM1000 10L - WTM1000 - -
CFS3000 5L - WTM7550 10L - WTM1000 10L - WTM1000 10L - WTM1000 -
CFS4000 5L - WTM7550 10L - WTM1000 10L - WTM1000 10L - WTM1000 10L - WTM1000
IRS2000 5L - WTM7550 15L - WTM3000 15L - WTM3000 - -
IRS3000 5L - WTM7550 15L - WTM3000 15L - WTM3000 15L - WTM3000 -
IRS4000 5L - WTM7550 15L - WTM3000 15L - WTM3000 15L - WTM3000 15L - WTM3000
IRX2000 5L - WTM7550 10L - WTM3200 15L - WTM3200 - -
IRX3000 5L - WTM7550 10L - WTM3200 10L - WTM3200 15L - WTM3200 -
IRX4000 5L - WTM7550 10L - WTM3200 15L - WTM3200 15L - WTM3200 15L - WTM3200
SFS2000 10L - WTM7550 10L - WTM7500 10L - WTM7500 - -
SFS3000 15L - WTM7550 10L - WTM7500 15L - WTM7500 - -
SFS4000 5L - WTM7550 15L - WTM7550 15L - WTM7500 15L - WTM7500 -
Vessel Media Filling Order

13Copyright © Puretec Pty Ltd 2020 CFS / IRS / IRX / SFS Series User Guide
Installing the Bypass (purchased separately)
Uninstall the plastic ttings
by turning the knob
counterclockwise. Connect the bypass assembly followed
by the plastic ttings. Hand tighten the
knobs, do not overtighten.
Refer to page 19 for Bypass Operation.
6
Installation
Connecting the System
Connect the system to main plumbing. Do not solder brass adapters while they are
inserted in the control module.
7
Apply plumbing tape to the nipple as required. Connect the pipe work to the valve,
refer to page 8 for identication.
Note: Solder joints must be done prior to connecting to the valve ttings. Leave
at least 6” between the tting and solder joints when soldering pipes. Failure to
do this could cause heat damage to the ttings. This should be carried out by a
qualied tradesperson. FOLLOW LOCAL PLUMBING CODES
CFS / IRS /IRX Models SFS Models

14 Installation & Operation Manual Copyright © Puretec Pty Ltd 2020
Programming
6.1 Plug into an uninterrupted electrical outlet.
Note: the system transformers are not weather resistant and should be
adequately protected. All electrical connections must be connected accordingly to
local codes.
6.2 Proceed to ‘Programming’ section.
9
Installation
Connecting the Drain Line
Locate the drain tube and attach to the drain connection, refer to Page 8 for
identication of the drain port.
8
Connect pipe to the drain line connection on the valve to the drain. Ensure the drain
line is not kinked. The line must not travel more than 2.4 m up from the valve,
otherwise increase the diameter of the drain line.
Connect drain and overow to sewer or stormwater, whatever is approved by local
authority for discharge water.
Ensure drain line has an adequate air gap of 2 times the pipe diameter or 25 mm,
whichever is larger.
DRAIN
DRAIN
CFS / IRS /IRX Models SFS Models

15Copyright © Puretec Pty Ltd 2020 CFS / IRS / IRX / SFS Series User Guide
Time - Hour
PM
Days To Regen
Regen
Min. Fill
Regen
Hour
SET
SET
SET
SET
Time - Hour
PM
Days To Regen
Regen
Min. Fill
Regen
Hour
OR
Time - Hour
PM
Days To Regen
Regen
Min. Fill
Regen
Hour
SET
Time - Hour
PM
Days To Regen
Regen
Min. Fill
Regen
Hour
SET
Programming
Programming
General Operation
When the system is operating one of two displays will be
shown. Pressing ▲ or ▼ button will alternate between the
displays. One of the displays is always the current time of day
(to the nearest hour).
The second display is the days remaining until the next
regeneration. If the days remaining is equal to one, a
generation will occur at the next present regeneration time.
The user can scroll between displays as desired.
If the system has called for a regeneration that will occur
at the present time of regeneration, the arrow will point to
Regen.
Set Time of Day
1. Press SET for 5 seconds
2. Current time: set HOUR by using the ▲ + ▼ button then
press SET. Repeat for MINUTES.
Note: Aer a power outage, the time of day will need to be
reset.
Other Settings
These have been factory set (only adjust if required).
1. From normal mode, press SET + ▲ buttons simultane-
ously for 5 seconds and release.
2. Regeneration Time: Set the clock to the hour the regen-
eration should occur by using the ▲ or ▼ buttons. Once
the hour is chosen, press SET and repeat for MINUTES.
Factory setting is 2 AM.
Press SET to go to STEP 3.

16 Installation & Operation Manual Copyright © Puretec Pty Ltd 2020
Time - Hour
PM
Days To Regen
Regen
Min. Fill
Regen
Hour
SET
SET
Time - Hour
PM
Days To Regen
Regen
Min. Fill
Regen
Hour
An arrow points to the word
Regen if a regeneration is
expected ‘Tonight’.
Programming
3. Days to Regen: This is factory set to 3 (3 days between
regenerations). The allowable range is 1 to 99. Refer to
"Regeneration" to set correct regen days.
Press SET to exit Installer Displays and Settings.
Note: The system is factory set to regenerate at 2 AM. If there
is a demand for water when the system is regenerating, untreated
water will be used.
Regeneration Mode
When the system begins to regenerate, the display will
change to indicate the cycle of the regeneration process that
is occurring and an arrow will also point to Regen. The system
will run through the steps automatically and will reset itself to
provide treated water when the regeneration is completed.
Manual Regeneration
Sometimes there is a need to regenerate the system, sooner
than when the system calls for it, usually referred to as a
manual regeneration. There may be a period of heavy water
usage because of guests or a heavy laundry day.
To initiate a manual regeneration at the preset delayed regen-
eration time, simultaneously press ▲ + ▼ buttons together
and release. The arrow will point to the word Regen if a
regeneration is expected ‘tonight’. To cancel the regeneration
simultaneously press ▲ + ▼ buttons and release.
To initiate a manual regeneration immediately, simultaneously
press ▼ + ▲ buttons together for 3 seconds. The system
will begin to regenerate immediately. The request cannot be
cancelled.
SET
Time - Hour
PM
Days To Regen
Regen
Min. Fill
Regen
Hour
RETURN TO NORMAL MODE

