ERNITEC K111DX Instruction Manual

Keyboard X
K111DX
Installation
User
Manual
Version 2.3
2851-00005
SYS EM
U
se
r

Operation
In addition to the normal keys, the Keyboard X also uses so-called 'Soft Keys'. The function of
the 'Soft Keys' depends on what selections the operator has made. The 'Soft Key symbols' in
the keyboard LCD display, changes according to the selections made by the operator.
0001001 0000
--
Soft Keys
Soft Key symbols
Alarm active
Numeric Status
Selected Camera/DVR
Selected Monitor
LonBox in controlSelected Site
The Escape key can be used to step back through the 'Soft Key symbols'.
ESCAPE
When operating a keyboard for the first time, the user will have to log on with User ID and
Password, and then select a monitor and a camera as the first operation.
User Log-on
Enter 'User ID' and 'Password'.
Ö
'Password'
ÖÖ
'User ID'
Ö
Select Monitor
Selects Monitor 3
MONITOR
Ö
3
Select Camera
Selects Camera 1 on the selected monitor
CAMERA
Ö
1
2851-00005 Page 11
SYS EM

Next/Previous Camera
(Disabled if a DVR camera is selected).
Next CameraPrevious Camera
Display Text
Toggles on/off Status Text, Camera Text
and Time/Date, on the selected monitor.
Options:
All text OFF.
Only Camera text ON.
Camera text and Time/Date ON.
All text ON.
TEXT
Select Remote Site (Soft Key)
The first camera on the Remote Site, will be displayed on
the selected monitor.
Selects Remote Site 3
Ö
3
Select Local Site (Soft Key)
The first camera on the Local Site, will
be displayed on the selected monitor.
Selects Local Site
SYS EM
Page 12 2851-00005

PTZ operation
PTZ Control
Using the joystick, or pressing one of the zoom/focus/iris keys,
will also enable PTZ control.
Enables/disables PTZ control for the selected camera
CONTROL
Zoom
WideTele
ÖÖ
ZOOM
Focus
NearFar
ÖÖ
FOCUS
Auto Focus
Enables Auto Focus.
FOCUS
Ö
AUTO
Iris
CloseOpen
ÖÖ
IRIS
Auto Iris
Enables Auto Iris.
IRIS
Ö
AUTO
2851-00005 Page 13
SYS EM

Pan/Tilt
When controlling a variable speed Pan/Tilt,
pushing the joystick towards its extremes will increase speed
Auto panning (Soft Key)
Starts Auto Panning at predefined speed.
Starts Auto Panning at e.g. 25% of maximum Pan Speed.
Actual speed depends on Pan/Tilt used.
Ö
25
Call Preset (Soft Key)
Calls preset 1, on the selected PTZ camera.
Ö
1
Preset Tour
Starts Preset Tour 1, on the selected PTZ camera
TOUR
Ö
1
SYS EM
Page 14 2851-00005

Auxiliary Function (Soft Key)
Activate/Deactivate AUX relay 1, on the selected PTZ camera
Ö
1
Direct Auxiliary Functions (Soft Keys)
Activate/De-activate the AUX relay
Ö
Backlight Compensation (Soft Key)
Toggle BLC on/off, on the selected PTZ camera
Define Preset (Soft Keys)
Defines Preset number 1
Maximum number of Presets depends on the
Telemetry Receiver used
Ö
1
Ö
Set Auto Panning Limits (Soft Keys)
Set ri
g
ht limi
t
Set left limit
ÖÖ
2851-00005 Page 15
SYS EM

Camera Sequence
Start Sequence
Starts Sequence 1 on the selected monitor
SEQUENCE
Ö
1
Hold Sequence
Pauses the sequence on the selected monitor.
Pressing HOLD again, resumes the sequence.
HOLD
Alarm Operation
Clear Alarm
Clears the alarm currently active on the
selected alarm monitor.
ALARM
Step Through Active Alarms
Switches to the selected
alarm.
Steps through the alarm
texts for the active alarms
on the alarm monitor.
ALARM
+
SHIFT
Ö
SYS EM
Page 16 2851-00005

