Enerzone Solution 2.0 User manual

45400A
Printed in Canada 30-01-2013
OWNER`S MANUAL
Solution 2.0 Insert
US ENVIRONMENTAL PROTECTION
AGENCY PHASE II CERTIFIED
WOOD INSERTS
Verified and tested following
ULC S628 and UL 1482 Standards
by:
Manufactured by : STOVE BUILDER INTERNATIONAL INC.
250, rue de Copenhague, Saint-Augustin-de-Desmaures (Quebec) G3A 2H3
Tel.: [phone] Fax: [phone]
www.enerzone-intl.com
READ AND KEEP THIS MANUAL FOR REFERENCE
This manual is available for free download on the manufacturer’s web site. It is a copyrighted
document. Re-sale is strictly prohibited. The manufacturer may update thismanual from time
to time and cannot be responsible for problems, injuries, or damages arising out of the use of
information contained in any manual obtained from unauthorized sources.

2
INTRODUCTION
SBI INC., one of the most important wood stove and fireplace manufacturers in Canada,
congratulates you on your purchase and wishes to help you get maximum satisfaction from your
wood insert. In the pages that follow, we will give you advice on wood heating and controlled
combustion aswellas technicalspecificationsregardinginstallation,operation andmaintenanceof
the model you have chosen.
The instructions pertaining to the installation of your wood stove comply with ULC-S628 and UL-
1482 standards.
We recommend that our woodburning hearth products beinstalled and servicedbyprofessionals
whoare certified intheUnited StatesbyNFI (National FireplaceInstitute®)or inCanadaby WETT
(Wood Energy Technical Training) or in Quebec by APC (Association des Professionnels du
Chauffage).
Read this entire manual before you install and use your new insert. If this insert is not
properly installed, a house fire mayresult. To reduce the risk of fire, follow the installation
instructions. Failure to follow instructions may result in property damage, bodily injury, or
even death.
Consult your municipal building department or fire officials about restrictions and
installations requirements in your area and the need to obtain a permit.
Keep and save this instructions manual for future references.
CAUTIONS:
THEINFORMATIONGIVENONTHECERTIFICATION LABELAFFIXED TO THE APPLIANCE ALWAYSOVERRIDES
THE INFORMATION PUBLISHED,IN ANY OTHER MEDIA (OWNER’S MANUAL,CATALOGUES,FLYERS,
MAGAZINES AND/OR WEB SITES).
HOT WHILE IN OPERATION.KEEP CHILDREN,CLOTHING AND FURNITURE AWAY.CONTACT MAY CAUSE
SKIN BURNS.
DO NOT USE CHEMICALS OR FLUIDS TO START THE FIRE.
DO NOT LEAVE THE STOVE UNATTENDED WHEN THE DOOR IS SLIGHTLY OPENED.
DO NOT BURN WASTES,FLAMMABLE FLUID SUCH AS GASOLINE,NAPHTHA OR MOTOR OIL.
DO NOT CONNECT TO ANY AIR DISTRIBUTION DUCT OR SYSTEM.
ALWAYS CLOSE THE DOOR AFTER THE IGNITION.
REGISTER YOUR WARRANTY ONLINE
To receive full warranty coverage, you will need to show evidence of
the date you purchased your stove. Keep your sales invoice. We
also recommend that you register your warranty online at
http://enerzone-intl.com/warranty-registration.aspx
Registering your warranty online will help us track rapidly the
information we need on your insert.

