ensol ES1V2.0 User manual

Installation instruction
of the flat solar collectors models ES1V2.0, ES1V2.65, EM2V/2,0 ES2V/2.0 AL,
ES2V/2.65 and ES2H/2.65 on the flat roof or the foundation.
Installation instruction
of the flat solar collectors models
ES1V2.0, ES1V2.65, ES2V/2.0 AL,
EM2V/2.0, ES2V/2.65, ES2H/2.65
on the flat roof or the foundation.
04/2014 Get acquainted before starting the installation.

Installation instruction
of the flat solar collectors models ES1V2.0, ES1V2.65, EM2V/2,0 ES2V/2.0 AL,
ES2V/2.65 and ES2H/2.65 on the flat roof or the foundation.
1. Introduction
Lightning protection
In case the height at which the collectors are to be installed exceeds 20 metres
and a building is not equipped with the lightning protection it is necessary to
connect all electrically conducting elements with an earth rod (minimal earth
rod cross-section –16mm2), and then with a compensating potential.
In case the height at which the collectors are to be installed does not exceed
20 metres it is not necessary to provide the lightning protection.
If the building is equipped with the lightning protection it is important to check
the connection of the solar system to the lightning protection. That task should
be performed by an electrician.
Recycling
Completely used up solar collectors can be returned to the manufacturer.
The returned solar collectors shall be utilized by the manufacturer in the way
which is the least burdensome for the natural environment.
2. Safety during installation
Before commencing the installation work it is necessary to immediately
get acquainted with the safety tips!
2.1. Notes included in the instruction.
The installation instruction includes important information concerning safety
and proper positioning of the collectors on the roof as well as the correct
execution of the hydraulic connection. Drawings and information included in
the instruction apply to a vertical installation of the collectors.
Installation of the collators can only be performed by qualified personnel with
professional experience in the field of water supply and gas systems.
Upon completion of works an installer should hand over the installation
instruction to a customer and clearly explain the principles of operation and
directions essential to a proper operation of the solar system.
2.2Application
This instruction includes a description of an assembly set to carry out the
installation of solar collectors on the roof or flat surface with the inclination
ranging from 30o up to 65o.
The assembly set shall exclusively be used to perform the installation of solar
collectors, it must not be used to install different devices on the roof.
Installation of only solar collectors on the supporting structure guarantees its
safety of operation.
Collectors mounted on the ground must be linked to the ground by the
foundation and construction of temporary (not included in the standard kit.
The minimum distance between the bottom edge of the collector surface of
the ground must be min.40cm

Installation instruction
of the flat solar collectors models ES1V2.0, ES1V2.65, EM2V/2,0 ES2V/2.0 AL,
ES2V/2.65 and ES2H/2.65 on the flat roof or the foundation.
3. Before commencing the installation.
Directions!
As the work on the roof can be dangerous it is recommended to hire a
roofwork firm.
DANGER OF GETTING SCALED.
In case the collectors and assembly materials are exposed to solar radiation
for a long time, there is a risk of getting scalded by hot elements.
In order to avoid the danger of scalding you should:
use protective clothing,
cover the collectors and the assembly materials with canvas cover (thanks
to which the heating up by sunbeams will be reduced).
3.1 Completeness of delivery
Before commencing the installation it is necessary to check if the delivery is
complete (see figure below) and the delivered components are free of
damage.
in case of discovering any damages the defected elements or parts should
be immediately replaced,
the replacement needs to be carried out with the application of original
spare parts only.
3.1.1 Mounting set for collectors ES1V/2.0; ES1V/2.65; ES2V/2.0 AL, EM2V/2.0, ES2V/2.65,
ES2H/2.65

