ESPRIT CT80-NT04 User manual

C
CT T8 80 0- -N NT T0 04 4 T Tr re ea ad dm mi il ll l
S
Se er rv vi ic ce e M Ma an nu ua al l

WARNING:
ALWAYS UNPLUG THE TREADMILL FROM THE ELECTRICAL
OUTLET BEFORE SERVICING THE UNIT.

S
Se er rv vi ic ce e M Ma an nu ua al l
T Ta ab bl le e o of f F Fi ig gu ur re es s
T
Ta ab bl le e o of f F Fi ig gu ur re es s 3 3
TABLE OF CONTENTS
Table of Contents...................................................................... 3
Table of Figures ........................................................................ 4
Description................................................................................ 5
AE LECTRICAL C ONFIGURATION ....................................... 5
1. CT80-nt04 Treadmill components............................ 5
1. Console ...................................................................... 6
2. Main controller.......................................................... 6
3. Treadmill motor ........................................................ 6
4. Incline motor............................................................. 6
Operation................................................................................... 8
AW INDOW D ISPLAY M ODE ............................................... 8
1. OFF Mode................................................................. 8
2. READY Mode .......................................................... 8
3. RUN Mode................................................................ 8
BF UNCTION ........................................................................ 9
1. SPEED ...................................................................... 9
2. Incline ....................................................................... 9
3. TIME......................................................................... 9
4. DISTANCE............................................................. 10
5. CALORIES ............................................................. 10
6. PULSE .................................................................... 10
CF UNCTION B UTTON I N M AIN M ODE ............................. 10
1. READY MODE ...................................................... 10
2. RUN MODE ........................................................... 11
D C ALIBRATION P ROCEDURE ................................. 12
1. Calibration............................................................... 12
Troubleshooting ...................................................................... 14
1. General.................................................................... 14
2. Troubleshooting Matrix .......................................... 15
3. controller debugging form ...................................... 22
Diagrams and Schematics ....................................................... 23

APPENDIX A......................................................................... 27
1. TREADBELT ADJUSTMENT.............................. 27
APPENDIX B ......................................................................... 29
1. TREADMILL LUBRICATION ............................. 29
APPENDIX C ......................................................................... 30
1. RESET SWITCH RESETTING ............................. 30
APPENDIX D......................................................................... 31
1. FUSE REPLACEMENT......................................... 31
APPENDIX E ......................................................................... 32
1. SPEED SENSOR ADJUSTMENT......................... 32
TABLE OF FIGURES
Figure 1 Operational Flowchart ............................................... 7
Figure 2 Console Layout........................................................ 23
Figure 3 Mechanical Layout .................................................. 23
Figure 4 Main Controller information & voltages................. 24
Figure 5 Function jack connector on Main Controller........... 24
Figure 6 Wiring Diagram........................................................ 26
Figure 8 If Treadbelt slips...................................................... 27
Figure 9 If tread belt shifts too far to the Right ..................... 27
Figure 10 If tread belt shifts too far to the Left...................... 28
Figure 11 Resetting Reset switch............................................ 30

S
Se er rv vi ic ce e M Ma an nu ua al l
D De es sc cr ri ip pt ti io on n
D
De es sc cr ri ip pt ti io on n 5 5
DESCRIPTION
A E LECTRICAL C ONFIGURATION
Note: Electrical servicing of this treadmill is limited to board
level replacement.
1. CT80-NT04 TREADMILL COMPONENTS
a) Safety key:
To fits on the Console that activate all functions. If no safety
key, console can not be controlled.
b)Console:
Interface that controls all functions of the treadmill.
c) Main controller:
The circuit board consist of the DC power supply for
consol e、 incline drive r and DC motor driver, link the
console to output appropriate voltages for motor that
control the treadmill functions.
d)Treadmill motor:
This is a variable speed for DC motor. To control the 0 –90
voltages on the main controller, it can to increase or
decrease speed of running belt.
e) Incline motor:
This is an ac motor. User can to control variable
elevation by console within main controller.

