Enerzone Destination 1.5 Insert User manual

26‐02‐201545771A
INSTALLATION
ANDOPERATION
MANUAL
Destination1.5
Insert
(EB00033)



READANDKEEPTHISMANUALFORREFERENCE
ww.kfenergy.cz
výrobce:StoveBuilderInternationalInc.
250,ruedeCopenhague,St‐Augustin‐de‐Desmaures(Quebec)KanadaG3A2H3
Výhradnídistributor:KFgroups.r.o.,Otín7,JindřichůvHradec

Thismanualisavailableforfreedownloadonthedistributer’swebsite.Itisacopyrighted
document.Re‐saleisstrictlyprohibited.Themanufacturermayupdatethismanualfromtimeto
timeandcannotberesponsibleforproblems,injuries,ordamagesarisingoutoftheuseof
informationcontainedinanymanualobtainedfromunauthorizedsources.


2Destination1.5InsertInstallationandOperationManual
THANKYOUFORCHOOSINGTHISENERZONEWOODINSERT
AsoneofNorthAmerica’slargestandmostrespectedwoodstoveandfireplacemanufacturers,
StoveBuilderInternationaltakesprideinthequalityandperformanceofallitsproducts.Wewant
tohelpyougetmaximumsatisfactionasyouusethisproduct.
Inthepagesthatfollowyouwillfindgeneraladviceonwoodheating,detailedinstructionsforsafe
andeffectiveinstallation,andguidanceonhowtogetthebestperformancefromthisinsertasyou
buildandmaintainfires,andmaintainyourwoodheatingsystem.
Alllocalandnationalregulations,includingthosereferringtonationalandEuropeanstandards,
shallbefollowedwheninstallingthisappliance.
Werecommendthatourwoodburninghearthproductsbeinstalledandservicedbyprofessionals.
Congratulationsonmakingawisepurchase.
Ifthisinsertisnotproperlyinstalled,combustiblematerialsnearitmayoverheat.Toreducethe
riskoffire,followtheinstallationinstructionsinthismanualexactly.Contactlocalbuildingor
fireofficialsaboutrestrictionsandinstallationinspectionrequirementsinyourarea.
Pleasereadthisentiremanualbeforeyouinstallanduseyournewinsert.Youmayneedtogeta
buildingpermitfortheinstallationofthisinsertandthechimneythatitisconnectedto.Consult
yourmunicipalbuildingdepartmentorfiredepartmentbeforeinstallation.Werecommendthat
youalsoinformyourhomeinsurancecompanytofindoutiftheinstallationwillaffectyour
policy.
Thisheatingunitisdesignedtoserveasasupplementaryheatsource.Werecommendthata
primaryheatsourcealsobeavailableinthehome.Themanufacturercannotberesponsiblefor
costsassociatedwiththeuseofanotherheatingsystem.



Destination1.5InsertInstallationandOperationManual3
Tableofcontent
PARTA‐OPERATIONANDMAINTENANCE.............................................5
1SafetyInformation............................................................................5
1.1SummaryofOperationandMaintenanceCautionsandWarnings......................................5
2GeneralInformation.........................................................................7
2.1Destination1.5InsertSpecifications.....................................................................................7
2.2ZoneHeatingandHowtoMakeitWorkforYou................................................................10
2.3TheBenefitsofLowEmissionsandHighEfficiency.............................................................10
2.4TheEnerzone’sCommitmenttoYouandtheEnvironment...............................................10
2.4.1WhatisYourNewInsertMadeOf?.................................................................................11
3OperatingYourInsert.....................................................................11
3.1YourFirstFires.....................................................................................................................11
3.2LightingFires........................................................................................................................12
3.3MaintainingWoodFires......................................................................................................12
3.3.1GeneralAdvice.................................................................................................................12
3.3.2AshRemoval.....................................................................................................................13
3.3.3RakingCharcoal................................................................................................................13
3.3.4FiringEachNewLoadHot................................................................................................13
3.3.5TurningDowntheAirSupply...........................................................................................14
3.3.6BuildingDifferentFiresforDifferentNeeds....................................................................15
3.4OptionalFanOperation.......................................................................................................16
4MaintainingYourWoodHeatingSystem.........................................17
4.1InsertMaintenance.............................................................................................................17
4.1.1CleaningDoorGlass.........................................................................................................17
4.1.2Dooradjustment..............................................................................................................18
4.1.3ReplacingtheDoorGasket...............................................................................................18
4.1.4ReplacingtheGlassGasketand/ortheGlass..................................................................19
4.1.5CleaningandPaintingtheInsert......................................................................................21
4.2ChimneyandChimneyLinerMaintenance.........................................................................21
4.2.1WhyChimneyCleaningisNecessary...............................................................................21
4.2.2HowOftenShouldYouCleantheChimney?...................................................................21
4.2.3CleaningtheChimney......................................................................................................22