Alarm Enable/Disable
From the keyboard, the operator can enable/disable specific alarm inputs.
The NodeManager software can generate a list, with the required alarm inforation.
Select alarm enable/disable menu.
Ö
Select Site
Select the site number where the alarm is connected.
Ö
1
Select Alarm Type
Select the Alarm Type. 0=Normal alarm, 5=Tamper alarm.
Ö
0
Select Alarm Box Number
Select the Alarm Box number.
Ö
1
Select Alarm Input Pin
Select the Input pin for the selected alarm box.
Ö
3
Enable/disable Alarm
Enable (ON) or Disable (OFF) the selected alarm.
or
Alarm status
Displays status for the selected alarm.
2851-00005 Page 17
SYS EM

Holiday Setup
Up to 30 Holidays can be programmed 1 year ahead.
Alarms activated on a Holiday will be handled according to the Alarm Zone setup in the
NodeManager software.
Select Holiday setup menu.
Ö
Set Holiday
Set June 20, as Holiday.
Ö
2006
Clear Holiday
Clear June 20, as Holiday.
Ö
2006
Holiday Status
Display Holiday status for June.
Ö
6
SYS EM
Page 18 2851-00005

DVR operation
When selecting a camera input, that has a DVR connected, the camera symbol will
automatically change to a DVR control symbol.
Take DVR control
Enables/disables DVR control of the selected DVR.
CONTROL
DVR Monitors (Soft Keys)
Select between DVR monitor outputs.
Spot monitor 2Spot monitor 1Main monitor
Select Camera
Selects Camera 1 on the selected DVR monitor
CAMERA
Ö
1
Digital Zoom
Hold zoom key until function activates.
Use joystick to "pan/tilt" while zoomed in.
WideTele
ÖÖ
ZOOM
Split Screen Modes (Soft Key)
Toggles between split screen modes.
2851-00005 Page 19
SYS EM

Direct Split Screen Modes (Soft Key)
Direct selection of 9-way split, cameras 1-9.
Ö
5
+
SHIFT
4-way, camera 17-20
Ö
13
20-way, split 5x4
Ö
12
20-way, split 4x5
Ö
11
10-way, camera 11-20
Ö
10
13-way, camera 1-13
Ö
9
10-way, camera 1-10
Ö
8
16-way, camera 1-16
Ö
7
9-way, camera 10-18
Ö
6
9-way, camera 1-9
Ö
5
4-way, camera 13-16
Ö
4
4-way, camera 9-12
Ö
3
4-way, camera 5-8
Ö
2
4-way, camera 1-4
Ö
1
Copy (Soft Key)
Copy Mode.
SYS EM
Page 20 2851-00005

Menu Access (Soft Key)
Access menu system.
Some menus uses numeric selections, others are navigated
using the joystick.
For details on navigating the DVR menus, please see the
Instructions for the DVR.
Numeric Menu Selections
Hold 'SHIFT' and press number.
'n'+
SHIFT
Playback (Soft Key)
Start playback mode.
Ö
Freeze (Soft Key)
Toggles image freeze on/off, on the main monitor
Ö
Record (Soft Key)
Toggles recording on/off.
Ö
2851-00005 Page 21
SYS EM

Special functions
Day/Night/Auto mode (Soft Key)
For cameras/domes with Day/Night camera.
AutoNight (b/w)Day (colour)
Ö
Auto/IR mode (Soft Key)
Toggles between Auto and IR (b/w) mode.
(Orion Dome only)
Ö
Camera connection Status
Show camera connection status
in groups of 32 cameras.
‘X’ means camera is detected.
Select the Camera connection
status menu.
or
ÖÖ
SYS EM
Page 22 2851-00005