Installation instruction
of the flat solar collectors models ES1V2.0, ES1V2.65, EM2V/2,0 ES2V/2.0 AL,
ES2V/2.65 and ES2H/2.65 on the flat roof or the foundation.
3.1.1 Completeness of delivery –inclined roof, tar paper
Flat roof,
foundation
Battery
No.
name
unit
1
2
3
4
5
6
7
8
9
10
1.
Triangle
pcs.
2
3
4
5
6
7
8
9
10
11
2.
Side
fastening
plate
PMB35
pcs.
4
4
4
4
4
4
4
4
4
4
3.
Inter
collector
fastening
plate
PMM112
pcs.
0
2
4
6
8
10
12
14
16
18
4.
ES1V/2,0
ES2V/2,0Al
EM2V/2.0
Multi-slot
section
l=2240
pcs.
2*1120
2*2240
2*1120
+
2*2240
4*2240
2*1120
+
4*2240
6*2240
2*1120
+
6*2240
8*2240
2*1120
+
8*2240
10*2240
5.
ES1V/2,65
ES2V/2,65
Multi-slot
section
l=2440
pcs.
2*1220
2*2440
2*1220
+
2*2440
4*2440
2*1220
+
4*2440
6*2440
2*1220
+
6*2440
8*2440
2*1220
+
8*2440
10*2440
6.
ES2H/2,65
Multi-slot
section
l=2500
pcs.
2x2500
4x2500
6x2500
8x2500
10x2500
12x2500
14x2500
16x2500
18x2500
20x2500
7.
Fastening
holder
UM145
pcs.
2
4
6
8
10
12
14
16
18
20
8.
Set of
clamping
bolt1
pcs.
4
8
12
16
20
24
28
32
36
40
hammer
head screew
inox inox
8x20
washer
inox M8
spring
washer
inox M8
nut inox M8
9.
Set of
clamping
bolt2
(triangle)
pcs.
4
6
8
10
12
14
16
18
20
22
hammer
head screew
inox inox
8x20
washer
inox M8
spring
washer
inox M8
nut inox M8
Wide
washer
inox M8

Installation instruction
of the flat solar collectors models ES1V2.0, ES1V2.65, EM2V/2,0 ES2V/2.0 AL,
ES2V/2.65 and ES2H/2.65 on the flat roof or the foundation.
3.1.2 Completeness of delivery –connecting system
Clamp fi 22
Clamping elbow
fi22 x GZ3/4"
compensator
fi22 x f22
Cross fitting
fi22 x GZ ¾”
Connecting system for harp collectors
(ES1V/2,0 ; ES1V/2,65)
Battery
No.
Name
unit
1
2
3
4
5
1.
Cross fitting fi22 x GZ3/4”
pcs.
1
1
1
1
1
2.
Camping elbow fi22 x GZ3/4”
pcs.
1
1
1
1
1
3.
Compensator fi22 x fi22
pcs.
0
1
2
3
4
Connecting system for meandric collectors
(EM2V/2.0, ES2V/2,65, ES2H/2,65)
Battery
No.
Name
unit
1
2
3
4
5
6
7
8
9
10
1.
Clamp fi22
pcs.
2
2
2
2
2
2
2
2
2
2
2.
Camping elbow fi22 x GZ3/4”
pcs.
1
1
1
1
1
1
1
1
1
1
3.
Compensator fi22 x fi22
pcs.
0
2
4
6
8
10
12
14
16
18
4.
Cross fitting fi22 x GZ3/4”
pcs.
1
1
1
1
1
1
1
1
1
1
Connecting system for aluminium
meandric collectors (ES2V/2,0 Al)
Battery
No.
Name
unit
1
2
3
4
5
6
7
8
9
10
1.
Zaślepka zaciskowa fi22 chrom
pcs.
2
2
2
2
2
2
2
2
2
2
2.
Kolanko zaciskowe fi22 x GZ3/4” chrom
pcs.
1
1
1
1
1
1
1
1
1
1
3.
Kompensator fi22 x fi22 chrom
pcs.
0
2
4
6
8
10
12
14
16
18
4.
Złącze krzyżowe fi22 x GZ3/4” chrom
pcs.
1
1
1
1
1
1
1
1
1
1