4Destination1.5InsertInstallationandOperationManual
PARTB–INSTALLATION.......................................................................23
4.3PositioningtheUnit.............................................................................................................23
5SafetyInformation..........................................................................27
5.1MinimumMasonryOpening,ClearancestoCombustibles,andFloorProtector...............27
5.2ComplianceofaCombustibleMantelShelf........................................................................29
6TheVentingSystem........................................................................29
6.1General................................................................................................................................29
6.1.1AirSupplyinConventionalHouses..................................................................................30
6.2Block‐OffPlate.....................................................................................................................30
6.3SuitableChimneys...............................................................................................................31
6.4Linerinstallation..................................................................................................................31
Appendix1:OptionalBlowerAssemblyWithBottomFacing(AC01354)
Installation.......................................................................32
Appendix2:OptionalBottomFacingWithoutBlower(AC01352)
Installation.......................................................................36
Appendix3:Optional29"HX44"WBackingPlate(MayBeCutTo26"H)
Installation.......................................................................38
Appendix4:OptionalBlowerReplacement..........................................41
Appendix5:InstallationofSecondaryAirTubesandBaffle..................44
Appendix6:RemovalInstructions........................................................47
Appendix7:ExplodedDiagramandPartsList.......................................48
ENERZONELIMITEDLIFETIMEWARRANTY...........................................51




Destination1.5InsertInstallationandOperationManual5
PARTA‐OPERATIONANDMAINTENANCE
PleaseseePartBforinstallationinstructions.
1SAFETYINFORMATION
1.1 SUMMARYOFOPERATIONANDMAINTENANCECAUTIONSANDWARNINGS
•HOTWHILEINOPERATION,KEEPCHILDREN,CLOTHINGANDFURNITUREAWAY.CONTACT
MAYCAUSESKINBURNS.GLOVESMAYBENEEDEDFORINSERTOPERATION.
•USINGANINSERTWITHCRACKEDORBROKENCOMPONENTS,SUCHASGLASSOR
FIREBRICKSORBAFFLESMAYPRODUCEANUNSAFECONDITIONANDMAYDAMAGETHE
INSERT.
•OPENTHEAIRCONTROLFULLYBEFOREOPENINGTHELOADINGDOOR.
•OPERATEONLYWITHDOORFULLYCLOSED.IFDOORISLEFTPARTLYOPEN,GASANDFLAME
MAYBEDRAWNOUTOFTHEOPENING,CREATINGRISKSFROMBOTHFIREANDSMOKE.
•THISINSERTHASNOTBEENTESTEDFORUSEWITHANOPENDOORTHEDOORMAYBE
OPENEDONLYDURINGLIGHTINGPROCEDURESORRELOADING.ALWAYSCLOSETHEDOOR
AFTERIGNITION.DONOTLEAVETHEINSERTUNATTENDEDWHENTHEDOORISOPENED.
•NEVERUSEGASOLINE,GASOLINE‐TYPELANTERNFUEL(NAPHTHA),FUELOIL,MOTOROIL,
KEROSENE,CHARCOALLIGHTERFLUID,ORSIMILARLIQUIDSORAEROSOLSTOSTARTOR
‘FRESHENUP’AFIREINTHISWOODINSERT.KEEPALLSUCHLIQUIDSORAEROSOLSWELL
AWAYFROMTHEWOODINSERTWHILEITISINUSE.
•DONOTSTOREFUELWITHINHEATERMINIMUMINSTALLATIONCLEARANCES.
•USEONLYRECOMMENDEDFUEL.BURNONLYSEASONEDNATURALFIREWOOD.
•DONOTCONNECTTHISUNITTOACHIMNEYFLUESERVINGANOTHERAPPLIANCE.
•THEUSEOFSOMETYPESOFPRESERVATIVE‐TREATEDWOODASAFUELCANBEHAZARDOUS.
•DONOTUSEASANINCINERATOR.
•DONOTCONNECTTOANYAIRDISTRIBUTIONDUCTORSYSTEM.



6Destination1.5InsertInstallationandOperationManual
•DONOTBURN:
oGARBAGEOFANYKIND,
oCOALORCHARCOAL,
oTREATED,PAINTEDORCOATEDWOOD,
oPLYWOODORPARTICLEBOARD,
oFINEPAPER,COLOREDPAPERORCARDBOARD,
oSALTWATERDRIFTWOOD,
oMANUFACTUREDLOGSCONTAININGWAXORCHEMICALADDITIVES,
oRAILROADTIESOR
oLIQUIDSSUCHASKEROSCENEORDIESELFUELTOSTARTAFIRE.

