Equalizer FC10TE Assembly instructions

OPERATOR INSTRUCTION MANUAL
EQUALIZER INTERNATIONAL LTD
www.equalizerinternational.com
HYDRAULIC
FLANGE CLOSING
TOOL
FC10TE

OPERATOR INSTRUCTION MANUAL IM_FC10TE_Rev09_A4
FC10TE HYDRAULIC FLANGE CLOSING TOOL
1
CONTENTS
1. INTRODUCTION
2. TOOL SAFETY
2.1 GENERAL SAFETY
2.2 PERSONNEL COMPETENCY
2.3 DISCLAIMER
2.4 DEFINITION OF TERMS
2.5 HAZARDS
3. FC10TE HYDRAULIC FLANGE CLOSING TOOL
3.1 TOOL CAPABILITIES
3.2 TOOL FUNCTION
3.3 KIT CONTENTS
3.4 TOOL DIMENSIONS
3.5 TOOL MAINTENANCE
4. REGULATORY INFORMATION
4.1 REGISTERED HEAD OFFICE
5. PARTS LISTS & SERVICE KITS
15/02/2019

OPERATOR INSTRUCTION MANUAL IM_FC10TE_Rev09_A4
FC10TE HYDRAULIC FLANGE CLOSING TOOL
2
1.
INTRODUCTION
The Equalizer FC10TE Hydraulic Flange Pulling Tools
are tools designed to assist in the maintenance and
installation of pipeline ange assemblies.
The FC10TE Hydraulic Flange Pulling Tools are used to
close any ange joint made up of anges with a bolt
hole of 22mm (7/8”) or greater producing a pulling force
of up to 20T when used as recomended in pairs. The
FC10TE can close from a distance of 600mm.
The use of these instructions will promote safe use, and
maximise the service life of the tool.
It is essential that the user familiarises themselves with
the contents of this manual prior to using the tool.
This manual contains information for the following tools:
• FC10TE Flange Closing Tool
2.
SAFETY INFORMATION
2.1
GENERAL SAFETY
These instructions cover the safe operation and
maintenance of THE EQUALIZER FC10TE HYDRAULIC
tools. The use of these tools should be as part of a broader
task-based risk assessment, which should be carried out
by the operation supervisor or other competent person.
Failure to comply with the safety information contained
within this manual could result in personal injury or
equipment damage. Read all instructions, warnings and
cautions carefully, and follow all safety precautions.
The safety of the operator, any assisting personnel and
the general public is of paramount importance. Always
work in accordance with applicable national, local, site &
company-wide safety procedures.
2.2
PERSONNEL COMPETENCY
Onlypersonneldeemedcompetentintheuseofmechanical
and hydraulic equipment should use these tools.
2.3
DISCLAIMER
Equalizer cannot be held responsible for injury or damage
resulting from unsafe product use, lack of maintenance
or incorrect product and/or system operation. If in doubt
as to the safety precautions and applications, contact
Equalizer using the contact details at the back of this
manual.

