Energica Eva 2018 User manual

https://www.motomanuals.net/

1
Dear customer,
it gives us great pleasure to welcome you to our family.
You are now the proud owner of an authentic piece of Italy's Motor Valley.
Our adventure rst took shape between 2008 and 2009 in the capitol of speed, Modena, when the entrepreneurial
vision of my family led us to imagine the future of electric vehicles from our own point of view.
In 2009, we seized an opportunity to develop an all-electric race motorcycle, and then raced this vehicle for two
years, taking advantage of this experience to put innovative technological solutions to the test.
Building on our experience in racing, we set ourselves the goal to evolve our vision even further and create a street
legal motorcycle - and Energica Motorcycle is the result of this.
The hard work and passion of out team of experts have created a pioneering motorcycle that you can now ride,
which embodies the perfect balance between innovation, power, technology, design and safety.
This your Energica: a potent electric bike which combines an environmentally friendly powertrain with extraordinary
performance, state of the art technology and a traditional passion for speed.
Enjoy the ride in the saddle of your Energica and live life to the full!
Livia Cevolini
CEO
https://www.motomanuals.net/

2
Cod. ENF003100
Rev. 02 (02/2018)
Owner Manual - Translated version
https://www.motomanuals.net/

3
INTRODUCTION............................6
Update...................................................... 6
Copying and disclosure.....................6
Information concerning trade
marks ........................................................6
Warning symbols ................................. 7
Warranty ...................................................... 7
Notice concerning the right to
repair or refund (Lemon Law) for
USA market ............................................ 8
Traveling safely.......................................... 8
What to do in the event of an
accident ........................................................9
General safety information.................. 10
Reporting safety defects ......................13
For USA customers ............................13
For Canadian customers ..................13
For UK, Europe and global market
customers ..............................................13
Motorcycle identication ..................... 14
Safety stickers...........................................16
DRIVING CONTROLS ................. 18
Location of controls................................18
Front brake lever......................................19
Rear brake pedal......................................19
Adjusting the position of the
footpegs (models tted with
adjustable footpegs) ....................... 20
Adjusting rear brake pedal
position (versions with
adjustable pedal) ................................21
Adjusting the stroke of the rear
brake pedal............................................21
Keys..............................................................22
Encoding the spare key:..................23
Left control switch .................................23
Dashboard .................................................27
Ignition Switch and Steering Wheel
Lock with Key.......................................... 30
Right control switch................................31
Throttle twist grip...................................32
DISPLAY.......................................33
Display overview.....................................33
Pop-up.........................................................39
Display modes.........................................40
Check screen ......................................40
Guide screens...................................... 41
Prole screen...................................... 44
Menu screens...................................... 46
Battery charge screens................... 49
Points of interest screen -
Charging stations.............................. 50
Contents
https://www.motomanuals.net/

4
MAIN PARTS................................52
Location of parts.....................................52
Rear-view mirrors ...................................53
Front fork adjusters ...............................53
Kickstand....................................................55
Battery charging socket.......................56
Rear shock absorber adjusters..........57
Standard shock absorber................57
Optional shock absorber.................58
Seat lock.................................................... 60
TECHNICAL
SPECIFICATIONS........................62
Dimensions ................................................62
Weights.......................................................62
Motor ...........................................................63
Performance .............................................63
Battery ........................................................63
Suspension and running gear............ 64
Brakes......................................................... 64
Tires............................................................. 64
Repairing and replacing tires ........65
Minimum depth of the tread......... 66
Headlamps/turn indicators ................ 66
Fuses........................................................... 68
Liquids.........................................................72
Tightening torque values.....................72
User messages .........................................73
Diagnostic codes.....................................77
INSTRUCTIONS FOR USE......... 84
Checks before start-up........................ 84
ABS system ...............................................85
Starting the motor..................................87
Moving off..................................................88
Stopping the motorcycle.................... 89
PARK ASSISTANCE mode.................. 90
Parking .........................................................91
Correct battery maintenance..............91
LPR function (Long Period Rest)......92
General warnings concerning
battery charging devices.................... 94
Charging cable.........................................95
Charging the battery ............................ 96
Headlamp adjustment.......................... 99
Replacing turn signal bulbs (USA
type approval) ...................................... 100
Lifting and transport.............................101
https://www.motomanuals.net/