•THISAPPLIANCESHOULDBEMAINTAINEDANDOPERATEDATALLTIMESINACCORDANCE
WITHTHESEINSTRUCTIONS.
•DONOTELEVATETHEFIREBYMEANSOFGRATES,ANDIRONSOROTHERMEANS.
•SOMEJURISDICTIONSREQUIREASUPPLYOFOUTDOORCOMBUSTIONAIRFORTHEINSERT.
INOTHERJURISDICTIONS,ANOUTDOORAIRSUPPLYISNOTREQUIRED,IFACARBON
MONOXIDE(CO)DETECTOR/ALARMISLOCATEDINTHEROOMINWHICHTHEINSERTIS
INSTALLED.THECODETECTORWILLPROVIDEWARNINGIFFORANYREASONTHEWOOD
INSERTFAILSTOFUNCTIONCORRECTLY.IFYOUAREREQUIREDTOINSTALLANOUTDOOR
AIRSUPPLY,WERECOMMENDTHATYOUALSOINSTALLACODETECTOR/ALARMTO
PROVIDEWARNINGIFSMOKESPILLAGEFROMTHEINSERTOCCURS.


Destination1.5InsertInstallationandOperationManual7
2GENERALINFORMATION
2.1 DESTINATION1.5INSERTSPECIFICATIONS
RecommendedFuelTypeWoodlogs(Birch,Beechor
Hornbeam)
TestStandardsEN13229/A2
TypeofcombustionIntermittent
Heatingcapacityrange*46to158m2
Reloadtimeatnominalheatoutput45min
ApproximateBurnTime*5to6hours
ColorMetallicblack
ShippingWeight145kg
Minimumfluedraught 12Pa
FireboxVolume0,043m3
MaximumLogLength495mm
Recommendedloglength406mm
FlueOutletDiameter150mm
BaffleMaterialC‐Cast
*Burntimeandheatingcapacitymayvarysubjecttolocationinhome,chimneydraft,chimney
diameter,locality,heatlossfactors,climate,fuelsandothervariables.
NominalHeatoutput*
6kW13,5kW
Fluegastemperature214°C282°C
Efficiency77,42%80,04%
CO2meanconcentration5,83%9,50%
*Valuesarewithouttheuseofablower.Theymayvaryslightlywiththeuseofthisaccessory.




8Destination1.5InsertInstallationandOperationManual
WithBlowerassemblywithbottomfacing(AC01354)










Withbottomfacingwithoutfacing(AC01352)




Destination1.5InsertInstallationandOperationManual9

CommonmeasurementswithAC01354andAC01352






10Destination1.5InsertInstallationandOperationManual
2.2 ZONEHEATINGANDHOWTOMAKEITWORKFORYOU
YournewDestination1.5woodinsertisaspaceheater,whichmeansitisintendedtoheatthe
areaitisinstalledin,aswellasspacesthatconnecttothatarea,althoughtoalowertemperature.
Thisiscalledzoneheatinganditisanincreasinglypopularwaytoheathomesorspaceswithin
homes.
Zoneheatingcanbeusedtosupplementanotherheatingsystembyheatingaparticularspace
withinahome,suchasabasementfamilyroomoranadditionthatlacksanotherheatsource.
Housesofmoderatesizeandrelativelynewconstructioncanbeheatedwithaproperlysizedand
locatedwoodinsert.Wholehousezoneheatingworksbestwhentheinsertislocatedinthepart
ofthehousewherethefamilyspendsmostofitstime.Thisisnormallythemainlivingareawhere
thekitchen,diningandlivingroomsarelocated.Bylocatingtheinsertinthisarea,youwillgetthe
maximumbenefitoftheheatitproducesandwillachievethehighestpossibleheatingefficiency
andcomfort.Thespacewhereyouspendmostofyourtimewillbewarmest,whilebedroomsand
basement(ifthereisone)willstaycooler.Inthisway,youwillburnlesswoodthanwithother
formsofheating.
Althoughtheinsertmaybeabletoheatthemainlivingareasofyourhousetoanadequate
temperature,westronglyrecommendthatyoualsohaveaconventionaloil,gasorelectricheating
systemtoprovidebackupheating.
Yoursuccesswithzoneheatingwilldependonseveralfactors,includingthecorrectsizingand
locationoftheinsert,thesize,layoutandageofyourhomeandyourclimatezone.Three‐season
vacationhomescanusuallybeheatedwithsmallerinsertsthanhousesthatareheatedallwinter.
2.3 THEBENEFITSOFLOWEMISSIONSANDHIGHEFFICIENCY
ThelowsmokeemissionsproducedbythespecialfeaturesinsidetheDestination1.5insertmean
thatyourhouseholdwillreleaseupto90percentlesssmokeintotheoutsideenvironmentthanif
youusedanolderconventionalinsert.Butthereismoretotheemissioncontroltechnologiesthan
protectingtheenvironment.
Thesmokereleasedfromwoodwhenitisheatedcontainsabouthalfoftheenergycontentofthe
fuel.Byburningthewoodcompletely,yourinsertreleasesalltheheatenergyfromthewood
insteadofwastingitassmokeupthechimney.Also,thefeaturesinsidethefireboxallowyouto
reducetheairsupplytocontrolheatoutput,whilemaintainingcleanandefficientflaming
combustion,whichbooststheefficientdeliveryofheattoyourhome.
Theemissioncontrolandadvancedcombustionfeaturesofyourinsertcanonlyworkproperlyif
yourfuelisinthecorrectmoisturecontentrangeof15to20percent.
2.4 THEENERZONE’SCOMMITMENTTOYOUANDTHEENVIRONMENT
TheEnerzoneteamiscommittedtoprotectingtheenvironment,sowedoeverythingwecanto
useonlymaterialsinourproductsthatwillhavenolastingnegativeimpactontheenvironment.