Installation instruction
of the flat solar collectors models ES1V2.0, ES1V2.65, EM2V/2,0 ES2V/2.0 AL,
ES2V/2.65 and ES2H/2.65 on the flat roof or the foundation.
3.2 Transport and storage.
during transport the collector connectors are protected by rubber caps,
collectors should be stored in a dry place. In case the collectors are stored
outside they should be protected against weather conditions.
3.3 Technical Documentation
Solar installation set consists of different components. Before installing any
of the components you should become familiar with an adequate instruction.
A separate installation instruction is attached to a given device or a piece
equipment.
installation instruction of solar collectors,
installation instruction of the pump group,
installation instruction of the solar controller,
installation instruction of the hot water container.
3.4 Additional tools and equipment
- level,
- harness with protective rope (to work high above ground),
- scaffolding, a roof ladder or a crane.
3.5 Location of a collector
Potential quantity of the absorbed radiation depends on a proper location of
the absorber in relation to falling sunbeams.
Optimum is a perpendicular position of a collector surface in relation to the
falling solar radiation.
Recommended location of a collector:
inclination angle:
40 –45o for a year-long installation,
approximately 30ofor installations used in summer,
approximately 60ofor installations used in winter,
positioning of a collector in the southern direction (or approximate to the
southern direction).
Recommended, the optimal angle of inclination of the collector is from
30 ° to 75 °.
The permissible angle of the collector is 15 ° to 90 °
It is recommended to install the collectors on the southern roof slope. During
the installation work particular attention should be paid to protect the
collectors from being overturned by strong winds. Permissible snow
and wind load amounts to max. 2,0 kN/m².
Collectors field should be located in such a way that the absorber will
not be shadowed by the adjacent buildings, trees, etc.
In case of a larger number of collector fields it is important that the
front row of the collectors do not shadow the back one.

Installation instruction
of the flat solar collectors models ES1V2.0, ES1V2.65, EM2V/2,0 ES2V/2.0 AL,
ES2V/2.65 and ES2H/2.65 on the flat roof or the foundation.
3.6 Technical data for the flat collector models: ES1V/2,0, ES2V/2,0AL, EM2V/2,0, ES1V/2,65,
ES2V/2.65 and ES2H/2.65
3.7 Required space
ES1V/2,0, EM2V/2,0 and ES2V/2,0 AL for vertical installation
Required about 2200 mm in height and 1200 mm in width for the first
collector and + 1110 mm in width for each consecutive one. In case of
mounting a collector on the inclined roof the minimum distance between
collectors and the roof edge is 1m.
ES1V/2,65, ES2V/2,65 for vertical installation
Required about 2560 mm in height and 1320 mm in width for the first
collector and + 1220 mm in width for each consecutive one. In case of
mounting a collector on the inclined roof the minimum distance between
collectors and the roof edge is 1m.
ES2H/2,65 for horizontal installation
Required about 1320 mm in height and 2560 mm in width for the first
collector and + 5210 mm in width for each consecutive one. In case of
mounting a collector on the inclined roof the minimum distance between
collectors and the roof edge is 1m.
Flat collector
Symbol
ES1V/2.0
ES2V/2.0
AL
EM2V/2.0
ES1V/2.65
ES2V/2.65
ES2H/2.65
Unit
Width
A
1006
1006
1006
1120
1120
2356
mm
Height
B
2007
2007
1988
2356
2356
1120
mm
Depth
C
85
85
85
85
85
85
mm
Collector weight
M
40
40
38
49
49
49
kg
Area
S
2,02
2,02
2,0
2,65
2,65
2,65
m2
Connectors: Cu pipe
Φ
22
22
22
22
22
22
mm
Fluid volume
V
1.8
1.8
1,8
2.2
2.2
2.2
dm3
Max working pressure
pmax
6.0
6.0
6,0
6.0
6.0
6.0
bar
Optimum flow min. -
max.
m
60-90
40-60
60-90
75-105
75-105
75-105
dm3/h