5
MAINTENANCE .........................104
Regular maintenance intervals ........104
MAINTENANCE
OPERATIONS .............................110
Checking the transmission
oil level .......................................................110
Checking the front brake
uid level .................................................... 111
Checking the rear brake
uid level ................................................... 112
Checking brake pad wear................... 113
General inspection of the
braking system........................................114
Checking the coolant level.................114
Adjusting the chain tension ............... 117
Chain lubrication ...................................120
General cleaning....................................120
Prolonged periods with
vehicle not in use ................................... 121
https://www.motomanuals.net/

6
INTRODUCTION
This booklet is an integral part of the motorcycle and
must remain with it for its entire service life. If the event
of a change of ownership, it must be handed over to the
motorcycle's new owner.
Keep this manual carefully: If the quality of the booklet
deteriorates or the booklet is lost, request a new
copy from an Energica dealer or authorized workshop
immediately.
The illustrations contained in this booklet are provided for
example purposes only.
Information may differ slightly depending on the
motorcycle software update version and from region to
region.
The accuracy of all the information, specications
and illustrations contained in this document has been
conrmed at the time of printing.
Update
To maintain the highest possible quality standards,
this motorcycle is subject to continuous technological
improvements. As a result, there may be some differences
between your motorcycle and the information in this manual.
As continuous improvement is a key priority for Energica
Motor Company, we reserve the right to modify the
product at any time.
It may nevertheless be updated following the release
of new software features by Energica Motor Company
in due course; such information is not contained in this
manual at the time of purchase. Energica Motor Company
undertakes to keep its customers informed of any updates
that are made to this manual. In the event of inconsistency
between the information in this owner manual and the
information given in the most recent updates, the latter
will be valid.
The Energica sales and service network will be happy to
give you detailed information on any updates available.
As you will certainly understand, therefore, any
discrepancies in the data, gures and illustrations
contained herein cannot be considered grounds for any
complaint or claim.
Copying and disclosure
Reproducing or disclosing the content of this publication,
either in whole or in part, is strictly prohibited. All rights
reserved. Written authorization to reproduce or disclose
content must be requested from Energica Motor Company
and a reason given therefore. Please contact an authorized
after-sales center for repairs or even simply to request
further information.
Information concerning trade marks
Apple® and Apple Store® are registered trade marks of
Apple Inc.
© 2015 Google Inc. All rights reserved. The Google name
and logo are registered trade marks of Google Inc.
The Bluetooth® trade mark and the relative logos are the
property of Bluetooth SIG, Inc.
https://www.motomanuals.net/

7
Warning symbols
This owner manual contains warnings which must be
strictly observed not only to ensure your safety and that
of others, but also to prevent damage to your motorcycle.
WARNING!
Failure to observe this instruction may create
hazardous situations and cause severe injury or
death.
CAUTION!
Failure to observe this instruction may damage the
motorcycle and/or its components.
IMPORTANT!
Note offering guidance on how to carry out work in
the most effective way and providing information
on features of the product.
Environmental notice
Failure to observe this instruction may seriously
harm the environment.
Warranty
It is in your best interest to ensure that your motorcycle
remains safe and reliable to use. We therefore strongly
recommend that you contact our after-sales network
to undertake any work that requires specialist technical
expertise. Our highly qualied personnel has the equipment
necessary to carry out all work to a professional standard,
and above all, uses only genuine spare parts, which are
completely compatible with your motorcycle and ensure
superior performance and durability.
This motorcycle has been congured specically for the
operating conditions and requirements for type approval
in the country of initial purchase and registration. If the
vehicle is to be used in a different country, modications
may be necessary to render the motorcycle suitable for
the specic operating conditions and compliant with
type approval requirements, should they be different. No
warranty claims will be accepted for a vehicle which is
not compliant with the type approval requirements of the
country of use.
All motorcycles sold by Energica Motor Company come
with a "Warranty Card".
During the warranty period, all rights pertaining to the
warranty shall be forfeited if:
• One or more components of the motorcycle is
tampered with, modied or replaced with a non-
genuine part.
• The motorcycle is used for racing or sporting events in
general.
https://www.motomanuals.net/