Destination1.5InsertInstallationandOperationManual11
2.4.1 WHATISYOURNEWINSERTMADEOF?
Thebodyofyourinsert,whichismostofitsweight,iscarbonsteel.Shoulditeverbecome
necessarymanyyearsinthefuture,almosttheentireinsertcanberecycledintonewproducts,
thuseliminatingtheneedtominenewmaterials.
Thepaintcoatingonyourinsertisverythin.ItsVOCcontent(VolatileOrganicCompounds)isvery
low.VOCscanberesponsibleforsmog,soallthepaintusedduringthemanufacturingprocess
meetsthelatestairqualityrequirementsregardingVOCreductionorelimination.
Theairtubesarestainlesssteel,whichcanalsoberecycled.
TheC‐Castbaffleismadeofanaluminosilicatefibrematerialthatiscompressedwithabinderto
formarigidboard.C‐Castcanwithstandtemperaturesabove1,093°C.Itisnotconsidered
hazardouswaste.Disposalatalandfillisrecommended.
Firebrickismainlycomposedofsilicondioxide,alsoknownassilica,aproductprocessedfroma
minedmineral.Itismostcommonlyfoundinnatureintheformofsandandclay.Disposalata
landfillisrecommended.
Thedoorandglassgasketsarefibreglasswhichisspunfrommeltedsand.Blackgasketshavebeen
dippedintoasolvent‐freesolution.Disposalatalandfillisrecommended.
Thedoorglassisa5mmthickceramicmaterialthatcontainsnotoxicchemicals.Itismadeof
naturalrawmaterialssuchassandandquartzthatarecombinedinsuchawaytoformahigh
temperatureglass.Ceramicglasscannotberecycledinthesamewayasnormalglass,soitshould
notbedisposedofwithyourregularhouseholdproducts.Disposalatalandfillisrecommended.

3OPERATINGYOURINSERT
•NEVEROVERFIREYOURWOODINSERT.IFANYPARTOFTHEWOODINSERTSTARTSTO
GLOWRED,OVERFIRINGISHAPPENING.READJUSTTHEAIRINTAKECONTROLATALOWER
SETTING.
•NEVERLOADYOURWOODINSERTUPTOTHEBAFFLE.ALWAYSLEAVE5TO10CENTIMETERS
TOALLOWPROPERCOMBUSTIONTHROUGHSECONDARYAIROPENINGS(NEVERPUTWOOD
ABOVETHEFIREBRICKLININGONTHEFIREBOX).THISWILLALSOPREVENTOVERFIRINGOF
YOURWOODINSERT.
•SHOULDTHEREBEASOOTORCREOSOTEFIREINYOURFLUESYSTEMALSOCALLEDCHIMNEY
FIRE,CLOSETHEAIRCONTROLCOMPLETELY.IMMEDIATELYCALLTHEFIREDEPARTMENT.
3.1 YOURFIRSTFIRES
Twothingswillhappenasyouburnyourfirstfewfires;thepaintcuresandtheinternal
componentsoftheinsertareconditioned.