S
Se er rv vi ic ce e M Ma an nu ua al l
D De es sc cr ri ip pt ti io on n
D
De es sc cr ri ip pt ti io on n 6 6
B. G ENERAL I NFORMATION
1. CONSOLE
f) Contains touch controls and LCD Display.
2. MAIN CONTROLLER
a) Include power supply 、 motor driver control circuit and
incline control circuit.
3. TREADMILL MOTOR
a) It’s a variable speed on 0-90 volt DC motor.
b)Have three wires red, black and green.
c) If there is DC voltage on the Red wire (M+) the treadmill
motor will turn clockwise.
d)If there is DC voltage on the Black wire (M-) the treadmill
motor will turn counter-clockwise.
e) The higher the voltage the faster the motor turns.
f) The green wire is ground.
4. INCLINE MOTOR
a) This is a 120 volt AC motor.
b)Have four wires, red, black, white and green.
c) Has one 3 pins cable of position sensor.
d)If there is AC voltage on the Red wire (UP) the incline motor
will increase the incline.
e) If there is AC voltage on the Black wire (DOWN) the
incline motor will decrease the incline.
f) The White wire (COM) is neutral.

S
Se er rv vi ic ce e M Ma an nu ua al l
D De es sc cr ri ip pt ti io on n
D
De es sc cr ri ip pt ti io on n 7 7
Figure 1 Operational Flowchart

S
Se er rv vi ic ce e M Ma an nu ua al l
O Op pe er ra at ti io on n
O
Op pe er ra at ti io on n 8 8
OPERATION
A W INDOW D ISPLAY M ODE
1. OFF MODE
a) When user doesn’t insert the SAFETY KEY on the console,
the treadmill enters the OFF Mode and all windows will
appear blank.
2. READY MODE
a) When the treadmill is ON and SAFETY KEY is inserted in
console,
b)Press MOED(Program) button to select Program.
c) Press START button to start treadmill on Manual Mode.
3. RUN MODE
a) In RUN Mode, pressing the “STOP” button and removing
the SAFETY KEY will cause the treadmill stop instantly
and enter OFF Mode.

S
Se er rv vi ic ce e M Ma an nu ua al l
O Op pe er ra at ti io on n
O
Op pe er ra at ti io on n 9 9
B F UNCTION
1. SPEED
a) Display the current speed in Kilometer per hour.
b)DISPLAY range is 0.0 to 99.9 km/h.
c) WORK range is 1.0 to 16.0 km/h.
d)Press Speed ↑ “FAST” or Speed ↓ ”SLOW” to adjust speed,
each increment and decrement is 0.1 km/h(mph).
2. INCLINE
a) Display the incline position from 0 to 12.
b)DISPLAY range is 0 to 999.
c) WORK range is 0 to 12.
d)INCLINE preset value is 0 to 12.
e) Press “UP” or ”DOWN” to adjust incline, each increment
and decrement is 1.
3. TIME
a) TIME is either COUNT UP or COUNT DOWN. System
preset is COUNT UP; if user sets the time then timer is
COUNT DOWN.
b)DISPLAY range is 0:00 to 99:99.
c) WORK range is 0:00 to 99:59.
d)COUNT DOWN setup range is 10:00 to 99:00.
e) When TIME is set, the count will go to zero.
f) In RUN Mode, press “STOP” button to save value of time
and enter “RUN Mode” again that value will continue count
up time.
g)

S
Se er rv vi ic ce e M Ma an nu ua al l
O Op pe er ra at ti io on n
O
Op pe er ra at ti io on n 1 10 0
h)
4. DISTANCE
a) Display the current distance in kilometer.
b)DISPLAY range is 0.00 to 99.99.
c) WORK range is 0.00 to 99.99.
5. CALORIES
a) Displays the cumulative calories burned at any given time
during your workout.
b)DISPLAY range is 0.0 to 999.0.
c) WORK range is 0.0 to 999.0.
6. PULSE
a) Displays the heart rate beat by using hand pulse or receiver.
When use receiver, a chest belt must be worn.
b) DISPLAY range is 0 to 999.
c) WORK range is 40 to 220.
d)In RUN Mode, if the treadmill doesn’t have a signal for 8
seconds then display value will become “ P ”.
e)
C F UNCTION B UTTON I N M AIN M ODE
1. READY MODE
a) SAFETY KEY: Fit safety key in right position to power on
the computer. When safety key is pulled away from its
position, the computer will be automatically shut down.
b)STOP button: Non-function.
c)
START button: Pressing “ START ” button to start
treadmill, When pressing “ START ” button, there will be 3
second final count down on window display, then machine