OPERATOR INSTRUCTION MANUAL IM_FC10TE_Rev09_A4
FC10TE HYDRAULIC FLANGE CLOSING TOOL
3
2.4
DEFINITION OF TERMS
A CAUTION is used to indicate correct operating or
maintenance procedures and practices to prevent damage
to, or destruction of equipment or other property.
A WARNING indicates a potential danger that requires
correct procedures or practices to avoid personal injury.
A DANGER is only used when your action or lack of action
may cause serious injury or even death.
DO: an illustration showing how the tool should
be used.
DON’T: an illustration showing an incorrect way
to use a tool.
2.5
HAZARDS
WARNING: ensure all hydraulic components are
rated to a safe working pressure of 700 bar
(10000 psi).
WARNING: Do not overload equipment. The risk
of hydraulic overloading can be minimised by using
the Equalizer Hand Pump, which has a factory-set
safety valve preventing the safe working pressure
being exceeded.
If alternative hydraulic pumps are used, ensure
that there are adequate systems to limit the the
working pressure to 700 bar (10,000 psi).
CAUTION: ensure components are protected
from external sources of damage, such as excessive
heat, ame, moving machine parts, sharp edges
and corrosive chemicals.
CAUTION: Take care to avoid sharp bends and
kinks in hydraulic hoses. Bends and kinks can
cause severe back-up pressure and cause hose
failure. Protect hoses from dropped objects; a
sharp impact may cause internal damage to hose
wire strands. Protect hoses from crush risks, such
as heavy objects or vehicles; crush damage can
cause hose failure.
WARNING: Applying pressure to a damaged
hose may cause it to rupture.
WARNING: Immediately replace worn or
damaged parts. Use only genuine Equalizer parts
from approved distributors or service centres.
Equalizer parts have been engineered and
manufactured to be t-for-purpose.
DANGER: To minimise risk of personal injury keep
hands and feet away from the tool and workpiece
during operation.
WARNING: Always wear suitable clothing and
Personal Protective Equipment (PPE).
DANGER: Do not handle pressurised hoses;
escaping oil under pressure can penetrate the
skin, causing serious injury. Seek medical attention
immediately if oil penetration is suspected.
WARNING: Only pressurize complete and fully
connected hydraulic systems. Do not pressurize
systems that contain unconnected couplers.
CAUTION: Do not lift hydraulic equipment by the
hosesor couplers.Useonly thedesignated carrying
handles.
CAUTION: Lubricate tools as directed in this
manual prior to operation. Use only approved
lubricants of high quality, following the lubricant
manufacturers instructions.
WARNING: Never place ngers in a joint held by
an activated tool
CAUTION: Never hammer or force the tool into a
bolt hole; if it does not t easily you are using the
wrong size of tool.

OPERATOR INSTRUCTION MANUAL IM_FC10TE_Rev09_A4
FC10TE HYDRAULIC FLANGE CLOSING TOOL
4
3.
FC10TE
HYDRAULIC FLANGE
CLOSING TOOL
3.1
TOOL CAPABILITIES
CLOSING FORCE
Closing force = 10 tonnes per tool
It is recommended that tools are used in pairs, giving 2
x 10 = 20 tonnes
If using the Equalizer HP550S/D Hand Pump (or if a
hydraulic pressure gauge is tted), the spreading force
per tool can be determined by taking a reading from the
gauge.
Gauge pressures will produce spreading forces as set out
below.
Pressure Bar 69 207 345 483 690
psi 1000 3000 5000 7000 10000
Spreading
force T135710
RANGE OF APPLICATION
Closing distance = 600mm - 0mm (23.5” - 0”)
Can be used on any ange joint with ange bolt holes of
22mm (7/8”) or greater.
Hydraulic oil grade: 15 centistokes(cSt) @ 40°C tested
by ASTM D 445
The FC10TE has not been designed or certied
as lifting equipment. If the tool is being used
to close ange joints with a Vertical Axis the
FC10TE must be used in conjuction with
certied lifting equipment.
3.2
FC10TE TOOL FUNCTION
FC10TE GENERAL GUIDANCE
1. The Pull Rod is inserted through the coresponding
bolt holes in the anges.
PULL ROD
2. The FC10TE Tool is slid over the pull rod untill the face
of the tool comes into contact with the ange.
FC10TE TOOL
3. The ratchet nut is slid over the pull rod and locked
into the tool.
REACTION NUT
4. The hydraulic hand pump and hoses are connected
HAND PUMP