8
• Any of the instructions in this manual are not
observed, especially those concerning correct battery
maintenance
Notice concerning the right to repair or refund
(Lemon Law) for USA market
Should the motorcycle fail to meet applicable standards
for quality and performance and Energica or its
dealerships cannot rectify the fault or defect within a
reasonable number of attempts, or if the motorcycle
remains inoperable for a specic number of days, the
customer is entitled to request that the vehicle be
replaced or repurchased in accordance with the Lemon
Law applicable in his or her state.
Lemon Law terms may vary from state to state. Where
permitted by state law, Energica requires the customer
to give due notication of any problems or service issues
encountered, to give Energica the opportunity to make
the necessary repairs, before exercising his or rights in
accordance with the aforementioned Lemon Law. In all
other states, Energica requires the customer to give due
notication in writing of any problems or service issues
encountered.
Written notication must be sent to Energica Motor
Company Inc. at the following address:
Energica Motor Company Inc.
North America Operations Headquarters
127 Goodwin Circle, Suite B
Mooresville, NC 28115
E-mail: [email protected]
Traveling safely
WARNING! Before using the motorcycle, read the
warnings below carefully.
This motorcycle has NOT been designed for use on
rough terrain or off-road. It must therefore only be
used on paved roads that have a smooth surface.
WARNING! Riding without a license is illegal
and punishable by law. Make sure that you are
in possession of the correct category of license
for riding this motorcycle. See the paragraph
“Technical specications” for the technical
specications of the motorcycle.
WARNING! Do not ride the motorcycle if under the
inuence of alcohol and/or drugs.
WARNING! Riding under the inuence of alcohol
and/or drugs is illegal and punishable by law.
WARNING! Before using the motorcycle, the rider
must check all the items listed in the column "Each
time the bike is used" in the “Regular maintenance
intervals” section of this manual.
https://www.motomanuals.net/

9
WARNING! Safety is also dependent on the
mechanical condition of the motorcycle. Observe
the maintenance schedule and adjustment
requirements contained in this manual exactly.
WARNING! Some medications may cause
drowsiness or bring about other effects that slow
down the rider's reexes and reduce their ability to
control the motorcycle, thus increasing the risk of
accident.
Check the motorcycle helmet laws in your
country or state; driving without a helmet may be
punishable by nes. Make sure that your helmet
complies with the relevant safety standards.
WARNING! Using the motorcycle without a helmet
increases the risk of serious physical injury or even
death.
WARNING! Wearing the correct clothing plays a
key role in motorcycle safety. Motorcycles cannot
protect riders against impacts in the same way that
cars can protect drivers.
IMPORTANT! Avoid wearing loose clothing or
accessories that could get caught in parts of the
motorcycle.
What to do in the event of an accident
Energica Motor Company has always taken the safety of
its customers and of its motorcycles very seriously, and
uses superior quality materials and active and passive
safety measures for all the safety-critical components and
functions of its motorcycles.
Despite this, please follow these guidelines in the event of
an accident:
WARNING! After an accident, do not touch
high voltage components such as, for example,
high voltage lines (with orange insulation) or
components in contact with high voltage wiring
with exposed metal cores.
WARNING! If the motorcycle is involved in an
accident, follow these additional safety measures
regarding the high voltage system: take all action
necessary to make the accident site safe.
Notify the emergency response services (e.g. police
or re ghters) immediately that this is an electric
vehicle with high voltage systems.
Turn off the ignition switch of the motorcycle.
Avoid breathing in any fumes released from the
battery pack, and keep at a safe distance from the
motorcycle.
WARNING! Avoid contact with any liquid escaping
from the battery pack. Corrosion hazard.
https://www.motomanuals.net/

10
General safety information
The motorcycle contains high-voltage components. The
high voltage used in these components is dangerous
and may cause personal injury, serious burns, electric
shock and even fatal injury if you do not take the correct
precautions.
The high-voltage system does not contain any replaceable
parts or require any maintenance by the user. Do not
disassemble, remove or replace any of the high-voltage
components, cables or connectors in the motorcycle.
High-voltage cables can be recognized by their orange
color.
IMPORTANT! Energica Motor Company shall not
be held liable for death, personal injury or material
damage resulting from the use or installation of
non-approved accessories. The manufacturer can
also not be held responsible for any damage or
injury if the vehicle has been tampered with or if
any maintenance work has been performed on
the motorcycle by persons without the necessary
specialization and/or qualication to work on
electric vehicles with high voltage systems.
Changes of any kind to the motorcycle must
be granted advance written approval by the
manufacturer.
WARNING! In the event of re, do not attempt to
extinguish it yourself. Call the local re brigade
immediately.
https://www.motomanuals.net/