S
Se er rv vi ic ce e M Ma an nu ua al l
O Op pe er ra at ti io on n
O
Op pe er ra at ti io on n 1 11 1
d)Clear/set button: Press “clear/set” button to change each
function. MANUAL can set using time, Pre-set PROGRAM
can set using time and speed, Heart Rate Control 1~2 can
set time, age and the value of heart rate.
e) Mode(PROGRAM) button: Press Mode(PROGRAM)
button to select manual, program and HRC program.
f) FAST button: If user doesn’t enter a setting then this button
is non-functional.
g)SLOW button: If user doesn’t enter a setting then this button
is non- functional.
h)UP button: If user doesn’t enter a setting then this button is
non- functional.
i) DOWN button: If user doesn’t enter a setting then this
button is non- functional.
j) SPEED RAPID button: 3 preset buttons for rapid speed:
3kph, 6kph, 9kph .
k)INCLINE RAPID button: 3 preset buttons for rapid incline:
3, 6, 9 .
l) FAN button: It can to control ON/OFF for the fan.
2. RUN MODE
a) SAFETY KEY: When safety key is pulled away from its
position, the computer will be automatically shut down.
b)STOP button: press “STOP” button to stop treadmill.
c) START button: non-functional.
d)Mode(Program) button: non-functional.
e) FAST button: Press the button to increase your speed and
each increase is 0.1kph. If button is pressed continuously
then speed increases to MAX SPEED quickly.
f) SLOW button: Press the button to decrease your speed and
each decrease is 0.1kph. If button is pressed continuously
then speed decreases to MIN SPEED quickly.

S
Se er rv vi ic ce e M Ma an nu ua al l
O Op pe er ra at ti io on n
O
Op pe er ra at ti io on n 1 12 2
g)UP button: Press the button to raise position and each
increase is 1, the maximum incline position is 12.
h)DOWN button: Press the button to lower position and each
decrease is 1, the minimum incline position is 0.
i) SPEED RAPID button: Speed will set to 3kph, 6kph, 9kph
quickly.
j) INCLINE RAPID button: Incline will set to 3,6,9position
quickly.
k)Fan button: It can to control ON/OFF for the fan.
l)
D C ALIBRATION P ROCEDURE
1. CALIBRATION
a) Turn on power.
b)Press and hold “mode(Program)” button at the same time.
c) Inserts the SAFETY KEY on console, all windows will
appear blank.
d)Press “Clear/Set” to Set wheel size: Press “FAST” or
“SLOW” button to adjust to 47.
e) Press “Clear/Set” button to memorize above setting and
enter next section of setting mode.
f) Set Min. speed: Press “FAST” or “SLOW” button to adjust
window to 1.0Kph / 0.5Mph.
g)Press “Clear/Set” button to memorize above setting and
enter next section of setting mode.
h)Set high speed: Press “FAST” or “SLOW” button to adjust
window to 18.0Kph / 12mph.
i) Press “Clear/Set” button to memorize above setting and
enter next section of setting mode.
j) Set high incline position: Press “UP” or “DOWN” button to
adjust to 12.

S
Se er rv vi ic ce e M Ma an nu ua al l
O Op pe er ra at ti io on n
O
Op pe er ra at ti io on n 1 13 3
k)Press”Clear/set”
l) Press “START” button to memorize all value, the treadmill
will calibrate automatically.
m) After calibrating, treadmill will reset then enter
“READY MODE”.

S
Se er rv vi ic ce e M Ma an nu ua al l
T Tr ro ou ub bl le es sh ho oo ot ti in ng g
T
Tr ro ou ub bl le es sh ho oo ot ti in ng g 1 14 4
TROUBLESHOOTING
WARNING:
ALWAYS UNPLUG THE TREADMILL FROM THE ELECTRICAL
OUTLET BEFORE SERVICING THE UNIT.
1. GENERAL
a) Do a visual check of all wiring and connections looking for
chafed wires or lose connections.
b)Make sure any wiring is safely positioned and/or secured
away from moving parts.
c) If you find a fuse blown on a circuit board replace the circuit
board.