12Destination1.5InsertInstallationandOperationManual
Asthepaintcures,someofthechemicalsvaporize.Thevaporsarenotpoisonous,buttheydo
smellbad.Freshpaintfumescanalsocausefalsealarmsinsmokedetectors.So,whenyoufirst
lightyourinsert,bepreparedbyopeningdoorsand/orwindowstoventilatethehouse.Asyou
burnhotterandhotterfires,moreofthepaintedsurfacesreachthecuringtemperatureofthe
paint.Thesmellofcuringpaintdoesnotdisappearuntilyouhaveburnedoneortwoveryhot
fires.
Burnoneortwosmallfirestobeginthecuringandconditioningprocess.Thenbuildbiggerand
hotterfiresuntilthereisnolongeranypaintsmellfromtheinsert.Oncethepaintsmell
disappears,yourinsertisreadyforseriousheating.
3.2 LIGHTINGFIRES
Eachpersonwhoheatswithwooddevelopstheirownfavoritewaytolightfires.Whatever
methodyouchoose,yourgoalshouldbetogetahotfireburningquickly.Afirethatstartsfast
produceslesssmokeanddepositslesscreosoteinthechimney.
3.3 MAINTAININGWOODFIRES
3.3.1 GENERALADVICE
Woodheatingwithaspaceheaterisverydifferentthanotherformsofheating.Therewillbe
variationsinthetemperatureindifferentpartsofthehouseandtherewillbevariationsin
temperaturethroughoutthedayandnight.Thisisnormal,andforexperiencedwoodburners
theseareadvantagesofzoneheatingwithwood.
Donotexpectsteadyheatoutputfromyourinsert.Itisnormalforitssurfacetemperaturetorise
afteranewloadofwoodisignitedandforitstemperaturetograduallydeclineasthefire
progresses.Thisrisingandfallingoftemperaturecanbematchedtoyourhouseholdroutines.For
example,theareatemperaturecanbecoolerwhenyouareactive,suchaswhendoinghousework
orcooking,anditcanbewarmerwhenyouareinactive,suchaswhenreadingorwatching
television.
Woodburnsbestincycles.Acyclestartswhenanewloadofwoodisignitedbyhotcoalsandends
whenthatloadhasbeenconsumeddowntoabedofcharcoalaboutthesamesizeasitwaswhen
thewoodwasloaded.Donotattempttoproduceasteadyheatoutputbyplacingasinglelogon
thefireatregularintervals.Alwaysplaceatleastthree,andpreferablymore,piecesonthefireat
atimesothattheheatradiatedfromonepiecehelpstoignitethepiecesnexttoit.Eachloadof
woodshouldprovideseveralhoursofheating.Thesizeofeachloadcanbematchedtothe
amountofheatneeded.
Whenyouburnincycles,yourarelyneedtoopentheinsert’sloadingdoorwhilethewoodis
flaming.Thisisanadvantagebecausethereismorechancethatsmokewillleakfromtheinsert
whenthedoorisopenedasafullfireisburning.
IFYOUMUSTOPENTHEDOORWHILETHEFUELISFLAMING,OPENTHEAIRCONTROLFULLYFOR
AFEWMINUTES,THENUNLATCHANDOPENTHEDOORSLOWLY.


Destination1.5InsertInstallationandOperationManual13
3.3.2 ASHREMOVAL
Ashshouldberemovedfromthefireboxeverytwoorthreedaysoffulltimeheating.Donotlet
theashbuildupinthefireboxbecauseitwillinterferewithproperfiremanagement.
Thebesttimetoremoveashisafteranovernightfirewhentheinsertisrelativelycool,butthereis
stillsomechimneydrafttodrawtheashdustintotheinsertandpreventitfromcomingintothe
room.
Afterasheshavebeenremovedfromtheinsertandplacedinatightlycoveredmetalcontainer,
theyshouldbetakenoutsideimmediately.Theclosedcontainerofashesshouldbeplacedona
non‐combustiblefloororonthegroundwellawayfromallcombustiblematerialspendingfinal
disposal.Ashesnormallycontainsomelivecharcoalthatcanstayhotforseveraldays.Iftheashes
aredisposedofbyburialinsoilorotherwiselocallydispersed,theyshouldberetainedinthe
closedcontaineruntilallcindershavethoroughlycooled.Otherwasteshouldnotbeplacedinthis
container.
NEVERSTOREASHESINDOORSORINANON‐METALICCONTAINERORONAWOODENDECK.
3.3.3 RAKINGCHARCOAL
Rekindlethefirewhenyounoticethattheroomtemperaturehasfallen.Youwillfindmostofthe
remainingcharcoalatthebackofthefirebox,furthestfromthedoor.Rakethesecoalstowards
thedoorbeforeloading.Therearetworeasonsforthisrakingofthecoals.First,itconcentrates
themnearwheremostofthecombustionairentersthefireboxandwheretheycanignitethenew
loadquickly,andsecond,thecharcoalwillnotbesmotheredbythenewloadofwood.Ifyouwere
tosimplyspreadthecharcoalout,thenewloadwillsmoulderforalongtimebeforeigniting.

Removeashfirst,andthenrakecharcoaltowardsthefrontofthefireboxbeforeloadingsothatit
willignitethenewload.
3.3.4 FIRINGEACHNEWLOADHOT
Placethenewloadofwoodonandbehindthecharcoal,andnottooclosetotheglass.Closethe
doorandopentheaircontrolfully.Leavetheaircontrolfullyopenuntilthefireboxisfullof
flames,thewoodhascharredtoblackanditsedgesareglowingred.Firingeachloadofwoodhot
accomplishesafewthings:
•drivesthesurfacemoisturefromthewood,
•createsalayerofcharonthewood,whichslowsdownitsreleaseofsmoke,
•heatsthefireboxcomponentssotheyreflectheatbacktothefire,and
•heatsthechimneysoitcanproducestrong,steadydraftfortherestofthecycle.


