ERGOMART Corner Shaper and Keyboard Arm User manual

1
C.
C.
C.
Fully tighten after step 2
Pre-assemble top and bottom portions of Corner Shaper
using Barrel Nuts. (Tighten Barrel Nuts in Step 2)
2
1) Slide Corner Shaper into corner of work surface
2) Tighten Barrel Nuts (shown in step 1)
3
If using the CornerShaper without a track If using the CornerShaper with a track
Attach Corner Shaper to the bottom of work surface
using screws A and B in their designated holes.
Attach Corner Shaper and track to the bottom of work
surface using screws B. (Bumper purchased with track)
A.
Bumper
5
Slide Keyboard Arm into Track
If using the CornerShaper with a track
If using the CornerShaper with a track
Install Stop
r™
Ergonomic solutions for office and light industrial work environments
©2014 Ergomart. All rights reserved.
www.ergomart.com | 888 420 3200
Installation Instructions
A.
B.
B.
B.
B.
B.
A. A.
A.
6
4
B.
B.
B.
B.
B.
Corner Shaper and Keyboard Arm

Ergonomic solutions for office and light industrial work environments
©2014 Ergomart. All rights reserved.
www.ergomart.com | 888 420 3200
Parts List
Hardware Included
Tools Needed
A 10-32 x 3/8” Screws 10
B 10-11 x 5/8” Screws 5
C Barrel Nuts 2
Phillips Head Screwdriver
Slotted Screwdriver
ITEM DESCRIPTION/ PART NO. QUANTITY
1/8” Drill Bit (used for making pilot holes for Screw A)
B
B
B
B
SCREW DIAGRAM WHEN NOT USING TRACK
B
THIS IS THE DIAGRAM FOR STEP 3
B
B
B
A
AA
A
SCREW DIAGRAM WHEN USING TRACK
THIS IS THE DIAGRAM FOR STEP 4
A/B A/B
A/B A/B
B
B
BB
B
BUMPER
THIS IS THE DIAGRAM FOR STEP 6
SCREWS TO USE FOR INSTALLING TRACK STOP
(”A/B” DESIGNATES THAT EITHER SCREW CAN BE USED)
A
AA
A
Screw Diagrams