S
Se er rv vi ic ce e M Ma an nu ua al l
T Tr ro ou ub bl le es sh ho oo ot ti in ng g
T
Tr ro ou ub bl le es sh ho oo ot ti in ng g 1 15 5
2. TROUBLESHOOTING MATRIX
Condition Reason Solve
When turn on power,
ON/OFF switch isn’t lit.
1 Power cord isn’t plugged into outlet.
2 Power cord isn’t plug into unit.
3 The voltage of outlet is too low.
4 Plug or connector of power cord is open.
5 Connector of power cord is broken.
6 Connecting cable disconnected.
7 Breaker tripped.
8 Breaker is broken.
9 ON/OFF switch is broken.
1 Plug the power cord into outlet.
2 Plug the power cord into unit.
3 Check the voltage of outlet.
4 Replace power cord.
5 Replace power cord.
6 Check if wire is disconnected, connect it
again.
7 Press the small red button to return to
original status.
8 Replace breaker.
9 Replace AC switch.
After turning on power,
treadmill has a popping
sound.
1 Incorrect input power, varistor is blown broken on controller. 1 Check the voltage of power is110-
120V. Replace controller.
When insert safe key, no
display on monitor.
1 Haven’t switch ON/OFF switch.
2 Insert the Safe key on wrong position.
3 10 PIN Computer connector not plugged in properly.
4 10 PIN computer cable is broken.
1 Switch the AC switch.
2 Insert the safe key on right position.
3 Please check the wire and connect
again.

S
Se er rv vi ic ce e M Ma an nu ua al l
T Tr ro ou ub bl le es sh ho oo ot ti in ng g
T
Tr ro ou ub bl le es sh ho oo ot ti in ng g 1 16 6
5 Fuse on controller is blown.
6 Varistor on controller is blown.
7 Reed switch of console is broken. (open)
8 Other components are faulty.
4 Replace 10 PIN computer cable.
5 Replace fuse or controller.
6 Replace varistor or controller.
7 Replace reed switch or console.
8 Replace console.
With no safe key but
treadmill could display or
operate
1 Reed switch of console is broken. (short)
2 Have other magnetic components on console.
1 Replace reed switch or console.
2 Remove magnetic component beside safe
key.
When press “START”,
treadmill doesn’t start.
1 Motor M+ or M- wire isn’t connected into right position.
2 Controller is broken. (No power to motor)
3 Motor is broken.
4 Treadmill controller shut down and LED would be ON.
1 Please check and plug again.
2 Replace controller or MOSFET IRFP
460 and add the Silicone Heat Sink
Paste suitably.
3 Replace motor or check the wire and
connector if it was broken.
4 Turn off the AC switch and turn on power
again.
Treadmill stops or shuts off
by itself.
1 House breaker tripped.
2 Treadmill breaker tripped.
3 Treadmill controller fuse is broken.
4 Treadmill controller shut down and LED would be ON.
1. Reset it.
2. Reset treadmill breaker.
3. Replace with new fuse
4. Turn off the AC switch and turn on

S
Se er rv vi ic ce e M Ma an nu ua al l
T Tr ro ou ub bl le es sh ho oo ot ti in ng g
T
Tr ro ou ub bl le es sh ho oo ot ti in ng g 1 17 7
power again.
After removing safe key,
treadmill can’t stop.
1. Reed switch of console is broken. 1. Replace with new reed switch or
console.
LCDs not bright,
incomplete or imperfect.
1. LCD light is broken.
2. Power to console too low.
1. Replace with new LCD or console.
2. Check AC power is 110-120V.
3. Check power to console.
4.Replace lower controller.
LCD displays not bright,
incomplete or imperfect.
1. LCD displays are broken. 1. Replace with new console and calibrate
it.
When press “START”
button to start treadmill,
running belt isn’t running
and window displays “Loss
Speed” error message after
8 seconds.
1. Controller experienced unusual shut down; the Shut_D light
will be always bright. (Controller debugging form)
2. Motor wires (red, black) aren’t plugged into controller.
3. Computer cables not connected properly.
4. Computer cables are broken or damaged.
5. Motor belt is broken.
6. Controller is broken.
7. Motor is broken.
8. Console is broken.
1. Turn off power and reset the treadmill.
2. Plug wires again.
3. Plug the wire again on controller,
connector and console.
4. Replace with new wires.
5. Replace with new motor belt.
6. Replace with new controller.
7. Replace with new motor.
8. Replace with new console.
SPEED windows display is
not 1.0 to 16.0 km
Monitor is not calibrated. Calibrate the console
INCLINE windows display 1 Console is not calibrated. 1 Calibrate the console.