OPERATOR INSTRUCTION MANUAL IM_FC10TE_Rev09_A4
FC10TE HYDRAULIC FLANGE CLOSING TOOL
5
5. The Hand Pump is actuated untill the cylinders reach
full stroke.
6. The Hydraulic pressure is released and the cylinders
are allowed to fully retract.
RELEASE VALVE
7. The Hand Pump is actuated until the cylinders reach
full stroke.
8. Steps 6 and 7 are repeated untill the ange joint is
closed.
INSTALLATION AND OPERATION
Note: Prior to attaching the FCT10TE it is
important that the location of the tools around
the ange joint is considered. the tools should
be attached to the bolt holes at the points
where the highest load is expected.
Consideration should also be given to the
ange Gasket/Seal ring, it may be neccesary
toinsertthe Gasket/SealringPrior toattaching
the tools.
1. The anges are placed with a gap of no more than
600mm between the backs of the anges and within
reasonable alignment.
2. Having determined the best location for the tools
insert both pull rods through the bolt holes in one
ange and into the corresponding bolt holes of the
mating ange.
SHORT
THREADED
SECTION
LONG THREADED SECTION
CAUTION: The Pull Rod has a long threaded
section and a short threaded section. The
threads on both sections are different!, The
short threaded end of the Pull Rod must be
passed through the anges to mate with the
pull nut.

OPERATOR INSTRUCTION MANUAL IM_FC10TE_Rev09_A4
FC10TE HYDRAULIC FLANGE CLOSING TOOL
6
6. The Secondary Ratchet Nuts are then slid up the pull
rods until the nut retaining pins engage in the key
holes in the FC10TE’s rear plate.
RETAINING
PIN KEY HOLE
SECONDARY
RATCHET
NUT
PULL ON THE
RELEASE SLEEVE
TO RETRACT
THE NUT
PULL ON THE
MAIN BODY TO
ADVANCE THE
NUT
ADVANCE
RETRACT
LOCK
LOAD ON THIS
FACE WILL
LOCK THE NUT
3. The Rod washers are slid over the Pull Rod and rotated
to align with the curvature of the ange.
4. The Pull Nuts are threaded on to the pull rod.
5. The FC10TE tools are slid on to the Pull Rods until the
face of the tools are in contact with the back of the
flange. You will feel / hear a clicking as the Primary
Ratchet nut slides along the Pull Rod.

OPERATOR INSTRUCTION MANUAL IM_FC10TE_Rev09_A4
FC10TE HYDRAULIC FLANGE CLOSING TOOL
7
RELEASE
VALVE
PRESSURE
GAUGE
HP550S
RELEASE
VALVE
PRESSURE
GAUGE
HP550D
9. The Pumps can now be connected to the tools using
the Hoses supplied. ensure all couplers are fully
tightened.
HP550D
HP550S
Note: The Ratchet Nut is designed to move
freely when advanced along the pull rod
(indicated by the green arrow).
The nut can only be advanced by gripping
on the nut body.
The nut will lock on to the pull rod when a
force is applied to the load face of the nut.
It is not possible to move the nut until the
load is removed from the load face of the
nut.
The nut can only be retracted by pulling on
the release sleeve in the retract direction
(indicated by the yellow arrow).
7. Rotate the secondary ratchet nuts clockwise 30
degrees to lock them on to the rear plate.
REAR PLATE
8. Check that the release valves on the hand pumps are
open by rotating fully anti-clockwise and then connect
the Pressure gauges to the pump ensuring all the
couplers are fully hand tight.
RELEASE
VALVE

OPERATOR INSTRUCTION MANUAL IM_FC10TE_Rev09_A4
FC10TE HYDRAULIC FLANGE CLOSING TOOL
8
12. Release the hydraulic pressure from the system. This
will allow the Actuators to retract and the secondary
ratchetnutto advancealongthepull rodautomatically.
13. Once the Actuators have fully retracted close the
release valve and continue priming the hand pump
until the actuators have reached full stroke.
14. Repeat steps 12 and 13 to continue closing the gap
between ange faces. Adjust the pressure on each
tool as neccesary to maintain an even gap around
the joint.
Note: If you are experiencing misalignment
of the anges during the nal stages of
closing the joint Equalizer International’s
Flange Alignment tools can be used in
conjuction with the FC10TE. For information
on these tools please vist “www.
equalizerinternational.com”
Note: Prior to operating the Equalizer
Hydraulic Hand Pumps please read the
Hydraulic Hand Pump Manual. This is
included in all tool kits and is also available
for download from
www.equalizerinternational.com
10. Close the release valve on the pump by turning
clockwise. To commence flange closing gently prime
the pump(s) adjusting the pressure on each tool as
neccessary to maintain parrallelism between flange
faces. If the pressure increases to 10,000 PSI with no
movement of the flanges then a greater number of
tools will be required to close the joint.
RELEASE
VALVE
11. Continue priming the Hand Pump untill the actuators
have reached full stroke 100mm (4”).