14Destination1.5InsertInstallationandOperationManual
Althoughitisimportanttofireeachnewloadhottoprepareforacleanburn,donotallowthefire
toburnatfullintensityformorethanafewminutes.
DONOTLEAVETHEINSERTUNATTENDEDWHILEANEWLOADISBEINGFIREDHOT.
DONOTOVERFIRE.
Whenyouburnanewloadofwoodhottoheatupthewood,theinsertandthechimney,the
resultwillbeasurgeofheatfromtheinsert.Thisheatsurgeiswelcomewhentheroom
temperatureisalittlelowerthandesirable,butnotwelcomeifthespaceisalreadywarm.
Therefore,alloweachloadofwoodtoburndownsothatthespacebeginstocooloffalittle
beforeloading.Lettingthespacecoolbeforeloadingisoneofthesecretstocleanburningand
effectivezoneheating.
3.3.5 TURNINGDOWNTHEAIRSUPPLY
Oncethefirewood,fireboxandchimneyarehot,youcanbegintoreducetheairsupplyfora
steadyburn.
Asyoureducetheairsupplytothefire,twoimportantthingshappen.First,thefiringrateslows
downtospreadtheheatenergyinthefueloveralongerperiodoftime.Second,theflowrateof
exhaustthroughtheinsertandfluepipeslowsdown,whichgivesmoretimeforthetransferof
heatfromtheexhaust.Youwillnoticethatasyoureducetheairsetting,theflamesslowdown.
Thisisyourindicationthattheinsertisburningatitspeakefficiency.
Iftheflamesgetsmallandalmost
disappearwhenyouturndowntheair,
youhaveturneddowntheairtooearly,or
yourfirewoodiswetterthanitshouldbe.
Withgoodfuelandcorrectaircontroluse,
theflamesshouldslowdown,butshould
staylargeandsteady,evenastheair
supplyisreduced.




Destination1.5InsertInstallationandOperationManual15
3.3.6 BUILDING DIFFERENT FIRES FOR DIFFERENT NEEDS
Usingtheaircontrolisnottheonlywaytomatchthewoodinsert’sheatoutputtotheheat
demand.YourhousewillneedfarlessheatinAprilthaninJulytobekeptatacomfortable
temperature.Ifyoufillthefireboxfullinfallweather,youwilleitheroverheatthespaceorturn
thewoodinsertdownsomuchthatthefirewillbesmokyandinefficient.Herearesome
suggestionsforbuildingfirestomatchdifferentheatdemand.
3.3.6.1 SmallFirestoTaketheChillOfftheHouse
Tobuildasmallfirethatwillproducealowheatoutput,usesmallpiecesoffirewoodandload
themcrisscrossinthefirebox.Thepiecesshouldbeonly75mmto100mmindiameter.After
rakingthecoals,youcanlaytwopiecesparalleltoeachothercornertocornerinthefireboxand
laytwomoreacrossthemintheotherdirection.Opentheaircontrolfullyandonlyreducetheair
afterthewoodisfullyflaming.Thiskindoffireisgoodformildweatherwhenyouarearoundto
tendthewoodinsertandshouldprovideenoughheatforfourhoursormore.Smallfireslikethis
areagoodtimetousesofterwoodspeciessotherewillbelesschanceofoverheatingthehouse.
3.3.6.2 LongLastingLowOutputFires
Sometimesyouwillwanttobuildafiretolastuptoeighthours,butdon’tneedintenseheat.In
thiscaseusesmallerpiecesofhardwoodandplacethelogscompactlyinthefireboxsothepieces
arepackedtightlytogether.Youwillneedtofiretheloadhotforlongenoughtofullycharthelog
surfacesbeforeyoucanturntheairdown.Makesurethefireisflamingbrightlybeforeleavingthe
firetoburn.
3.3.6.3 HighOutputFiresforColdWeather
Whentheheatdemandishighduringcoldweather,you’llneedafirethatburnssteadilyand
brightly.Thisisthetimetouseyourbiggestpiecesofhardwoodfuelifyouhaveit.Putthebiggest
piecesatthebackofthefireboxandplacetherestofthepiecescompactly.Adenselybuiltfirelike
thiswillproducethelongestburnyourwoodinsertiscapableof.
Youwillneedtobecautiouswhenbuildingfireslikethisbecauseiftheairisturneddowntoo
much,thefirecouldsmoulder.Makesurethewoodisflamingbrightlybeforeleavingthefireto
burn.Thewoodshouldbepositionedinanorth/southfashion,thatis,fromthefronttotheback
ofthefirebox.
3.3.6.4 MaximumBurnCycleTimes
Theburncycletimeistheperiodbetweenloadingwoodonacoalbedandtheconsumptionof
thatwoodbacktoacoalbedofthesamesize.Theflamingphaseofthefirelastsforroughlythe
firsthalfoftheburncycleandthesecondhalfisthecoalbedphaseduringwhichthereislittleor
noflame.Thelengthofburnyoucanexpectfromyourwoodinsert,includingboththeflamingand
coalbedphases,willbeaffectedbyanumberofthings,suchas:
•fireboxsize,
•theamountofwoodloaded,
•thespeciesofwoodyouburn,
•thewoodmoisturecontent,
•thesizeofthespacetobeheated,
•theclimatezoneyoulivein,and
•thetimeofyear.