3
TABLE OF CONTENTS
INTRODUCTION...................................................................................................................................... 2
Section 1.0 Pre-Installation Requirements............................................................................................. 5
1.1 Masonry & Zero Clearance Requirements.................................................................................. 5
1.2 Venting Requirements.................................................................................................................... 6
Section 2.0 Installation ............................................................................................................................. 7
2.1 Safety information.......................................................................................................................... 7
2.2 Installation instructions.................................................................................................................. 8
2.3 Compliance of the masonry fireplace ........................................................................................... 8
2.4 The masonry fireplace's draft control system.............................................................................. 9
2.5 Compliance of a combustible top shelf ......................................................................................... 9
2.6 Positioning the unit....................................................................................................................... 10
2.7 Minimum masonry opening, clearances to combustibles, and floor protector....................... 14
2.8 Connector installation.................................................................................................................. 16
2.8.1 Chimney liner installation......................................................................................................... 17
2.8.1.1 If the chimney liner does align with the insert’s flue outlet, you have two options:......... 17
2.8.1.2 If the chimney liner does not align with the insert’s flue outlet:........................................ 18
2.9 Air control plate, faceplate and fan Assembly Instructions .....................................................19
Section 3.0 Operation ............................................................................................................................. 20
3.1 Safety Information........................................................................................................................ 20
3.2 Fuel................................................................................................................................................. 21
3.2.1 Simple Wood Moisture Test ..................................................................................................... 22
3.3 Notes About First Firing .............................................................................................................. 22
3.4 Lighting A Fire.............................................................................................................................. 23
3.5 Maintaining The Fire.................................................................................................................... 25
3.6 Fan Operation............................................................................................................................... 25
Section 4.0 Maintenance......................................................................................................................... 26
4.1 Care and Cleaning........................................................................................................................ 26
4.1.1 Glass Cleaning and maintenance ............................................................................................. 26
4.2 Ash Removal.................................................................................................................................. 27
4.3 Chimney Cleaning......................................................................................................................... 27
4.4 Baffle Installation and brick layout for Solution 2.0................................................................. 28
4.5 Secondary Air Tube Replacement............................................................................................... 29
4.6 Fan Maintenance & Care............................................................................................................. 30
4.7 Removal instructions.................................................................................................................... 30
Section 5.0 Specifications ....................................................................................................................... 31
5.1 Solution 2.0 Insert......................................................................................................................... 31
ENERZONE LIMITED LIFETIME WARRANTY ........................................................................... 32

4
Solution 2.0 Dimensions

5
Section 1.0 Pre-Installation Requirements
1.1 Masonry & Zero Clearance Requirements
The masonry fireplace must meet the minimum code requirements, or NFPA 211 or the equivalent for a
safe installation. Contact your local Building Inspector for requirements in your area. An inspection of
the fireplace should include the following:
1. CONDITIONOF THE FIREPLACEAND CHIMNEY: Examine the masonry fireplace and chimney
prior to installation to determine thatthey are free from cracks, loose mortar, creosote deposits, blockage, or
other signs of deterioration. If evidence of deterioration is noted, the fireplace or chimney should be
upgraded prior to installation.
2. INSTALLATIONINTO ANEXISTINGFACTORY-BUILTZERO-CLEARANCEFIREPLACE:
It is possible to install a wood insert into an existing factory-built zero-clearance fireplace. However, there
currently exists no UL or ULC standard specific to that type of installation. The first thing that must be
verified is that the factory-built zero clearance fireplace is listed (it must be certified by a competent
certification body such as Omni or Warnock Hersey). It must be suitable for use with solid fuel and nothing
in the owner’s manual must specifically prohibit the installation of a fireplace insert. When in doubt, check
with the fireplace manufacturer. The installation of the zero-clearance fireplace MUST be thoroughly
inspected by a professional in order to ensure that it still meets the manufacturer’s specs and code
conformity. The chimney must be of at least 1" (25 mm) larger in diameter to accommodate a required
continuous stainless steel liner running from the flue collar to the top of the chimney termination.
Never remove parts that serve to insulate the zero-clearance fireplace from combustible material. Only
readily detachable parts that are easily replaced, such as damper parts, screens, and doors, are to be removed
from the fireplace. These parts must be stored nearby and available for retrofit ifthe insert is ever removed.
Removal of any parts which render the fireplace unfit for use with solid fuel requires the fireplace to be
permanently labelled by the installer as being no longer suitable for solid fuel until the removed parts are
replaced and the fireplace is restored to its original certified condition. Furthermore, any air vents, grilles, or
louvers that serve to create an air circulation pattern around and outside the zero-clearance fireplace shall
never be removed.
3. CHIMNEY CAPS: Mesh type chimney caps must have provision for regular cleaning, or the mesh
should be removed to eliminate the potential of plugging.
4. LINER:The chimney must have an acceptable masonry liner suitable for solid fuel; otherwise a
continuous stainless steel liner must be installed.
5. ADJACENTCOMBUSTIBLES: The fireplace should be inspected to makesure that thereis adequate
clearance to combustibles, both exposed combustibles to the top, side, and front as well as concealed
combustibles, in the chimney and mantel area. Your local inspector should have information on whether
older fireplaces are of adequate construction.
6. OPENING SIZE: Refer to “Suitable Fireplace Dimensions” (Sec. 2.2) for suitable size fireplace
openings.
NOTE: A METAL TAG IS PROVIDED AND IS TO BE FASTENED TO THE BACK WALL OF
THE FIREPLACE IF THE FIREPLACE HAS BEEN MODIFIED TO ACCOMMODATE THE
INSERT.