OPERATOR INSTRUCTION MANUAL IM_FC10TE_Rev09_A4
FC10TE HYDRAULIC FLANGE CLOSING TOOL
9
17. Now that the pressure has been released from
the system the hydraulic Pump and Hoses can be
detached.
18. Now that the load has been released from the tools,
the secondary ratchet nut can be removed. Rotate the
nut anticlock wise through 30 degrees to disengage it
from the rear plate then slide the nut off by gripping
and pulling on the pull sleeve section of the nut.
PULL
SLEEVE
SECONDARY
RATCHET
NUT
15. Once the ange joint has been fully closed insert and
tighten as many bolts as possible with the FC10TE still
in position.
FLANGE
BOLTS
CAUTION: The FC10TE Ratchet Nuts will not
release until they are fully unloaded, this is
achieved by tightening the ange bolts until all
the load has been transferred onto them.
16. Once the ange bolts have been tightened sufciently
to remove any load from the FC10TE turn the release
valves on the pump(s) anticlockwise to release the
pressure from the hydraulic system.

OPERATOR INSTRUCTION MANUAL IM_FC10TE_Rev09_A4
FC10TE HYDRAULIC FLANGE CLOSING TOOL
10
19. The FC10TE can now be removed by gripping and
pulling on the pull sleeve section of the primary nut.
PULL
SLEEVE PRIMARY
RATCHET
NUT
20. The Pull Rod complete with pull nut and washer can
now be withdrawn from the ange joint.
21. Now that the tool has been removed all the ange
bolts can be inserted and tightened in accordance
with the relevant procedure.

OPERATOR INSTRUCTION MANUAL IM_FC10TE_Rev09_A4
FC10TE HYDRAULIC FLANGE CLOSING TOOL
11
FC10TE MAXI KIT
Product Code: FC10TEMAX
2 x FC10TE Tools
4 x 10,000 psi (700 bar) 5T Hydraulic cylinders
1 x 10,000 psi (700 bar) HP550D Sealed Hand Pump
with Gauges
2 x 10,000 psi (700 bar) Hydraulic Hose, 2m (78.75”)
1 x Instruction Manual
1 x Carry-Case with Protective Foam Inserts
Carry Case dimensions:
890 x 570 x 165 mm
(35.04” x 22.44” x 6.50”)
Tool Weight: 11kg (24.25 lb)
Gross Kit Weight: 36.5kg (50.47 lb)
3.3
KIT CONTENTS
FC10TE STANDARD KIT
Product Code: FC10TESTD
1 x FC10TE Tool
2 x 10,000 psi (700 bar) 5T Hydraulic cylinders
1 x 10,000 psi (700 bar) HP550S Sealed Hand Pump with
Gauge
1 x 10,000 psi (700 bar) Hydraulic Hose, 2m (78.75”)
1 x Instruction Manual
1 x Carry-Case with Protective Foam Inserts
Carry Case dimensions:
890 x 570 x 165 mm
(35.04” x 22.44” x 6.50”)
Tool Weight: 11kg (24.25 lb)
Gross Kit Weight: 23.5kg (51.80 lb)

OPERATOR INSTRUCTION MANUAL IM_FC10TE_Rev09_A4
FC10TE HYDRAULIC FLANGE CLOSING TOOL
12
3.4
FC10TE TOOL DIMENSIONS
165 mm
(6.5”)
385 mm
(15.2”)
1000 mm
(39.4”)
259 mm
(10.2”)