11
Information on waste disposal and recycling.
Energica Motor Company is committed to putting
its credo of environmental responsibility into
practice in its products.
Energica Motor Company is currently exploring
recycling solutions and evaluating the possibility of
reusing the used batteries of its products.
While Energica does not have a used battery
collection program in place at the present time,
it is already actively investigating solutions for
the recycling and disposal of used batteries in
each of the markets that its products are sold.
Meanwhile, an electric vehicle battery recycling
process is already operational. When necessary,
used batteries are collected and processed by
third party recycling facilities specialized in the
environmentally responsible recycling of batteries
and/or parts of batteries.
The disposal of end-of-life batteries may require
special processes.
More detailed information on disposal may be
requested from your local authorities or from a
specialized waste collection center.
IMPORTANT! Always unplug the charging cable
before performing any work on the motorcycle,
even if it is not currently on charge.
This motorcycle is equipped with a high capacity lithium-
ion polymer battery. The battery is housed in a watertight
shell which contains the cells, the battery management
system (BMS) and all the systems and devices necessary
to ensure the safety of the vehicle. This solution keeps all
high voltage components insulated, making any risk of
accidental exposure to high voltage electricity extremely
improbable. This battery is an intelligent device equipped
with dozens of sensors and electromechanical devices
constituting a closed, autonomous system that combines
superlative vehicle performance with absolute rider safety
in all weather conditions.
WARNING! Only Energica technicians are
authorized to remove and/or open the battery
pack.
Energica recommends always using the emergency cut-
off switch when performing any maintenance. See
the paragraph "Right control switch" (emergency cut-off
switch) for more information.
Observe the applicable laws and directives in your
state when disposing of the lithium ion battery.
https://www.motomanuals.net/

12
WARNING! Some liquids used in vehicles, such
as brake uid and coolant, are toxic. Care should
therefore be taken not to inhale or swallow them,
or allow them to come into contact with wounds.
For safety reasons, read and follow the health
advice and instructions for correct disposal of these
liquids provided on their containers.
WARNING! In the event of an accident, do
not touch high-voltage wires, connectors or
components connected to cables.
WARNING! In the event of re, do not attempt to
extinguish it yourself. Call the local re brigade
immediately.
California Proposition 65
California State law requires the product to carry
the following warning statements.
CAUTION: Certain motorcycles contain or release
chemicals known to the State of California to cause
cancer and birth defects or other reproductive
harm. Moreover, certain uids used in these
vehicles and certain products deriving from the
wear or usage of their components contain or
release chemicals known to the State of California
to cause cancer and birth defects or other
reproductive harm.
Warning required by California relative to
perchlorate
CAUTION: Certain components of this motorcycle,
such as the lithium batteries, may contain
perchlorate. Special handling may apply for the
maintenance or disposal of these components.
See www.dtsc.ca.gov.
https://www.motomanuals.net/

13
For Canadian customers
In addition to contacting the Defect Investigations and
Recalls department of Energica Motor Company Inc.,
Canadian customers also wishing to report safety defects
to Transport Canada may do so by calling the toll-free
number 1 800 333 0510. Information on vehicle safety is
also available from the website www . tc . gc . ca / roadsafety.
For UK, Europe and global market customers
If you believe that your vehicle has a defect which could
cause an accident, injury or death, please contact your
authorized Energica dealer immediately. If the issue
cannot be resolved through your authorized Energica
dealer, please contact Energica Motor Company S.p.A.
directly by dialing + 390597231722, by writing to the
e-mail address [email protected] or via the
website www.energicamotor.com.
Reporting safety defects
For USA customers
If you believe that your vehicle has a defects which may
cause any accident or injury (fatal or otherwise), you are
required to notify the National Highway Trafc Safety
Administration (NHTSA) immediately of the defect and
report it to Energica Motor Company Inc.
On receipt of a complaint regarding safety, the NHTSA
may decide to conduct an investigation. If a defect
affecting the safety of a group of vehicles is found by this
investigation, it may order the manufacturer to implement
a recall campaign to rectify the defect. The NHTSA,
however, will not arbitrate any disputes between the
customer and the dealer or between the customer and
Energica Motor Company Inc.
To contact the NHTSA:
• call the toll-free vehicle safety line:
1-888-327-4236 (TTY: 1-800-424-9153)
• access the website: www.safercar.gov
• write to:
Administrator
NHTSA Headquarters
1200 New Jersey Avenue, SE
Washington, DC 20590
Further information on the safety of motor vehicles is
available from the website: www.safercar.gov
https://www.motomanuals.net/