6
1.2 Venting Requirements
The flue is a critical component to a satisfactory installation. Your insert will attain its best performance if
installed with a flue that generates its own draft. The minimumventing requirement will be the installation
of a flue connector from the insert into the first tile of the chimney (see Figure 2.3). If you are using a
masonry chimney, it is important that it be built in compliance with the specifications of the National
Building Code or other applicable standard having jurisdiction. It must be lined with fire clay bricks, metal
or clay tiles sealed together with fire cement (round flues are the most efficient). Ideally, the interior
diameter of the masonry chimney should be identical to the insert smoke exhaust. You may also run a
stainless steel liner inside the masonry chimney. A continuous 6" (152mm) stainless steel liner from the top
of the chimney to the insert’s smoke exhaust (see Figure 2.2) is the optimum system and will provide the
best performance, as well as compensate for poor draft situations caused by large cross-sectional chimneys.
The insert will not work without a positive seal in the chimney.
Chimneys constructed outside of the home, on an exteriorwall, should be avoided if possible, especially in
colder climates. Outside chimneys may not draw as well and may downdraft due to the difficulty in heating
them up to operating temperature. Cooler chimneys will result in increased creosoting, less draft, and poorer
performance. Draft is proportional to overall chimney height as well as to stack temperature. Draft can be
increased by increasing chimney height, and by reducing heat loss from the chimney through an insulated
liner.
Ensure that all joints in the flue systems are tightly sealed, since any leaks will result in reduced
performance as well as a possible safety hazard. Using a fire screen at the extremity of the chimney requires
regular inspection in order to insure that it is not obstructed thus blocking the draught, and it should be
cleaned when necessary.
Do not connect this unit to a chimney flue serving another appliance.
This heating unit must serve as a supplementary heat source. An alternate heat source should be available in
the home if needed. The manufacturercannot be responsible for additional heating costs associated with the
use of an alternative heat source.
It is recommended that the user buys this product from a retailer who can provide installation and
maintenance advices.

7
Section 2.0 Installation
2.1 Safety information
NOTE: THIS APPLIANCE IS NOT RECOMMENDED FOR USE IN A HOME IF AN
OCCUPANT HAS ANY RESPIRATORY OR ANY OTHER RELATED PROBLEMS.
1. It is important to follow the installation and operation instructions. An improperly installed or
operated insert could result in a safety hazard or fire, or damage to the unit, which would not be
covered by the warranty. Contact local building or fire officials about restrictions and installation
requirements in your area. You should be familiar with the installation and be sure that the work is
done in accordance with this manual.
WARNING: DO NOT INSTALL THIS INSERT IN A SLEEPING ROOM.
2. Where lesser clearances are desired, consult your local authority as regulations may vary regarding
the use of clearance reducing devices. Listed wall and floor shields are available to reduce
clearances, and most building codes provide information on materials which may be used to reduce
clearances.
1. Maintain at least the minimum clearances to combustible material as specified in this manual.
Clearances are measured to the nearest part of the insert (i.e. top edge on the side). Clearances to
any combustibles, when measured directly out from the front, must be a minimum of 48"
(1219mm).
4. Maintain at least the minimum floor protection for combustible floor materials as specified in this
manual. Floor protection to the front is to be measured from the fuel loading door opening.
5. Osburn recommends that you install a listed smoke detector or alarm in your home. Normal
operation of the insert will have no effect on the detector or alarm.
6. The insert is to be connected only to a lined masonry chimney and masonry fireplace conforming to
building codes for use with solid fuel. Do not remove bricks or mortar from the existing fireplace
when installing the insert.
7. Minimum chimney size is 6" (152mm) diameter. Maintain a 15' (4.5m) minimum overall height
measured from the base of the appliance. Chimneys should be inspected to check for deterioration
and to determine if they meet the minimum requirements, and be upgraded if necessary. The
chimney must extend at least 3' (914mm) above the roof and at least 2' (610mm) above the highest
point within an area of 10' (3m) of the chimney.
8. Do not use makeshift compromises during installation, as they could create a safety hazard and a fire
could result.
9. DONOT CONNECTTHIS APPLIANCETO THECHIMNEY ORFLUE SERVINGANOTHER
APPLIANCE.