OPERATOR INSTRUCTION MANUAL IM_FC10TE_Rev09_A4
FC10TE HYDRAULIC FLANGE CLOSING TOOL
13
3. Before disassembling the nut any further, take note
of the three centre dab marks on the cage rear ring,
the lock washer, and the nut cap. These marks should
be aligned.
CENTRE
DAB
MARKS ..
.
4. Unscrew the lock screws and remove the cage circlip.
The lock washer can now be removed to expose the
Nut Cap Return Screws.
LOCK
SCREWS
LOCK
WASHER
CAGE CIR-
CLIP
5. Unscrew and remove the Nut Cap Return Screws
and return springs this will allow the Nut Cap to be
removed from the Ratchet Nut Body.
RETURN
SPRINGS
RETURN
SCREWS
NUT CAP
6. Having removed the Nut Cap you can then remove
the upper Reaction Circlip, the Reation Plate and the
lower Reaction Circlip.
REACTION
PLATE
REACTION
CIRCLIPS
NUT CAP
3.5
FC10TE TOOL MAINTENANCE
INSPECTION
A thorough inspection should be carried out prior
to usage, storage or transportation to ensure the
completeness and condition of the tool.
Inspection should include:
• visual inspection of the outer parts of the tool,
checking for obvious damage, degradation or missing
parts.
Cleaning and servicing should be undertaken as required
prior to the tool being used, stored or transported.
CLEANING
At regular intervals and specically after exposure to salt
water Equalizer FC10TE tools should be dismantled, and
all parts cleaned with a clean rag and WD40 (or similar)
to remove dirt and old grease, and then relubricated: The
following procedure should be followed when dismantling
and rebuilding the tools.
1. Unscrew and remove the primary ratchet nut retaining
screws. This will allow the ball washer and ratchet nut
to be removed from the assembly.
RETAINING
SCREWS
PRIMARY
RATCHET
NUT
BALL
WASHER
2. Unscrew and remove the three lock screws and
remove the end cap from the ratchet nut.
LOCK
SCREWS
END
CAP

OPERATOR INSTRUCTION MANUAL IM_FC10TE_Rev09_A4
FC10TE HYDRAULIC FLANGE CLOSING TOOL
14
10. Clean all components with a rag and WD40 (or
similar), removing any visible dirt or grit (paying
particular attention to the Collet Segments, Cage and
Nut Body).
Smear all mating surfaces with a high performance
molybdenum disulphide grease such as Rocol
Sapphire Hi-Load 2.
Replace missing, worn or damaged parts. Use only
genuine Equalizer parts from approved distributors or
service centres. Equalizer parts have been engineered
and manufactured to be t for purpose.
11. Reassemble by reversing steps 1-9
If topping or replacing hydraulic oil as part of a service,
use only premium quality hydraulic oil of the grade 15 cSt.
7. Unscrew and remove complete collet assembly from
the nut body.
8. Having removed the collet assembly please note
the centre dab marks indicating the position of the
rst collet section. Please also note that the collet
segments are arranged on the cage such that the
external ridges form one continuous thread.
CENTRE
DAB
MARKS ..
CAGE
EXTERNAL
RIDGES
9. Unclip the Collet Retaining Springs and remove the
Collet Segments from the Cage.
COLLET
RETAINING
SPRING
COLLET
RETAINING
SPRING