Installation instruction
of the flat solar collectors models ES1V2.0, ES1V2.65, EM2V/2,0 ES2V/2.0 AL,
ES2V/2.65 and ES2H/2.65 on the flat roof or the foundation.
3.8 Flow resistance for collectors
3.8 Warranty conditions of the installation and use of the collectors ES2V/2.0 AL
with aluminum absorber
It is allowed to use only solar fluids that is accepted and offered by the producer, e.g.
ENSOLICOL-AL -30,
The solar thermal system must be closed (hermetic):
the solar system can not contain automatic vents (potential place through the installation can
get into air),
before the first start, the solar system must be completely deaerated, and be leakproofed by
the plumber,
It is allowed to use only connections systems that are offered by the producer,
It is recommended to do the solar system with flexible stainless steel tubes or steel tubes. It is
forbidden to connect directly the connector pipe of the collector witch any copper or brass parts
of the solar system with increases the possibility of electrochemical corrosion.
1-10 x ES2V/2,0 AL
20
30
40
50
60
70
80
90
100
40 90 150 210 270 330 390 450 510 570 630 690 750 810 870
liquid flow [dm3/h]
pressure drop [mbar]
1-2 3-4 5-6 7-8 9-10
1-10 x ES2V/2,65 i ES2H/2,65
20
40
60
80
100
120
140
160
60
120
180
240
300
360
420
480
540
600
660
720
780
840
900
960
1020
1080
1140
1200
1260
1320
1380
liquid flow [dm3/h]
pressure drop [mbar]
1-2 3-4 5-6 7-8 9-10
ES1V/2,0
0
5
10
15
20
25
30
35
40
50 100 150 200 250 300
liquid flow [dm3/h]
pressure drop [mbar]
ES1V/2,65
0
2
4
6
8
10
12
14
16
18
20
020 40 60 80 100 120 140 160 180 200
liquid flow [ dm3/h]
pressure drop [mbar]

Installation instruction
of the flat solar collectors models ES1V2.0, ES1V2.65, EM2V/2,0 ES2V/2.0 AL,
ES2V/2.65 and ES2H/2.65 on the flat roof or the foundation.
4. Installation of the supporting structure
4.1 Inclination angle for the collectors
4.1.1 Roof or flat surface.
In case of collectors installed on the roof or the flat surface the inclination
angle of the assembly set corresponds directly with the assumed inclination of
the collectors.
4.1.2 Roof or surface of the inclination up to 20°.
In case of roofs inclined
towards the south - „A”
you must subtract the
value of the roof
inclination from
the assumed inclination of
the collectors.
In case of roofs inclined
towards the north - „B” you
must add the value of the
roof inclination to the
assumed inclination of the collectors.
The obtained value indicates the inclination angle of the assembly set.
4.2 Setting the inclination angle
4.2.1 Setting the inclination angle of the assembly set for collectors
ES2H/2,65
Inclination angle of the assembly set can be adjusted by cutting the profile in
the right, marked place. Standard angles of inclination have been determined
as 30, 45 and 60° depending on the setting of the assembly set.

Installation instruction
of the flat solar collectors models ES1V2.0, ES1V2.65, EM2V/2,0 ES2V/2.0 AL,
ES2V/2.65 and ES2H/2.65 on the flat roof or the foundation.
4.2.2 Setting the inclination angle of the assembly set for collectors
ES1V/2.0, ES2V/2.0 AL, EM2V/2.0, ES1V/2.65, ES2V/2.65.
Inclination angle of the assembly set can
be adjusted by means of telescopic rails.
Standard angles of inclination have been
determined as 30, 45 and 60° depending
on the setting of the assembly set. In
order to obtain an assumed angle of
inclination you should properly connect
the sections of the assembly set.
30oangle is obtained by joining the
holes: A1 with B1 and B2 with C1.
45oangle is obtained by joining the
holes: A2 with B1 and B3 with C1.
60oangle is obtained by joining the
holes: A2 with B1 and B4 with C1.
where:
A –Prop of the supporting frame
B –Upper strut
C –Bottom strut
If it is necessary to set up the assembly set at a different angle you should
make the connecting holes by yourself, bearing in mind the extreme setting of
the solar collectors inclination ranging from 15 to 75°.