8
2.2 Installation instructions
Inspect the masonry fireplace according to the safety information and fireplace requirements and have it
cleaned and/or upgraded as necessary.
2.3 Compliance of the masonry fireplace
Where the masonry fireplace opening is 6 ft2(0.56 m2) or larger, the hearth extension shall extend at least 20''
(508 mm) in front of the facing material and at least 12'' (305 mm) beyond each side of the fireplace opening.
Where the masonry fireplace opening is less than 6 ft2(0.56 m2), the hearth extension shall extend at least 16''
(406 mm) in front of the facing material and at least 8'' (203 mm) beyond each side of the fireplace opening.
Notethat ifyou must modify thehearth extension tocomply with thesemeasures,depending on thesize of the
masonry fireplace opening, the hearth extension must have a minimum of 4'' (102 mm ) thick (see Figure 2.6a
and 2.6b.)

9
2.4 The masonry fireplace's draft control system
Ifthe fireplace'sdraft control systemis to remainin the masonry fireplace,it mustbe locked openforaccessof
the chimney liner or removed entirely. If you remove draft control system from the masonry hearth, you will
needtoinstall the metalplate (27009),suppliedwith the owner’s manualkit, indicatingthatthemasonryhearth
has been modified. It must be secured inside the masonry hearth, in a visible place and easy to locate.
2.5 Compliance of a combustible top shelf
To ensure compliance of an existing top shelf or to install any combustible shelf, refer to table below and
Figure 2.5 for a safe installation or to perform changes if necessary. For example, a shelf with a 6’’ depth
(152 mm) must be installed at least 17" (432 mm) above the top of the insert (see Figure 2.5). Different shelf
dimensions are listed in the following table in order to facilitate installation. However, no combustible shelf
can be installed at less than 17" (432 mm) above the top of the insert. If the depth of the shelf is not listed in
the table, add 11" (279 mm) to the depth of your shelf to obtain the safe positioning of your shelf. For
example, for a 9" (229 mm) shelf, the safe positioning would be 20" (508 mm) above the top of the insert
(11" (279 mm) + 9" (229 mm)).
SHELF POSITIONING
MAXIMUM SHELF
DIMENSION (X) SHELF POSITION (I)
6" / 152 mm 17" / 432 mm
8" / 203 mm 19" / 483 mm
10" / 254 mm 21" / 533 mm
12" / 305mm 23" / 584 mm

10
2.6 Positioning the unit
In addition to ensuring compliance of the masonry fireplace hearth extension (see Compliance of the
masonry fireplace in Section 2.3), it is necessary to have a floor protection made of non-combustible
materials that meets the measurements specified in table FLOOR PROTECTION (see Section 2.7). To
determine the need to add a floor protection (D) beyond the hearth extension, you must do the following
calculation using the data in Table Data for floor protection calculation of this section: D = B - (A - C). If
the value (D) is negative or zero, you do not have to add more floor protection in front of the unit, because
the masonry fireplace hearth extension is long enough. If the value (D) is positive, you will need a floor
protection in front of the hearth extension at least equivalent to the result (D).
Here is a sample calculation to determine the needto add a non-combustible materials floor protection. For
someone living in the USA whose fireplace opening is less than 6 ft2and which the insert would protrude 3"
(76 mm) into the room (C) the calculation would be:
Value D = B - (A - C)
Value D = 16" - (16" - 3")
Value D = 16" - 13"
Value D = 3"
This person should install a non-combustible floor protection of at least 3"(76mm) in front of the fireplace
hearth extension.

11
If a non-combustible material floor protection needs to beadded in front and level with the hearth extension
masonry fireplace (see Figure 2.6a), an R factor equal to or greater than 1.00 is required. If the extension of
the masonry hearth is raised at least 4" from the floor protection (see Figure 2.6b), a non-combustible
material without an R factor is sufficient.
Figure 2.6a
Figure 2.6b