17Copyright © Puretec Pty Ltd 2020 CFS / IRS / IRX / SFS Series User Guide
Operation and Maintainance
Power Loss
Your Puretec electronic control valve maintains the time for up to 8 hours using the internal PCB
battery if power is interrupted. Nonvolatile memory stores the stats & programming & are not
aected by power outages. Aer 8 hours of backup use, replace the battery with a type 2032,
3-volt lithium coin cell battery. If the time ashes on & o aer a power loss the time of day
should be reset & the at battery replaced.
In the unlikely event of a power loss during backwash, when power is restored, a dry-reset should
be performed (refer to page 16 ), followed by a manual backwash/regeneration (refer to page 13)
if convenient.
Start-up
Now programming is completed (if required) you are ready to start the system.
1. Open the nearest tap downstream of the lter system (aer the lter system).
2. Allow water to ow through the system slowly, and allow all air to escape out of the closest
tap. Wait until the water is owing out of the tap and then increase the ow slowly up to full
ow. Allow to run for 5 - 10 minutes.
3. Close the opened tap and check for leaks.
4. Conduct a full manual regeneration.
5. Your system is ready for use.
Regeneration
E1 Valve (Regeneration Time: 20 mins)
This valve is factory set to regenerate every third day. The required frequency of regeneration is
dependant on the level of contaminates and the amount of water used.
To change the regeneration setting refer to the ‘programming’ section.

18 Installation & Operation Manual Copyright © Puretec Pty Ltd 2020
Media Replacement
Customer Service Helpline at 1300 140 140 (AU) and 0800 130 140 (NZ) for more details.
The nuts and caps are designed to be unscrewed or tightened by hand or with the special plastic
wrench. If necessary a pliers can be used to unscrew the nut or cap. Do not use a pipe wrench
to tighten or loosen nuts or caps. Do not place screwdriver in slots on caps and/or tap with a
hammer.
Media Replacement
Series: Model: Media Replacement Code:
CFS
CFS2000 RMK-CFS2000
CFS3000 RMK-CFS3000
CFS4000 RMK-CFS4000
IRS
IRS2000 RMK-IRS2000
IRS3000 RMK-IRS3000
IRS4000 RMK-IRS4000
IRX
IRX2000 RMK-IRX2000
IRX3000 RMK-IRX3000
IRX4000 RMK-IRX4000
SFS
SFS2000 RMK-SFS2000
SFS3000 RMK-SFS3000
SFS4000 RMK-SFS4000

19Copyright © Puretec Pty Ltd 2020 CFS / IRS / IRX / SFS Series User Guide
Bypass Operation
SUPPLY WATER
EXITS
SUPPLY WATER
ENTERS NO WATER EXITS
SUPPLY WATER
IS SHUT OFF
FROM THE HOUSE
& THE VALVE
‘TREATED’ WATER
EXITS
SUPPLY WATER
ENTERS
SUPPLY WATER
EXITS
SUPPLY WATER
ENTERS
OF F
Normal Operation Bypass Operation
Diagnostic Mode Shut Off Mode
Bypass Valve Operation - optional accessory

20 Installation & Operation Manual Copyright © Puretec Pty Ltd 2020
Troubleshooting Guide
Troubleshooting Guide
PROBLEM POSSIBLE CAUSE SOLUTION
No display/blank screen on valve. A. Transformer not connected. A. Connect transformer.
B. No power at outlet/source. B. Use working outlet/repair
outlet.
C. Switched outlet/improper
voltage.
C. Use uninterrupted outlet/ensure
source is delivering proper
voltage.
D. Dead battery. D. Replace battery (CR2032).
E. Defective transformer. E. Replace transformer.
F. Defective PC Board. F. Replace PC Board.
Valve does not display correct
time of day.
A. Power outage(s). A. Reset time of day, replace
battery (CR2032).
B. Time of day set incorrectly. B. Reset to correct time of day.
C. Switched outlet. C. Use uninterrupted outlet.
D. Tripped breaker switch. D. Reset breaker switch.
E. Defective PC Board. E. Replace PC Board.
Valve regenerates at wrong time
of day.
A. Power outage(s). A. Reset time of day, replace
battery (CR2032).
B. Time of day set incorrectly. B. Reset to correct time of day.
C. Time of regeneration set
incorrectly.
C. Reset regeneration time.
Time of day flashes on and off. A. Power outage(s). A. Reset time of day, replace
battery (CR2032) and then
perform a ‘dry’ reset.
‘Dry’ Reset Procedure
From time to time, the valve
may display an error code
for various reasons. The first
troubleshooting step is to
perform a ‘dry’ reset.
Remove the faceplate, opening the tabs on either side of the
valve. This will expose the Power Circuit board with a number of
wires connected.
On the bottom right hand corner is a 4 pin adaptor labelled
‘12VAC PWR’, disconnect the adaptor and reconnect after 5
seconds. The valve will then whir twice, and should return to the
normal screen.
If the error message is still present, refer to the troubleshooting
guide