Installation instruction
of the flat solar collectors models ES1V2.0, ES1V2.65, EM2V/2,0 ES2V/2.0 AL,
ES2V/2.65 and ES2H/2.65 on the flat roof or the foundation.
4.3 Mounting a collector on the flat roof or the foundation

Installation instruction
of the flat solar collectors models ES1V2.0, ES1V2.65, EM2V/2,0 ES2V/2.0 AL,
ES2V/2.65 and ES2H/2.65 on the flat roof or the foundation.
4.4 Assembly of supporting triangles
4.4.1 Assembly of supporting triangles for ES1V/2.0, ES2V/2.0 AL,
EM2V/2.0, ES1V/2.65, ES2V/2.65, ES2H/2.65
Supporting triangles are the base of the assembly set. All triangles are
assembled in the same way.
Directions!
Before commencing the assembly of a supporting triangle you should lay out
all its components according to the figure presented below.
After planning out the location of all the components you can start bolting
together an assembly triangle, bearing in mind the setting of a suitable
inclination angle (4.2 Determining the inclination angle of the collectors)

Installation instruction
of the flat solar collectors models ES1V2.0, ES1V2.65, EM2V/2,0 ES2V/2.0 AL,
ES2V/2.65 and ES2H/2.65 on the flat roof or the foundation.
4.4.2 Assembly of supporting triangles for ES2H/2,65
Supporting triangles are the base of the assembly set. All triangles are
assembled in the same way.
4.6 Determination of the minimal surface
Installation of the support constructions may take place only on a specially prepared
surface. Bellow are presented the minimum dimensions of foundations supporting
constructions Ensol.
Installing the collector on a flat roof the minimum distance from the edge of the roof
is 1m.
4.6.1 Number and spacing of supporting triangles
Two supporting triangles are needed for the first collector. Each consecutive
collector should be provided with one supporting triangle more.
Spacing between supporting triangles depends on the number of the installed
collectors and amounts correspondingly to:
Number
of
collectors
Number
of
triangles
Distance betweend the triangles
[mm]
ES1V/2,0
ES2V/2.0AL
EM2V/2,0
ES1V/2,65
ES2V/2.65
ES2H/2.65
1
2
0,805
0,920
2,155
2
3
0,955
1,070
2,335
3
4
1,005
1,120
2,390
4
5
1,030
1,145
2,420
5
6
1,045
1,160
2,440

Installation instruction
of the flat solar collectors models ES1V2.0, ES1V2.65, EM2V/2,0 ES2V/2.0 AL,
ES2V/2.65 and ES2H/2.65 on the flat roof or the foundation.
4.7 Number and spacing of multi-slot sections
The assembly set includes an adequate number of multi-slot sections
depending on the number of collectors.
Assembly triangles are provided with
holes for installing the profile rails.
Tab. Joint length of sections for a given quantity of collectors. The table
provides a joint number of sections and connectors for the upper and bottom
set of sections.
Number of
collectors
ES1V/2.0 ES2V/2.0AL
EM2V/2,0
ES1V/2.65; ES2V/2.65
ES2H/2.65
Section 1115
mm
Section 2235
mm
Section 1215
mm
Section 2435
mm
Section 2495
mm
1
2 pcs
-
2 pcs
-
2 pcs
2
-
2 pcs
-
2 pcs
4 pcs
3
2 pcs
2 pcs
2 pcs
2 pcs
6 pcs
4
-
4 pcs
-
4 pcs
8 pcs
5
2 pcs
4 pcs
2 pcs
4 pcs
10 pcs
4.8 Connecting the multi-slot sections
Multi-slot sections should be connected with each other in accordance with
the table of configurations, see the figure below.
Directions!
In order to avoid an uncontrollable displacement of a connector, screws can
be used as distance elements (screws are not delivered with the set).
The connector itself is not assembled.
screws need to be screwed in the sections at the distance of x = 105 mm from
the edge,
using a delivered connecting component you should join the sections with
each other.