12
The use of an R value is convenient when more than one material is going to be usedin the hearth extension
to cover the combustible surface. This is because R values are additive, whereas K values are not. To find
the corresponding R factor to use for some selected materials, please see Table Thermal characteristics of
common floor protection materials in this section.
There are two ways to calculate the R factor of the floor protection. First, by adding the R-values of
materials used, or by the conversion if the K factor and thickness of the floor protection are given.
To calculate the total R factor from R factors of the materials used, simply add the R-values of materials. If
the result is equal to or greater than the R-value requirements, the combination is acceptable. To know the
R-values of some selected materials, see table Thermal characteristics of common floor protection
materials.
Example:
Required floor protection R of 1.00. Proposed materials: four inches of brick and one inch of Durock®
board
Four inches of brick (R = 4 x 0,2 = 0,8) plus 1 inch of Durock®(R = 1 x 0.52 = 0.52).
0.8 + 0.52 = 1.32.
This R value is larger than the required 1.00 and is therefore acceptable
In the case of a known Kand thickness of alternative materials to be used in combination, convert all K
values to R by dividing the thickness of each material by its Kvalue. Add the Rvalues of your proposed
materials as shown in the previous example.
Example:
K value = 0.75
Thickness = 1
R value = Thickness/K = 1/0.75 = 1.33
The more extended the insert, the greater the heat transfer to the room. You may install the insert within the
minimum and maximum extension listed in the table below (value (C)) or any position in between. The
position chosen will depend on your own preference for most installations, your current configuration, the
compliance with the preceding installation instructions and compliance with the building code requirements.
To determine the minimum and maximum protrusion of the insert, refer to table Data for floor protection
calculation.

13
Data for floor protection calculation
MAXIMUM
EXTENDED
A B
(Note 1) C E
Smaller
than 6 ft2* Bigger or
= to 6 ft2*
INCHES 16" 20"
CAN: 18"
USA: 16" 5 1/2" 10 1/2"
MILLIMETRE
S 406 mm 508 mm CAN: 457 mm USA: 406 mm 140 mm 267 mm
MINIMUM
EXTENDED A B
(Note 1) C E
Smaller
than 6 ft2* Bigger or
= to 6 ft2*
INCHES 16" 20"
CAN: 18"
USA: 16" 3 1/4" 8 1/4"
MILLIMETRE
S 406 mm 508 mm CAN: 457 mm USA: 406 mm 83 mm 210 mm
*Refers to masonry fireplace opening.
Thermal characteristics of common floor protection materials*
MATERIAL CONDUCTIVITY
(k) PER INCH RESISTANCE (R) PER INCH THICKNESS
Micore®160 0.39 2.54
Micore®300 0.49 2.06
Durock®1.92 0.52
Hardibacker®1.95 0.51
Hardibacker®500 2.3 0.44
Wonderboard®3.23 0.31
Cement mortar 5.00 0.2
Common brick 5.00 0.2
Face brick 9.00 0.11
Marble 14.3 – 20.00 0.07 – 0.05
Ceramic tile 12.5 0.008
Concrete 1.050 0.950
Mineral wool insulation 0.320 3.120
Limestone 6.5 0.153
Ceramic board (Fibremax) 0.450 2.2
Horizontal still air** (1/8") 0.135 0,920**
* Information as reported by manufacturers and other resources
**For a 1/8" thickness. You cannot «stack» horizontal still air toaccumulateR-values;you mustseparateeach laterofhorizontalstill
air with another noncombustible material.

14
2.7 Minimum masonry opening, clearances to combustibles, and floor protector

15
MINIMUM MASONRY
OPENING
J 22 3/4" (578 mm)
K 28 7/8" (733 mm)
L 10 3/8" (264 mm)
CLEARANCES
F 12" (305 mm)
G 10" (254 mm)
H 10" (254 mm)
I 17" (432 mm)*
FLOOR PROTECTOR
CANADA USA
B 18" (457 mm) – Note1 16" (406 mm) – Note 1
M 8" (203 mm) N/A (Canada only)
N N/A (USA only) 8" (203 mm)
* For a 6" (152 mm) shelf. See Table SHELFPOSITIONING (Section 2.5) for other shelf dimensions.
Note 1: From door opening. The depth of a non-combustible shelf in from of the insert is included in
the calculation of the floor protector’s dimensions.
IMPORTANT: The masonry hearth should be at least 4 inches (102 mm) higher than the combustible
floor in front of it. If the hearth elevation is lower than 4 inches, the non-combustible floor protector in
front of the insert should have an R value equal or greater than 1.00.

16
2.8 Connector installation
A masonry flue connector may provide acceptable performance (Figure 2.8a); however, we recommend the
use of a chimney liner (rigid or flexible) to ensure satisfactory performance (Figure 2.8b). To ensure an
optimal draft, we also strongly recommend adding a minimum of 18” rigid liner between the roof flashing
and the rain cap. Slip connectors for continuous liners should also be installed. Use Listed Chimney Liners
– UL1777, CAN/ULC-S635.
Figure 2.8a Figure 2.8b
ATTENTION INSTALLER: When positioning the unit in a fireplace opening prior to the flue
installation, install the insert into the opening until the top lip of air jacket is flush with fireplace facing.
If lag-bolts and anchors are to be used to secure the insert, the whole locations should be marked with
the unit in place. Remove the insert and locate the anchors.

