Erco&Gener GENPRO 40E R2 User manual

EG_GENPRO40ER2_1006E_IS_003_UK
Dct_425_01
Instructions Sheet
GenPro 40e R2
Reference : EG_GENPRO40ER2_1006E_IS_003_UK
Revision : 003
Date : 20/01/2016
Author : MSU
Download from our web site the
User Guide, documentations, Drivers and the Skylight software.
The corresponding markings appear under the appliance.
S.A.S. ERCOGENER
ZI de St. Lambert-des-Levées –BP 30163 –F-49412 SAUMUR Cedex
Tél. : [phone] –Fax : [phone]
www.ercogener.com –i[email protected]
SAS CAPITAL 500 000 € – R.C.S Angers 801 206 228 –APE 2630Z - TVA Intra : FR18 801 206 228
The information and non contractual pictures in this document are given for indication purposes
only. ERCOGENER reserves the right to modify its products and documentation at any time.
The GenPro 40e R2 complies with:
- EN 60950-1 : 2006 standards (electrical safety).
- EN 301 908 & EN 301 511.
- ETSI EN 301 489-3 V1.4.1 (02) and EN 301 489-7 V1.3.1 (05).
- R&TTE Directive 1999/5/EC of 9 March 1999.
- Council Recommendation 1999/519/EC of 12 July 1999.
- ROHS II Compliant : Directive 2011/65/EU
- REACH 151 N°1907/2006

EG_GENPRO40ER2_1006E_IS_003_UK
Dct_425_01
The information and non contractual pictures in this document are given for indication purposes
only. ERCOGENER reserves the right to modify its products and documentation at any time.
WARNING
- To avoid any risk of electrocution, do not open the modem.
- No internal parts can be repaired by the user.
- The modem must be returned to the factory for any repairs.
- The modem must not be connected directly to the mains supply; a voltage
adapter must be used.
- To ensure electromagnetic compatibility, the length of USB cable and power
supply cable must not exceed a length of 3 meters.
1 General
The GenPro 40e R2 is a GSM/GPRS/UMTS/LTE modem designed for
transmitting asynchronous binary data, SMS, operating in automatic call and
answer mode according to the AT commands (as per Standards ITU-T V250,
3GPP TS 27.005 & TS 27.007).
The GenPro 40e R2 RF performances comply with the ETSI guidelines.
The main reception parameters are:
- GSM 850 / EGSM 900 -112 dBm @ 25 °C
- DCS 1800 -112 dBm @ 25 °C
- PCS 1900 -112 dBm @ 25 °C
- UMTS Band 1,2,5,8 -110 dBm ±1 @ 25 °C
- LTE Band 1,3,7,8,20 -99 dBm ±1 @ 25 °C
The main transmission parameters are:
- GSM 850/EGSM 900 (Class 4) 32 dBm ± 1 @ 25 °C
- GSM 850/EGSM 900 (ClassE2) 27 dBm ± 1 @ 25 °C
- DCS 1800/ PCS 1900 (Class1) 29 dBm ± 1 @ 25 °C
- DCS 1800/ PCS 1900 (ClassE2) 26 dBm ± 1 @ 25 °C
- UMTS Band 1,2,5,8 (Class3) 23 dBm ± 1 @ 25 °C
- LTE Band 1,3,8,20 23 dBm ± 1 @ 25 °C
- LTE Band 7 22 dBm ± 1 @ 25 °C
2 Description
Box dimensions:
Length: 73mm Width: 54mm Depth: 25mm
On the front of the box:
- Micro-Fit 3.0TM female 4-pin connector for the electrical supply.
- Connector USB type mini B.

EG_GENPRO40ER2_1006E_IS_003_UK
Dct_425_01
The information and non contractual pictures in this document are given for indication purposes
only. ERCOGENER reserves the right to modify its products and documentation at any time.
On the rear part:
- 2 x SMA-F connector for connecting the GSM antenna MAIN & AUX.
- GSM modem ‘Activity’ LED.
- SIM card access.
Under the box:
- The CE label and the IMEI number.
- The "ROHS" Mark label.
3 Supply Consumption and Operating Conditions
The GenPro 40e R2 may be powered with 5.5 to 32VDC.
The GenPro 40e R2 is delivered with a power cable fitted with a fuse F 2.5A/
L250V (5x20mm).
The GenPro 40e R2 provides an external use via the 3G Watcher graphic
interface or via an AT commands set (see Commands List “4118014 AirPrime
EM73xx-MC73xx AT Command Reference”).
The GenPro 40e R2 is delivered with a USB cable (A Male / mini B Male).
- Operating conditions
Temperatures : - Operating range .......-30°C to +70°C
- Storage range...........-40°C to +85°C
Atmospheric pressure : - 700 hPa à 1060 hPa (-400 m à 3000 m).
Weight : - 87g.
- SIM card: 3V or 1.8V DC
4 Using the modem
4.1 Introduction
Before doing anything else, it is prudent to check that the modem is correctly
configured and that all the necessary operating components are present.
The modem is delivered in its own packaging, together with the present
documentation, a 2-wires cable (power) and two fixing brackets.
4.2 Connection
It is recommended making all the connections with the unit un-powered.

EG_GENPRO40ER2_1006E_IS_003_UK
Dct_425_01
The information and non contractual pictures in this document are given for indication purposes
only. ERCOGENER reserves the right to modify its products and documentation at any time.
Connection to the supply
The GenPro 40e R2 must be connected to a DC supply by the supplied power
cable.
Network connection
A main GSM antenna must be connected to the MAIN SMA connector.
A secondary GSM antenna may be connected to the AUX SMA connector.
- In all cases, the main antenna (MAIN) must
be connected.
- The non connection of the secondary
antenna (AUX), does not stop the
functioning but can reduce the performances
of data transfer.
DTE connection
A straight USB Type A to USB mini B is used to connect to the DTE to the host.
SIM card
Remove the SIM card cover.
Insert the SIM card (push/push mechanism)
Put the SIM card cover back.
4.3 USB Driver installation
It is necessary to use the Drivers available on our website when using and
installing the GenPro 40e R2 modem associated to the USB port.
We advise you to install the driver before switching the modem on.
Depending on the installations of USB drivers already made on your computer,
the installation of the USB Driver for the GenPro 40eR2 will not be automatic
and necessary.
4.4 Switching on
Switch the modem on.
The GSM LED lights permanently and then flashes once every two seconds if
the PIN code has been entered.
Documentation describing the AT commands for GSM is available from our
website.