Installation instruction
of the flat solar collectors models ES1V2.0, ES1V2.65, EM2V/2,0 ES2V/2.0 AL,
ES2V/2.65 and ES2H/2.65 on the flat roof or the foundation.
4.9 Connecting multi-slot sections with supporting triangle
Bolts, which were delivered with the set, should be placed in the multi-slot
sections in such quantity as the number of supporting triangles, see the figure
below.
Taking into account spacing of the supporting triangles and multi-slot
sections, the profile rails must be bolted with the supporting triangles, as in
the figure below.
4.10 Mounting a collector on a multi-slot section.
Each collector should rest on two fastening holders
which protect it against sliding down.
Fastening holders should be located at the distance of
x = 200 –250 mm from the collector's edge.
4.11 Assembly of the fastening holders.
Collector's fastening holders must be fixed in the upper gap of the bottom
multi-slot section, as shown below.
Attach the fastening holder on the wider edge of the multi-slot section

Installation instruction
of the flat solar collectors models ES1V2.0, ES1V2.65, EM2V/2,0 ES2V/2.0 AL,
ES2V/2.65 and ES2H/2.65 on the flat roof or the foundation.
4.12 Fastening the structure to the surface
After assembly the supporting structure needs to be located at its place of
destination. The supporting structure must then be fixed to the surface with
anchor bolts to protect it against being torn out of the surface.
Mark out the places of fixing the
structure to the ground through the holes
in the foot of the supporting frame.
After marking out the holes you should then:
- unbolt the foot of the supporting frame (put
gently the structure away to be able to work
freely),
- make the anchor holes,
- fix the base to the surface,
- bolt the foot of the supporting frame.

Installation instruction
of the flat solar collectors models ES1V2.0, ES1V2.65, EM2V/2,0 ES2V/2.0 AL,
ES2V/2.65 and ES2H/2.65 on the flat roof or the foundation.
5. Installation of the collectors
5. 1 Installation of the collectors on the supporting structure.
During the installation of the collectors all safety rules must be obeyed.
Hazard
when the work on the roof is carried out it is necessary to obey safety rules in
order to avoid accidents,
during the work on the roof the installers should be protected against falling
down,
installation should be carried out by at least two persons,
protective clothing needs to be worn at work,
upon completing the installation it must be checked if the assembly set and
the collectors have been installed in a stable way.
Directions!
During transport and installation the collectors need to be protected against
falling down.
There are four fasteners for each collector, two on each profile.
place the bolts in the multi-slot sections, two for each collector,
locate the collector on the multi-slot sections in such a way that it is
supported by the bottom fastening holders,
collectors should be hydraulically connected by means of a compensator
(see 6.3.1),
mount the fastening plates at the bottom gap of the collector's frame,
screw the nut with the bolt located in the section, as shown below.

Installation instruction
of the flat solar collectors models ES1V2.0, ES1V2.65, EM2V/2,0 ES2V/2.0 AL,
ES2V/2.65 and ES2H/2.65 on the flat roof or the foundation.
6.0 Hydraulic connection of the collector
ATTENTION!
ALL CLAMPING CONNECTIONS
SCREW WITH STRENGTH 45 -50 Nm
COUNTER DURING SCREWING
Counter wrench with the connector can not
change the position during the screwing
In case of leakage, tighten the clamping connections with a
force of max 80 Nm
In case of further leaks, use sealant Loxeal 8672 according
to instructions on the package sealer.
6.1 Hydraulic connection of the harp collectors ES1V/2.0 and ES1V/2.65
Directions!
Hydraulic conduits and fixtures can be connected at the left or right side of
the collector battery. The instruction presents the connection at the right side,
as an example.
One-sided connection of maximum 5 collectors.
When forming a battery you can connect maximum 5 collectors.
6.2 Hydraulic connection of the meander collectors ES2V/2.0 AL. ES2V/2,65,
EM2V/2,0 and ES2H/2,65
Directions!
The power supply*1 and return*2 must be connected to the diagonal of the
collector or the battery. The power supply*1 should be connected to the lower
connection and the return*2 to the top connector. The Connection for power
supply*1/return*2 is arbitrary –in can be from the left or right sight. In the two
other connections should be clamps. The instruction presents the connection
at the right side, as an example.
One-sided connection of maximum 10 collectors.
When forming a battery you can connect maximum 10 collectors.
*1 power supply = inlet of cold fluid *2 return = Outlet of warmed fluid