17
2.8.1 Chimney liner installation
To install of the chimney liner, the preferred methods are those found in Section 2.8.1.1. Use a liner offset
adapter (Section 2.8.1.2) only as a last resort.
2.8.1.1 If the chimney liner does align with the insert’s flue outlet, you have two options:
A) Install the chimney liner starter adapter, provided with the chimney liner. Follow the chimney liner
starter adapter manufacturer's instructions.
In order to connect the chimney liner starter adapter to the flue outlet, you can install the brackets
with the screws that are in the instruction manual kit.
Using a powered driver, secure the three brackets with the three screws provided 30131 on top of the
insert in the three holes in front of the flue outlet. The long end of the brackets must be attached to
the insert. Insert the chimney liner into the flue collar of the unit and secure the liner to the brackets
with three self-tapping screws (not included).

B) You can get from your dealer a liner fixation system (AC02006), sold separately. Follow the
installation instructions provided with the liner fixation system.

18
2.8.1.2 If the chimney liner does not align with the insert’s flue outlet:
You can get a liner offset adapter (AC01370), sold separately. If you must install a liner offset
adapter, using a powered driver, secure the three brackets with the three screws provided 30131 on
top of the insert in the three holes in front of the flue outlet. The long end of the brackets must be
attached to the insert. The brackets and screws are in the insert’s instruction manual kit. Then follow
the instructions in the manual provided with the liner offset adapter kit.


19
2.9 Air control plate, faceplate and fan Assembly Instructions
1. Place the faceplate panels with the finished side down on a flat, soft, non-abrasive surface.
2. Assemble the faceplate trim, attaching the mitered corners with the corner brackets.
(see Figure 2.9a)
3. Line up the holes of the side and top panels and secure with the screws, washers and nuts. (see
Figure 2.9b)
4. Slide the assembled trim over the edges of the faceplate.
5. Secure trim to faceplate using "U" shaped clips. (see Figure 2.9c)
6. Fan is already attached to the unit at the factory with two tie straps. Remove the two tie straps
and clip the blower assembly back onto the unit.
Figure 2.9a Figure 2.9b
Figure 2.9c

20
Section 3.0 Operation
3.1 Safety Information
1. This insert is designed for safe operation WHENBURNING CORDWOODONLY. Altering or modifying
the unit or the installation without proper authorization will void the certification, warranty, and
safety listing, and may result in a safety hazard.
2. For safety reasons, never leave the unit unattended with the door open or ajar. An open door, and
especially a door partially open or cracked, if left for longer than required for good ignition can
potentially result in unsafe chimney temperatures, and if left unattended, hot embers or ignited fuel
may fall out of the unit. Prolonged door open operation is not necessary provided the unit has
been properly installed and dry kindling is used to start the fire.
3. Do not abuse the unit, either by over firing or by using wood or combustibles with salt content, or
harmful chemicals. Misuse is not covered by warranty.
4. Even though your Enerzone insert has been specifically designed and tested to prevent smoke
spillage, always open the door slowly as this will minimize the likelihood of smoke spillage or a
back draft causing flame or smoke to spill into the room.
5. Never use gasoline type lantern fuel, kerosene, solvents, charcoal lighter fluid, or inflammable
liquids to start or "freshen" a fire in the insert. Keep all such liquids well away from the insert
while it is in use.
6. All insert surfaces become very hot during operation. Care is needed, especially with children, to
avoid contacting these surfaces.
7. Do not elevate the fire by means of grates, and irons or other means.
8. CAUTION:DO NOT OVER FIRE THIS HEATER.Do not burn fuel in the insert at a rate higher than that
which will cause the ember bed level to exceed half the door opening height. If burning hot fires
regularly, purchase an insert top thermometer, and do not exceed 840oF (450oC) as measured on
the cook top. If the door handle of the insert becomes excessively hot to the touch, consider this to
be an indication of over firing. Over firing can result in a safety hazard and can permanently
damage the insert and chimney. This damage is not covered by the warranty.
9. Although the ceramic glass is extremely durable under any normal use, a few precautions are
required. Do not attempt to push logs further into the fire by using the door, as the glass may
break if it is heavily contacted by any solid object.