OPERATOR INSTRUCTION MANUAL IM_FC10TE_Rev09_A4
FC10TE HYDRAULIC FLANGE CLOSING TOOL
15
STORAGE AND TRANSPORTATION
Equalizer tools should be stored in a cool, dry place. Tools
should always be cleaned, serviced and lubricated prior to
storage. Ensure that tools are stored in their designated
packing cases.
LONG-TERM STORAGE - MAINTENANCE PLAN
1. Rub components down with a dry cloth to remove
moisture.
2. Coat EVERY surface and contact point with a corrosion
inhibitor. Where necessary, coat inside and outside of
component
3. Nuts and threads must also be coated with a corrosion
inhibitor.
4. Once surfaces have been coated, seal individual
components in clear plastic bags or clear vacuum
bags or clear shrink wrap.
NOTE: bags/shrink wrap must be clear for visibility.
Take care when using shrink wrap that the tool is/
components are still easy to see.
5. Remove all or, where not vacuum sealed, as much air
from bags as possible.
6. Once bags have been closed and sealed DO NOT re-
open. Any visual inspections must be done with closed
and sealed bags. If bags are opened the components
will have to be dried, re-coated and re-sealed in bags/
shrink wrap.
7. Replace silica gel (100g) EVERY TIME the case is
opened.
NOTE: depending on moisture content of air, silica gel
should be changed weekly.
8. Visually inspect kits after 30-days and every 30-days
thereafter. Remember to replace silica gel before
closing case.

OPERATOR INSTRUCTION MANUAL IM_FC10TE_Rev09_A4
FC10TE HYDRAULIC FLANGE CLOSING TOOL
16
4.
REGULATORY
INFORMATION
4.1
REGISTERED HEAD OFFICE
EQUALIZER INTERNATIONAL LTD.
Equalizer House
Claymore Drive
Aberdeen
Scotland
AB23 8GD
5.
PARTS LISTS
& SERVICE KITS

OPERATOR INSTRUCTION MANUAL IM_FC10TE_Rev09_A4
FC10TE HYDRAULIC FLANGE CLOSING TOOL
17
FC10TE PART LIST
ITEM KIT PART No. DESCRIPTION QTY.
01
02
03
04
05
06
07
08
09
10
11
12
13
14
15
16
17
18
070001-01
300901-01
750101-01
750201-01
752101-01
752201-01
752301-01
752401-01
752501-01
752506-01
752601-01
752701-01
752801-01
752901-01
753001-01
753501-01
754001-01
752510-01
READ INSTR. STICKER
HYDRAULIC COUPLER
FRONT PLATE
REAR PLATE
SCKT HEAD SCREW
SCKT HEAD SCREW
CYLINDER NOSE SCREW
CYLINDER NOSE ADAPTOR
5T H. CYLINDER
SET SCREW
COUPLING HOSE
BALL WASHER
PULL ROD
ROD WASHER
NUT RETAINING SLEEVE
RATCHET NUT
PULL NUT
CYLINDER REAPAIR KIT (Illustrated
on next page)
01 each
01 each
01 each
01 each
04 each
04 each
02 each
02 each
02 each
01 each
01 each
01 each
01 each
01 each
02 each
02 each
01 each
01 kit
RATCHET NUT PART LIST
ITEM PART No. DESCRIPTION QTY.
01
02
03
04
05
06
07
08
09
10
11
12
13
14
15
16
17
18
750301-01
750401-01
750501-01
750601-01
750701-01
750801-01
751001-01
751101-01
751201-01
751301-01
751401-01
751501-01
751601-01
751701-01
751801-01
751802-01
751901-01
752001-01
CAGE REAR RING
CAGE FRONT RING
CAGE SIDE BAR
COLLET SEGMENT 1
COLLET SEGMENT 2
COLLET SEGMENT 3
NUT BODY
NUT CAP
LOCK WASHER
REACTION PLATE
END CAP
COLLET RETAINING SPRING
CAP RETAINING SPRING
CAP RETAINING SCREW
BUTTON HEAD SCREW
BUTTON HEAD SCREW
CIRCLIP INTERNAL
CIRCILIP EXTERNAL
01 each
01 each
03 each
01 each
01 each
01 each
01 each
01 each
01 each
01 each
01 each
02 each
03 each
03 each
03 each
03 each
02 each
01 each