Installation instruction
of the flat solar collectors models ES1V2.0, ES1V2.65, EM2V/2,0 ES2V/2.0 AL,
ES2V/2.65 and ES2H/2.65 on the flat roof or the foundation.
6.3.1 Connecting the collectors with a clamping pipe union.
Collectors ES1V/2.0 and ES1V/2.65 –connecting upper connectors pipe
Collectors ES2V/2.0 AL, ES2V/2.65, EM2V/2,0 and ES2H/2.65 –connecting
upper and bottom connector pipe
1 –connector pipe of
the collector
2 –strengthening sleeve
3 –pipe union nut
4 –clamping ring
5 –compensator
Mount the compensator on the first collector, then move the second collector
closer and fasten the pipe union on both collectors.
place the strengthening sleeve (2) in the connector pipe of the collector (1),
pipe union nut (3) should be put on the connector pipe of the collector (1),
clamping ring (4) should be placed on the connector pipe of the collector,
screw the nut (3) onto the pipe union body,
place the strengthening sleeve in the connector pipe of the second collector,
put the nut on the connector pipe of the second collector,
place the clamping ring on the connector pipe of the second collector,
move the second collector closer to the compensator,
screw the nut onto the compensator.
Directions
The nut should be tightened up so as to secure the leak-tightness of the
connection, however, not too strong in order to avoid damage to the
connector pipe of the collector.
6.3.2 Connection of the collectors power supply *1
1 –connector pipe of the collector
2 –strengthening sleeve
3 –nut
4 –clamping ring
5 –elbow body
6 –gasket
7 –insulated flexible hose
strengthening sleeve (2) in the connector pipe of the
collector (1), elbow nut (3) should be put on the connector pipe of the collector (1),
clamping ring (4) should be placed on the connector pipe of the collector (1),
screw the nut (3) onto the elbow (5),
flexible hose (6) needs to be screwed on the elbow (5),
connect the flexible hose to the solar system.
*1 power supply = inlet of cold fluid *2 return = Outlet of warmed fluid

Installation instruction
of the flat solar collectors models ES1V2.0, ES1V2.65, EM2V/2,0 ES2V/2.0 AL,
ES2V/2.65 and ES2H/2.65 on the flat roof or the foundation.
6.3.3 Connection of the collector return *2
1 –connector pipe of the collector,
2 –strengthening sleeve,
3 –clamp nut,
4 –clamping ring,
5 –complete cross fitting with a manual vent and
immersion sleeve,
6 –insulated flexible hose
place the strengthening sleeve (2) in the connector pipe of the collector (1),
put the clamp nut (3) on the connector pipe of the collector (1),
place the clamping ring (4) on the connector pipe of the collector (1),
immersion sleeve with the complete cross fitting (5) needs to be placed in the
connector pipe of the collector (1),
screw the clamp nut (3) onto the cross fitting (5) at the left side,
screw the insulated flexible hose (6) at the bottom of the pipe-cross (5),
connect the flexible conduit to the solar system.
6.3.4 - Option for mounting an automatic air escape.
If there is not any space for an automatic air escape a manual air escape
should be installed.
7 –adapter ¾ '' x 3/8 '' - unscrew the manual air escape from
8 –ball valve 3/8 '' the top of the pipe-cross (5),
9 –automatic air escape 3/8 '' - successively screw the adapter (7),
valve (8) and automatic air escape
(9) at the top of the pipe-cross.
Directions!
Due to high temperatures in the solar systems it is necessary to use
air escapes made completely of metal.
6.3.5 Connection of the clamps
- for collectors ES2V/2.0AL, EM2V/2.0, ES2V/2,65 and ES2H/2,65
Mount the clamps on the empty connectors (on the
diagonal of the collector or the battery).
1. Clamp
2. Solar collector
*1 power supply = inlet of cold fluid *2 return = Outlet of warmed fluid