16Destination1.5InsertInstallationandOperationManual
Thetablebelowprovidesaverygeneralindicationofthemaximumburncycletimesyouarelikely
toexperience,basedonfireboxvolume.
FIREBOXVOLUMEMAXIMUMBURNTIME
<0.042cubicmeter3to5hours
0.042m3to0.056m35to6hours
0.056m3to0.071m36to8hours
0.071m3to0.085m38to9hours
>0.085m39to10hours

Longburntimesarenotnecessarilyanindicationofefficientwoodinsertoperation.Whenyouare
homeduringthedayandabletotendthefire,itispreferabletobuildasmallerfirethatmight
providethreeorfourhoursofheatingthantofullyloadthefireboxforamuchlongerburn.
Shorterburncyclesmakeiteasiertomatchtheheatoutputofthewoodinserttotheheat
demandofthespace.
3.4 OPTIONALFANOPERATION
Allowtheinserttoreachoperatingtemperature(approximatelyonehour),beforeturningonthe
fan,sinceincreasedairflowfromthefanwillremoveheatandaffectthestart‐upcombustion
efficiency.
Theinsert'soptionalfanassemblyisequippedwithaheat
sensor.Youcansettheswitchtothemanualposition(1)to
operatethefanatanytime.Selecttheposition(2)tomanually
stopthefan.


Theoptionalfanhasarheostat,seetheillustrationonthe
righttoidentifythedifferentadjustmentpositions;either
fromhigh(HI)tolow(LO)orturnedoff(OFF).


NOTE:ENSURETHEFANCORDISNOTINCONTACTWITHANYSURFACEOFTHEINSERTTO
PREVENTELECTRICALSHOCKORFIREDAMAGE.DONOTRUNCORDBENEATHTHEINSERT.


Destination1.5InsertInstallationandOperationManual17
4MAINTAININGYOURWOODHEATINGSYSTEM
Keepinmindwheninstallingyourwoodinsertthatthereisaneedtokeepanaccesstotheflue
gasconnectorandthechimneyflue.
Maintenanceshouldbeperformedbyacompetentengineer.
4.1 INSERTMAINTENANCE
Yournewinsertwillgivemanyyearsofreliableserviceifyouuseandmaintainitcorrectly.Some
oftheinternalcomponentsofthefirebox,suchasfirebricks,bafflesandairtubes,willwearover
timeunderintenseheat.Youshouldalwaysreplacedefectivepartswithoriginalparts(see
Appendix7:ExplodedDiagramandPartsList).Firingeachloadhottobeginacycleasdescribed
abovewillnotcauseprematuredeteriorationoftheinsert.However,lettingtheinsertrunwith
theaircontrolfullyopenfortheentireburncyclescancausedamageovertime.Thehotteryou
runtheinsertthroughoutburncycles,themorequicklyitscomponentswilldeteriorate.Forthat
reason,neverleavetheinsertunattendedwhileanewloadisbeingfiredhot.
4.1.1 CLEANING DOOR GLASS
Undernormalconditions,yourdoorglassshouldstayrelativelyclear.Ifyourfirewoodisdry
enoughandyoufollowtheoperatinginstructionsinthismanual,awhitish,dustydepositwillform
ontheinsideoftheglassafteraweekorsoofuse.Thisisnormalandcanbeeasilyremovedwhen
theinsertiscoolbywipingwithadampclothorpapertowelandthendrying.Nevertrytoclean
theglasswhentheinsertishot.
Inspringandfallwhentheinsertisrunatlowertemperatures,youmayseesomelightbrown
stainsforming,especiallyatthelowercornersoftheglass.Thisindicatesthatthefirehasbeen
smokyandsomeofthesmokehascondensedontheglass.Whentheweatherismild,youmay
findthatlettingthefiregooutisbetterthantryingtomaintainacontinuousfire.Usethe
techniquedescribedaboveforbuildingafiretotakethechilloffthehouse.
Ifyoudogetbrownstainsontheglassyoucanremovethemwithspecialcleanersforwoodheater
glassdoors.Donotuseabrasivestocleanyourinsert’sdoorglass.
Thedepositsthatformontheglassarethebestindicationofthequalityofyourfuelandhowwell
youaredoinginoperatingtheinsert.Yourgoalshouldbeclearglasswithnobrownstains.Ifyou
continuetoseebrownstainsontheglass,somethingaboutyourfuelandoperatingprocedure
needstobechanged.Stainsontheglassindicateincompletecombustionofthewood,whichalso
meansmoresmokeemissionsandfasterformationofcreosoteinthechimney.
Ifyouseebrownstreakscomingfromtheedgeoftheglass,itistimetoreplacethegasketaround
theglass.Visityourinsertretailertogettheself‐adhesiveglassgasketandfollowtheinstructions
ofSection4.1.4:ReplacingtheGlassGasketand/ortheGlassforinstallation.
Donotabusetheglassdoorbystrikingorslammingshut.Donotusetheinsertiftheglassis
broken.