S
Se er rv vi ic ce e M Ma an nu ua al l
T Tr ro ou ub bl le es sh ho oo ot ti in ng g
T
Tr ro ou ub bl le es sh ho oo ot ti in ng g 1 18 8
is not 0 to 12
The speed of the belt
doesn’t match console
display.
1. Console is not calibrated. 1.Calibrate the console
The incline position doesn’t
match console
1 Console is not calibrated. 1 Calibrate the console.
INCLINE ERR window
displays “E2”.
1 Position sensor value of incline motor is wrong. 1 Turn off the AC switch and turn on power
again.
2. Calibrate the monitor.
INCLINE window displays
“----” during training.
1 Position sensor value of incline motor is wrong. 1 Turn off power and reset the treadmill.
INCLINE window displays
“----”.
1 Position sensor value of incline motor is wrong. 1.Check the 3 pins cable of the incline
motor.
TIME window display “E3”
1.EEPROM is broken. 1.Replace with new console and calibrate
it.
After pressing “START”
button, the treadmill stops
immediately.
1 Controller is broken. 1 Turn off the AC switch and turn on power
again.
2 Replace controller and calibrate it.
Erratic pulse display. 1. Another chest belt in use around treadmill.
2. Other magnetic field disturbance.
1. Check for other chest belt use around
treadmill.
2. Change the position or direction of

S
Se er rv vi ic ce e M Ma an nu ua al l
T Tr ro ou ub bl le es sh ho oo ot ti in ng g
T
Tr ro ou ub bl le es sh ho oo ot ti in ng g 1 19 9
3. Receiver is broken.
treadmill.
3. Replace with new receiver.
After pressing “START”
button, the treadmill stop
immediately.
Controller was broken. Replace with new controller and calibrate
it.
FAST/SLOW button of
SPEED ADJUSTMENT
SWITCH can’t be used.
Speed button just can press
FAST, can’t press SLOW.
Speed button just can press
SLOW, can’t press FAST.
1 The connector of SPEED CABLE (UPPER) and
CONSOLE not connected properly.
2 The connector of SPEED CABLE (UPPER) and SPEED
ADJUSTMENT SWITCH W/CABLE not connected properly.
3 The connector of SPEED CABLE (UPPER) or
SPEED ADJUSTMENT SWITCH/W/CABLE is
damaged.
4. Button of SPEED ADJUSTMENT SWITCH is broken.
5. The connector of SPEED CABLE (UPPER) or SPEED
ADJUSTMENT SWITCH/W/CABLE is damaged.
6. The connector of SPEED CABLE (UPPER) or SPEED
ADJUSTMENT SWITCH/W/CABLE is damaged.
1. Connect cables again.
2. Connect cables again.
3. Connect cable again.
4. Replace with new buttons.
5. Replace with new cable.
6. Replace with new cable.

S
Se er rv vi ic ce e M Ma an nu ua al l
T Tr ro ou ub bl le es sh ho oo ot ti in ng g
T
Tr ro ou ub bl le es sh ho oo ot ti in ng g 2 20 0
UP/DOWN button of
INCLINE ADJUSTMENT
SWITCH can’t be used.
Incline button just can
press UP, can’t press
DOWN.
Incline button just can press
DOWN, can’t press UP.
1 The connector of INCLINE CABLE (UPPER)
and CONSOLE not connected properly.
2. The connector of INCLINE CABLE (UPPER)
and INCLINE ADJUSTMENT SWITCH W/CABLE not
connected properly.
3 The connector of INCLINE CABLE (UPPER) or
INCLINE ADJUSTMENT SWITCH CABLE
got damage.
4. Button of INCLINE ADJUSTMENT SWITCH is broken.
5. The connector of INCLINE CABLE (UPPER) or
INCLINE ADJUSTMENT SWITCH CABLE
got damage.
6. The connector of INCLINE CABLE (UPPER) or
INCLINE ADJUSTMENT SWITCH CABLE
damaged.
1 Connect the wires again.
2. Connect the wires again.
3. Replace the cable.
4. Replace buttons.
5. Replace the cable.
6. Replace the cable.
Hand pulse lost its function.
(No pulse displayed on
monitor)
1. Hands not on the hand pulse sensors or only one hand on
sensor.
2. The connector of HANDPULSE W/WIRE and Console not
connected properly.
3. The wires got damaged when connecting the HANDPULSE
1. Two hands hold the hand pulse.
2. Connect the cable again.
3. Replace with new cable.
