Cut-Through Card
Model CTC-239S
SECTION PAGE #
1. GENERAL................................................................1
2. APPLICATIONS.......................................................1
3. CIRCUIT DESCRIPTION........................................1
4. INSTALLATION.......................................................2
5. CUSTOMER SERVICE...........................................2
6. WARRANTY AND REPAIRS.................................2
7. SPECIFICATIONS...................................................2
1. GENERAL
The CTC-239S is a 239-type plug-in card that allows
network and customer transmission paths to be
connected through a T1 line repeater housing.
Document Status
Whenever this practice is updated, the reason will be
stated in this paragraph.
Product Features
4-wire transmission path connection
Fits standard 239-type repeater card slots
Passive, non-powered operation
2. APPLICATION
When installed in a T1repeater slot, the CTC-239S
provides ametallic cut-through of transmission pairs
from input to output. The card eliminates the need for
manual splicing of cable pairs in applications that require
bypassing of line repeaters.
3. CIRCUIT DESCRIPTION
Signals pass through the CTC-239S from input side to
output side as shown in Figure 2.
Figure 1. Front view of CTC-239S
Figure 2. CTC-239S block diagram

001-01-000054 Rev.000 Page 2 of 2
4. INSTALLATION
The CTC-239S mounts in one position of a 239-type
repeater housing or shelf. Electrical connections are
made through the 12-pin card edge connector. Pin
designations are outlined in Table 1.
PIN
DESCRIPTION
6
Side 1 Input - Tip
5
Side 1 Input - Ring
4
Side 1 Output - Tip
3
Side 1 Output - Ring
12
Side 2 Input - Tip
11
Side 2 Input - Ring
9
Side 2 Output - Tip
8
Side 2 Output - Ring
Table 1. CTC-239S pin designations
5. CUSTOMER SERVICE
If technical or customer assistance is required, please
contact Enginuity at the following address or phone
number:
Enginuity Communications
1251 Nagel Blvd.
Batavia, Illinois 60510
Toll Free: 1-800-980-3266
Voice: [phone]
www.enginuitycom.com
6. WARRANTY & REPAIRS
Warranty
Enginuity warrants this product for five (5) years from
date of purchase. Any attempt to repair or modify the
equipment by anyone other than an authorized Enginuity
representative will void the warranty.
Repair and Return
Enginuity equipment will be repaired or replaced without
cost during the warranty period if the product is defective
for any reason other than abuse, improper use, or
improper installation. Before returning defective
equipment,first request a Return Material Authorization
(RMA) number from Enginuity. Once an RMA number is
obtained, return the unit, freight prepaid, along with a
brief description of the problem, to:
Enginuity Communications
1251 Nagel Blvd.
Batavia, Illinois 60510
ATTN: Repair & Return Dept.
Replacements will be shipped in the fastest manner
consistent with the urgency of the situation. Repair or
replacement of faulty equipment beyond the warranty
period is available for a nominal charge. Contact
Enginuity for details.
7. SPECIFICATIONS
Mounting: 239-type T1 repeater slot
Size: 2.7" H x 0.6" W x 6.2" D
Weight: 0.1lb (1.6oz).