18Destination1.5InsertInstallationandOperationManual
4.1.2 DOORADJUSTMENT
Inorderforyourstovetoburnatitsbestefficiency,thedoormustprovideaperfectsealwiththe
firebox.Therefore,thegasketshouldbeinspectedperiodicallymakingsuretoobtainanairtight
fit.Airtightnesscanbeimprovedwithasimplelatchmechanismadjustment.Toadjust:
1. Slightly unfasten the bolts (A) using a ratchet and a 3/8” (10 mm) hexagonal socket.
2. Adjust to the desired tension. Increase the mechanism tension by sliding it backward.
3. Fasten the bolts (A)

4.1.3 REPLACING THE DOOR GASKET
Itisimportanttomaintainthegasketingoodcondition.Afterayearormoreofuse,thedoor
gasketwillcompressandbecomehard,whichmayallowairtoleakpastit.Youcantestthe
conditionofthedoorgasketbyclosingandlatchingthedooronastripofpaper.Testallaround
thedoor.Ifthepaperslipsouteasilyanywhere,itistimetoreplacethegasket.
Usethecorrectreplacementgasketthatyoucanpurchasefromyourretailer.Thediameterand
densityofthegasketisimportanttogettingagoodseal.
Placethedoorface‐downonsomethingsoftlikeacushionofragsorpieceofcarpet.Removethe
oldgasketfromthedoorbypullingandpryingitoutwithanoldscrewdriver.Thenusethe
screwdrivertoscrapetheoldgasketadhesivefromthedoor.Nowruna1/4”(6mm)beadofhigh
temperaturesiliconeinthedoorgasketgroove.Startingfromthemiddleofthehingeside,press
thegasket(B)intothegroove.Donotstretchthegasketasyouplaceit.Leavethegasketabout
1/2”longwhenyoucutitandpresstheendintothegroove.Tuckanyloosefibresunderthe
gasketandintothesilicone.Closethedooranddonotusetheinsertfor24hours.


Destination1.5InsertInstallationandOperationManual19
 
LocationLengthDimensions
Doorframe1.6MRound22mm
4.1.4 REPLACINGTHEGLASSGASKETAND/ORTHEGLASS
Inordertoreplacetheglass,usethe
followingprocedure;
1. Removethedoorfromitshingesand
layitonaflatsurface.
2. Removethescrews(A)holdingin
placetheupperglassretainer(B)and
thelowerglassretainer(C)tothe
doorframe(D).
3. Removeglass(F)andthedecorative
accentplate(E).
4. Repeatthestepsinreverseorderto
installthenewglass.
Thegasketmustbecentredontheedgeoftheglass.Todothiseasily,peelbackasectionofthe
papercoveringtheadhesiveandplacethegasketonatablewiththeadhesivesideup.Stickthe
endofthegaskettothemiddleoftopedgeoftheglass,thenpresstheedgeoftheglassdown
ontothegasket,takingcarethatitisperfectlycentredonthegasket.Peeloffmoreofthebacking
andpressthewholelengthoftheedgeoftheglassontothegasket.Donotstretchthegasketas
youplaceit.Cuttothenecessarylength.NowpinchthegaskettotheglassinaUshapeoverthe
frontandbackoftheglass.Dothesameforthebottomedgeoftheglass.


20Destination1.5InsertInstallationandOperationManual

EmplacementLongueurDimensions
Aroundglass848mm(2X)“U”shapedselfadhesive
Behindtheglass2MFlat,self‐adhesif3.175mmx25.4mm
Anotherglassgasket(C)islocatedonthedoorframe,behindtheglass.Whenreplacingtheglass
orasneeded,installaccordingtofollowingillustration.Notethatonthedoorframe,thereisa
lightgroovetoshowpositionofthegasket.

Reinstalltheglass,beingcarefultocentretheglasscarefullyinthedoor.Donotover‐tightenthe
screws.Notethatthetwomaincausesofbrokendoorglassareunevenplacementinthedoorand
over‐tighteningofretainingscrews.
Donotabusetheglassdoorbystrikingorslammingshut.DONOTUSETHEWOODINSERTIFTHE
GLASSISBROKEN.Tochangetheglass,performthesameoperationdescribedabove.