Macro Operation
Macros (Soft Keys)
Macro soft key menu
Ö
Start/Stop/Pause Macro (Soft Keys)
StopPauseStartMacro No.
Ö
1
LonBox Operation
LonBox Control (Soft Key)
Takes control of LonBox 1
Ö
1
Release control of LonBox
+
SHIFT
LonBox Relays (Soft Keys)
Activate/Deactivate LonBox relays
Ö
2851-00005 Page 23
SYS EM

Keyboard setup
A few setup options are made available for the user.
Language (Soft Keys)
Toggles between the four languages available
(if programmed)
Ö
Keyboard beeper (Soft Keys)
Beep ONBeep OFF
Ö
Animate Softkeys (Soft Keys)
Toggles between animated and static Softkeys
Ö
Set Time/Date (Soft Keys)
Set Time/Date, format and weekday
Ö
To set e.g. Tuesday, March 20, 2001, 13:33
Year 2001March 20Tuesday
Ö
2001
ÖÖ
2003
ÖÖ
3
EnableFormatTime 13hh33mm
ÖÖÖ
1333
SYS EM
Page 24 2851-00005

Dome setup
When navigating the menu system on connected Domes, the following general keys can be
used.
Some Dome types may require special key combinations for specific menu operations. Please
see the I151SX-DOME Installation Manual, for details.
Access menu system
Access menu system.
MENU
Navigate menu system
UP / DOWN / RIGHT / LEFT
8
6
4
2
+
SHIFT
ENTER/Select
Enter sub-menu, and/or select option.
+
SHIFT
Return
Exits to the previous menu.
ESCAPE
+
SHIFT
Exit menu system
Exit menu system.
CONTROL
+
SHIFT
2851-00005 Page 25
SYS EM

Operator Messages
The Keyboard X displays various operator messages for guidance, when e.g. wrong/invalid
selections are made.
Type your user ID. Press Next
Key in your user ID defined during installation, and press Next (right arrow key).
Type your password. Press Next
Key in your password defined during installation, and press Next (right arrow key).
Invalid User ID
You have entered an invalid user ID.
Wrong Password
You have entered a wrong password.
User 'XXXX' is logged on
You have logged on to the system, and the keyboard is ready for operation.
Automatic logoff in 'X' seconds
You will be logged off in 'X' seconds, due to 'X' seconds of inactivity, defined during
installation. Press the Clear key to override logoff.
Illegal key: 'X'
You have pressed an illegal or invalid key.
Illegal key: Shift+'X'
You have pressed an illegal or invalid key combination.
Invalid camera: 'X'
The selected camera does not exist, or is made invalid.
Invalid Monitor: 'X'
The selected monitor does not exist, or is made invalid.
Invalid sequence: 'X'
The selected camera sequence does not exist.
Camera 'X' controlled by kbd. 'X'. Press CONTROL
The selected PTZ camera is controlled by keyboard 'X'. Press the CONTROL key to take the
control from keyboard 'X' (if your user priority allows it).
Camera 'X' controlled by Matrix
The selected PTZ camera is being controlled by a matrix/macro. Press the CONTROL key to
take the control from the matrix/macro (if your user priority allows it).
Camera 'X' does not respond
The selected camera is fixed, and does not respond to PTZ control.
The selected PTZ camera is switched off, faulty or off line.
Preset 'X' reached
The selected preset is reached.
Preset 'X' stored
The preset has been stored by the Telemetry Receiver.
SYS EM
Page 26 2851-00005

Monitor 'X' controlled by kbd. 'X'
The selected monitor is being controlled by keyboard 'X', which has higher user priority.
Monitor 'X' controlled by Alarm
The selected monitor is in alarm mode, and can only be selected by the alarm keyboard
defined during installation.
Monitor 'X' controlled by Macro
The selected monitor is running a macro, started by a higher priority user.
Communication Error
Communication on the LON Network has failed.
Matrix reset, monitor control lost
The SYSTEM X matrix has been rebooted, and all keyboard control is lost.
No free Videolink from Site 'X'
All video links from Site 'X' are used by higher priority users.
No access to Site 'X'
The Site does not exist, or you are not allowed to access it.
2851-00005 Page 27