14
Motorcycle identication
Every motorcycle can be identied by a set of unique
codes. The pictures below show where these are located
on the motorcycle.
1. VIN
2. Identication plate (Europe)
3a. Identication plate (USA)
3b. EPA plate (USA)
4. Identication plate (Canada)
5. Electric motor code (ID)
1
EN0001
https://www.motomanuals.net/

15
VEHICLE EMISSION
CONTROL INFORMATION
THIS VEHICLE CONFORMS TO U.S. EPA AIR EMISSIONS REGULATIONS
APPLICABLE TO 2016 MODEL YEAR NEW HIGHWAY MOTORCYCLES
ENGINE FAMILY:
GENMCLIONEGO
EMISSION CONTROL SYSTEM
BATTERY-ONLY ELECTRIC VEHICLE
ENERGICA MOTOR
COMPANY SRL
MFD by ENERGICA MOTOR COMPANY SRL
VIN:ZNNV1A194HM000001
DATE OF MFR:04/15
TYPE: MC GVWR/PNBV:
426 kg (940 lb)
This vehicle conforms to all applicable standards prescribed under the
Canadian Motor Vehicle Safety Regulations in effect on the date of manufacture
Ce véhicule est conforme à toutes les normes qui lui sont applicables en vertu
du règlement sur la sécurité des véhicules automobiles du Canada en vigueur
à la date de sa fabrication
FRONT
181 kg (400 lb) WITH 120/70ZR17M/C(58W)TIRE
RIM: 17XMT 3.50 AT 290 kPa (42 psi) COLD
GAWR/PNBE:
REAR
245 kg (540 lb) WITH 180/55ZR17M/C(73W)TIRE
RIM: 17XMT 5.50 AT 290 kPa (42 psi) COLD
GAWR/PNBE:
ZNNG1A1B1GM000001
MFD by ENERGICA MOTOR COMPANY SRL
VIN:ZNNV1A194HM000001
This vehicle conforms to all applicable Federal motor vehicle safety
standards in effect on the date of manufacture shown above.
Type: Motorcycle
DATE OF MFR:04/15
GVWR:
426 kg (940 lb)
GAWR FRONT: 181 kg (400 lb) WITH 120/70ZR17M/C(58W)TIRE
RIM: 17XMT 3.50 AT 290 kPa (42 psi) COLD
GAWR REAR: 245 kg (540 lb) WITH 180/55ZR17M/C(73W)TIRE
RIM: 17XMT 5.50 AT 290 kPa (42 psi) COLD
ZNNG1A1B1GM000001
4
2
3a
3b
5
EN0002
https://www.motomanuals.net/

16
*
Safety stickers
EN0003
* Label applied to models sold in the United States and
Canada
https://www.motomanuals.net/

17
EN0004
https://www.motomanuals.net/

18
DRIVING CONTROLS
Location of controls
A. Front Brake Lever
B. Rear Brake Pedal
C. Keys
D. Left control switch
E. Dashboard
F. Ignition Switch and Steering Wheel Lock with Key
G. Right control switch
H. Throttle twist grip
EN0005
G
H
EF
D
C
A
B
https://www.motomanuals.net/

19
A. Front brake lever
To apply the motorcycle's front brake, press the lever (2)
towards the grip (1). The brake is hydraulic and therefore
requires very little manual force to actuate it.
21 3
EN0006
You can adjust the span between the lever and the grip
using the adjustment screw (3). Find the setting that best
suits your hand and enables to you use the brake lever
comfortably.
Only adjust the span when the motorcycle is
stationary and has been switched off.
B. Rear brake pedal
To apply the rear brake, depress the pedal (1) with your
foot. The control system is hydraulic.
1
EN0007
The position of the footpegs and the pedal can be
adjusted. You can also adjust the pedal stroke.
The steps described refer to a specic type of
pedal; you should therefore check that your
motorcycle is tted with this particular pedal
before performing them.
https://www.motomanuals.net/