OPERATOR INSTRUCTION MANUAL IM_FC10TE_Rev09_A4
FC10TE HYDRAULIC FLANGE CLOSING TOOL
18
5TE HYDRAULIC CYLINDER PART LIST
ITEM PART No. DESCRIPTION QTY.
1
2
3
4
5
6
7H
8
9H
10
11
12
13
14
300901-01
510707-01
752502-01
752503-01
752504-01
752505-01
752506-01
771106-01
771107-01
752510-01
376601-01
771103-01
771104-01
771105-01
HYDRAULIC COUPLER
SCREW
CYLINDER BASE
PISTON ROD
SPRING
SPRING LOCK
SET SCREW
FASTE NUT
SCREW M5X16
5T. CYLINDER SERVICE KIT
GASKET SEAL
O-RING
BACK-UP RING
WIPER
01
01
01
01
01
01
01
01
01
01
01
01
01
01
9 1
73
12 13 5
4 6 11 2 8 14

OPERATOR INSTRUCTION MANUAL IM_FC10TE_Rev09_A4
FC10TE HYDRAULIC FLANGE CLOSING TOOL
19
9
3X
8
4X
58
4X
7
6
56
4
5
1
48
49
2X
33
4X
50
3X
27 28
32 29 30 31
40
41
42
45
46
2X
3
24
53
54
55
47
2X
51
52
26
25
12
13
14
15
16
17
1824 20
21
19
22
57
38
2X
37
2X
36
2X
35
2X
34
2X
39
2X
43
44
23
63
10 11
64
2X
2
61
60
59
62
HP550S HYDRAULIC SINGLE PORT
SEALED HAND PUMP
737373-01 REV. 04
ITEM KIT/PART No. DESCRIPTION QTY.
1 710101-01 PUMP HOUSING 1
2
708002-01 RESERVOIR 1
3
707067-01 SCREW 1
4 A/N OIL FILTER 1
5
A/N O-RING 1
6
A/N REFILLING PLUG 1
7 B/P TAIL BASE 1
8
B/P SPRING WASHER 4
9 B/P NUT 3
10
B/P PUMP RETAINING CLIP NUT 1
11
B/P PUMP RETAINING CLIP 1
12
C O-RING 1
13
C BACK-UP RING 1
14
C H.P. PISTON 1
15
C SNAP RING 1
16 C O-RING 1
17
C BACK-UP RING 1
18 C L.P. PISTON 1
19
D/O YOKE 1
20
D/O PISTON PIN 1
21 D/O YOKE PIN 1
22
D/O RETAINING RING 1
23
D/O HANDLE GRIP 1
24
D/O SCREW 2
25
E YOKE BASE 1
26
E SPRING PIN 1
27 F SPACER 1
28
F WASHER 1
29
F RELEASE VALVE SCREW 1
30
F/J M5 SCKT SET SCREW 1
31
F/J RELEASE KNOB 1
32
F/J ADAPTOR 1
ITEM KIT/PART No. DESCRIPTION QTY.
33 F/K/R CHECK BALL 4
34
G SPRING 2
35
G STEEL BALL 2
36
G OUTLET BALL SPRING 2
37 G COPPER WASHER 2
38
G VALVE COVER SCREW 2
39
G/Q STEEL BALL 2
40 H STEEL BALL 1
41
H SPRING END CAP 1
42
H L.P. SPRING 1
43 H CONE SEAT 1
44
H CONE 1
45
H LONG SEPARATOR SPRING 1
46 H SCREW 2
47
H SET SCREW 2
48
I BASE PLATE 1
49 I SCREW 2
50
K SCREW 3
51
L GAUGE COUPLER MALE 1
52 L GAUGE 1
53
M PORT GAUGE ADAPTOR 1
54
M GAUGE COUPLER FEMALE 1
55 M 3/8" NPT COUPLER 10ksi 1
56
N RESERVOIR BLADDER 1
57
O HANDLE 1
58 P SCREW 4
59
ON REQUEST HP550S STICKER 1
60 070260-01 MAX PRESSURE STICKER 1
61
070059-01 OPEN-CLOSE STICKER 1
62
070013-01 QC SEALED STICKER 1
63
070001-01 WARNING READ INSTRUCTION STICKER 1
64 070058-01 EQUALIZER LOGO RESERVOIR STICKER 2
